Combi Flash 7650 Series Manuel utilisateur

Be sure to carefully read this instruction manual before using the product to ensure proper use of the stroller.

Please keep instruction manual for future reference. Record the following information for quick reference.

Parts List

Name of Parts

Make sure you have all the parts listed below before using your stroller. If any parts are missing,

call Customer Service at 1-800-992-6624.

Warranty Card

Instruction

Manual

1 Handle Grip

2 Stroller Pack

3 Folding Lever

4 Carrying Strap

5 L-Shaped Brackets for Infant Carrier

6 Infant Seat Attachment Rail

7 Infant Seat Attachment Strap

8 Locking Lever

9 Basket

10 Swivel Lock Lever

Located on the rear right leg.

Attach copy of sales receipt.

Combi USA, Inc. • 1962 HWY 160 W, Suite 100 • Fort Mill, SC 29708 • www.combi-intl.com

Customer Service 1-800-992-6624 • 8:30 a.m. - 5:00 p.m. Eastern Time • Monday - Friday

Flash 7650 Series

Instruction Manual

Date Purchased: _______________________________ Model Number: 7650 - _______ Color ___________________________________________________

Front Wheels

(x2)

Rear Wheels

(x2)

Main Body

11 End Cap

12 Plastic Rail Cover

Stroller Pack

WARNING

Excessive weight in basket (or

items placed in basket which

overflow the top or side of

basket) may cause a hazardous

condition to exist.

WARNING

Do not load more than 10

lbs. (4.5kg) in the basket.

- 2 -

WARNINGS For your child’s safety:

If your stroller is not used in compliance with these instructions, serious injury may result.

In the event of damage or

problems, discontinue use and

contact Combi Customer Service

for instructions: 1-800-992-6624.

WARNING

AVOID SERIOUS INJURY FROM

FALLING OR SLIDING OUT. ALWAYS

USE ATTACHMENT STRAP. INFANT

SEAT HARNESS MUST BE USED

WHEN USING THIS PRODUCT.

WARNING

NEVER LEAVE CHILD

UNATTENDED.

WARNING

DO NOT LIFT AND CARRY

the stroller while open with a

child in it. The stroller may fold.

WARNING

Do not use the stroller on

steep slopes, stairs, escala-

tors, beaches, rough roads,

mud, etc.

WARNING

Do not allow your child to stand

in or on the stroller.

WARNING

Do not put or hang items on the

handle because it could cause the

stroller to become unbalanced or

tip over.

WARNING

Always engage both brakes

when parking the stroller.

WARNING

Never carry more than one child

in the stroller. Do not allow a

child to ride or sit on areas of

stroller other than the seat.

WARNING

DO NOT ALLOW CHILD TO LEAN

OVER SIDES OF STROLLER. IT

MAY BECOME UNBALANCED

AND TIP OVER.

CAUTIONS:

1. Improper usage or lack

of knowledge regarding the

instructions can result in

dangerous situations,

personal injury or damage to

the stroller.

2. Completely remove all

plastic bags and packing

materials before using

this product to prevent a

possible choking hazard.

3. Push the stroller at a

normal walking speed only.

All products specifications are subject to change without notice. Sizes and

weights are intended as guides and are approximations. Combi® reserves the

right to modify the products in its line during the course of the year. Non con-

tractual media. Colors are as accurate as the media in which they appear allows.

©Combi USA, Inc. 2004

Please refer to manufacturer's infant carrier instruction manual

for minimum and maximum weight accommodation. Only trans-

port infants that are within size and weight limitations of infant

car seat as described in the manufacturer’s instruction manual.

Note: Illustrations are for

reference only and may not

represent the actual product.

WARNING

TO AVOID BURNS, do not place

bottles/cups with hot liquids in

the Stroller Pack. Do not place

more than 2 lbs. in the Stroller

Pack.

1. Remove stroller and wheel assemblies from the plastic bag.

2. Remove and discard both black rubber caps from stroller

frame.

3. Release locking latch by pulling latch away from stroller frame.

4. Grip the handle on each side with an under hand hold and

turn outward to open.

