Commax DRC-41UN Manuel utilisateur

Door camera DRC-41UN

User Manual

•Thank you for purchasing COMMAX products.

•Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow

instructions to use a product exactly.

•The company is not responsible for any safety accidents caused by abnormal operation of the product.

1. Introdution..................................................... 2

2. Important Safeguard ..................................... 3

3. Part Names................................................... 4

4. Installation & Wiring ...................................... 6

5. Package contents ......................................... 8

6. Specification ................................................ 9

Contents

Your unit is designed so it can be flush mounted on the or used. When flush mounted on the wall, the stand permils you to the

unit for an gular of unit view. The model number is located on the bottom and record the serial number in the space provided

below(available). Refer to these numbers whenever you call upon your COMMAX dealer regarding this product.

Model No. Serial No.

To prevent fire or shock hazard, do not expose the unit to rain or moisture.

This symbol is intended to alert the use to the presence of uninsulated

“

“dangerous Voltage”

”

within the product’s enclose that

may be of sufficient magnitude to constitute a risk of electric shock to persons.

This symbol is intended to alert the use to the presence of important operating and maintemance(servicing) instructions in the

literature accompanying the appliance

CAUTION: To reduce the risk of electrix shick, do not remove cover(or back) no user-serviceable

part sinside refer servicing to quaured service personnel

caution

Rosk of electric shock

do not open

1. Introdution

▲

Damage Requiring Service: This equipment from the power source and source and refer servicing to qualified service personnel under the following

conditions:

ⓐwhen the power is damaged.

ⓑif liquid has been spiled or objects have hallen into the unit

ⓒif the equipment has been exposed to rain or water.

ⓓif the equipment has beem dropped or otherwise damaged.

ⓔwhen the equipment exhibits a distinct change in performance- this indicates a need for service.

▲

Water and Moisture: Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink, or laundru tub, in a wet basement, or near

a swimming pool, and the like.

▲

Accessories: The product may fall, causing serious injury to a child or adult, and serious damage to the appliance. Any mounting of the manufacture’s

insturctions, and should use a mounting accessory recommended by the manufacturer.

▲

Object and Liquid Entry: Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts

that could result in a fire or electric shock. Never spill liquid of any kind on the product.

▲

Lightning: For added protection for this product before a lihgtning storm, or when it is left un attached and un used for long periods of time, unplug it from

the wall outlt and disconnect the other system. This will prevent damage to the product due to lightming and power-line surges. If you live in an

ared heavily prone to lightning stoms, it is recommended that you invest in power-line, telephone-line, RFcable and actuator/ polarization surge

protectors to protect your appliance system from possiple damage

2. Important Safeguard

3. Part Names.

①Camera Lens: Transfering images, Keep it clean to get clear view

②LED & illumination Sensor : Providing clear image at night

③Speaker : Delivering the voice from the monitor to the camera

④Name card : You can write the house number

⑤Call button : Calling a residence

⑥Microphone : Delivering the voice of visitor to the household

⑦Angle Adjuster : Adjusting the camera lens

⑧Volume Controller VR : Turn it right to increase the volume. ([+], [-]Driver)

⑨Door release cable : Conncet it to the door relay

⑩Monitor connecting terminal: Connect it to the monitor (Be careful with the polarity)

Installation & Wiring

①Line up the holes of wall and flush box and fix it on the wall.

②Do the monitor wiring cosidering the polarity according to the the image (Wiring diagram)

③Fit the product from the above and press it against the bracket. Then, check the monitor

screen, if it shows the place that you would like to see.

④Fix it from the bottom with the screw

5. Package contents

Door Camera Flush box

SCREW CAP

카메라

고정 스크류

현관카메라 벽걸이 브라켓

고정 스크류

SCREW CAP

카메라

고정 스크류

현관카메라 벽걸이 브라켓

고정 스크류

SCREW CAP

카메라

고정 스크류

현관카메라 벽걸이 브라켓

고정 스크류

SCREW CAP

카메라

고정 스크류

현관카메라 벽걸이 브라켓

고정 스크류

Connector

(4PX200) Manual

Camera

Screw(4EA)

(M3X8)

Tp Rp Vp

QTpQPp QRpXp

Rp TpSp Up Vp

6. Specification

Model DRC-41UN

Power source 12V (from Monitor)

Wiring 4 wires(Polariry)C

Camera Module C-MOS(COLOR)

Communication Duplex

Frequency NTSC STANDARD

Min. Lux. 0.1Lux(300mm from camera)

Light LED (Operation in Dark)

Camera Angle Horizontal 68°, Vertical 55°

Angle Adjustment Up, Down, Left, Right, 10° each

Temperation -10°C(tested up to -40°C) ~ +50°C

Dimesion(mm) 130(W) X 182(H) X 39(D)

Diameter(pie) 0.5 0.65 0.8 1

Distance(M) 28 50 70 115

Distance (TIV Cable)
