Code Alarm PROFESSIONAL SERIES Manuel utilisateur

PROFESSIONAL

SERIES

Security and Keyless Entry

Installation Guide

ca1045

**This guide is a reference for module rmware version 5.0 or higher**

2ca1045 rev B

Before You Begin.........................................................................................3

Wire Connection Guide............................................................................... 4

5 Pin Main Harness ................................................................................... 5

6 Pin Input / Output Harness .....................................................................6

2 Pin Door Lock Output Harness ............................................................... 8

Additional Ports.........................................................................................12

LED Port ..................................................................................................12

Programming Port ................................................................................... 12

On-Board Shock Sensor .........................................................................12

DBI Port ...................................................................................................12

Set Up & Programming ............................................................................. 13

Transmitter Programming ........................................................................13

Manual Feature Programming ................................................................. 13

Programming Feature Banks ..................................................................14

PC Based Feature Programming / Firmware Updates - (Optional) ......... 16

Dome Light Delay / Theater Dimming ..................................................... 16

Chirp Delete - User Accessible ................................................................ 17

User Selectable LED ............................................................................... 17

Feature Descriptions................................................................................. 18

Transmitter Button Functions .................................................................. 22

Security Trigger Zones.............................................................................. 22

System Layout...........................................................................................23

Table of Contents

PROFESSIONAL INSTALLATION

STRONGLY RECOMMENDED

Installation Precautions:

Roll down window to avoid locking keys in vehicle

during installation

Avoid mounting components or routing wires near

hot surfaces

Avoid mounting components or routing wires near

moving parts

Tape or loom wires under hood for protection and

appearance

Technical Support (800) 421-3209

or go to

www.voxxuniversity.com

Use a Digital Multi Meter for testing and verifying

circuits. DO NOT USE A TEST LIGHT, OR

“COMPUTER SAFE PROBE” as these can set o󰀨 air

bags or damage vehicle computers.

Use grommets when routing wires through metal

surfaces

BEFORE YOU BEGIN

4ca1045 rev B

6 Pin Input / Output Harness

5 Pin Main Harness

2 Pin Door Lock Output Harness

1WHITE/REDPARKING LIGHT INPUT

2WHITE PARKING LIGHT OUTPUT

3BLACKGROUND

4BROWNSIREN / HORN OUTPUT

5REDBATTERY 12V ( + )

5 PIN MAIN

1PURPLE DOOR TRIGGER INPUT ( + )

2BLUE TRUNK PIN INPUT ( - )

3GREEN DOOR TRIGGER INPUT ( - )

4YELLOWIGNITION INPUT ( + )

5ORANGE GROUND WHEN ARMED OUTPUT ( - )

6RED/WHITETRUNK RELEASE OUTPUT ( - )

6 PIN INPUT / OUTPUT

1BLUE UNLOCK ( - )

2GREEN LOCK ( - )

2 PI

LOCK

3 BLACK GROUND

Connect the BLACK wire to a solid chassis ground point using a ring terminal and

self tapping screw (not supplied). Scrape away paint from the grounding point to

ensure a good connection. The recommended grounding point is a metal surface in

the driver’s side kick panel area.

NOTE: Do not ground the BLACK wire with any other vehicle components.

5 Pin Main Harness

1 WHITE/RED PARKING LIGHT INPUT

2 WHITE PARKING LIGHT OUTPUT

Locate the parking light output wire at the vehicle’s light switch.

  Verication: This wire registers positive voltage when the parking lights

are turned on.

Positive switching Parking Lights:

Connect the WHITE/RED wire to a 15 Amp max fused battery source.

Connect the WHITE wire to the parking light output wire.

Negative switching Parking Lights:

Connect the WHITE/RED wire to a good chassis ground.

Connect the WHITE wire to the parking light output wire.

4 BROWN SIREN / HORN OUTPUT

This output is available to be used as a constant ( + ) siren output OR a pulsed

( - ) horn output and is selectable by changing the jumper position on the main

module. Refer to the system layout on page 22 for location.

SIREN:

Connect the BLACK siren wire to a chassis ground using a ring terminal and self

tapping screw (not supplied).

Route the BROWN siren output wire from the control module through the rewall and

connect to the RED wire on the siren.