5. Lift up the handle

and snap the stroller

away from you. It

will open and lock

automatically

into position.

Note: Illustrations

are for reference only

and may not represent

the actual product.

Attaching & Removing the Front Swivel Wheels

Removing the Swivel Wheels

Press in the rectangular button located at

the bottom of the wheel holder while pull-

ing the assembly off of the swivel shaft.

Release Button

1. Turn stroller over and remove

packaging material from stroller

frame.

2. Insert the front wheels onto

the stroller leg. Make sure the

swivel wheel lever is behind the

stroller leg and released. You

will hear a click when the wheel

is properly attached.

- 3 -

Assembling the Stroller

Locate the small opening on each rear

wheel assembly.

2. Locate the small chrome pin on each rear stroller leg.

Attaching and Removing the Rear Wheels

3. Insert the leg into the

wheel assembly until the

small chrome pin locks

into the opening.

To remove the wheels, push in small chrome

pin and pull wheels off the frame.

- 4 -

To lock brakes, push both brake levers down.

To unlock brakes, lift both brake levers up.

CAUTION

Push the stroller forward to ensure that

the brakes are properly engaged.

Using the Brakes

Using the Swivel Wheels

To lock swivels, lift both swivel lock levers up.

To unlock swivels, push both swivel lock levers down.

WARNINGS

When infant car seat/carrier is

in the stroller, always fasten the

infant seat harness as well as the

carrier attachment straps.

The Combi Flash is only to be

used when attaching infant car

seat/carriers. Do not use for any

other purpose.

To assure safety for the baby,

please refer to the manufacturer’s

instructions for use of your infant

car seat/carrier.

If unable to securely attach infant

car seat/carrier to the Combi

Flash, discontinue use and con-

tact Combi Customer Service.

Do not lift stroller by using infant

car seat/carrier handle.

Discontinue use if fraying or

damage is noted to carrier attach-

ment strap.

Trade name and trademarks of Graco®, Century®, and Evenflo® and Cosco® are the property of their respective owners and no

endorsement of or approval by them is intended or implied. All Combi Flash strollers are compatible with specified models of the Graco®,

Century®, and Evenflo® and Cosco® infant car seat/carrier models as of the date this printing was prepared.

Flash Compatible Infant Car Seats

Combi® Tyro

Graco® Snug Ride®, Snug Ride DX5®, Snug Ride LX5®

Century® Smart Fit Supreme®, Assura, Smart Fit Plus 22, Smart Fit Plus 22V, Smart Fit

Elite, Avanta SE, Avanta DX.

Evenflo® Portabout, Discovery

Cosco® Eddie Bauer

Trade name and trademarks of Graco®, Century®, and Evenflo® and Cosco® are the prop-

erty of their respective owners and no endorsement of or approval by them is intended

or implied. The Combi Flash stroller is compatible with specified models of the Graco®,

Century®, and Evenflo® and Cosco® infant car seat/carrier models as of the date this print-

ing was prepared. Copyright May 2004 Combi USA, Inc.

Compatibility

- 5 -

Trade name and trademarks of Graco®, Century®, Evenflo® and Cosco® are the property of their respective owners and no endorsement

of or approval by them is intended or implied. All Combi Flash strollers are compatible with specified models of the Graco®, Century®, and

Evenflo® infant car seat/carrier models as of the date this printing was prepared.

Attaching/Releasing Infant Seat

1. Unbuckle the attachment strap and lay over the right

and left side of the stroller frame.

2. Hook the infant seat onto front rail of the stroller. The

foot end of infant car seat/carrier will rest on the two

L-shaped brackets.

Remove the infant car seat/carrier by reversing the

above steps. See your infant car seat manufacturer's

instructions for proper release lever operation.

REMOVING THE INFANT SEAT/CARRIER

3. Bring the infant seat attachment straps through the

seat belt guides in the infant car seat/carrier and fas-

ten the buckle. To loosen, tilt the buckle and pull up.

To tighen, pull the strap.

Note: Illustrations are for

reference only and may not

represent the actual product.

WARNING

Never use this product without securing the attachment

strap to the infant seat.

WARNING

The infant harness must be buckled correctly per your

manufacturer's instructions.

