QuickSpecs

Compaq AlphaStation XP1000

DA-10030 Canada — Version 22 — December 31, 2001

Overview

At A Glance

AlphaStation XP1000 Systems

include:

• Towerenclosure withAlpha

21264A (EV67)667-MHz CPU

with 64-KB data cache,

64-KB instruction cache, and

4-MB Level2 cache

• Five Expansion slots on two

buses: Two 64-bit PCI slots, two

32-bit PCI slots, one PCI/ISA

32-bit combination slot

• Two memory option banks, four

DIMM slots per bank, maximum

2-GB memory

• Six Storage bays: One diskette

drive bay, one CD-ROM drive

bay, two 5.25″x 1.6″removable

media bays, two 3.5″x 1” hard

disk drive bays

• 400W power supply

• Onboard wide UltraSCSI adapter

• Onboard 16-bit Soundblaster

compatible audio

• Onboard 10/100 Ethernet

(Twisted pair); ThinWire and

Thick wire optional

• Integrated I/O comprising parallel

port, two serial ports, audio in,

audio out, headphone,

microphone, mouse, and

keyboard ports

• 1.44-MB diskette drive

• 650-MB 40X CD-ROM drive

• Factory Installed Software: Tru64

UNIX or OpenVMS

• Protected by Compaq Services,

includinga three-year on-site

limited warranty —Certain

restrictionsand exclusionsapply.

For details, consult the Product

Information Centre at 1-888-88-

COMPAQ.

QuickSpecs

Compaq AlphaStation XP1000

DA-10030 Canada — Version 22 — December 31, 2001

Standard Features

Processor Alpha 21264A (EV67) 667-MHz CPU

Cache Memory 64-KB data cache, 64-KB instruction cache and 4-MB Level 2 cache

Upgradability 500-MHz to 667-MHz CPU upgrade available

Memory Standard Minimum of 256-MB mandatory for CTO systems

Maximum 2 GB

Network Controller Onboard 10/100 Fast Ethernet adapter

Expansion Ports Parallel (25-pin) 1

Serial (9-pin) 2

Pointing device (mouse) P/S2 1

Keyboard P/S2 1

Microphone 1

Headphones/Audio-out 1

Audio-in 1

Expansion Slots I/O (total) 5

PCI 2 (64-bit), 2 (32-bit)

Shared PCI/ISA 1

Storage Controller Onboard Wide UltraSCSI adapter

Storage Diskette Drive 1.44 MB

CD-ROM 650-MB 40X ATAPI CD-ROM Drive

Internal Hard Drives Choice of 9.1-GB, 18.2-GB, 36.4-GB drives

Maximum Internal Storage 146 GB

Manageability Compaq Insight Manager

OS Support Tru64 UNIX systems include Tru64 UNIX V5.1 with Tru64 UNIX base license and 2-user license

OpenVMS systems include OpenVMS 7.2-1 with OpenVMS Systems Value License Package with OpenVMS Alpha

base license, OpenVMS 1-user license, NAS Client 150

Service and Support Compaq Services provides a wide range of service offerings including a three-year limited warranty fully supported

by a worldwide network of resellers and service providers; lifetime toll-free 7 x 24 hardware technical phone support.

NOTE: Certain restrictions and exclusions apply. For details, consult the Product Information Centre at 1-888-88-

COMPAQ.

QuickSpecs

Compaq AlphaStation XP1000

DA-10030 Canada — Version 22 — December 31, 2001

Systems/Options

Step 1 −

−−

−Select system

Configure-to-order (CTO) Systems

CTO systems require the mandatory selection of the following items:

• Minimum of 256-MB memory

• Hard disk drive

Country-specific keyboard; keyboard is not mandatory but essential for full system operation

NOTE: Additional items in Steps 3 through 11 are optional and will be factory integrated when ordered with CTO systems.

OS CPU Memory Graphics Hard Drive Order No.

Tru64 UNIX 667 MHz Mandatory Optional Mandatory SN-E2G6W-32

OpenVMS 667 MHz Mandatory Optional Mandatory SN-E2G6W-A4

Step 2 −

−−

−Country Kits

• Tru64 UNIX and OpenVMS universal country kits include two country-specific power cords and mouse; multi-lingual user documentation is shipped with

system kernel. Tru64 UNIX license included with associated CTO systems.