NOTE: Be sure to loom the siren wires, and seal the grommet.

6ca1045 rev B

5 RED BATTERY 12V ( + )

Locate 1 of the vehicle’s constant 12 Volt battery wires at the ignition switch.

 Verication:This wire will register ( + ) voltage in all positions of the

ignition switch.

Connect the RED wire to the constant 12 Volt battery wire.

NOTE: Remove all fuses until all connections are made.

6 Pin Input / Output Harness

1 PURPLE DOOR TRIGGER INPUT ( + )

Locate the vehicle’s dome light or door pin switch wire.

 Verication:This wire will register positive voltage (POS) when the door is

opened and the interior light is on. This wire will

o󰀨.

Connect the PURPLE wire to the vehicle’s positive door input wire(s).

NOTE: Certain vehicles may require multiple connections. Refer to vehicle

application guide

2 BLUE TRUNK PIN INPUT ( - )

Locate the vehicle’s trunk pin switch wire and connect to the BLUE wire.

 Verication:This wire when connected will register ground when the

vehicle’s trunk is opened.

Connect the BLUE wire to the trunk pin.

HORN:

Locate the vehicle’s horn wire.

 Verication:This wire will register at positive voltage and register

ground when the horn switch is pressed.

Connect the BROWN wire to the vehicle’s horn wire. This is a low current output,

300mA.

5 ORANGE GROUND WHEN ARMED OUTPUT ( - )

This wire will have a continuous ( - ) 500mA output when the system is Armed. This

wire is typically used for controlling window modules or additional sensors.

4 YELLOW IGNITION INPUT ( + )

Locate the vehicle’s ignition wire at the ignition switch.

  Verication:This wire registers voltage when the key is turned to the ON (or

RUN) position. The voltage does not drop out when the key is turned to the

START (or CRANK) position.

Connect the YELLOW wire to the vehicle’s Ignition wire.

6 RED/WHITE TRUNK RELEASE OUTPUT ( - )

Locate the vehicle’s trunk release wire at the trunk release switch.

 Verication:This wire will register either positive voltage or ground when

the trunk release is activated.

This is a low current output, 200mA.

3 GREEN DOOR TRIGGER INPUT ( - )

Locate the vehicle’s dome light or door pin switch wire.

 Verication:This wire will register ground (NEG) when the door is opened

and the interior light is on. This wire will register positive voltage when the

door is closed and the interior light is o󰀨.

Connect the GREEN wire to the vehicle’s negative door input wire(s).

NOTE: Certain vehicles may require multiple connections. Refer to vehicle

application guide

8ca1045 rev B

2 Pin Lock Output Harness

1 BLUE UNLOCK ( - )

2 GREEN LOCK ( - )

The door lock / unlock outputs are designed to control several di󰀨erent types of

systems which may require additional parts. Please review the wire and location

chart to see which type of door lock system is in your vehicle. The most common

types are shown in the following diagrams.

Negative Switching Locks

All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock

switch.

  Verication: These wires will register ground when the Lock and Unlock

switches are activated.

Connect the GREEN and BLUE wires shown in the diagram below.

Lock

Unlock

Vehicle Door Lock

Control Relays

GREEN ( - ) Lock Output

BLUE ( - ) Unlock Output

Negative Locks:

Positive Switching Locks

All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock

switch.

  Verication: These wires will register positive voltage when the Lock and

Unlock switches are activated.

Connect the GREEN and BLUE wires shown in the diagram below.

Reverse Polarity Locks (5-Wire Door locks)

All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock

switch.

  Verication: These wires will rest at ground and register positive

voltage when the Lock and Unlock switches are activated.

Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram below

using (2) SPDT relays (not supplied).

Lock

Unlock

87a

86 85

87a

86 85

Fused +12 Volt

Battery Souce

Fused +12 Volt

Battery Souce

GREEN ( - ) Lock Output

BLUE ( - ) Unlock Output

Reverse Polarity Locks:

Cut

To Door Lock Motor

Lock

Unlock

87a

86 85

87a

86 85

Vehicle Door Lock

Control Relays

Fused +12 Volt

Battery Souce

Fused +12 Volt

Battery Souce

GREEN ( - ) Lock Output

BLUE ( - ) Unlock Output

Positive Locks:

10 ca1045 rev B

Negative Multiplexed Locks

All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock

switch.

