1.Introduction

Thankyoufor purchasingtheHands-Free expandableVideoIntercom

SystemHFX-700M.

For moreinformationregardingthecompletelineofourproducts,

pleasevisit www.comelitusa.com

Thisintercom system uses2-wireinstallationandallowsyoutoidentify

andcommunicatewithcallersat thedoor, fromthesecurity and

convenienceofanyroom inyourhomeor office. Visitorsactivatethe

systemby pressinga call buttonontheoutdoor camera,whichsounds

a doorbellchimeaswell asturningontheinsidevideomonitor.

Atwo-way intercom thenletsyouspeakwithvisitorsafterfirst visually

identifyingthem.

It consistsofa monitor stationandanoutdoor doorbell/camera unit.

Thisunit iscapableofexpandinguptoa total of4indoor monitorsand

2door cameras. Expansionmonitorsavailablefor thissystem comein

twomodels,video(EX-700H) or Audio only (EX-700A).

Section1:UserArticle

2.HFX-700MKIT

2.1.HFX-700MKITPartsIdentification

8 9 10117

178mm

(7.0)

36mm

(1.42) 118mm

(4.65)

1.3.5" Color TFTScreen

2.Speaker

3.InuseLED

4.Monitor LED

5.Intercom LED

7.Microphone

8.Cut-offbutton()

9.Intercom button()

10. Monitoringbutton()

11. Door releasebutton()

12. Powerswitch

13. Brightness tuner()

14. Sharpnesstuner()

15. Bell Volumetuner()

16. SpeakerVolumetuner()

17.

18.

19.

CommunicationLED

JP1, videodisplay optionduringdoor releaseoperation

Enablevideodisplay (JP1left)(default)

Disablevideodisplay (JP1right)

JP2, door statusreportoption

Bell toneindication(JP2left)(default)

LEDlightonDoor OpenButton(JP2right)

JP3, external doorbell triggeroption

N.O. dry contact(default)(allowbypasscurrent of24VDC/1A)

12VDC150mAcurrent output

[Mainmonitor]

2.1.1HFX-700MMainmonitoridentification

130mm

(5.12)"

36mm

(1.42)"

1.WhiteLED Illumination

2.1/3" Color CCD

3.Microphone

4.Speaker

5.Call button

6.Screwcover

(-6degrees, 0degrees,8degrees, 16degrees)

8.Wiretodoor strike

9.WiretomainMonitor

10.

11.

CCDverticalviewangleadjustmentdial

JP2(automaticLEDlight supplement option)

JP1, lockcontrol outputoptionandCCDon/offduringtheoutput

98mm

(3.86)"

JP1

JP2

1 2 3 4

8 9

[DoorStation]

N.O. dry contact output; CCDon.(default)(24VDC/1A

bypass current)

12VDC/300mAcurrent output; CCDoffto. (tosavepower)

2.1.2.HFX-700MorEX-700DDoorCameraidentification

2.2.1.VisitorCallsfromDoorCamera

A.WhentheCall buttononthecamera ispressed, All monitorsonthe

systemwill ringwitha chimesoundandall monitorswillbeactivated.

B.Afterthecall, ifnothingonthemonitor ispressed,thesystem will time

out after30seconds. Ifthemonitor buttonispressed,thesystem

will stay activefor 90seconds.

C.Youareabletoterminatetheactivityonthemonitor atany timeby

pressingtheCut-offbutton.

D.Pressdoor releasebuttonfrommonitor canreleaseremotedoor

strikeat door camera.

Operatingthevideointercomsystem consistsofrespondingtovisitor

callsfromdoor camera, releasingadoor strikefrom indoor monitor;

audioandvideomonitoringfromany indoor monitor; voicebroadcast

from onemonitor toall others; engageintercom functionaftervoice

broadcast.

2.2.2.AudioandVideomonitoring

A.Pressingthemonitor buttonwill turnontheaudioandvideofrom

door camera.

B.Ifthereisa seconddoor cameraonthissystem, pressingtheMonitor

buttonagainwill scroll theimagetothesecondexpansiondoor

camera.

Atanytimeifyouwishtoterminatethemonitoring,presstheCut-off

buttontoterminatethesystem.

2.2.HFX-700MKITOperation

2.2.3. (similartowalky-talky)Pushtotalkmode

A. onmeansvoiceisfree togooutfrom monitor to

door camera.

CommunicationLED

B.Duringtheconversation,presstheMonitor Buttonfor 2secondsto

switchtopush-to-talk mode.Inthismode, pressingtheMonitor Button

(CommunicationLEDwillturnon)willactivatetheone-way voice

communicationtothedoor camera; releasingtheMonitor Buttonand

(CommunicationLEDturnsoff )allowfor one-way voicecommunication

tocomeinfrom thedoor camera tothemonitor.

C.Thisfunctioncanbeuseful whentheenvironment at door cameraside

becomestoo noisy.

3.ExpansionVideoMonitor(EX-700H)

3.1.EX-700HIdentification

8 9 10 117

178mm

(7.0)

36mm

(1.42) 118mm

(4.65)

1.3.5" Color TFTScreen

2.Speaker

3.InuseLED

4.Monitor LED

5.Intercom LED

7.Microphone

8.Cut-offbutton()

9.Intercom button()

10. Monitoringbutton()

11. Door releasebutton()

12. Powerswitch

13. Brightness tuner()

14. Sharpnesstuner()

15. Bell Volumetuner()

16. SpeakerVolumetuner()

17.

18.

CommunicationLED

JP1, videodisplay optionduringdoor releaseoperation

Enablevideodisplay (JP1left)(default)

Disablevideodisplay (JP1right)

JP2, door statusreportoption

Bell toneindication(JP2left)(default)

LEDlightonDoor OpenButton(JP2right)

[EX-700H]

Operatesthesameasthemainmonitor unit (Refertopage4).

3.2.EX-700HOperation

Mainmonitor

Doorcamera

Call button

Cut-off button

Intercombutton

Monitoringbutton

Doorreleasebutton

3.2.1.Broadcastandintercomfunction

A.Whensystem consistsofmainmonitor andexpansionmonitor andan

outdoor doorbell/camera unit,thesystemcanprovideintercom function.

B.Presstheintercombuttonfrom any monitor, allothermonitorswill

reactbymakingbellsound. Atthesametime,hostcanspeakand

broadcastvoicemessagetoall othermonitors.

C.Thebroadcast modecanlast for 20 seconds. Duringthe20seconds,

any othermonitor cananswerthecall by havingtheintercom button

pressedinordertoengagetheintercom communication. Oncethe

intercomcommunicationhasbeenestablished,talk timeisfor a

maximum of90seconds.Thisfunctionprovidesaudiointercom

communicationonly, monitorswill notshowany video.

D.Atanytimeifyouwishtoterminatethemonitoring,presstheCut-off

buttontoterminatethesystem.

Expansionmonitor

Cut-off button

Intercombutton

Monitoringbutton

Doorreleasebutton

4.ExpansionAudioMonitor(EX-700A)

4.1.EX-700AIdentification

1.Speaker

2.InuseLED

3.Monitor LED

4.Intercom LED

6.Microphone

7.Cut-offbutton()

8.Intercom button()

9.Monitoringbutton()

10. Door releasebutton()

11. Powerswitch

12. Bell Volumetuner()

13. SpeakerVolumetuner()

14.

CommunicationLED

JP2, door statusreportoption

Bell toneindication(JP2left)(default)

LEDlightonDoor OpenButton(JP2right)

7 8 9 106

11 12

178mm

(7.0)

36mm

(1.42) 118mm

(4.65)

[EX-700A]
