ProLiant 8500 Servers

I/O Module Upgrade Guide

Second Edition (April 2001)

Part Number 216597-002

Compaq Computer Corporation

Compaq Confidential – Need to Know Required

Writer: Ruben Garcia Project: Compaq ProLiant 8500 Servers I/O Module Upgrade Guide Comments:

Part Number: 216597-002 File Name: 216597-002 IO Module Upgrade Guide.doc Last Saved On: 3/15/01 1:49 PM

Notice

Compaq, the Compaq logo, Compaq Insight Manager, ProLiant, and SmartStart Registered in U.S.

Patent and Trademark Office.

Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation in the

United States and other countries.

All other product names mentioned herein may be trademarks of their respective companies.

Compaq shall not be liable for technical or editorial errors or omissions contained herein. The

information in this document is provided “as is” without warranty of any kind and is subject to change

without notice. The warranties for Compaq products are set forth in the express limited warranty

statements accompanying such products. Nothing herein should be construed as constituting an

additional warranty.

Compaq ProLiant 8500 Servers I/O Module Upgrade Guide

Second Edition (April 2001)

Part Number 216597-002

Compaq Confidential – Need to Know Required

Writer: Ruben Garcia Project: Compaq ProLiant 8500 Servers I/O Module Upgrade Guide Comments:

Part Number: 216597-002 File Name: 216597-002 IO Module Upgrade Guide.doc Last Saved On: 3/15/01 1:49 PM

Contents

Compaq ProLiant 8500 Servers I/O Module Upgrade Guide

Introduction .................................................................................................................1

Kit Contents..........................................................................................................2

Tools Required .....................................................................................................2

Upgrade Precautions....................................................................................................3

Preparing the Server ....................................................................................................4

Selecting an Upgrade Method ..............................................................................4

Preparing the Server for the Upgrade ...................................................................6

Updating the Drivers, System Partition, and Compaq Insight Manager

Console.................................................................................................................7

Migrating the System..........................................................................................10

Removing the Existing I/O Module...........................................................................11

Removing the Cable Management Arm .............................................................11

Accessing the Existing I/O Module....................................................................12

Removing the I/O Module..................................................................................14

Transferring I/O Expansion Boards Between the I/O Modules .................................16

Removing PCI Expansion Boards from the Existing I/O Module......................16

New I/O Module PCI/PCI-X Slot Information...................................................17

Installing the I/O Expansion Boards in the New I/O Module.............................20

Installing the Remote Insight Lights-Out Edition Board ....................................22

Installing the New I/O Module ..................................................................................25

Completing the Upgrade............................................................................................26

Installing the New Labels ...................................................................................26

Connecting the Cable Management Arm and Cables .........................................27

Transferring the Serial Number to the New I/O Module ....................................28

Confirming the Serial Number and Service Number Display ............................29

Configuring the Server ..............................................................................................30

iv Compaq ProLiant 8500 Servers I/O Module Upgrade Guide

Compaq Confidential –Need to Know Required

Writer: Ruben Garcia Project: Compaq ProLiant 8500 Servers I/O Module Upgrade Guide Comments:

Part Number: 216597-002 File Name: 216597-002 IO Module Upgrade Guide.doc Last Saved On: 3/15/01 1:49 PM

Compaq ProLiant 8500 Servers I/O Module Upgrade Guide

continued

Removing the Virtual Power Button Cable................................................................31

Removing Cable Segment A...............................................................................31

Removing Cable Segment B...............................................................................36

Removing Cable Segment C...............................................................................39

Index

Compaq Confidential –Need to Know Required

Writer: Ruben Garcia Project: Compaq ProLiant 8500 Servers I/O Module Upgrade Guide Comments:

Part Number: 216597-002 File Name: 216597-002 IO Module Upgrade Guide.doc Last Saved On: 3/15/01 1:49 PM

Compaq ProLiant 8500 Servers I/O Module

Upgrade Guide

Introduction

Use this option kit and the instructions provided in this guide to add PCI-X

technology and the ROM-Based Setup Utility (RBSU) to Compaq

ProLiant™ 8500 servers.

The upgrade is performed by one of two methods. The method used depends

on the current server setup and operating system. Depending on the current

setup, the operating system may have to be reinstalled.

After the upgrade, the server will become a ProLiant DL760 server model. A

new service number will be assigned to the server to identify the new

components. This service number will be used to identify the type of system

you have and will ensure that proper help and diagnosis is given by the

Compaq Call Center or service technician. You will maintain the current

system serial number. When you call for service, provide both the original

system serial number and the upgrade service number.

CAUTION: If you are planning to upgrade the server with the I/O module

upgrade and the 900-MHz processor upgrade simultaneously, perform the I/O

module upgrade first. Performing the I/O module upgrade first will ensure the

latest BootBlock ROM chip is installed in the server.

