Comprehensive CHE-2 Manuel utilisateur

User Manual

CHE-2

Table of Contents

1.0 Introduction……………………………………………………..1

2.0 Specifications……………………………….…………….……2

3.0 Package Contents………………………………………….…..3

4.0 Panel Descriptions…………………………………….…….…3

5.0 Connection and operation...................................................4

6.0 Troubleshooting……………………………………….…….…5

Cable and Connectivity Company

HDMI SUPER EXTENDER BY CAT-5e/6

１

HDMI EXTENDER (By CAT-5e/6 cable)

Dear customer

Thank you for purchasing this product. For optimum performance and safety,

please read these instructions carefully before connecting, operating or adjusting

this product. Please keep this manual for future reference.

1.0 INTRODUCTION

This kind of HDMI Extender by CAT-5e/6 uses two pieces of UTP cable with cross

stand inside to extend the HDTV display up to 60 meters for 1080p. It not only

breaks the limitation of the HDMI cable transmission length，but also CAT-5e/6

has more flexibility and convenience in cable construction.

It is equipped with HDMI (high definition multimedia interface) connectors and is

capable of supporting DVI (digital visual interface) equipment when used with an

HDMI to DVI Adapter, providing greater flexibility and options when integrating

several home theater components.

This product offers solutions for residential consumers: HDTV retail and show site,

HDTV, STUB, DVD and Projector factories, noise, space and security concerns,

data center control, information distribution, conference room presentation, school

and corporate training environments.

1.1 BENEFITS

1) The length of HDMI cable is fixed and unchangeable after it is produced.

Because the HDMI connector can only be soldered or terminated by the

professional workers in factory, the users can not reduce or increase by

themselves. However CAT-5e/6 cables are available everywhere and be

processed easily by the user or installer.

2) Because the header of the long HDMI cable is big, using it must in hidden

method. What's more, it is not easy to bend the HDMI cable and to pull it

through the in-wall tube or tray. However, CAT-5e/6 cable has no such

problems.

3) Using this Extender together with UTP cable with cross stand inside, the

transmission distance can be up to 60 meters for 1080p. For the general HDMI

cables, they must be customized when the length is over 10 meters.

1.2 FEATURES

This HDMI Extender has many features that enable it to perform in a superior

manner. Among those features you will find:

One pair as a full functional module, no need of setting.

HDMI SUPER EXTENDER BY CAT-5e/6

２

CAT-5e/6 cable can substitute HDMI cable to achieve long distance

transmission.

Follow the standard of IEEE-568B.

Transmission distance can be up to 60 meters for 1080p using UTP cable with

cross stand inside.

Auto-adjustment of feedback, equalization and amplify, the user does not

need to care about the length of the cable.

Compact size.

Supports highest video resolution 1080p.

Supports 165MHz/1.65Gbps per channel (4.95Gbps all channel) bandwidth.

Supports 8bit per channel (24bit all channel) deep color.

Supports HDCP Support uncompressed audio such as LPCM

Supports compressed audio such as DTS Digital, Dolby Digital（including

DTS-HD and Dolby True HD）

Support 3D all format, including 1080[email protected]8/24Hz,

720p@59.94/60Hz/50Hz, bandwidth up to 165MHz.

2.0 SPECIFICATIONS

Signal Inputs/Output

Input Video Signal

5 Volts p-p (TTL)

Maximum Single Link Range

1920x1080P

Output Video

HDMI

HDMI Input/Output Connector

Type A 19 pin

Operating Frequency

Vertical Frequency Range

50/60Hz

Video Amplifier Bandwidth

1.65Gbps/165MHz

Resolutions(HDTV)

Interlaced(50&60Hz)

480i,576i,1080i

Progressive(50&60Hz)

480p,576p,720p,1080p

Mechanical

Size(H-W-D)

45mmW x 25mmH x 81mmD

Weight(Net)

0.246KGs

Warranty

Limited Warranty

2 Years Parts and Labor

Environmental

Operating Temperature

0 ℃to +70℃

Operating Humidity

10% to 85 % RH (no condensation)

Storage Temperature

-10℃to +80℃

Storage Humidity

5% to 90 % RH (no condensation)

Power Requirement

External Power Supply

5V DC@2A

HDMI SUPER EXTENDER BY CAT-5e/6

３

Power consumption (Max)

Regulatory Approvals

Converter Unit

FCC,CE,UL

Power Supply

UL,CE,FCC

Accessories Adapter

AC Power Adapter

US standard, UK standard and so on

User Manual

Note: 1. In order to achieve the high transmission quality, please choose the UTP cable

with cross stand inside

2: The cables with lower quality will not achieve the perfect transmission effect

and long distance.

3: Theoretically the function of the product is normal when adopt short distance

transmission.

If the product cannot transmit long distance, this is to say, there are quality problems in the

transmission cables.

3.0 PACKAGE CONTENTS

Before attempting to use this unit, please check the packaging and make sure the

following items are contained in the shipping carton:

1) Main unit NO. 1 Sender

2) Main unit NO. 2 Receiver

3) 5V DC Power Supply.

4) User’s Manual

4.0 PANEL DESCRIPTIONS

Sender

HDMI Input

CAT5e- 2

CAT5e- 1

HDMI SUPER EXTENDER BY CAT-5e/6

４

Receiver

1) HDMI input

2) CAT-5e output.

3) CAT-5e output.

4) HDMI output

5) CAT-5e Input1

6) CAT-5e Input2

7) Power Input

5.0 Connection and Operation

1) Connect the HDMI input sources such as：HD-DVD、PS3、STB etc.

2) Connect two CAT-5e/6 cables to both the output of the transmitter and input

of the receiver.

3) Connect the HDMI output ( such as : HD-LCD、HD-DLP)into the receiver.

4) Plug the power into the receiver.

Attention: Insert / Extract cable gently.

DC 5V

HDMI Output

CAT5e- 2 CAT5e- 1

HDMI SUPER EXTENDER BY CAT-5e/6

５

5.1 CONNECTION DIAGRAM

DC 5V

CAT-5e/6 cable

SenderReceiver

CAT-5e/6 cable

6.0 TROUBLESHOOTING

the product doesn’t appear to be functioning, make certain that there are four

points you should pay attention.

First, check the connection between the HDMI cable and the extender correctly.

They all should be connected with a length 6 feet or less. (In other words, make

certain that the problem is not caused by long cables).

Second, measure the cable length you are attempting to use between the sender

and the receiver. They all should connect correctly by UTP cable with cross stand

inside for 1080p. Then, they can reach the length of 60M.

If the signal is present under those conditions, make certain that the power is

present to the product. If it is, all cables should be premium quality.

Lastly, inspect the cables and connectors for damage.

HDMI signal source

such as STB

Display Such as

LCD TV

55 Ruta Ct. South Hackensack, NJ 07606

Toll Free: 800 526-0242

Email:

[email protected]

www.comprehensivecable.com