• Country kit required for system to be operational

• Bulk system orders must include country kits equal to the total number of systems ordered

Country FIS and Documentation, Language Supported

United States English

SN-PBB0U-AA

Canada French

SN-PBB0U-AC

Step 3 −

−−

−Keyboards, Mouse

• CTO systems do not include a keyboard. Selection of keyboard is not mandatory, but is essential for full system operation.

• Select an opal or carbon keyboard and mouse depending on the monitor colour selection (opal or carbon/silver).

Opal Carbon

Keyboard/Language Tru64 UNIX OpenVMS Tru64 UNIX OpenVMS

U.S./English keyboard SN-LKQ47-AA LK462-AA 3R-LKQ48-AA 3X-LK462-A2

Canadian/English keyboard -LK461-AQ -3X-LK462-AQ

Canadian/French keyboard SN-LKQ47-AC LK461-AC 3R-LKQ48-AC 3X-LK462-AC

Mouse 3-button mouse – opal SN-PBQWS-WA

3-button mouse – carbon 3R-A3480-AA

Step 4 −

−−

−Memory

• Selection of aminimum of 256-MB memory is mandatory for CTO systems

• Systems support a maximum of 2-GB memory (two memory banks support four DIMMs per bank)

256-MB ECC memory DIMMs (4 x 64MB DIMMs) SN-MSP01-KB

512-MB ECC memory DIMMs (4 x 128MB DIMMs) SN-MSP01-KC

1024-MB ECC memory DIMMs (4 x 256MB DIMMs) SN-MSP01-KD

QuickSpecs

Compaq AlphaStation XP1000

DA-10030 Canada — Version 22 — December 31, 2001

Options

Step 5 −

−−

−Internal Storage

Step 5a −

−−

−SCSI Controllers −

−−

−Internal

• All systems include onboard UltraSCSI controller for internal disks only

• Systems support a maximum of two additional PCI storage adapters or RAID controllers for additional storage

Maximum # Supported

Tru64 UNIX OpenVMS

PCI single-channel UltraSCSI single-ended adapter (uses one PCI slot)

2 2

SN-KZPBA-CA

PCI single-channel UltraSCSI differential adapter (uses one PCI slot)

2 2

SN-KZPBA-CB

PCI 64-bit/66-MHz dual-channel wide Ultra3 SCSI adapter (uses one PCI slot) –

requires Ultra3 cable kit (3X-BN53A-01)

V5.1 -

3X-KZPEA-DB

PCI single-channel wide Ultra2 (LVD) adapter (uses one PCI slot)

1 1

3X-KZPCA-AA

Step 5b −

−−

−Internal Storage -- Disk Drives and Removable Media

• CTO systems require one mandatory hard disk drive

• Hard disk driveordered with Tru64 UNIX or OpenVMS CTO systems includes factory installed software

Systems support up to four hard disk drives:

- Two 3.5-inch x 1″hard disk drives in internal bays.

- Two 3.5-inch x 1.6″or 1″hard disk drives supported in the 5.25″removable media bays

SCSI Disk Drives 9.1-GB Ultra3 LVD Wide SCSI 10K rpm 1″hard disk drive SN-PBXRW-VB

18.2-GB Ultra2 LVD Wide SCSI 7200 rpm 1″hard disk drive SN-PBXRW-TB

18.2-GB Ultra3 LVD Wide SCSI 10K rpm 1″hard disk drive SN-PBXRW-WC

36.4-GB Ultra3 LVD Wide SCSI 10K rpm 1″hard disk drive SN-PBXRW-XB

Removable Media • Systems include one 5.25″40X CD-ROM drive

• Systems support two additional 5.25″removable media devices (5.25″removable media bays also support

hard disk drives)

• Systems support additional ATAPI device

• DVD-ROM is data support only (no MPEG-2 capability)

• DVD-ROM is backward compatible with CD-ROM media

35/70-GB 8 mm AIT Wide SCSI internal tape drive SN-PBXTA-AA

50/100-GB 8 mm AIT Ultra2 (LVD) SCSI internal tape drive 3X-SZ50X-AA

12/24-GB 4 mm DAT internal SCSI tape drive, 1.6″front accessible bay SN-TLZ10-LK

20/40-GB 4 mm DAT Ultra2 (LVD) SCSI internal tape drive 3X-SD20X-AA

100-MB ATAPI ZIP drive SN-PBXRX-CA

6X/32X ATAPI DVD-ROM drive (data device only) SN-PBXRV-AA

QuickSpecs

Compaq AlphaStation XP1000

DA-10030 Canada — Version 22 — December 31, 2001

Options

Step 6 −

−−

−External Storage −

−−

−Optional

• UltraSCSI configurations require UltraSCSI components (controllers, shelves, disks, cables)

Step 6a -- StorageWorks BA356/BA370 Options

Storage Controllers/Adapters for StorageWorks BA356/BA370 Pedestals and Shelves

• Storage controllers require a minimum operating system revision of Tru64 UNIX V4.0F or OpenVMS V7.1-2 unless noted otherwise.

