Code Alarm Ca 1051 Manuel utilisateur

1ca1051revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

PROFESSIONAL

SERIES

Security and Keyless Entry

Installation Guide

ca 1051

2 ca1051revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

Before You Begin ......................................................................................3

Wire Connection Guide ...........................................................................4

5 Pin Main Harness ...................................................................................5

6 Pin Input / Output Harness ....................................................................6

2 Pin Door Lock Output Harness .............................................................8

Additional Ports ......................................................................................12

LEDPort...................................................................................................12

ProgrammingPort....................................................................................12

On-Board Shock Sensor ........................................................................12

Set Up & Programming..........................................................................13

Transmitter Programming........................................................................13

Manual Feature Programming.................................................................13

Programming Feature Banks ..................................................................14

Chirp Delete - User Accessible..............................................................15

Dome Light Delay / Theater Dimming .....................................................15

Feature Descriptions ............................................................................. 15

Transmitter Button Functions .............................................................17

Security Trigger Zones .........................................................................17

System Layout.........................................................................................18

Table of Contents

3ca1051revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

PROFESSIONALINSTALLATION

STRONGLYRECOMMENDED

Installation Precautions:

Roll down window to avoid locking keys in vehicle

during installation

Avoid mounting components or routing wires near

hot surfaces

Avoid mounting components or routing wires near

moving parts

Tape or loom wires under hood for protection and

appearance

Technical Support (800) 421-3209

or go to

http://techservices.codesystems.com

Use a Digital Multi Meter for testing and verifying

circuits. DO NOT USE A TEST LIGHT, OR

"COMPUTER SAFE PROBE" as these can set off air

bags or damage vehicle computers.

Use grommets when routing wires through metal

surfaces

BEFORE YOU BEGIN

4 ca1051revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

6 Pin Input / Output Harness

5 Pin Main Harness

2 Pin Door Lock Output Harness

5ca1051revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

3 BLACK GROUND

Connect the BLACK wire to a solid chassis ground point using a ring terminal and

self tapping screw (not supplied). Scrape away paint from the grounding point to

ensure a good connection. The recommended grounding point is a metal surface

in the driver’s side kick panel area.

NOTE: Do not ground the BLACK wire with any other vehicle components.

5 Pin Main Harness

1 WHITE/RED PARKINGLIGHTINPUT

2 WHITE PARKINGLIGHTOUTPUT

Locate the parking light output wire at the vehicle’s light switch.

Verification: This wire registers positive voltage when the parking lights

are turned on.

Positive switching Parking Lights:

Connect the WHITE/RED wire to a 15 Amp max fused battery source.

Connect the WHITE wire to the parking light output wire.

Negative switching Parking Lights:

Connect the WHITE/RED wire to a good chassis ground.

Connect the WHITE wire to the parking light output wire.

4 BROWN SIREN/HORNOUTPUT

This output is available to be used as a constant ( + ) siren output OR a pulsed

( - ) horn output and is selectable by changing the jumper position on the main

module. Refer to the system layout on page 18 for location.

SIREN:

Connect the BLACK siren wire to a chassis ground using a ring terminal and self

tapping screw (not supplied).

Route the BROWN siren output wire from the control module through the firewall

and connect to the RED wire on the siren.

NOTE: Be sure to loom the siren wires, and seal the grommet.

6 ca1051revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

5 RED BATTERY 12V ( + )

Locate 1 of the vehicle’s constant 12 Volt battery wires at the ignition switch.

Verification: This wire will register ( + ) voltage in all positions of the

ignition switch.

Connect the RED wire to the constant 12 Volt battery wire.

NOTE: Remove all fuses until all connections are made.

6 Pin Input / Output Harness

1 PURPLE DOORTRIGGERINPUT( +)

Locate the vehicle’s dome light or door pin switch wire.

Verification: This wire will register positive voltage (POS) when the door is

opened and the interior light is on. This wire will

off.