2Compaq ProLiant 8500 Servers I/O Module Upgrade Guide

Compaq Confidential –Need to Know Required

Writer: Ruben Garcia Project: Compaq ProLiant 8500 Servers I/O Module Upgrade Guide Comments:

Part Number: 216597-002 File Name: 216597-002 IO Module Upgrade Guide.doc Last Saved On: 3/15/01 1:49 PM

IMPORTANT: Refer to the section, "Preparing the Server for the Upgrade," for a list of the

ProLiant DL760 supported operating systems. Also, the server will only support three 5V

I/O expansion boards and eight 3.3V I/O expansion boards. For detailed PCI/PCI-X

expansion slot information, refer to the “PCI-X and PCI Bus Distribution Guidelines PCI-X

and PCI Bus Distribution Guidelines” section of this document.

NOTE: The I/O module upgrade will take approximately two to four hours to complete.

Duration may vary from case to case.

Kit Contents

The following items are included in this kit:

■ I/O module prewired for an optional Remote Insight Lights-Out Edition

board

■ Compaq SmartStart™ for Servers 5.0 CD

■ Compaq ProLiant DL760 Documentation CD

■ ProLiant 8500 I/O Module Upgrade Migration diskette

■ Compaq ProLiant 8500 Server I/O Module Upgrade Quick Installation

poster

■ Two PCI/PCI-X access panel hood labels

■ One ProLiant DL760 server label

■ Two service number labels

Tools Required

A Torx T-15 or a flathead screwdriver will be required to complete this

upgrade.

Compaq ProLiant 8500 Servers I/O Module Upgrade Guide 3

Compaq Confidential –Need to Know Required

Writer: Ruben Garcia Project: Compaq ProLiant 8500 Servers I/O Module Upgrade Guide Comments:

Part Number: 216597-002 File Name: 216597-002 IO Module Upgrade Guide.doc Last Saved On: 3/15/01 1:49 PM

Upgrade Precautions

WARNING: There is a risk of personal injury from hazardous energy levels. The

installation of options and routine maintenance and servicing of this product

shall be performed by individuals who are knowledgeable about the procedures,

precautions, and hazards associated with equipment containing hazardous

energy circuits.

WARNING: To reduce the risk of personal injury or damage to the equipment,

refer to the documentation supplied with the system, and observe the

appropriate safety precautions and option installation instructions.

WARNING: To reduce the risk of personal injury from hot surfaces, allow the

internal system components to cool before touching them.

WARNING: To reduce the risk of electric shock or damage to the equipment:

■ Do not disable the power cord grounding plug. The grounding plug is an

important safety feature.

■ Plug the power cord into a grounded electrical outlet that is easily

accessible at all times.

■ Disconnect power from the system by unplugging the power cord from

either the electrical outlet or the system.

CAUTION: To prevent damage to the system, you must become static-free by

touching a screw or unpainted surface on the system’s housing before

beginning these procedures. In addition, avoid touching any exposed metal on

the option board and chip or on the system’s circuit boards.

4Compaq ProLiant 8500 Servers I/O Module Upgrade Guide

Compaq Confidential –Need to Know Required

Writer: Ruben Garcia Project: Compaq ProLiant 8500 Servers I/O Module Upgrade Guide Comments:

Part Number: 216597-002 File Name: 216597-002 IO Module Upgrade Guide.doc Last Saved On: 3/15/01 1:49 PM

Preparing the Server

This section explains the two upgrade methods that can be used. Also, the

procedures necessary to prepare the existing server for the upgrade are

discussed in this section.

Selecting an Upgrade Method

The I/O module upgrade can be performed by either of two methods. The

method to use depends on the existing server setup.

IMPORTANT: Using Method 1 is strongly recommended. Reinstalling the operating

system using the SmartStart for Servers 5.0 CD results in a cleaner upgrade.

■ Method 1—This method is the preferred method. It involves reinstalling

the supported operating system using SmartStart for Servers 5.0.

■ Method 2—This method involves keeping the same supported operating

system, but updating the System Partition with the System Dispatcher

and Compaq Server Diagnostics utilities, updating the drivers, and

updating the Compaq Insight Manager™Console using the Compaq

Management 5.0 CD.

Use Table 1 to determine the supported operating systems for the

ProLiant DL760 server and Table 2 to determine the upgrade method to use.

Table 1

Supported Operating Systems.

Operating System Vendor Version

Windows NT Server 4.0

Windows NT Server 4.0 Enterprise Edition

Windows 2000 Advanced Server

Microsoft

Windows 2000 Server

NetWare 4.2 SMP

NetWare 4.2

Novell

NetWare 5 and 5.1

SCO UnixWare 7.1.2

Compaq ProLiant 8500 Servers I/O Module Upgrade Guide 5

Compaq Confidential –Need to Know Required

Writer: Ruben Garcia Project: Compaq ProLiant 8500 Servers I/O Module Upgrade Guide Comments:

Part Number: 216597-002 File Name: 216597-002 IO Module Upgrade Guide.doc Last Saved On: 3/15/01 1:49 PM

Table 2

Upgrade Methods

Scenario Method to Use Explanation

No operating system is installed

on the existing server.

