COMPANION COMP2012 Manuel utilisateur
2
GENERAL WARNINGS
• This appliance shall only be connected to a cylinder with 3/8” gas cylinder
valve certied to AS2469 standards.
• This appliance is designed for outdoor use only and must be operated a
minimum of 1000mm from any ammable material or surfaces and materials.
• This appliance is to be stored in a dry and well ventilated location
free from direct sunlight.
• Do not store when valve is still connected to the cylinder.
• Make sure that the cylinder is disconnected and is stored in a well-ventilated
area, free from direct sunlight, heat and ignition sources.
• If cylinder is being stored indoors, ensure that the indoor storage location
complies with the standard AS / NZS1596
• This appliance must only be serviced by an authorised service agent, return
to your place of purchase for
service and repair.
IMPORTANT
Read these instructions for use carefully.
Familiarise yourself with the appliance before connecting it to a gas container.
Keep these instructions for future reference.
When unpacking appliance remove any packaging etc from around appliance & ensure
pot support is correctly positioned
DANGER!
• During operation all surfaces will be extremely hot and should not be
touched or handled.
• Do not use the appliance if it has a leak, worn, deteriorated or damaged seals.
• Handle with care even after brief use; always pick up using the handles
not the cylinder.
3
OWNERS MANUAL
• It may be hazardous to attempt to t other types of gas containers or cartridges.
• Use only in well ventilated areas.
• Always operate appliance a minimum of 1000mm from ammable materials
and walls, and a minimum of 1000mm from ceiling.
• Do not use adaptors or modify appliance to t other connectors or cylinders.
• Do not modify appliance.
• Do not use multiple appliances to heat a single utensil.
• Children must be supervised by an adult at all times.
• Never leave appliance unattended when operating.
• Use as a cooking appliance only, not to be used as heater or
modied for any other reason.
• Avoid boil over and spills on to burners.
• Not suitable for marine environment.
CARBON MONOXIDE HAZARD
This appliance produces carbon monoxide which has no odour.
Using the appliance in enclosed spaces, for example;
caravan, car, boat or mobile home could cause DEATH.
IMPORTANT
• Keep children away from appliance at all times.
• Surfaces of the appliance will become hot during operation, please
take care when handling or moving the appliance.
• Do not move appliance during cooking, allow to cool completely.
• Appliance is to be used on a stable, level, at, non-ammable surface.
The appliance should be protected from direct drafts and in a well
-ventilated place.
• Only cooking vessels with a minimum diameter of 150mm and no wider
than 200mm diameter are to be used with this appliance.
5
OWNERS MANUAL
SAFETY INSTRUCTIONS
This appliance must only be used in an above ground open air situation with natural
ventilation without stagnant areas, where gas leakage is rapidly dispersed by wind and natural
convection.
Any enclosure in which the appliance is
used should comply with one of the following:
A. An enclosure with walls on all sides, but
with no overhead cover.
B. Within a partial enclosure that includes an
overhead cover and no more than two walls
C. Within a partial enclosure that includes an
overhead cover and no more than two walls,
the following must apply
1. At least 25% of the total wall area is
completely open
2. 30% or more in total of the remaining
wall side, back and front wall areas is
open and unrestricted.
3. In the case of balconies, 20% or more of
the total wall area must remain open and
unrestricted.
6
CONNECTION
Your stove is designed to connect directly to a gas cylinder with a 3/8”
gas valve using the specially designed LP Gas hose and in built regulator.
1. Check that the cylinder gas control is in the “OFF” position
(turned fully clockwise)
2. Check seals visually for wear before connecting before making connections
to appliance and cylinder
3. Take the hose and attach to the gas inlet on the appliance and tighten
4. Attach the other end of the hose to the gas cylinder, tightening using a spanner
5. Check that both gas controls are in the “OFF” position, then turn the
cylinder gas valve on in an anti-clockwise direction for one full turn and
then check the connections for leaks with soapy water. If a leak is detected
turn the cylinder gas valve “OFF” and retighten all connections then retest
7
OWNERS MANUAL
OPERATING - Stove
1. Open the Lid of the Stove and Remove the PE Cutting Board
2. Turn the gas cylinder valve on in an anti-clockwise direction for one full turn
3. Turn the gas control in an anti-clockwise direction approximately ¼ of a turn
and press the Piezo button
4. If the burner does not ignite, turn the gas control in the clockwise direction
to the “OFF” position and allow the residual gas to disperse before
attempting to reignite the burner.
8
ADJUSTING HEAT OUTPUT
1. Turn the gas control in an anti-clockwise direction to achieve a higher
ame and in the clockwise direction for a lower ame. –
TURNING THE STOVE OFF
If the appliance is no longer to be used and to reduce the risk of blocked gas jets caused
by excess gas being left in the hose, all remaining gas must be expelled from the hose
assembly.
1. With the ame still operating, turn the valve on the gas cylinder in the
clockwise direction until it is off. Allow the ame to burn down then
extinguish once all remaining gas in the hose has been used.
2. Turn the gas controls on the appliance clockwise to the “Off” position.
hiGh LOW
9
OWNERS MANUAL
OPERATING – LED Light
1. Open the Lid of the Stove position the LED light in the required position by
sliding along the length of the lid
2. Press button to turn “ON” and press again to turn “OFF”
10
CARE INSTRUCTIONS
Using warm soapy water with a mild detergent wipe down all surfaces and areas of the
appliance, taking care not to allow water to enter the burner outlets or aeration holes
located in the burner tube.
DO NOT SUBMERGE THE APPLIANCE IN A SINK OR BOWL
DO NOT USE ABRASIVE CLEANERS OR BLEACH
MAINTENANCE AND SERVICE
• During operation if it is noted that the burner ame is unstable, is changing
colour from Blue to Yellow or has a distinct smell it is important that you take
the appliance to your local authorised gas appliance repairer for inspection.
• Periodically check the gas control is tight and has no leaks, follow the testing
for leaks procedure. Check the gas hose & regulator for any signs of wear, cuts
or fraying, if identied replace immediately with a Gas Certied replacement
hose and/ or regulator
• For further information or assistance please contact customer service.
SPECIFICATIONS
Dimensions 645W x 297L x 159hmm
Gas Type Propane
Consumption Total 24Mj/hr – Total (12Mj/hr per burner)
Inject Size 0.37mm
Certificate SAi-400049
Weight 8.8Kg