• Each storage controller/adapter uses one PCI slot

Maximum # Supported

Tru64 UNIX OpenVMS

PCI 1-port UltraSCSI single-ended adapter; includes internal 68-pin and 50-pin HD

connectors and external 68-pin HD connector; requires BN38C-xx cable (2-20m) to

connect to single ended UltraSCSI shelf

2 2

SN-KZPBA-CA

PCI 1-port UltraSCSI differential adapter; includes external 68-pin HD connector;

requires BN38C-xx cable (2-25m) to connect adapter to Differential UltraSCSI

shelf or RAID controller

2 -

SN-KZPBA-CB

68-pin HD male-to-VHDCI male UltraSCSI cable; required for each external UltraSCSI

shelf attached to KZPBA-CA/CB adapter BN38C-xx

PCI 1-port UltraSCSI RAID controller with 4-MB cache memory, includes RAID Array

230/Plus subsystem software and documentation kit and VHDCI female connector;

tape drives not supported −18.2-GB or higher disk drives not supported on

KZPAC-xx RAID controllers

1 1

SN-KZPAC-AA

PCI 3-port UltraSCSI RAID controller with 4-MB cache memory, includes RAID Array

230/Plus subsystem software and documentation kit; tape drives not supported;

SCSI cable required for each active port; requires BN31K-0E for external third-port

connection −18.2-GB or higher disk drives not supported on KZPAC-xx RAID

controllers

1 1

SN-KZPAC-CA

PCI 3-port UltraSCSI RAID controller with 8-MB cache memory, includes RAID Array

230/Plus subsystem software and documentation kit; tape drives not supported;

SCSI cable required for each active port; requires BN31K-0E for external third-port

connection −18.2-GB or higher disk drives not supported on KZPAC-xx RAID

controllers

1 1

SN-KZPAC-CB

Cache battery backup for KZPAC controller KZPSC-UB

VHDCI male-to-VHDCI male UltraSCSI cable,

xx=02, 2E(2.5), 03, 05, 10, 20 m)

NOTE: Manufacturing may substitute BN37A-02 cable for specific cabinet

configurations

BN37A-xx

SCSI cable/bulkhead assembly kit with KZPAC-CA/CB, allows external connection of

one third port BN31K-0E

SCSI cable/bulkhead assembly kit with two ports for KZPAC-CA/CB, allows external

connection of two third ports KZPAC-SB

PCI 3-channel 64-bit Ultra2 LVD RAID controller, 64-MB cache – supported with DS-

BA356-SG and DS-BA35X-FC only

1 -

DS-KZPCC-CE

PCI 1-channel 64-bit Ultra2 LVD backplane RAID controller, 16-MB cache

V4.0F/4.0G/5.1

(not TruCluster

V5.1)

DS-KZPCC-AC

QuickSpecs

Compaq AlphaStation XP1000

DA-10030 Canada — Version 22 — December 31, 2001

Options

Step 6 −

−−

−External Storage −

−−

−Optional (continued)

StorageWorks UltraSCSI BA356 Pedestals and BA370 Rackmount Enclosure

StorageWorks BA356 Pedestals • UltraSCSI top gun blue pedestals provide support for UltraSCSI disk drives; pedestal is available in single-

bus or split-bus configurations and includes a personality module and 180W power supply

• UltraSCSI shelf supports: seven 3.5″hard disk drives, or one 5.25″device and four 3.5″hard disk drives, or

two 5.25″devices and one 3.5″hard disk drive

• Installation of redundant power supply reduces number of 3.5″drive slots by one

UltraSCSI single-ended pedestal, single-bus personality module, 180W power supply DS-BA356-KF

UltraSCSI single-ended pedestal, split-bus personality module, 180W power supply DS-BA356-KG

