Combi Flash EX 655 Manuel utilisateur

Read all instructions BEFORE assembly and USE of product.

KEEP INSTRUCTIONS FOR

FUTURE USE.

Record the following information for quick reference.

Note: Illustrations are only representative

and not actual. Attach copy of sales receipt.

Parts List

Name of Parts

Make sure you have all the parts listed below before using your stroller. If any parts are missing,

call Consumer Affairs at 1-800-992-6624.

Warranty Card

Instruction

Manual

1 Handle Grip

2 Stroller Pack

Folding Lever

4 Carrying Strap

5 L-Shaped Brackets for Infant Carrier

Infant Seat Attachment Rail

7 Infant Seat Attachment Strap

Locking Lever

Basket

10 Swivel Lock Lever

4 Carrying Strap

5 L-Shaped Brackets for Infant Carrier

10 Swivel Lock Lever

1 Handle Grip

2 Stroller Pack

Located on the rear right leg.

Attach copy of sales receipt.

Combi USA, Inc. • 1962 HWY 160 W, Suite 100 • Fort Mill, SC 29708 • www.combi-intl.com

Consumer Affairs 1-800-99-COMBI

Flash EX

7655

Series

Instruction Manual

Date Purchased:

_______________________________

Model Number: 7655 - _______ Color

___________________________________________________

Front Wheels

(x2)

Rear

Wheels

(x2)

Main Body

7 Infant Seat Attachment Strap

11 End Cap

Plastic

Rail Cover

Stroller Pack

WARNING

Excessive weight in basket (or

items placed in basket which

overflow the top or side of

basket) may cause a hazardous

condition to exist.

WARNING

Do not load more than 10

lbs. (4.5kg) in the basket.

- 2 -

WARNINGS For your child’s safety:

If your stroller is not used in compliance with these instructions, serious injury may result.

In the event of damage or

problems, discontinue use and

contact Combi Consumer Affairs

for instructions: 1-800-992-6624.

WARNING

AVOID SERIOUS INJURY FROM

FALLING OR SLIDING OUT. ALWAYS

USE ATTACHMENT STRAP. INFANT

SEAT HARNESS MUST BE USED

WHEN USING THIS PRODUCT.

WARNING

NEVER LEAVE

CHILD

UNATTENDED.

WARNING

DO NOT LIFT AND CARRY

the stroller while open with a

child in it. The stroller may slip.

WARNING

Do not use the stroller on

steep slopes, stairs, escala-

tors, beaches, rough roads,

mud, etc.

WARNING

o not allow your child to stand

in or on the stroller.

WARNING

Do not put or hang things on the

handle because it could cause the

stroller to become unbalanced or

tip over.

WARNING

lways engage both brakes

when parking the stroller.

WARNING

Never carry more than one child

in the stroller. Do not allow a

child to ride or sit on areas of

stroller other than the seat.

WARNING

DO NOT ALLOW CHILD TO LEAN

OVER SIDES OF STROLLER. IT

MAY BECOME UNBALANCED

AND TIP OVER.

CAUTIONS:

. Improper usage or lack

of knowledge regarding the

instructions can result in

dangerous situations,

personal injury or damage to

the stroller.

2. Completely remove all

plastic bags and packing

materials before using

this product to prevent a

possible choking hazard.

3. Push the stroller at a

normal walking speed only.

All products specifications are subject to change without notice. Sizes and

weights are intended as guides and are approximations. Combi® reserves the

right to modify the products in its line during the course of the year. Non con-

tractual media. Colors are as accurate as the media in which they appear allows.

©Combi USA, Inc. 2004

Please refer to manufacturer's infant carrier instruction manual

for minimum and maximum weight accommodation

Only trans-

port infants that are within size and weight limitations of infant

car seat as described in the manufacturer’s instruction manual.

Note: Illustrations are

for

reference only and may not

represent the

actual product.

WARNING

TO AVOID BURNS, do not place

bottles/cups with hot liquids in

the Stroller Pack. Do not place

more than 2 lbs. in the Stroller

Pack.

1. Remove stroller and wheel assemblies from the plastic bag.

2. Remove and discard both black rubber caps from stroller

frame.

Release locking latch by pulling latch away from stroller fram

Grip the handle on each side with an under hand hold and

turn outward to open.

5. Lift up the handle

and snap the stroller

away from you.

will open and lock

automatically

into position

Note: Illustrations

are

for reference only

and may not represent

the ac

tual product.