Combi Tyro, Graco Snugride,

Evenflo Portabout

WARNING

Make sure you tighten the attachment strap before usage.

Attaching/Releasing Infant Seat

- 6 -

Trade name and trademarks of Graco®, Century®, Evenflo® and Cosco® are the property of their respective owners and no endorsement

of or approval by them is intended or implied. All Combi Flash strollers are compatible with specified models of the Graco®, Century®, and

Evenflo® infant car seat/carrier models as of the date this printing was prepared.

2. Unbuckle the

attachment

strap and lay

over the right

and left side

of the stroller

frame.

3. Hook the infant

seat onto front

rail of the stroller.

The foot end of

infant car seat/

carrier will rest on

the two L-shaped

brackets.

Cosco Eddie Bauer

Evenflo Discovery

1. Use object to press in plastic tabs to release right and left end caps.

(See diagram A) The plastic tabs are located underneath the front rail

of the stroller on the plastic right and left rail covers. (See diagram 1)

Right and left end caps will be released by pressing in plastic tabs.

(See diagram B) End caps must be removed to install Cosco Eddie

Bauer or Evenflo Discovery infant carrier.

WARNING

Never use this product without securing the attachment

strap to the infant seat.

WARNING

The infant harness must be buckled correctly per your

manufacturer's instructions.

Note: Illustrations are for

reference only and may not

represent the actual product.

Remove End Cap

REMOVING THE INFANT SEAT/CARRIER

Remove the infant car seat/carrier by reversing the

above steps. See your infant car seat manufacturer's

instructions for proper release lever operation.

3. Bring the infant seat attachment straps through the

seat belt guides in the infant car seat/carrier and fas-

ten the buckle. To loosen, tilt the buckle and pull up.

To tighen, pull the strap.

WARNING

Make sure you tighten the attachment strap before

usage.

- 7 -

Folding the Stroller

CAUTION

For safety purposes, the folding levers should be

operated only when folding the stroller.

1. Remove infant seat.

2. Lock both front swivel wheels.

3. Empty the basket.

4. Lift the folding levers on both sides of the

handle. 5. Tilt handle back and fold.

6. Fold handle inward and lock with the folding latch.

Attaching the Basket CAUTION

Do not place more than 10 lbs. in the basket.

Remove all items from the basket before folding the

stroller.

1. Loop the front, rear and middle straps of the bas-

ket around the stroller frame and snap together.

Removing the Basket

1. Press the gray plastic tabs together to detach bas-

ket. Gray tabs are located at the top corner of the

basket in the front, middle and rear.

Note: Illustrations are for

reference only and may not

represent the actual product.

456

- 8 -

Routine Maintenance

STORE IN A COOL AND DRY AREA, especially in the summer. Do not store the stroller in the trunk of

a vehicle.

WAIST BELT AND BASKET

Hand wash with brush. Wipe out excess water with a dry cloth and dry in a shaded area. For stubborn

dirt, dilute a mild detergent and apply directly to the dirty area. Wipe out the detergent.

MAIN BODY

Briskly wipe off any mud and dirt. To clean the body, wipe with a damp cloth then wipe out any traces

of moisture on the body with a dry cloth. The main body might become moldy and musty if not wiped

dry.

Excessive exposure to the sun could cause premature color fading of stroller

plastic and fabric.

WHEEL ASSEMBLIES

After prolonged normal use, the wheels of your stroller may not swivel or turn as easily as when the

stroller was new. This is usually due to a buildup of dirt in the swivel mechanism. Before adding lubri-

cation, remove the swivel wheels by pressing in the release button and wiping off mud and dirt. Do

not use soap and water to wash wheels. Periodically check that all screws, bolts and nuts are tight.

Avoid lubricating the swivel wheels whenever possible. Excessive lubrication or adding lubricant to

swivel wheels when new may cause them to develop a shimmy or wobble that may quicken their

deterioration. Add silicone* to the wheel assemblies in small amounts.

Do not use lubricants because oil attracts dust and would hinder the movement rather than

improve it.

*Silicone spray is available in varying size cans at most hardware stores.