UltraSCSI pedestal, single-channel differential personality module, 180W power supply DS-BA356-KH

180W power supply, includes 120V North American and 240V IEC power cord CK-BA35X-HH

• M-series cabinets (H9A10 and H9A15) allow one BA370 enclosure to be installed in front cabinetStorageWorks BA370 Rackmount

Enclosure • Host adapter, RAID Array controller, platform-specific Solutions Software Kit, and disk drives must be

ordered separately

BA370 front mount rackmount enclosure with five 180W power supplies, includes RETMA

rackmount kit; first BA370 enclosure must be front mounted in cabinet, 20U height 2T-BA370-AS

Factory configured RAID of rackmounted BA370/HSZ80 YS-ASCRD-AA

• StorageWorks shelf supports seven 3.5″x 1.6″hard disk drives; with the addition of redundant power

supply, six drives are supported

StorageWorks UltraSCSI Rackmount

Shelves −

−−

−Requires selection of

UltraSCSI adapter and SCSI cable • StorageWorks shelf kits are mounted back-to-back in rackmount cabinets

StorageWorks UltraSCSI single-bus shelf kit BA36R-RC

StorageWorks UltraSCSI split-bus shelf kit BA36R-RD

3-m SCSI cable BN37A-03

Devices Supported in StorageWorks UltraSCSI Shelves

Disk Drives • Maximum six (10,000 rpm) or seven (7,200 rpm) drives supported in StorageWorks shelf

• One power supply supports a maximum of six 10,000 rpm disks

9.1-GB UltraSCSI drive 7,200 rpm DS-RZ1DA-VW

9.1-GB UltraSCSI drive 10,000 rpm DS-RZ1DD-VW

18.2-GB UltraSCSI drive 7,200 rpm DS-RZ1EA-VW

18.2-GB UltraSCSI drive 10,000 rpm DS-RZ1ED-VW

36.4-GB UltraSCSI drive 10,000 rpm DS-RZ1FC-VW

Removable Media Devices 12/24-GB 4 mm DAT narrow SCSI tape drive in StorageWorks carrier DS-TLZ10-VA

35/70-GB AIT tape drive in StorageWorks carrier DS-AIT35-VW

600-MB 32X CD-ROM drive in StorageWorks carrier DS-RRD47-VA

QuickSpecs

Compaq AlphaStation XP1000

DA-10030 Canada — Version 22 — December 31, 2001

Options

Step 6 −

−−

−External Storage −

−−

−Optional (continued)

Step 6b – StorageWorks Model 42xx and 43xx Options

StorageWorks Model 42xx and 43xx Adapters/Controllers

• Storage controllers require a minimum operating system revision of Tru64 UNIX V4.0F or OpenVMS V7.1-2 unless noted otherwise.

• Each storage controller/adapter uses one PCI slot

Maximum # Supported

Tru64 UNIX OpenVMS

PCI 1-port Ultra2 SCSI (LVD) single-ended adapter, 68-pin HD connector, requires

BN38C cable (2 to 20m) to connect to single-ended UltraSCSI shelf – Model 42xx

only

1 1

3X-KZPCA-AA

68-pin HD male-to-VHDCI male UltraSCSI cable; required for each external UltraSCSI

shelf attached to KZPCA-AA adapter

BN38C-xx

PCI 2-channel LVD multimode Ultra3 adapter, VHDCI – Model 43xx only

V5.1 1

3X-KZPEA-DB

PCI 3-channel 64-bit Ultra2 LVD RAID controller, 64-MB cache

1 -

DS-KZPCC-CE

PCI 1-channel 64-bit Ultra2 LVD backplane RAID controller, 16-MB cache

V4.0F/4.0G/5.1

(not TruCluster

V5.1)

- DS-KZPCC-AC

StorageWorks Model 43xx Universal Drive Shelves

Model 4314R (Ultra3 SCSI) StorageWorks Model 4314R Ultra3 SCSI rackmount single bus universal drive shelf DS-SL13R-AA

(US/Canada orders)

Model 4354 (Ultra3 SCSI) StorageWorks Model 4354R Ultra3 SCSI rackmount dual bus universal drive shelf DS-SL13R-BA

(US/Canada orders)

Model 4300 I/O Module (Ultra3 SCSI) StorageWorks Model 4300 Ultra 160 SCSI single port LVD, I/O module 190212-B21

(US/Canada orders)

