Clifford Matrix 1 Manuel utilisateur

MMaattrriixx11

➤

OOwwnneerr’’ssGGuuiiddee

lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy

Directed Electronics, Inc. ("Directed®") promises to the original purchaser to repair or

replace with a comparable reconditioned model any Directed®unit (hereafter the "unit"),

excluding without limitation the siren, the remote transmitters, the associated sensors and

accessories, which proves to be defective in workmanship or material under reasonable use

during the lifetime of the vehicle provided the following conditions are met: the unit was

professionally installed and serviced by an authorized Directed®dealer; the unit will be

professionally reinstalled in the vehicle in which it was originally installed by an autho-

rized Directed®dealer; and the unit is returned to Directed®, shipping prepaid with a leg-

ible copy of the bill of sale or other dated proof of purchase bearing the following infor-

mation: consumer's name, telephone number and address; the authorized dealers name,

telephone number and address; complete product description, including accessories; the

year, make and model of the vehicle; vehicle license number and vehicle identification

number. All components other than the unit, including without limitation the siren, the

remote transmitters and the associated sensors and accessories, carry a one-year warranty

from the date of purchase of the same. This warranty is non-transferable and is automat-

ically void if: the original purchaser has not completed the warranty card and mailed it

within ten (10) days of the date of purchase to the address listed on the card; the unit's

date code or serial number is defaced, missing or altered; the unit has been modified or

used in a manner contrary to its intended purpose; the unit has been damaged by acci-

dent, unreasonable use, neglect, improper service, installation or other causes not arising

out of defects in materials or construction. The warranty does not cover damage to the

unit caused by installation or removal of the unit. Directed®, in its sole discretion, will

determine what constitutes excessive damage and may refuse the return of any unit with

excessive damage. TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUD-

ING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MER-

CHANTABILITY, FITNESS FOR PARTICULAR PURPOSE AND WARRANTY OF NON-INFRINGE-

MENT OF INTELLECTUAL PROPERTY, ARE EXPRESSLY EXCLUDED; AND Directed®NEITHER

ASSUMES NOR AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIG-

ATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS. DIRECTED®DISCLAIMS AND

HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS

AUTHORIZED DEALERS OR INSTALLERS. DIRECTED®SECURITY SYSTEMS, INCLUDING THIS

UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED®IS NOT OFFERING A GUAR-

ANTEE OR INSURANCE AGAINST VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS

PARTS OR CONTENTS; AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER,

INCLUDING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VANDALISM.

THIS WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE, REMOVAL OR REIN-

STALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT

OF A CLAIM OR A DISPUTE INVOLVING DIRECTED®OR ITS SUBSIDIARY, THE PROPER VENUE

SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND

APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM

RECOVERY UNDER ANY CLAIM AGAINST DIRECTED®SHALL BE STRICTLY LIMITED TO THE

AUTHORIZED DIRECTED®DEALER'S PURCHASE PRICE OF THE UNIT. DIRECTED®SHALL NOT

BE RESPONSIBLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY

CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME,

LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE.

NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER A LIMITED WARRAN-

TY TO REPLACE OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do

not allow limitations on how long an implied warranty will last or the exclusion or limi-

tation of incidental or consequential damages. This warranty gives you specific legal rights

and you may also have other rights that vary from State to State.

This product may be covered by an Anti-Theft Guarantee. See your authorized Directed®

dealer for details of the plan or call Directed®Customer Service at 1-800-876-0800.

Directed®security systems, including this unit, are deterrents against possible theft.

Directed®is not offering a guarantee or insurance against vandalism, damage or theft of

the automobile, its parts or contents; and hereby expressly disclaims any liability whatso-

ever, including without limitation, liability for theft, damage and/or vandalism. Directed®

does not and has not authorized any person or entity to create for it any other obligation,

promise, duty or obligation in connection with this security system.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

➤Date of purchase

➤Your full name and address

➤Authorized dealer's company name and address

➤Type of alarm installed

➤Year, make, model and color of the automobile

➤Automobile license number

➤Vehicle identification number

➤All security options installed on automobile

➤Installation receipts

ttrraaddeemmaarrkkssaannddccooppyyrriigghhttss

Bitwriter™, Clifford®, Code-Hopping™, DEI®, Directed®, Doubleguard®, ESP™, FailSafe®,

Ghost Switch™, Learn Routine™, Nite-Lite®, Nuisance Prevention Circuitry®, NPC®,

Revenger®, Silent Mode™, Soft Chirp®, Stealth Coding™, Stinger®, Valet®, Vehicle

Recovery System®, VRS®, and Warn Away®are all Trademarks or Registered Trademarks

of Directed Electronics, Inc.

ttaabblleeooffccoonntteennttss

LLiimmiitteeddLLiiffeettiimmeeCCoonnssuummeerrWWaarrrraannttyy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i

WWhhaattIIssIInncclluuddeedd. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

IImmppoorrttaannttIInnffoorrmmaattiioonn. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Your Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

FCC/ID Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

TTrraannssmmiitttteerrFFuunnccttiioonnss. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Standard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