Method 1 SmartStart for Servers 5.0

will be used to install a

supported operating system.

A non-supported operating system

is installed on the existing server.

Method 1 SmartStart for Servers 5.0

will be used to reinstall a

supported operating system.

New expansion boards will be

added to the new I/O module.

Method 1 Reinstalling the operating

system with SmartStart for

Servers 5.0 ensures that the

correct drivers are loaded.

The 5V expansion boards on the

existing secondary bus must be

moved to the primary bus due to

the new slot keying on the 3.3V

secondary bus.

Method 1 Reinstalling the operating

system with SmartStart for

Servers 5.0 ensures that the

correct drivers are loaded.

The existing server has a

supported operating system, but it

will be reinstalled.

Method 1 Reinstalling the operating

system with the SmartStart

for Servers 5.0 CD provides a

cleaner upgrade.

The existing server has a

supported operating system, but it

will not be reinstalled.

Method 2 SmartStart for Servers 5.0

must be used to update the

System Partition and the

drivers.

Note: If upgrade Method 2 is used, do not install any new expansion boards during the

I/O module upgrade.

6Compaq ProLiant 8500 Servers I/O Module Upgrade Guide

Compaq Confidential –Need to Know Required

Writer: Ruben Garcia Project: Compaq ProLiant 8500 Servers I/O Module Upgrade Guide Comments:

Part Number: 216597-002 File Name: 216597-002 IO Module Upgrade Guide.doc Last Saved On: 3/15/01 1:49 PM

Preparing the Server for the Upgrade

After you have determined which upgrade method to use, use the following

procedures to prepare the server for the upgrade:

CAUTION: The ProLiant 8500 I/O Module upgrade process may destroy data on

the server. To ensure that you do not lose data, always back up the server

before starting the upgrade process.

CAUTION: Disconnect any data drives present to prevent data from being

erased when running the Erase utility from SmartStart.

1. Back up your data.

2. Shutdown the operating system as described in the operating system’s

instructions.

3. Disconnect any data drives.

4. Power down the server.

5. Gather the kit contents.

Upgrade Method 1

IMPORTANT: Using upgrade Method 1 is strongly recommended. Reinstalling the

operating system using the SmartStart for Servers 5.0 CD results in a cleaner install.

If Method 1 is used, proceed to the “Migrating the System”section of this

guide. You will install (reinstall) the operating system after the migration has

taken place.

Upgrade Method 2

If Method 2 is used, go to the “Updating the Drivers, System Partition, and

Compaq Insight Manager Console”section of this guide.

Autres manuels pour ProLiant 8500

Table des matières

Autres manuels Compaq Serveur

Compaq

Compaq DL320 - ProLiant - G3 Manuel technique

Compaq

Compaq ML350 - ProLiant - G2 Instructions d'utilisation et de sécurité

Compaq

Compaq 221050-001 - ProLiant - 5000R Manuel utilisateur

Compaq

Compaq DL760 - ProLiant - 1 GB RAM Manuel utilisateur

Compaq

Compaq 234664-002 - ProLiant - ML330T02 Instructions d'utilisation et de sécurité

Compaq

Compaq ProSignia 200 Guide de démarrage rapide

Compaq

Compaq ML530 - ProLiant - 128 MB RAM Guide d'installation

Compaq

Compaq Proliant 800 Manuel

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Manuel de référence

Compaq

Compaq 386746-001 - ProLiant - 1600 Guide de démarrage rapide

Compaq

Compaq DL320 - ProLiant - G3 Instructions d'utilisation et de sécurité

Compaq

Compaq DH-64BAA-AA - AlphaServer - ES40 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Instructions d'utilisation et de sécurité

Compaq

Compaq 108164-003 - ProLiant - 800 Guide de référence rapide

Compaq

Compaq AlphaServer GS160 Manuel utilisateur

Compaq

Compaq 307560-001 - ProLiant - 2500R Manuel utilisateur

Compaq

Compaq DL320 - ProLiant - G3 Manuel

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Instructions de montage

Compaq

Compaq 219700-001 - ProLiant - 1500 Guide de référence rapide

Compaq

Compaq 108164-003 - ProLiant - 800 Guide de démarrage rapide

Compaq

Compaq Evo Thin Client t20 Manuel de service

Compaq

Compaq ProLiant 3000 Instructions d'utilisation et de sécurité

Compaq

Compaq ML350 - ProLiant - G2 Instructions d'utilisation et de sécurité

Compaq

Compaq AlphaServer DS20 Manuel utilisateur

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur

Planet

Planet NAS-7410 Manuel utilisateur