StorageWorks Model 4300 Ultra 160 SCSI dual port LVD, I/O module 190213-B21

(US/Canada orders)

9.1-GB Ultra2 (LVD) 7,200 rpm 1.0″Universal drive 3R-A0525-AADisk Drives (Supported in Model 42xx

and 43xx Universal Drive Shelves) 9.1-GB Ultra3 (LVD) 10,000 rpm 1.0″Universal drive 3R-A0584-AA

9.1-GB Ultra3 (LVD) 15,000 rpm 1.0″Universal drive 3R-A1542-AA

18.2-GB Ultra2 (LVD) 7,200 rpm 1.0″Universal drive 3R-A0527-AA

18.2-GB Ultra3 (LVD) 15,000 rpm 1.0″Universal drive 3R-A1543-AA

36.4-GB Ultra3 (LVD) 10,000 rpm 1.0″Universal drive 3R-A0919-AA

72.8-GB Ultra 3 (LVD) 10,000 rpm 1.0” Universal Drive 3R-A3050-AA

Drive-height converter 4-pack 3R-A0528-AA

QuickSpecs

Compaq AlphaStation XP1000

DA-10030 Canada — Version 22 — December 31, 2001

Options

Step 6 −

−−

−External Storage −

−−

−Optional (continued)

Step 6c -- Tabletop Tape Drives

• Tape drives require single-ended UltraSCSI adapter (KZPBA-CA or KZPCM-DA) and power cord

12/24-GB 4-mm DAT narrow single-ended tabletop SCSI tape, includes 120V North

American power cord, requires BN31W-xx SCSI cable DS-TLZ10-DB

32/64-GB DAT loader in carrier TLZ9L-VA

32/64-GB tabletop DAT loader TLZ9L-DB

20/40-GB SCSI (DLT 4000E) tabletop drive (Tru64 UNIX and OpenVMS only) 112907-B21

(US/Canada orders)

5, 7, 10, 14-GB 8-mm tabletop, single-ended SCSI TKZ9F-TA

Step 7 −

−−

−Graphics/Audio

• Graphics adapter optional for Tru64 UNIX and OpenVMS CTO systems

• System consists of two PCI buses −three PCI slots on Bus 0 and two PCI slots on Bus 1

• For optimal graphics performance, all graphics adapters should be installed on Bus 0; there will be a loss of performance on any adapter placed on PCI

Bus 1

• First graphics adapter for single head systems must be installed on PCI Bus 0

• Multi-head systems must be homogeneous −all ELSA GLoria Synergy or all PowerStorm 300, etc.

• Tru64 UNIX and OpenVMS graphics options require DIGITAL Open3D media, included in factory installed software (FIS)

Maximum # Supported

Tru64 UNIX OpenVMS

ELSA GLoria Synergy graphics with 8-MB SGRAM, TruColour at 1280 x 1024

SN-PBXGK-BB

PowerStorm 300 midrange 3D graphics with 15-MB frame buffer memory and 16-MB

texture memory, TruColour at 1280 x 1024

324

SN-PBXGD-AD

PowerStorm 350 midrange 3D graphics with 30-MB frame buffer memory and 32-MB

texture memory, TruColour at 1900 x 1200

324

SN-PBXGD-AE

3Dlabs Oxygen VX1 32-MB PCI 2D graphics accelerator card

SN-PBXGF-AB

NOTES:

(1) Tru64 UNIX and OpenVMS support one to four heads for 2D only.

(2) Updates on multi-head support can be located at http://www1.service.digital.com/open3d NOTE: This website is available in English only.

(3) PowerStorm 350 customers that require displaying the highest resolution stereo graphics (1280x1024 @ 120Hz) should consider the Viewsonic P817

monitor as their monitor solution.

(4) OpenVMS supports up to three PowerStorm 300 adapters and one PowerStorm 350 adapter on the same PCI bus. The TIMA update kit for multi-head

support can be found at http://www.openvms.compaq.com/openvms/products/mmov NOTE: This website is available in English only.