Connect the PURPLE wire to the vehicle’s positive door input wire(s).

NOTE: Certain vehicles may require multiple connections. Refer to vehicle

application guide

2 BLUE TRUNKPININPUT (-)

Locate the vehicle’s trunk pin switch wire and connect to the BLUE wire.

Verification: This wire when connected will register ground when the

vehicle's trunk is opened.

Connect the BLUE wire to the trunk pin.

HORN:

Locate the vehicle’s horn wire.

Verification: This wire will register at positive voltage and register

ground when the horn switch is pressed.

Connect the BROWN wire to the vehicle’s horn wire. This is a low current output,

300mA.

7ca1051revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

5 ORANGE GROUNDWHENARMEDOUTPUT(- )

This wire will have a continuous ( - ) 500mA output when the system is Armed. This

wire is typically used for controlling window modules or additional sensors.

4 YELLOW IGNITIONINPUT(+)

Locate the vehicle’s ignition wire at the ignition switch.

Verification: This wire registers voltage when the key is turned to the ON (or

RUN) position. The voltage does not drop out when the key is turned to the

START(or CRANK) position.

Connect the YELLOW wire to the vehicle’s Ignition wire.

6 RED/WHITE TRUNKRELEASE OUTPUT(- )

Locate the vehicle’s trunk release wire at the trunk release switch.

Verification: This wire will register either positive voltage or ground when

the trunk release is activated.

This is a low current output, 200mA.

3 GREEN DOORTRIGGERINPUT (- )

Locate the vehicle’s dome light or door pin switch wire.

Verification: This wire will register ground (NEG) when the door is opened

and the interior light is on. This wire will register positive voltage when the

door is closed and the interior light is off.

Connect the GREEN wire to the vehicle’s negative door input wire(s).

NOTE: Certain vehicles may require multiple connections. Refer to vehicle

application guide

8 ca1051revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

2 Pin Lock Output Harness

1 BLUE UNLOCK ( - )

2 GREEN LOCK ( - )

The door lock / unlock outputs are designed to control several different types of

systems which may require additional parts. Please review the wire and location

chart to see which type of door lock system is in your vehicle. The most common

types are shown in the following diagrams.

Negative Switching Locks

All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock /

unlock switch.

Verification: These wires will register ground when the Lock and Unlock

switches are activated.

Connect the GREEN and BLUE wires shown in the diagram below.

Lock

Unlock

Vehicle Door Lock

Control Relays

GREEN (-) Lock Output

BLUE (-) Unlock Output

Negative Locks:

9ca1051revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

Positive Switching Locks

All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock /

unlock switch.

Verification: These wires will register positive voltage when the Lock and

Unlock switches are activated.

Connect the GREEN and BLUE wires shown in the diagram below.

Lock

Unlock

87a

86 85

87a

86 85

Vehicle Door Lock

Control Relays

Fused +12 Volt

Battery Souce

Fused +12 Volt

Battery Souce

GREEN (-) Lock Output

BLUE (-) Unlock Output

Positive Locks:

Reverse Polarity Locks (5-Wire Door locks)

All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock /

unlock switch.

Verification: These wires will rest at ground and register positive

voltage when the Lock and Unlock switches are activated.

Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram

below using (2) SPDT relays (not supplied).

Lock

Unlock

87a

86 85

87a

86 85

Fused +12 Volt

Battery Souce

Fused +12 Volt

Battery Souce

GREEN (-) Lock Output

BLUE (-) Unlock Output

Reverse Polarity Locks:

Cut

To Door Lock Motor

10 ca1051revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

Negative Multiplexed Locks

All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock /

unlock switch.

Verification: This wire will show variable ground when the switch is activated.

Please consult the wire and location chart for specific resistor values for

your vehicle.

Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram

below using (2) SPDT relays (not supplied).

