Comtrend Corporation GCA-7000 Manuel utilisateur
1
Connect one adapter to the
LAN port on the Network
Device (Modem/ Router) via
an Ethernet cable.
2
3
4
Connect the second
coaxial cable to the “G.hn”
connector of the other
Coax Adapter and to a
coax wall outlet.
5
6
Plug the adapter into a power outlet via the power
adapter. Note: If the Power LED is not GREEN,
then please refer to the FAQs on the back page.
Reset
7
1. It takes two adapters to create a G.hn Coax Network. If you are adding onto an existing G.hn Coax Network,
then please skip to Step B. If you are adding on to an already securely paired G.hn Coax Network (i.e. the
Security LED is GREEN), then you must complete Step C.
Get To Know Your G.hn Wave 2 Coax Adapter
The Power LED,
Connection LED, and
Ethernet LED should
be GREEN on both
adapters.
GCA
-7000 G.hn Coax Adapter
Quick Installation Guide
Connect the coaxial cable to the
“G.hn” connector of the Coax
Adapter and to a coax wall outlet.
Network Device
(Modem/Router)
Coax Outlet
Power Outlet
A) Set Up the First Adapter Near Your Network
Device (Modem/Router)
Plug this adapter into a power outlet via the power adapter.
Note: If the Power LED is not GREEN, please refer to the FAQs.
Now connect the adapter
into your Internet device
(i.e. Gaming Console, PC,
etc.) via an Ethernet
cable.
TV
Gaming Console
Coax Outlet
Power Outlet
B) Set Up the Second Adapter Near Your Internet Device
(Smart TV, Gaming Console, PC, etc.)
2. We do not recommend using this G.hn Coax Adapter if you receive Cable TV services. If this is your situation,
please contact our Tech Support at (855) 337-6750 to discuss alternative options for your connectivity.
This connector is
for non-Cable
traditional TV
services.
This connector is to
power the adapter.
This connector is to
connect the adapter
to the G.hn Coax
network.
This Ethernet port
connects to the
Network Device or
Internet Device.
The Button and LED
descriptions can be found on
the back page.
Right
Left
IMPORTANT: Read
Before Setting Up the Adapter
3. Plug adapters into wall electrical outlets instead of power strips. Using a power strip will affect
network performance and may even cause dropped connections.
Press the Security Button
on one adapter until you
see the Security LED
start blinking GREEN.
Reset
Reset
1
2
Within two minutes,
press the Security Button on the second adapter
until you see the Security LED
start blinking GREEN.
Reset
Security Button
Power
Connection
Buttons
Q: Which connector should I use to connect my Internet Device to the Coax
Adapter?
A. Please use the G.hn connector – it is used to transmit networking traffic between your
home networking device.
Q. When should I use the TV Out connector?
A. The TV Out connector is to be used only when transmitting CATV (Community Access
Television/ Community Antenna Television) and Satellite services to your TV.
Q: Is the GCA-7000 interoperable with MoCA adapters?
A: No, it is not. If a location has implemented MoCA over Coax to deliver Internet service,
the G.hn over Coax solution will not work in those specific locations due to frequency
conflict issues with MoCA over Coax.
Q: Can I use G.hn Wave 1 and G.hn Wave 2 on the same network?
A: We do not recommend using G.hn Wave 1 and G.hn Wave 2 together in a single
network.
Q: What should I do if my GCA-7000 will not power on?
A: If your GCA-7000 adapter will not power on, then try using a different power adapter to
determine if the power adapter is faulty.
Q: What should I do if my devices will not connect?
A: If your GCA-7000 adapters are not connecting (i.e. the Connection LED is OFF),
then first plug the problem GCA-7000 unit into a coax outlet next to the other GCA-7000
unit; both GCA-7000 having been connected by Ethernet cable to their respective devices
(i.e. Network Device, Smart TV, PC, etc.). After approximately 10 seconds, the Connection
LED should light up GREEN. If not, then first reset both devices by pressing the Reset
Button on each adapter for more than 10 seconds. Then go to Step B in the Quick Install
Guide and follow the installation steps.
8
D) The device is now part of a
G.hn Coax Network!
C) Optional: Create a Secure G.hn Coax Network by Pairing
Button
s & LEDs Descriptions
The Security LED
should be solid
GREEN on both
adapters when
they are
successfully
paired.
First Adapter
Second Adapter
Reset Button
LEDs
Push this button for more
than 2 seconds to securely
pair the network.
Push this button for 10
seconds (until all of the
LEDs on the device blink)
to reset the device to
factory default.
Security
Ethernet
Adapter is powered on.
Adapter is powered off or
faulty.
Coax connection rate is
more than 40Mbps.
Coax connection rate is
less than 40Mbps and
more than 5Mbps.
Coax connection rate is
less than 5Mbps.
There is no coax
connection.
Ethernet LAN connection
is established.
An Ethernet LAN
connection is not
established.
Data over the Ethernet
LAN connection is being
transmitted.
The adapter is secure (it
has received or
generated network keys).
The adapter is not secure.
The adapter is in the
process of being secure.
Frequently Asked Questions
Need More Help?
(855) 337-6750
Home.Support@Comtrend.com
https://us.comtrend.com/products/gca-7000/
Call
Email
Visit our webpage
for FAQs/ User
Manual/ Videos
To add additional Coax Adapters, follow
Steps B and C.
Important Note: If you are adding on to an already securely paired G.hn Coax Network, then you must complete this Step.
You can have up to 16 G.hn Coax Adapters in
one G.hn
Coax Network.
Blinking
Blinking
WARNING ( ATTENTION )
nUnplug the power supply from the device before
servicing
nFor indoor use only
nDo NOT open the casing
nDo NOT use near water
nKeep away from the fire
nFor use in ventilated environment / space
nDébranchez l'alimentation électrique avant
l'entretien
nCet appareil est conçu pour l'usage intérieur
seulement
nN'ouvrez pas le boîtier
nN'utilisez pas cet appareil près de l'eau
nN'approchez pas du feu
nVeuillez utiliser dans un environnement aéré
Power Specifications ( Alimentation ) : Input
12Vdc, 1A