  Verication: This wire will show variable ground when the switch is activated.

Please consult the wire and location chart for specic resistor values for

your vehicle.

Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram below

using (2) SPDT relays (not supplied).

Positive Multiplexed Locks

All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock

switch.

  Verication: This wire will show variable positive voltage when the switch is

activated. Please consult the wire and location chart for specic resistor

values for your vehicle.

Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram below

using (2) SPDT relays (not supplied).

Lock

Unlock

Vehicle Door Lock

Control Relays

GREEN ( - ) Lock Output BLUE ( - ) Unlock Output

Multiplex Locks:

87a

85 85

Fused +12 Volt

Battery Source

Resistor

Lock

Unlock

Vehicle Door Lock

Control Relays

GREEN ( - ) Lock Output BLUE ( - ) Unlock Output

Multiplex Locks:

87a

85 85

Fused +12 Volt

Battery Source

Ground

Resistor

Autres manuels pour PROFESSIONAL SERIES

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Code Alarm Démarreur à distance

Code Alarm

Code Alarm ca4054 Manuel utilisateur

Code Alarm

Code Alarm ca 4552 Manuel utilisateur

Code Alarm

Code Alarm CA-500 Manuel utilisateur

Code Alarm

Code Alarm PROFESSIONAL CASECRS Manuel utilisateur

Code Alarm

Code Alarm CA2LCD5 Manuel utilisateur

Code Alarm

Code Alarm CA 5055 Manuel utilisateur

Code Alarm

Code Alarm ca5554 Professional series Manuel utilisateur

Code Alarm

Code Alarm CA-520 Manuel utilisateur

Code Alarm

Code Alarm PROFESSIONAL SERIES Manuel utilisateur

Code Alarm

Code Alarm CA 5150 Manuel utilisateur

Code Alarm

Code Alarm ca 4552 Manuel utilisateur

Code Alarm

Code Alarm PROFESSIONAL SERIES Manuel utilisateur

Code Alarm

Code Alarm CA 5150 Manuel utilisateur

Code Alarm

Code Alarm CA 410A Manuel utilisateur

Code Alarm

Code Alarm CA-630 Manuel utilisateur

Code Alarm

Code Alarm Professional Series CA6555 Manuel utilisateur

Code Alarm

Code Alarm CA 411 Manuel utilisateur

Code Alarm

Code Alarm Professional Series CA 5050 Manuel utilisateur

Code Alarm

Code Alarm CA 440SS Manuel utilisateur

Code Alarm

Code Alarm Professional Series CA 6550 Manuel utilisateur

Code Alarm

Code Alarm ca 2051 Manuel utilisateur

Code Alarm

Code Alarm ca5154 professional Series Manuel utilisateur

Code Alarm

Code Alarm Professional Series CA 1050 Manuel utilisateur

Code Alarm

Code Alarm SRT 9000 Manuel utilisateur

Manuels Démarreur à distance populaires d'autres marques

AstroStart

AstroStart 803U Manuel utilisateur

Durite

Durite 0-649-20 Manuel

EINHELL

EINHELL BT-PS 1000 Manuel

Linear

Linear ACCESS AK-21 Caractéristiques techniques

Soundstream

Soundstream TARANTULA RS.2 Manuel utilisateur

Jaycar Electronics

Jaycar Electronics MB3752 Manuel utilisateur

Ultra Start

Ultra Start 72 Series Manuel utilisateur

ADS

ADS FLASHLOGIC FLRSVW1 Manuel utilisateur

Selecta

Selecta JS012 Manuel utilisateur

Black Widow Security

Black Widow Security BW RAS 400 Manuel utilisateur

Vector

Vector Power City DK080706 Supplément

Ozito

Ozito OJS-800 Manuel utilisateur

Profi-Partner

Profi-Partner 46387 Manuel utilisateur

EZ STARTER

EZ STARTER EZ-45 Manuel utilisateur

Viper

Viper 4204 Manuel utilisateur

Essex Electronics

Essex Electronics KE-1701 Manuel utilisateur

EINHELL

EINHELL EGS 3600 Manuel

Rooboost

Rooboost RB-1750WP Manuel utilisateur