Front Swivel

Wheel

Rear Wheel

Using the Stroller Pack WARNING

TO AVOID BURNS, do not place bottles/

cups with hot liquids in the Stroller Pack.

Do not place more than 2 lbs. in the

Stroller Pack

WARNING

Attaching

Hook the clips into the slots on the handle and

wrap the velcro straps around the handle.

Removing

Unfasten the velcro straps and unhook the clips.

- 9 -

Trouble Shooting

STROLLER WILL NOT FOLD

- Check to see that the attachment strap is not caught in the side.

- Make sure front swivels are locked.

- Remove all items from the basket.

DIFFICULT TO STEER/STROLLER PULLS TO ONE SIDE

- Remove any items hanging from the handle.

- Make sure weight in basket is distributed evenly.

- Check that the brakes are not in the locked position.

- Clean and add silicone to wheels, if necessary.

DIFFICULT TO GET UP CURBS

- Pulling stroller backward makes going

up a curb difficult, and could pose a safety hazard.

Pull the handle up to lift the rear wheels

onto the curb, then pull the stroller backward

until the front wheels clear.

Note: Illustrations are for

reference only and may not

represent the actual product.

- 10 -

Table des matières

Autres manuels Combi Poussette

Combi

Combi Ultra Savvy PM 2900 Series Manuel utilisateur

Combi

Combi AuraStar Manuel utilisateur

Combi

Combi Savvy DX 2530 Series Manuel utilisateur

Combi

Combi Twin Savvy LX Manuel utilisateur

Combi

Combi Perfect Match 6525 Manuel utilisateur

Combi

Combi Counterpart 7525 Series Manuel utilisateur

Combi

Combi Flash EX 655 Manuel utilisateur

Combi

Combi Soho Sport 2000 Series Manuel utilisateur

Combi

Combi Fold N Go Manuel utilisateur

Combi

Combi Dreamy Manuel utilisateur

Combi

Combi Cosmo E Manuel utilisateur

Combi

Combi Ultra Savvy 2730 Series Manuel utilisateur

Combi

Combi Perfect Match 6630 Series Manuel utilisateur

Combi

Combi Nemurie UF800 Manuel utilisateur

Combi

Combi City Savvy Select 2520 Series Manuel utilisateur

Combi

Combi NE-YO PLUS Manuel utilisateur

Combi

Combi Handy 4Cas Plus Manuel utilisateur

Combi

Combi Savvy Soho 2200 Series Manuel utilisateur

Combi

Combi Savvy Soho 2200 Series Manuel utilisateur

Combi

Combi Tetra TS 6700 Manuel utilisateur

Combi

Combi Urbano Manuel utilisateur

Combi

Combi Cozy Light Compact Manuel utilisateur

Combi

Combi Culetmieuller FS Manuel utilisateur

Combi

Combi LX-720 Granpaseo Manuel utilisateur

Manuels Poussette populaires d'autres marques

Hauck

Hauck Priya Trioset Manuel utilisateur

CHILDHOME

CHILDHOME CWQDN Manuel utilisateur

Dreamer Design

Dreamer Design Rebound GST Manuel utilisateur

Britax

Britax STEELCRAFT AGILE Manuel utilisateur

Graco

Graco 7427 Manuel utilisateur

Comfort

Comfort COMPASS Manuel utilisateur

OBaby

OBaby Aura Manuel utilisateur

Tutek

Tutek Tirso Manuel utilisateur

Babify

Babify Dual Plus Manuel utilisateur

Graco

Graco Stroller Manuel utilisateur

Special Tomato

Special Tomato Jogger Manuel utilisateur

Chicco

Chicco CORTINA TOGETHER TWO-PASSENGER STROLLER Manuel utilisateur

Otto Bock

Otto Bock Kimba neo Manuel utilisateur

Milly Mally

Milly Mally ROYAL Guide de démarrage rapide

Hauck

Hauck DUETT 3 PRAM Manuel utilisateur

BOB

BOB DUALLIE Manuel utilisateur

Nuna

Nuna Pepp Manuel utilisateur

Britax

Britax B2 Manuel utilisateur