Attaching & Removing the Front Swivel Wheels

Removing the Swivel Wheels

Press in the rectangular button located at

the bottom of the wheel holder while pull-

ing the assembly off of the swivel shaft.

Release Button

Turn stroller over and remove

packaging material from stroller

frame.

Insert the front wheels onto

the stroller leg. Make sure the

swivel wheel lever is behind the

stroller leg and released. You

will hear a click when the wheel

is properly attached.

- 3 -

Assembling the Stroller

Locate the small opening on each rear

wheel assembly.

. Locate the small chrome pin on each rear stroller leg.

Attaching and Removing the Rear Wheels

. Insert the leg into the

wheel assembly until the

small chrome pin locks

into the opening.

To remove the wheels,

push in small chrome

pin and pull wheels off the frame.

- 4 -

To lock brakes

, push both brake levers

down

To unlock brakes

, lift both brake levers

CAUTION

Push the stroller forward to ensure that

the brakes are properly engaged.

Using the Brakes

Using the Swivel Wheels

To lock swivels

, lift both swivel lock levers

To unlock swivels

, push both swivel lock levers

down

WARNINGS

When infant car seat/carrier is

in the stroller, always fasten the

infant seat harness as well as the

carrier attachment straps.

The

Combi Flash EX

is only to be

used when attaching infant car

seat/carriers. Do not use for any

other purpose.

To assure safety for the baby,

please refer to the manufacturer’s

instructions for use of your infant

car seat/carrier.

If unable to securely attach infant

car seat/carrier to the Combi Flash

EX,

discontinue use and contact

Combi Consumer Affairs.

Do not lift stroller by using infant

car seat/carrier handle.

Discontinue use if fraying or

damage is noted to carrier attach-

ment strap.

Trade name and trademarks of Graco

, Century

, Evenflo

and Cosco

® and Cosco

and Peg-Perego are the property of their respective owners and no endorse-

® and Peg-Perego are the property of their respective owners and no endorse-

ment of or approval by them is intended or implied. All

Combi Flash EX

strollers are compatible with specified models of the Graco

, Century

Evenflo

®,

and the

Peg-Perego

infant car seat/carrier models

® infant car seat/carrier models

as of the date this printing was prepared.

ombi USA Inc.

Flash EX

Compatible Infant Car Seats

Combi

Tyro, Combi Connection

Graco

Snug Ride

, Snug Ride DX5

, Snug Ride LX5

Century

Smart Fit Supreme

, Assura, Smart Fit Plus 22, Smart Fit Plus 22V, Smart Fit

Elite, Avanta SE, Avanta DX.

Evenflo

Portabout

, Discovery

Cosco

Eddie Bauer

Peg-Perego

- Primo Viaggio

Trade name and trademarks of Graco

, Century

, Evenflo

Cosco

and

® and

Peg-Perego

are the

property of their respective owners and no endorsement of or approval by them is intended or

implied.

The Combi Flash EX

stroller is compatible with specified models of the Graco

Century

and Evenflo

®,

osco

and

Peg-Perego

infant car seat/carrier models

as of the date this printing

was prepared.

SA, Inc.

Compatibility

- 5 -

Trade name and trademarks of Graco

, Century

, Evenflo

and Cosco

® and Cosco

and Peg-Perego are the property of their respective owners and no endorse-

® and Peg-Perego are the property of their respective owners and no endorse-

ment of or approval by them is intended or implied. All

Combi Flash EX

strollers are compatible with specified models of the Graco

, Century

Evenflo

®,

and the

Peg-Perego

infant car seat/carrier models

® infant car seat/carrier models

as of the date this printing was prepared.

ombi USA Inc.

Attaching/Releasing Infant Seat

Unbuck

le the attachment strap and lay over the right

and left side of the stroller f

rame.

Hook the infant seat onto front rail of the stroller. The

foot end of infant

car seat/carrier will rest on the two

L-shaped brackets.

Remove the infant car seat/carrier by reversing the

above steps.

See your infant car

seat manufactu

rer's

instruction

s for proper rel

ease lever operation.

REMOVING THE

INFANT SEAT/CARRIER

Bring the infant seat attachment straps through the

seat belt guides in the infant car seat/carrier and fas-

ten the buckle. To loosen,

tilt the buckle and pull up.

To tighen, pull the strap.

