Concord Camera Eye-Q 3103 Manuel utilisateur

Quick Start Guide

Camera Nomenclature

Back

Viewfinder

LED indicator

/ Zoom In / Up button

/ Continuous shutter / Right button

Battery cover

/ Zoom Out / Down button

LCD Monitor screen

Power button

/ /Stop button

/ Self-timer / Left button

/ / Flash / / Play / / Pause button

Battery Installation

1.Openthebatterycoverbypushingandslidingittotheside.

Self-timer lamp

Flash Viewfinder

Microphone

Lens

Exposure sensor

Front

button Shutter button

Mode dial

Speaker

Quick Start Guide

2.Check inscription on battery chamber for correct

negative/positive installation.

3.Install2-AA alkaline batteries.

4.Close the battery cover.

Camera Working Mode

You can select the camera’s working mode by using the

Mode dial located on the top of the camera. There are 4

working modes in this camera.

Auto Photo Mode ( )

Inthis mode, the camera will automaticallyset the

exposure and white balance according to your shooting

environment.

Manual Photo Mode ( )

You can manually set the exposure and white balance before shooting.

Playback Mode ( )

1.Replay or delete images from the camera.

2. Download and display images to your computer.

Video Mode ( )

1. Use this mode to record movies.

2. Youcanalso manuallysettheexposureandwhitebalancebeforerecordingthevideo.

Ali

n point

Quick Start Guide

Taking Pictures

There are two Modes you can choose from to take a picture. In the Auto

Mode, just press the shutter button and let the camera judge the

environmentalconditionsforyou. In theManual Mode, youcanmanually

adjust the exposure and set the white balance based on different

environmental conditions.Please refer to page 21 of the user's manual.

1. Turn the Mode dial to Auto ( ) or Manual ( ).

Taking a Picture

2. Press the POWER button ( ) to power on the camera.

Using the Digital Zoom

) to zoom out.4.Press the Down button (

3.Press the UP button ( )to zoom in on the subject.

1.Turn the Mode dial to Auto ( ) or Manual ( ).

2.Turnon theLCDscreenand theInformationdisplay(if not,press

DISPbutton).

When the LCD screen is on in Auto or Manual Mode, you can zoom

in on the subject before the image is taken.

3.Press the Shutter button halfway and

align the auto focus mark on the

subject you want to take. When the focus

islocked, the auto focus mark turns green.

If the display indicators on LCD screen turn

red, this means the camera’s auto exposure

and autowhitebalance functionisnotready

or the conditions are not ideal for optimal

quality picture taking. If you take the picture despite the

conditions, the picture may be over or under exposed.

4. Take a picture by pressing the shutter button further. When the camera

beeps, the image has been captured and will be recorded on the card

or in the internal memory.

* The camera will not emit a beeping sound if this function is disabled.

5. During recording to the memory card, the LED indicator will flash

Green. Once the LED indicator stops flashing, the recording has

finished.

Quick Start Guide

1. Turn the Mode dial to Playback ( ). The LCD screen displays

the last recorded image.

2. Use the RIGHT/LEFT button ( /) to view different pictures.

· Press the STOP button (

Youcan view up to 9 images at atimebyusingthe THUMBNAIL function ( ).

1.Turn the Mode dial to Playback mode ().

2. The LCD screen displays the last recorded image.

3.Press button twice to enter thumbnail mode.

You can view pictures and images in Playback mode.

Viewing Pictures in Thumbnail

Deleting Pictures

You can delete a single or all images while in Playback mode ().

Deleting a Single Image

1.Turn the Mode dial to Playback mode( ).

Pressthe MENU button. Use the UP/DOWN to toggle between the options.

3. Press the SET button to make your selection.

·If you press STOP while the video is playing, the video

will return to the first image.

) to stop the video.

Reviewing Your Pictures and Videos

Viewing Pictures

4.UsetheUP/DOWNbuttontohighlightthe iconandreturntothe

MENU”. Press the down button to highlight the delete icon ( ).

Deleting All Unprotected Images

1.Turn the Mode dial to Playback mode( ).

menuand notdeletethe image. PressSETto returntothe “DELETE

5. Press the SET button to confirm your selection.

2. Press MENU button.

3. Press the UP/DOWN button to toggle between the options.

4. Press the SET button. Use the UP/DOWN buttons to toggle

between CANCEL and YES.

5. Press the SET button to confirm your selection.

NOTE: ·To view video clips, press the PLAY button ().

Quick Start Guide

Downloading Images to a Computer

Installing the Driver & Software

Installing the Driver

Installing Camera Drivers (Windows 98/98SE)

If your operating system is Windows 98/98SE:

1. Insert the CD into your PC CD-ROM drive.Make sure that

your camera is not connected to the computer.

2. A red check mark appears on the left side of each installaiton

NOTE:

If your system requires a manual installation: Click Run, type “(the

3. Click on install.

4. Follow the on-screen instructions. After the installation has finished,

reboot your computer. You are now ready to install the software.

CD-ROM drive):/install.exe”, then click OK.

choice. Remove all checks except the one for the camera

driver by clicking on the checks next to each choice.

Follow the directions that follow to install all the software.

Note: You do not need to install the drivers if you are running Windows,ME, 2000 or XP. 

 Please go to the "Installing the Software" section.

Note to Mac users: You do not need to install drivers or software to transfer pictures.  

   Please see "Downloading Images to a Computer" for instructions.

Installing the Software

Installing the Software (Windows Users)

If your operating system is Windows 98/98SE/2000/ME/XP:

1.Insert CD into your PC CD-ROM drive.Make sure that

2.A Welcome window will be displayed.

Click [Next>] to move to the next step.

your camera is not connected to the computer.

3. Click on install.

1. Click the MGI PhotoSuite 4 SE menu on autorun frame.

2. Click on Photo Studio, Movie Studio, Video Conferencing and

Panorama tools. A red check mark should appear in the circle next

to each option. Camera Driver does not need to be checked.

You may choose to skip the software installation procedure if you already

have photo editing software loaded on your computer or if you would like

to transfer pictures without editing them.

Please refer to the Downloading Images section for instructions on transferring

pictures to you computer.

Installing the Software

3. The Software License Agreement window will be displayed.

If you agree to this, click [YES], the window will then move to the

next step. If you disagree, click [NO] and the install program will

be canceled.

4. Click Next to continue the installation.

5. Select Destination Location. Click on Next

Installing the Software

6. We suggest creating a shortcut on your desktop by selecting this

option. Click Next to continue the installation.

7. Click Next to continue the installation.

8. Start Copying Files window will displayed.

Click [Next>] to start installation.

Installing the Software

9. Wait while the software is installed.

10. Click Finish to complete the the setup.

11.Click Continue.