UUssiinnggYYoouurrSSyysstteemm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Multi-Level Security Arming (Optional Feature) . . . . . . . . . . . . . . . . . . . . . . . . 7

Arming While Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Siren Silencing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Disarming Without a Transmitter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Remote Controlled Chirp Muting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Panic Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Valet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Remote Controlled Valet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

False Alarm Control Technology (FACT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

DDiiaaggnnoossttiiccss. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Arming Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Disarming Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Table of Zones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

AAnnttii-CCooddeeGGrraabbbbiinngg((AACCGG)). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

HHiigghhFFrreeqquueennccyy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

OOwwnneerrRReeccooggnniittiioonn. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

SSmmaarrttPPoowweerrUUppIIII. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

PPoowweerrSSaavveerrMMooddee. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

PPrrooggrraammmmiinnggOOppttiioonnss. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

IInnssttaallllaattiioonnOOppttiioonnss. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

VVeehhiicclleeRReeccoovveerryySSyysstteemm((VVRRSS)). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Arming the VRS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

VRS Triggered Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Disarming the VRS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

GGlloossssaarryyOOffTTeerrmmss. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

SSeeccuurriittyy&&CCoonnvveenniieenncceeEExxppaannssiioonnss. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

QQuuiicckkRReeffeerreenncceeGGuuiiddee((RReemmoovvaabbllee)). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

wwhhaattiissiinncclluuddeedd

➤➤A control module

➤➤A pair of 3-button transmitters

➤➤An XHF receiver/antenna

➤➤A shock sensor (on-board the alarm module)

➤➤A siren

➤➤A red LED status indicator light

➤➤A push-button Valet switch

➤➤Your warranty registration

➤➤Fault-proof starter interrupt ready circuitry (may require

additional labor)

iimmppoorrttaannttiinnffoorrmmaattiioonn

Congratulations on the purchase of your state-of-the-art vehicle

security system. It has been designed to provide years of trouble-

free operation. This system must be installed by an authorized

dealer. Installation of this product by anyone other than an

authorized dealer voids the warranty. As verification of

authorization, all authorized dealers are provided with

preprinted dealer certificates.

In order to maximize the use of this system, please review this

owner's guide carefully prior to using your system. You can print

additional or replacement copies of this owner’s guide by

accessing the Clifford website at www.clifford.com.

system maintenance

The system requires no specific maintenance. Your remote

control is powered by a miniature 3V lithium battery that will

last approximately one year under normal use. When the battery

weakens, operating range will be reduced and the LED on the

remote will dim.

your warranty

Your warranty registration must be completely filled out and

returned within 10 days of purchase. Your product warranty

will not be validated if your warranty registration is not returned.

Make sure you receive the warranty registration from your

dealer. It is also necessary to keep your proof of purchase, which

reflects that the product was installed by an authorized dealer.

fcc/id notice

This device complies with Part 15 of FCC rules. Operation is

subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) This device must accept any

interference received, including interference that may cause

undesired operation.

Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to

operate this device.

➜

ttrraannssmmiitttteerrffuunnccttiioonnss

The receiver uses computer-based code learning to learn the

transmitter buttons. This makes it possible to assign any trans-

mitter button to any receiver function. The transmitter initially

comes programmed with standard configuration, but may also

be customized by an authorized dealer. The buttons in all of the

instructions in this manual correspond to a standard configuration

transmitter.

standard configuration

Button

The arming, disarming and panic function are usually controlled

by this button.

Button

Remote Controlled Chirp Muting and an optional accessory

function are controlled by . (Remote Controlled Chirp

Muting works by pressing for less than one second before

arming or disarming the system. An optional accessory function,

such as trunk release, can be controlled by pressing for 1.5

seconds.) This accessory output controls __________________.

Button

An optional accessory convenience or expansion function that

you have added to your system can be activated by pressing

. This accessory output controls ___________________.

➜

uussiinnggyyoouurrssyysstteemm

The buttons used in the instructions in this manual correspond

to the standard transmitter configuration. If your transmitter has

been custom configured, the icons on your transmitter buttons

may not correspond to the indicated functions.

arming

You can activate, or arm, the system by pressing on your

transmitter for one second. When the system arms, you will hear

a short siren sound, or chirp, and see the parking lights flash

once. If the vehicle’s power door locks have been connected to the

system, the doors will lock.

While the system is armed, the LED status indicator will flash

approximately once per second, showing that the system is

actively protecting your vehicle. If you hear a second chirp after

arming, and see the LED status indicator flashing in groups, refer

to the Diagnostics section of this guide. This extra chirp is called

Bypass Notification.

The security system also can be programmed to arm itself

automatically (called passive arming). If the system is

programmed for passive arming, it will automatically arm 30

seconds after the ignition is turned off and the system "sees" you

leave the vehicle by opening and closing a door. Whenever the

system is in its 30-second passive-arming countdown, the LED

status indicator will flash twice as fast as it does when the system

➜

is armed. The siren will chirp once 20 seconds after the last door

has been closed. The system is not actually armed at that point.