Note: Illustrations are

for reference only and may not represent

the

actual product.

WARNING

Never

use this product without securing the

attachment

strap to the infant seat.

WARNING

The infant harness must be buckled correctly per your

manufacturer's instructions.

Combi Tyro, Combi Connection, Graco Snugride, Evenflo.

Portabout, Peg-Perego

WARNING

Make sure

you tighten the attachment strap before u

ge.

Attaching/Releasing Infant Seat

- 6 -

Trade name and trademarks of Graco

, Century

, Evenflo

and Cosco

® and Cosco

and Peg-Perego are the property of their respective owners and no endorse-

® and Peg-Perego are the property of their respective owners and no endorse-

ment of or approval by them is intended or implied. All

Combi Flash EX

strollers are compatible with specified models of the Graco

, Century

Evenflo

®,

and the

Peg-Perego

infant car seat/carrier models

® infant car seat/carrier models

as of the date this printing was prepared.

ombi USA Inc.

Unbuck

le the

attachment

strap and lay

over the right

and left side

of the stroller

rame.

Hook the infant

seat onto front

rail of the stroller.

The foot end of

infant

car seat/

carrier will rest on

the two L-shaped

brackets.

Cosco, Eddie Bauer,

Evenflo, Discovery, Peg-Perego

Use object to press in plastic tabs to release right and left end caps.

(See diagram A)

The plastic tabs are located underneath the front rail

of the stroller on the plastic right and left rail covers.

(See diagram 1)

Right and left end caps will be released by pressing in plastic tabs.

(See diagram B)

End caps must be removed to install Cosco Eddie

Bauer, Evenflo, Discovery or Peg-Perego

infant carrier.

Bauer, Evenflo, Discovery or Peg-Perego

WARNING

Never

use this product without securing the

attachment

strap to the infant seat.

WARNING

The infant harness must be buckled correctly per your

manufacturer's instructions.

Note: Illustrations are

for

reference only and may not

represent the

actual product.

Remove End Cap

REMOVING THE

INFANT SEAT/CARRIER

Remove the infant car seat/carrier by reversing the

above steps.

See your infant car

seat manufactu

rer's

instruction

s for proper rel

ease lever operation.

Bring the infant seat attachment straps through the

seat belt guides in the infant car seat/carrier and fas-

ten the buckle. To loosen,

tilt the buckle and pull up.

To tighen, pull the strap.

WARNING

Make sure

you tighten the attachment strap before

ge.

- 7 -

Folding the Stroller

CAUTION

For safety purposes, the folding levers should be

operated only when folding the stroller.

1. Remove infant seat.

2. Lock both front swivel wheels.

3. Empty the basket.

4. Lift the folding levers on both sides of the

handle.

. Tilt handle back and fold.

6. Fold handle inward and lock with the folding latch.

Attaching the Basket

CAUTION

Do not place more than 10 lbs. in the basket.

Remove all items from the basket before folding the

stroller.

Loop the front, rear and middle straps of the bas-

ket around the stroller frame and snap together.

Removing the Basket

Press the gray plastic tabs together to detach bas-

ket. Gray tabs are located at the top corner of the

basket in the

front, middle and rear.

Note: Illustrations are

for

reference only and may not

represent the

actual product.

- 8 -

Routine Maintenance

STORE IN A COOL AND DRY AREA,

especially in the summer. Do not store the stroller in the trunk of

a vehicle.

WAIST BELT AND BASKET

Hand wash with brush. Wipe out excess water with a dry cloth and dry in a shaded area. For stubborn

dirt, dilute a mild detergent and apply directly to the dirty area. Wipe out the detergent.

MAIN BODY

Briskly wipe off any mud and dirt. To clean the body, wipe with a damp cloth then wipe out any traces

of moisture on the body with a dry cloth. The main body might become moldy and musty if not wiped

dry.

Excessive exposure to the sun could cause premature color fading of stroller

plastic and fabric.

WHEEL ASSEMBLIES

After prolonged normal use, the wheels of your stroller may not swivel or turn as easily as when the

stroller was new. This is usually due to a buildup of dirt in the swivel mechanism. Before adding lubri-

cation, remove the swivel wheels by pressing in the release button and wiping off mud and dirt.

not use soap and water to wash wheels.

Periodically check that all screws, bolts and nuts are tight.