Audio • In addition to the integral audio capability, an Ensoniq PCI audio 1372 card can be

selected

Ensoniq PCI audio 1373 card with headphone, jack, and CD audio cable SN-AVH10-AC

Step 8 −

−−

−Monitors – Select opal or carbon/silver

• Country Kit includes two country-specific power cords, one for system and one for monitor

Opal Monitors V570 15″(13.8″viewable image size) multiple-scan colour monitor with Invar Shadow

Mask, VGA to 1024 x 768 @ 75 Hz, 0.28mm AG, TCO99; Northern Hemisphere with NA

power cord

3R-A3082-AA

V500 15″(13.8″viewable image size) auto-scanning colour monitor, VGA to 1024 x 768

@75 Hz, 0.28 mm FST, MPRII Southern Hemisphere with Australia/New Zealand power

cord

3R-VRQV5-11

QuickSpecs

Compaq AlphaStation XP1000

DA-10030 Canada — Version 22 — December 31, 2001

Options

Step 8 −

−−

−Colour Monitors (continued)

P710 17″(16″viewable image size) auto-scanning colour monitor, Diamondtron NF, 0.25

mm aperture grille pitch, VGA to 1280 x 1024 @ 75 Hz, TCO99, with power cord 3R-A2936-AA

P910 19″(18″viewable image size) auto-scanning colour monitor, Diamondtron NF, 0.25

mm aperture grille pitch, VGA to 1280 x 1024 @ 85 Hz, TCO99, with power cord 3R-A2935-AA

P1100 21″(19.8″viewable image size) auto-scanning colour monitor, 0.28mm aperture

grill pitch, VGA to 1600 x 1200 @ 75 Hz NI, TCO99, Southern Hemisphere with

Australia/New Zealand power cord

3R-VRQP1-23

P1210 22″(20″viewable image size) auto-scanning colour monitor, Diamondtron NF, 0.24

mm aperture grille pitch, VGA to 1600 x 1200 @ 85 Hz, TCO99 with power factor

correction, with power cord

3R-A2934-AA

Carbon/Silver Monitors V570 15″(13.8″viewable image size) multiple-scan colour monitor, VGA to 1024 x 768

@85 Hz, 0.28 mm DP, MPRII/Energy Star Compliant, with power cord, VGA cable 3R-A3383-

228113-001

P720 17″(16″viewable image size) auto-scanning colour monitor, Diamondtron NF, 0.25

mm aperture grille pitch, VGA to 1280 x 1024 @85 Hz, MPRII/TCO 99/Energy Star

Compliant, with power cord, VGA cable

3R-A3388-AA

244373-001

P920 19″(18″viewable image size) auto-scanning colour monitor, Diamondtron NF, 0.24

mm aperture grille pitch, VGA to 1600 x 1200 @85 Hz, MPRII/TCO 99/Energy Star

Compliant, with power cord, VGA cable

3R-A3393-AA

244375-001

P1220 22″(20″viewable image size) auto-scanning colour monitor, Diamondtron NF, 0.24

mm aperture grille pitch, VGA to 1792 x 1344 @85Hz, dual video input, USB Hub,

MPRII/TCO 99/Energy Star Compliant, with power cord, VGA cable

3R-A3398-AA

244374-001

Carbon/Silver Flat Panel Monitors TFT8030, 18.1″(18.0″viewable image size) TFT flat panel monitor, 0.28mm pixel pitch,

1280 x 1024 @75 Hz, multi-mode support, MPRII/TCO99/Energy Star compliant, six video

input connectors (two VGA, two DVI-I, one S-video, and one C-video), power cord, VGA

and DVI-I cables

3R-A3511-

234362-001

TFT5030, 15.1″(15.0″viewable image size) TFT flat panel monitor, 0.3 mm pixel pitch,

1024 x 768 @75 Hz, multi-mode support, MPRII/TCO99/Energy Star compliant, two video

input connectors (one VGA and one DVI-I), power cord, VGA and DVI-I cables

3R-A3353-AA

228134-001

Video Cable • Each monitor includes a 1.8-m signal cable – a video cable is required for most server applications

1.8-m video cable BN39C-02

Monitor Power Cords 120V, 75″BN26J-1K

QuickSpecs

Compaq AlphaStation XP1000

DA-10030 Canada — Version 22 — December 31, 2001

Options

Step 9 −

−−

−Network Options

• Systems include onboard 10/100 Ethernet (Twisted pair) controller

Maximum # Supported

Tru64 UNIX OpenVMS

XP1 MAU 10Base5 AUI/Thickwire

1 1

SN-PCXAN-DE

XP1 MAU Card 10Base2 ThinWire

1 1

SN-PCXAN-DF

PCI-to-10/100 Ethernet NIC 8255x

2 2

3X-DE600-AA

PCI dual-port 10/100 UTP Fast Ethernet adapter and base module, must be installed in

primary PCI 64-bit slot; requires Tru64 UNIX V4.0F and NHD2 1.0.3 or OpenVMS

V7.2-1

2 2

3X-DE602-AA

Single-port multi-mode (MMF) add-on daughter card for 3X-DE602-AA, must be

installed in primary PCI 64-bit slot; requires Tru64 UNIX V4.0F and NHD2 1.0.3 or

