CONTROL SOLUTIONS LogTag VFC400-USB Fiche technique
www.vfcdataloggers.com
VFC400-USB
Vaccine temperature
monitoring Data
Logger
Product User Guide
Document Release Version: 2.0
Published 1. October, 2021
Copyright © Control Solutions, 2018-2021
All rights reserved.
Control Solutions
VFC400-USB User Guide 2
Contents
Safety Information 4
Introduction 6
Features 7
Case 7
Buttons 7
Display and LED 8
External Probes 8
Power Supply 8
PDF 8
What You Need 9
Required Items 9
Optional Items 9
Preparing a VFC400-USB for first use 11
In the Office 11
On-site 11
Inserting the Batteries 12
Configuring the VFC400-USB for logging 13
Finalizing the configuration 21
Adding the Probes and the Power Supply 21
Display Overview 22
Powering the VFC400-USB 25
Low power operation 26
Audible Alarm 28
Real-Time Clock 29
Manually adjusting the time zone 29
Starting the Logger 32
Push button start 32
Push Button Start with Start Delay 33
During Recording 34
Switching Channels on the Display 35
VFC400-USB User Guide 3
Clearing an Alarm 38
Paused Readings 39
Marking a reading with an inspection mark 40
Probe is disconnected 40
Power Save 41
Clearing the Min/Max Values 42
Reviewing Day Statistics on the Display 43
Stopping the VFC400-USB 49
Plugging the VFC400-USB into a USB port 50
Accessing the files 52
Downloading the VFC400-USB to Control Solutions VTMC 53
Re-deploying the VFC400-USB 53
Interpreting the Data 54
Data Evaluation - Report 54
Data Evaluation - Data List 57
Data Evaluation - Day Summary 59
Resetting the Logger 61
Hibernating a VFC400-USB 62
Replacing the Batteries 63
Appendix 1 - Accuracy and Resolution 64
Temperature Accuracy 64
Temperature Resolution 64
Appendix 2 - Glossary 65
Safety Information VFC400-USB User Guide 4
Safety Information
The VFC400-USB PDF USB temperature logger contains two "AAA" non-rechargeable
batteries. These batteries can be replaced as detailed in Replacing the AAA batteries.
The logger also contains a non-rechargeable backup battery (LiMnO2 CR2032 coin cell).
When this battery indicates “LOW” ( ), it can be replaced by a
qualified technician. Please contact your distributor for further
information and also refer to the section about Powering the
VFC400-USB on page25.
Keep out of the reach of children!
Do not expose the logger to extreme temperatures as it may lead to the destruction of
the battery and may cause injuries.
Empty batteries should be recycled or disposed of according to your local regulations.
Liability
Control Solutions’s standard warranty terms apply. A copy can be requested by emailing
[email protected]. In addition, Control Solutions shall not be held liable
lif the device was used beyond Control Solutions’s stated limitations;
lfor any claims due to the improper storage and use of the device;
lfor any problems with refrigeration units;
lfor the bad quality of the monitored goods, if any;
lfor incorrect readings if the device was used with a low battery; or
lfor consequential loss.
Battery Life
The batteries in the VFC400-USB designed to power the device for up to 12 months of
operation, provided
lfresh batteries from a reputable manufacturer are used;
lthe acoustic alarm is not active over long periods;
lthe recording interval is not shorter than 5 minutes; and
lthe device is stored and operated according to Control Solutions’
recommendations.
Safety Information VFC400-USB User Guide 5
Disclaimer
The VFC400-USB monitors temperature exposure and not the quality of the goods it
accompanies. Its purpose is to signal if product quality evaluation/testing is required.
Typographical Conventions
Text in this font refers to buttons on the VFC400-USB.
Text in this font refers to option settings, dialogue boxes or actions to be taken in
Control Solutions VTMC.
Text in this font describes features of the product.
This text describes certain aspects of the product, where incorrect use of a
feature may lead to inadvertent loss of data.
This text contains important information for the correct operation of
your VFC400-USB.
This text contains information that explains some aspects of a feature in more
detail.