Avoid lubricating the swivel wheels whenever possible. Excessive lubrication or adding lubricant to

swivel wheels when new may cause them to develop a shimmy or wobble that may quicken their

deterioration. Add silicone* to

the wheel assemblies

in small amounts.

Do not use lubricants because oil attracts dust and would hinder the movement rather than

improve it.

*Silicone spray is available in varying size cans at most hardware stores.

Front Swivel

Wheel

Rear Wheel

Using the Stroller Pack

WARNING

TO AVOID BURNS, do not place bottles/

cups with hot liquids in the Stroller Pack.

Do not place more than 2 lbs. in the

Stroller Pack

WARNING

ttaching

Hook the clips into the slots on the handle and

wrap the velcro straps around the handle.

Removing

Unfasten the velcro straps and unhook the clips.

- 9 -

Trouble Shooting

STROLLER WILL NOT FOLD

- Check to see that the attachment strap is not caught in the side.

- Make sure front swivels are locked.

- Remove all items from the basket.

DIFFICULT TO STEER/STROLLER PULLS TO ONE SIDE

- Remove any items hanging from the handle.

- Make sure weight in basket is distributed evenly.

- Check that the brakes are not in the locked position.

- Clean and add silicone to wheels, if necessary.

DIFFICULT TO GET UP CURBS

- Pulling stroller backward makes going

up a curb difficult, and could pose a safety hazard.

Pull the handle up to lift the rear wheels

onto the curb, then pull the stroller backward

until the front wheels clear.

Note: Illustrations are

for

reference only and may not

represent the

actual product.

- 10 -

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Combi Poussette

Combi

Combi Savvy Soho 2200 Series Manuel utilisateur

Combi

Combi Cosmo DX Manuel utilisateur

Combi

Combi Savona PM 4100 Manuel utilisateur

Combi

Combi Travel Savvy 2120 Series Manuel utilisateur

Combi

Combi MECHACAL HANDY AUTO4CAS Manuel utilisateur

Combi

Combi Flare Manuel utilisateur

Combi

Combi Strolee STS-1 3100 Series Manuel utilisateur

Combi

Combi Quickids Manuel utilisateur

Combi

Combi Cosmo E Manuel utilisateur

Combi

Combi Coccoro Flash Manuel utilisateur

Combi

Combi Ultra Savvy TS Manuel utilisateur

Combi

Combi 4010 Manuel utilisateur

Combi

Combi Twin Savvy E Manuel utilisateur

Combi

Combi Cosmo E Manuel utilisateur

Combi

Combi Travel Savvy 2125 Series Manuel utilisateur

Combi

Combi Flex Manuel utilisateur

Combi

Combi CFS Manuel utilisateur

Combi

Combi 7735 Manuel utilisateur

Combi

Combi Savvy Soho 2200 Series Manuel utilisateur

Combi

Combi Twin Savvy EX 7230 Series Manuel utilisateur

Combi

Combi I-Thruller Manuel utilisateur

Combi

Combi City Savvy 2460 Series Manuel utilisateur

Combi

Combi Ultra Savvy PM 2900 Series Manuel utilisateur

Combi

Combi Perfect Match 6630 Series Manuel utilisateur

Manuels Poussette populaires d'autres marques

Hauck

Hauck Priya Trioset Manuel utilisateur

CHILDHOME

CHILDHOME CWQDN Manuel utilisateur

Dreamer Design

Dreamer Design Rebound GST Manuel utilisateur

Britax

Britax STEELCRAFT AGILE Manuel utilisateur

Graco

Graco 7427 Manuel utilisateur

Comfort

Comfort COMPASS Manuel utilisateur

OBaby

OBaby Aura Manuel utilisateur

Tutek

Tutek Tirso Manuel utilisateur

Babify

Babify Dual Plus Manuel utilisateur

Graco

Graco Stroller Manuel utilisateur

Special Tomato

Special Tomato Jogger Manuel utilisateur

Chicco

Chicco CORTINA TOGETHER TWO-PASSENGER STROLLER Manuel utilisateur

Otto Bock

Otto Bock Kimba neo Manuel utilisateur

Milly Mally

Milly Mally ROYAL Guide de démarrage rapide

Hauck

Hauck DUETT 3 PRAM Manuel utilisateur

BOB

BOB DUALLIE Manuel utilisateur

Nuna

Nuna Pepp Manuel utilisateur

Britax

Britax B2 Manuel utilisateur
