Cooler Master GM27-CF Manuel utilisateur
GM27-CF
Cooler Master 27" Curved Gaming Monitor
User Manual
Table of Contents
Important Safety Instructions ................................................................................... 1
Connecting the Monitor to the Base ........................................................................ 2
External Control Buttons ......................................................................................... 5
OSD Function Introductions .................................................................................... 7
Main Menu .............................................................................................................. 9
Color Setting ........................................................................................................... 10
Picture Quality Setting .............................................................................................
.....................................................................................................................
11
Display 11
OSD ......................................................................................................................... 13
Other........................................................................................................................
...........................................................................................................
14
Specifications 15
.....................................................................Declaration of Restricted Substances 16
Wall Mount Installation Instructions .........................................................................4
Cooler Master LCD Monitor User Manual-1
Please read the following instrucons carefully.
1. To clean the LCD monitor screen:
Turn othe LCD monitor and unplug the power cord.
Spray a non-solvent cleaning soluon onto a rag and clean the screen gently.
2. Do not place the LCD monitor near a window. Exposing the monitor to rain,
moisture or sunlight can severely damage it.
3. Do not apply pressure to the LCD screen. Excessive pressure may cause
permanent damage to the display.
4. Do not remove the cover or aempt to service this unit yourself.
An authorized technician should perform servicing of any nature
5. Store the LCD monitor in a room with a temperature of -20° to 60° C
(- 4° to140° F). Storing the LCD monitor outside this range may result in
permanent damage.
6. Immediately unplug your monitor and call an authorized technician if any of
the following circumstances occur:
• Monitor -to -PC signal cable is frayed or damaged.
• Liquid spills onto the LCD monitor or the monitor is exposed to rain.
• The LCD monitor or case is damaged.
Important Safety Instructions
Click!
J
K
Cooler Master LCD Monitor User Manual-2
Connect the monitor to the base
7
DC
DC IN
www.coolermaster.com
8
Cooler Master LCD Monitor User Manual-3
DP
DP
1 2
3 4
5
Cooler Master LCD Monitor User Manual-4
Wall Mount Installation Instructions
FreeSync
Press any of the buttons to enter the quick navigation menu,
i.e., to activate the Quick Mode
This function enables the graphic source supporting FreeSync to adjust the
screen refresh rate of the monitor in a dynamic manner.
1
Press the button to enter the OSD menu
to activate the Quick Mode
After entering the OSD menu, press the
button to enter submenu
a.
b.
5Power button
Turn on/off the monitor. Blue indicates the power is on.
Flashing blue light indicates the monitor is under Standby Mode.
OSD menu
Switch to the Game Mode to activate FreeSync
2
3
4
When the OSD menu is activated,
press the button for Down
a. Press the button under the Quick Mode to turn on
in-game crosshairs
Press the button to quickly switch between the Game,
Graphic and Standard Scene Mode
b.
a.
b.
When the OSD menu is activated, press the button for Up
a.
b. When the OSD menu is activated, press the button to return
to the last menu/exit the OSD menu
Quick button for
in-game crosshairs
Quick button
for Scene Mode
Quick button
for low blue light
Press the button under the Quick Mode to switch to the
Low Blue Light Mode
Cooler Master LCD Monitor User Manual-5
External Control Buttons
DP (1.2): 165Hz (Overclock 200Hz), Adaptive Sync supported under 1920X1080
HDMI (2.0): 165Hz, Adaptive Sync supported under 1920X1080
HDMI (1.4): 120Hz, Adaptive Sync supported under 1920X1080
Cooler Master LCD Monitor User Manual-6
Back
Level1 Level2 Level3 Default Value
DP
HDMI1（2.0）
HDMI2（1.4）
Brightness 0~100 90
BlackLevel 0~100 50
Contrast 0~100 50
On
Off
1.8
2.0
2.2
2.4
2.6
Standard
Graphic
Movie
Game
Warm
Cool
USER
Low Blue Light 0~100 0
Hue 0~100 50
Saturation
RGB Range
0~100
Limited
Full Full
50
Sharpness 0~100 50
Off
Fastest
Fast
Normal
Off
High
Middle
Low
On
Off
Wide Screen
4:3
1:1
0-100 0
Auto
Normal
Off
Flicker
Off
2.2
Standard
Warm
Off
Off
Wide Screen
Normal
DCR
Gamma
Picture Mode
Color Temperature
Response Time Override
Super Resolution
Dynamic Luminous Control.
Aspect Ratio
LED Mode (Rear)
Crosshair Transparency
Input Source
Brightness/Contrast
Color Setting
Picture Quality Setting
Display
Cooler Master LCD Monitor User Manual-7
OSD Function Introductions
Normal
On
Off
Volume 0~100 50
HDMI1[2.0]
HDMI2[1.4]
DP
Off
PIP Mode
PBP 2Win
DP
HDMI1
HDMI2
Small
Medium
Large
TopRight
TopLeft
BottomRight
BottomLeft
OSDH-Position 0~100 50
OSDV-Position 0~100 50
OSD Transparency 0~100 50
OSD Time Out 5~100 20
Normal
90
180
270
On
Off
Normal
Off
Off
Medium
TopRight
English
Language
OSD Rotation
FreeSync
Off
Muti-Window
Sub Win2 Input
PIP Size
PIP Position
Swap
Audio
Multi-Window
OSD
Other
Mute
Audio Source
Level1 Level2 Level3
Reset
Cooler Master LCD Monitor User Manual-8
OSD Function Introductions
Default Value
中文
English
한국의
РУССКИЙ
Español
日本語
繁體中文
Francais
