DOOR PHONE DP-201LA

User Manual

•Thank you for purchasing COMMAX products.

•Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow

instructions to use a product exactly.

•The company is not responsible for any safety accidents caused by abnormal operation of the product.

1. Introduction .....................................................2

2. Important Safeguards .....................................3

3. Overview.........................................................4

4. Operation .......................................................5

5. Wiring..............................................................6

6. Specifications..................................................7

Contents

Your unit is designed so it can be flush mounted on the or used. When flush mounted on the wall, the stand permils you to the

unit for an gular of unit view. The model number is located on the bottom and record the serial number in the space provided

below(available). Refer to these numbers whenever you call upon your COMMAX dealer regarding this product.

Model No. Serial No.

To prevent fire or shock hazard, do not expose the unit to rain or moisture.

This symbol is intended to alert the use to the presence of uninsulated

“

“dangerous Voltage”

”

within the product’s enclose that

may be of sufficient magnitude to constitute a risk of electric shock to persons.

This symbol is intended to alert the use to the presence of important operating and maintemance(servicing) instructions in the

literature accompanying the appliance

1. Introduction

CAUTION : To reduce the risk of electric shock, do not remove cover(or back) no user-serviceable

part inside refer servicing to qualified service personnel

caution

Risk of electric shock

do not open

▲

Damage Requiring Service: This equipment from the power source and source and refer servicing to qualified service per-

sonnel under the following conditions:

ⓐwhen the power is damaged.

ⓑif liquid has been spilled or objects have fallen into the unit

ⓒif the equipment has been exposed to rain or water.

ⓓif the equipment has been dropped or otherwise damaged.

ⓔwhen the equipment exhibits a distinct change in performance- this indicates a need for service.

▲

Water and Moisture: Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink, or laundry

tub, in a wet basement, or near a swimming pool, and the like.

▲

Accessories: The product may fall, causing serious injury to a child or adult, and serious damage to the appliance. Any

mounting of the manufacture’s instructions, and should use a mounting accessory recommended by the manu-

facturer.

▲

Object and Liquid Entry: Never push objects of any kind into this product through openings as they may touch dangerous

voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any

kind on the product.

▲

Lightning: For added protection for this product before a lightning storm, or when it is left un attached and un used for long

periods of time, unplug it from the wall outlt and disconnect the other system. This will prevent damage to the prod-

uct due to lightning and power-line surges. If you live in an area heavily prone to lightning storms, it is recom-

mended that you invest in power-line, telephone-line, RFcable and actuator/ polarization surge protectors to protect

your appliance system from possible damage

2. Important Safeguards

3. Overview

Controls and functions

ROOM STATION

①VOLUME SWITCH

②HANDSET

③DOOR RELEASE BUTTON

④HANDSET CORD

⑤POWER CORD

DOOR STATION

①SPEAKER

②CALL BUTTON

③WALL MOUNTING BRACKET

④MICROPHONE

1. When the call button(②on the door station) is pressed, the chime sounds.

2. Adjust the volume switch(①on the room station) to control the call sound.

3. Pick up the handset(②on the room station) to talk.

4. Press the door release button(③on the room station) to open the door.

The door-lock should be instatlled.

5. Place the handset to finish talking.

Operation

5. Wiring

①Connect two wires of door station (1) to the terminal ①, ②of room-station (2).

②Connect electrical door-lock(3) to the terminal ⑤, ⑥as below picture.

③When finished the connection, put in the power cord at AC outlet.

OUTPUT POWER

6. Specifications

POWER SOURCE 220V~, 50Hz

High 300mW across 8 ohm

Low 50mW across 8 ohm

DISTANCE 100m(Ø0.65mm), 150m(Ø0.8mm)

DIMENSION 208(D) X 98 (W) X 65(H)mm / Room station.

WEIGHT 700g

DOOR-STATION DR-201D / DR-201H / DR-201A/DR-2R/DR-2L

MEMO

Printed In Korea / 2013.06.105

513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea

Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133

Web site : www.commax.com