The system arms and the doors lock (if connected and

programmed for passive locking) at 30 seconds, but the siren will

not chirp. The early chirp provides you with a 10-second

warning prior to arming.

When armed, your vehicle is protected as follows:

➤➤Light impacts will trigger the Warning Zone signal. When

triggered, the siren will chirp and the parking lights will flash

for a few seconds.

➤➤Heavy impacts will trigger the system. The triggered

sequence is between 1-180 seconds of constant siren and

flashing parking lights.

➤➤If a door is opened, the system will immediately start

chirping the siren and flashing the parking lights. Three

seconds later, the siren output changes to a continuous blast.

This progressive response gives you time to disarm the sys-

tem with your transmitter if you inadvertently open the door

while the system is armed, while still providing an instant

response (even if the door is immediately closed).

note: If any protected entry point (such as a door or a switch-

protected trunk or hood) is open, the system will not

passively arm (unless forced passive arming is programmed

on.) See Programming Options section of this guide.

Additionally, each time a sensor is triggered during the

arming countdown, the 30-second countdown starts over.

➤➤Turning on the ignition key will trip the same two-stage

response as opening a door.

➤➤The optional starter interrupt prevents the vehicle’s starter

from cranking.

multi-level security arming (optional feature)

Multi-Level Security Arming allows you to select which of the

security system's inputs or sensors will be active and which will

be bypassed at the time that the system is armed. (See Table of

Zones section.) Pressing the arm button again within five seconds

of arming the security system will activate the Multi-Level

Security Arming feature. Each time the arm button is pressed

again, a different security level is selected. The different security

levels can be selected as follows:

➤➤Pressing the arm button one time: The siren chirps once. The

system is armed.

➤➤Pressing the arm button a second time within five seconds:

The siren chirps twice followed by a long chirp. Zone Two is

now bypassed.

➤➤Pressing the arm button a third time within five seconds: The

siren chirps three times followed by a long chirp. Zone Four

is now bypassed.

note: Multi-Level Security Arming is only available when

using an optional 4-button Radar Master transmitter that

has been configured with separate transmitter buttons for

arming and disarming.

➜

Autres manuels pour Matrix 1

Table des matières

Autres manuels Clifford Alarme de voiture

Clifford

Clifford Nova 3 Manuel utilisateur

Clifford

Clifford Arrow 5.1 Manuel utilisateur

Clifford

Clifford Model RSX1.2 Manuel utilisateur

Clifford

Clifford Centurion Manuel utilisateur

Clifford

Clifford SmartWindows 4 Manuel utilisateur

Clifford

Clifford AvantGuard 5.1 Manuel utilisateur

Clifford

Clifford concept 50 Manuel utilisateur

Clifford

Clifford intelliguard 900-IQ Manuel utilisateur

Clifford

Clifford Wireless Immobilizer XL 500 Manuel utilisateur

Clifford

Clifford AvantGuard 2 Manuel utilisateur

Clifford

Clifford Concept 40 Manuel utilisateur

Clifford

Clifford IntelliGuard 9000 Manuel utilisateur

Clifford

Clifford Concept 100 Manuel utilisateur

Clifford

Clifford 590.4X Manuel utilisateur

Clifford

Clifford Virtual Key 2UK Manuel utilisateur

Clifford

Clifford 520.4X Manuel utilisateur

Clifford

Clifford Concept 650 Manuel utilisateur

Clifford

Clifford RS1.1L Manuel utilisateur

Clifford

Clifford SE 2020 Special Edition Manuel utilisateur

Clifford

Clifford Matrix 10.2X Manuel utilisateur

Clifford

Clifford AVANTGUARD 5 Manuel utilisateur

Clifford

Clifford Concept 200 Manuel utilisateur

Clifford

Clifford Matrix RS2 Manuel utilisateur

Clifford

Clifford 4105X Manuel utilisateur

Manuels Alarme de voiture populaires d'autres marques

Ultra Start

Ultra Start 2500M SERIES Manuel utilisateur

Ultra Start

Ultra Start 650 Series Manuel utilisateur

Audiovox

Audiovox Prestige Platinum+ APS-511C Manuel utilisateur

Sparkrite

Sparkrite SRA8 Manuel utilisateur

Viper

Viper 4708V Manuel utilisateur

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manuel

Falcon

Falcon Predator XL3 Guide de l'utilisateur

Audiovox

Audiovox Auto Security XR91 Mode d'emploi

CrimeStopper

CrimeStopper CS-8717 Guide de démarrage rapide

Ultra Start

Ultra Start 450 SERIES Manuel utilisateur

Scytek electronic

Scytek electronic Vectra X3 Manuel utilisateur

Excalibur

Excalibur AL-1860-EDPB Manuel utilisateur

Gemini

Gemini 7057 Manuel utilisateur

FlashLogic

FlashLogic FLRSBA PRESTIGE Manuel utilisateur

Magicar

Magicar FAI-440 Manuel utilisateur

Viper

Viper 560XV Manuel utilisateur

SECO-LARM

SECO-LARM 300C Manuel utilisateur

Python

Python 660XP Manuel utilisateur