Lock

Unlock

Vehicle Door Lock

Control Relays

GREEN (-) Lock Output BLUE (-) Unlock Output

Multiplex Locks:

87a

85 85

Fused +12 Volt

Battery Source

Ground

Resistor

Positive Multiplexed Locks

All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock /

unlock switch.

Verification: This wire will show variable positive voltage when the switch is

activated. Please consult the wire and location chart for specific resistor

values for your vehicle.

Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram

below using (2) SPDT relays (not supplied).

Lock

Unlock

Vehicle Door Lock

Control Relays

GREEN (-) Lock Output BLUE (-) Unlock Output

Multiplex Locks:

87a

85 85

Fused +12 Volt

Battery Source

Resistor

Autres manuels pour ca 1051

Table des matières

Autres manuels Code Alarm Démarreur à distance

Code Alarm

Code Alarm ca4054 Manuel utilisateur

Code Alarm

Code Alarm ca 4552 Manuel utilisateur

Code Alarm

Code Alarm F30 Manuel utilisateur

Code Alarm

Code Alarm CA 5150 Manuel utilisateur

Code Alarm

Code Alarm ca5554 Professional series Manuel utilisateur

Code Alarm

Code Alarm Professional Series CA 6550 Manuel utilisateur

Code Alarm

Code Alarm Professional ca5054 Manuel utilisateur

Code Alarm

Code Alarm PROFESSIONAL SERIES Manuel utilisateur

Code Alarm

Code Alarm CA 421 Manuel utilisateur

Code Alarm

Code Alarm ca4053 Manuel utilisateur

Code Alarm

Code Alarm CA 4051 Manuel utilisateur

Code Alarm

Code Alarm CA 5150 Manuel utilisateur

Code Alarm

Code Alarm ca6553 Manuel utilisateur

Code Alarm

Code Alarm ca5554 Professional series Manuel utilisateur

Code Alarm

Code Alarm CA 5051MT Manuel utilisateur

Code Alarm

Code Alarm CA611 Manuel utilisateur

Code Alarm

Code Alarm PC 4400 Manuel utilisateur

Code Alarm

Code Alarm SRT 6700 Manuel utilisateur

Code Alarm

Code Alarm Elite ca6555E Manuel utilisateur

Code Alarm

Code Alarm PROFESSIONAL SERIES Manuel utilisateur

Code Alarm

Code Alarm ca5554 Professional series Manuel utilisateur

Code Alarm

Code Alarm professional series PROCOMP Manuel utilisateur

Code Alarm

Code Alarm PC 4300 Manuel utilisateur

Code Alarm

Code Alarm ca5154 professional Series Manuel utilisateur

Manuels Démarreur à distance populaires d'autres marques

AstroStart

AstroStart 803U Manuel utilisateur

Durite

Durite 0-649-20 Manuel

EINHELL

EINHELL BT-PS 1000 Manuel

Linear

Linear ACCESS AK-21 Caractéristiques techniques

Soundstream

Soundstream TARANTULA RS.2 Manuel utilisateur

Jaycar Electronics

Jaycar Electronics MB3752 Manuel utilisateur

Ultra Start

Ultra Start 72 Series Manuel utilisateur

ADS

ADS FLASHLOGIC FLRSVW1 Manuel utilisateur

Selecta

Selecta JS012 Manuel utilisateur

Black Widow Security

Black Widow Security BW RAS 400 Manuel utilisateur

Vector

Vector Power City DK080706 Supplément

Ozito

Ozito OJS-800 Manuel utilisateur

Profi-Partner

Profi-Partner 46387 Manuel utilisateur

EZ STARTER

EZ STARTER EZ-45 Manuel utilisateur

Viper

Viper 4204 Manuel utilisateur

Essex Electronics

Essex Electronics KE-1701 Manuel utilisateur

EINHELL

EINHELL EGS 3600 Manuel

Rooboost

Rooboost RB-1750WP Manuel utilisateur

Code Alarm ca 1051 Manuel utilisateur

Manuels Démarreur à distance populaires d'autres marques