This text contains tips that help you get the best out of your VFC400-USB logger
Introduction VFC400-USB User Guide 6
Introduction
The Control Solutions VFC400-USB Vaccine temperature monitoring Data Logger
features a display, USB connectivity, data logging memory storing up to 16065
temperature readings per channel and a separate statistical memory, storing maximum
and minimum reading as well as alarm duration for each of the last 30 days.
During recording the display shows the following, alternating for each channel:
lThe current temperature (of the most recent reading)
lThe alarm status (within or outside the acceptance range)
lAn alarm trigger summary of up to the last 30 days (today and 29 days previous)
lThe current time and battery status
lMinimum and maximum temperatures since the start of the trip
Alarm events can be triggered when a number of readings are outside pre-set
temperature thresholds, and a “day alarm indicator” appears on the display.
Logged temperature data can be viewed on any PC by plugging the unit into a
computer’s USB port via a micro-USB cable. A PDF file is generated, which can be
accessed using free PDF software such as Acrobat Reader. The VFC400-USB can also be
downloaded to the free companion software Control Solutions VTMC, where you can
display data in chart, list or summary formats. The software also allows electronic
archiving and exporting to Control Solution Web Base VTMC (Vaccine Temperature
Monitoring Cloud) for managing your region/clinical storage & handling needs.
Features VFC400-USB User Guide 7
Features
The VFC400-USB Dual-channel temperature logger features a large display and USB
connectivity with a familiar LogTag feel.
Case
lMounting lug for secure fastening of logger to fixtures
lMicro-USB socket with attached protective cap
lGold-plated, high-quality temperature sensor sockets
lRobust polycarbonate case, IP51
l2 user replaceable AAA batteries, accessible via a compartment at the rear of the
product
Buttons
lSTART/CLEAR/STOP button ( )
This is used to start the unit, and clear active alarms. It is also used to exit the
statistics review.
Features VFC400-USB User Guide 8
lREVIEW/MARK button ( )
This is used to review recorded data the trip directly on the display, to reset the
min/max data on the display and to stop the unit.
It is also used to place an inspection mark in the data.
lChannel button ( )
This button is used to manually switch the channels shown on the display.
Display and LED
The extra large display shows current, minimum and maximum temperatures and if
alarm events have occurred for the current day and up to 29 days in the past. Details of
any alarm event can be checked by inspecting the statistics history on the logger's
display or in more detail via Control Solutions VTMC. In addition, a red Alarm LED
shows if an alarm event has occurred.
External Probes
The VFC400-USB will accept external probes from the ST100 product range.
Power Supply
The same USB socket that is used for communication is also used for providing power to
the VFC400-USB, using an external 5V USB power supply. The AAA batteries maintain
all functionality when USB power is not connected. A long-life CR2032 lithium backup
battery maintains essential functions if the AAA batteries are empty and external power
is not supplied.
PDF
The VFC400-USB will generate a detailed PDFreport when plugged into a USB port of a
PC. The PDF report shows a summary of the trip, presents the data in chart and list
format and also includes a day summary page, showing an overview of the statistics
collected. A CSV file of the data list is also available.
What You Need VFC400-USB User Guide 9
What You Need
Required Items
In addition to your Control Solutions VFC400-USB Vaccine temperature monitoring Data
Logger you will need the following:
la micro-USB cable to connect the VFC400-USB to your PC (it is recommended that
you connect each VFC400-USB via a permanently plugged in USB cable to protect
your computer’s USB socket)
lone or two external probes of the ST100 series
la PC running Windows 7 SP1 or later and Control Solutions VTMC 3 installed if you
wish to configure and download the logger
la PC with PDF reader software installed for viewing the generated PDF files
Optional Items
In addition to the above, following items are useful accessories:
la 5V/5W USB power supply, if you wish to power the unit permanently via the USB
socket
la wall mount bracket, which can be used, for example, to attach the VFC400-USB
to the side of a fridge
What You Need VFC400-USB User Guide 10
lone or two glycol temperature buffers, which simulate environmental behavior of a
vaccine vial
