Part Number MN/MBT4000.IOM - Revision 3
MBT-4000
Multi-Band Transceiver System
Installation and Operation Manual
IMPORTANT NOTE: The information contained in this document supersedes all previously published
information regarding this product. Product specifications are subject to change without prior notice.
Filename: T_ERRATA 1
Errata A
Comtech EF Data Documentation Update
Subject: Appendix A. Remote Control Operation
Date: December 9, 2005
Document: MBT-4000 Multi-Band Transceiver System, Installation and
Operation Manual, Revision 3, dated January 3, 2005,
Part Number: MN/MBT4000.EA3
Collating Instructions: Attach this page to page A-16
Comments:
Change FRE commands to read:
Change Specifics:
Filename: T_ERRATA 2
Operating
RF
Frequency
FRE=xxxxx
.xxx
BDC
BUC
9 bytes,
numeric
Command or Query
Valid Operating RF frequency, in MHz.
For Ku BDCs:
FRE values: 10950-11700 MHz an LO of 10000 MHz is
activated
FRE values: 11701-12250 MHz an LO of 10700 MHz is
activated
FRE values: 12251-12750 MHz an LO of 11300 MHz is
activated
Example: FRE=11300.000
FRE=(message ok)
FRE? (received ok,
but invalid arguments
found)
FRE* (message ok,
but not permitted in
current mode)
FRE! (command not
accepted by MBT-
4000 base unit. It
must be addressed to
BUC or BDC sub-
units)
FRE? FRE=xxxxx.x
xx
(see
description of
arguments)
Errata B
Comtech EF Data Documentation Update
Subject: Chapter 2. Installation
Date: March 9, 2006
Document: MBT-4000 Multi-Band Transceiver System, Installation and
Operation Manual, Revision 3, dated January 3, 2005,
Part Number: MN/MBT4000.EB3
Collating Instructions: Attach this page to page 2-1
Comments:
Change Table 2-1, ITT Cannon connector from “KPT06B-12-35” to “KPT06B-12-3S”.
Change Specifics:
2.1.1 PWR IN (J1) Pin Connections
Table 2-1. PWR IN (J1) Pin Connections
Pin PWR IN (J1)
A LINE
B NEUTRAL
C GND
Mating Connectors:
ITT Cannon KPT06B-12-3S
CEFD PN CN/MS-STPG03F02
Errata C
Comtech EF Data Documentation Update
Subject: Chapter 3. System Operation
Date: December 21, 2006
Document: MBT-4000 Multi-Band Transceiver System, Installation and
Operation Manual, Revision 3, dated January 3, 2005,
Part Number: MN/MBT4000.EC3
Collating Instructions: Attach this page to page 3-1
Comments:
Change Table in section 3.1.1: Add new C-Band BDC option
Change Specifics:
3.1.1 Block Down Converter (BDC-4000)
The BDC-4000 translates a band-specific input frequency block (C-, X-, or Ku- or Ka-), from the LNA,
down to L-Band (950 to 2000 MHz).
BDC-4000 C, X, Ku, Ka
Band Frequency LO Frequency Inverting
C-Band 3400 – 4200 MHz 5150 MHz Yes
C-Band(opt) 3625 – 4200 MHz 2300 MHz No
X-Band 7250 – 7750 MHz 6300 MHz No
Ku-Band-W 10.95 – 12.75 GHz
11.7 – 12.20 GHz
12.250 – 12.275 GHz
10.00 GHz
10.75 GHz
11.30 GHz
No
Ka-Band 20.20 – 21.20 GHz
Notes: 1.No spectral inversion, selectable inversion for inverted Block Down Converter
2. 10 dB gain adjustment.
Errata D
Comtech EF Data Documentation Update
Subject: Revised Ku-Band -W
Date: January 23, 2007
Document: MBT-4000 Multi-Band Transceiver System, Installation and
Operation Manual, Revision 3, dated January 3, 2005,
Part Number: MN/MBT4000.ED3
Collating Instructions: Attach this page to page 3-1
Comments:
Change Ku-Band specified under Band in Table :
Change Specifics:
3.1.1 Block Down Converter (BDC-4000)
The BDC-4000 translates a band-specific input frequency block (C-, X-, or Ku- or Ka-), from the LNA,
down to L-Band (950 to 2000 MHz).
BDC-4000 C, X, Ku, Ka
Band Frequency LO Frequency Inverting
C-Band 3400 – 4200 MHz 5150 MHz Yes
C-Band(opt) 3625 – 4200 MHz 2300 MHz No
X-Band 7250 – 7750 MHz 6300 MHz No
Ku-Band-W
(Single module
containing three
LOs)
10.95 – 11.70 GHz
11.7 – 12.20 GHz
12.250 – 12.75 GHz
10.00 GHz
10.75 GHz
11.30 GHz
No
Ka-Band 20.20 – 21.20 GHz
Notes: 1.No spectral inversion, selectable inversion for inverted Block Down Converter
2. 10 dB gain adjustment.