OpenVMS V7.2-1

2 2

3X-DE602-FA

PCI Token Ring adapter, must be installed in PCI-1 bus on Tru64 UNIX systems

2 2

SN-PBXNP-AC

PCI FDDI adapter, DAS TP-PMD

2 2

3X-DEFPA-MC

PCI FDDI adapter SAS TP-PMD

2 2

3X-DEFPA-UC

PCI FDDI adapter, SAS MMF, SC

2 2

3X-DEFPA-AC

PCI FDDI adapter, DAS UTP, MMF, SC

2 2

3X-DEFPA-DC

PCI 4-port asynchronous controller

PBXDA-AA

PCI 8-port asynchronous controller

PBXDA-AB

PCI 16-port asynchronous controller

PBXDA-AC

PCI 2-port synchronous controller, requires BC33x-06 cable

PBXDP-AA

PCI 4-port synchronous controller, requires BC33x-06 cable

PBXDP-AB

PCI 8-port synchronous controller, requires BC33x-06 cable

SN-PBXDP-AC

Gigabit Ethernet adapter

1 1

DEGPA-SA

PCI-to-ATM 155 Mb adapter - Fiber

1 -

3X-DAPBA-FA

PCI-to-ATM 155 Mb adapter - UTP

1 -

3X-DAPBA-UA

NOTES:

(1) Controllers supported with Tru64 UNIX V4.0F only

Step 10 – AlphaStation XP1000 Rackmount Options

M-series Rackmount Kit • Rackmount kit must be ordered separately −requires removal of XP1000 front door

AlphaStation XP1000 M-series rackmount shelf kit; includes front panel bezel assembly SN-BA26R-RA

M-series enclosures require the mandatory selection of the following items:

M-series Cabinets and

Accessories • H9A10, or H9A15 Cabinet, 120V or 240V

• Cabinet front door based on cabinet height

• Factory Integration

• Ballast kits as required

Autres manuels pour Professional XP1000

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Compaq Ordinateur de bureau

Compaq

Compaq AP400 - Professional - 64 MB RAM Manuel utilisateur

Compaq

Compaq AP250 - Deskpro Workstation - 128 MB RAM Manuel d'utilisation et d'entretien

Compaq

Compaq dc7800 - Convertible Minitower PC Guide d'installation

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Guide rapide

Compaq

Compaq D300v - Evo - 128 MB RAM Manuel utilisateur

Compaq

Compaq DIGITALPC 5510 Manuel utilisateur

Compaq

Compaq DA-64CAA-DA - AlphaServer - ES40 Model 2 Manuel utilisateur

Compaq

Compaq 3000R - ProLiant - 128 MB RAM Manuel d'exploitation et d'entretien

Compaq

Compaq Presario SR2100 - Desktop PC Comment utiliser

Compaq

Compaq Presario 6500 Mode d’emploi

Compaq

Compaq dc5850 - Microtower PC Manuel d'utilisation et d'entretien

Compaq

Compaq Presario CQ1-1100 Manuel d'instructions

Compaq

Compaq Presario 7360 Manuel utilisateur

Compaq

Compaq Deskpro Workstation AP230 Fiche technique

Compaq

Compaq Presario SR1800 - Desktop PC Instructions d'installation

Compaq

Compaq Evo W6000 Fiche technique

Compaq

Compaq dc5800 - Microtower PC Manuel utilisateur

Compaq

Compaq ProLiant DL580 Manuel utilisateur

Compaq

Compaq dc5850 - Microtower PC Manuel utilisateur

Compaq

Compaq Presario SR1700 - Desktop PC Manuel utilisateur

Compaq

Compaq Compaq Evo D310 MT Instructions d'installation et d'entretien

Compaq

Compaq Deskpro EC Manuel utilisateur

Compaq

Compaq 8000 - Elite Convertible Minitower PC Manuel utilisateur

Compaq

Compaq 6000 - ProLiant - 128 MB RAM Manuel de programmation

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur
