Outdoor IP-rated xtures
CLF products are applied to ocial classied IP norm levels. For this product the IP rate is IP65 when using the covers for the chassis
parts. IP65 means according classied norm: shielded against dust and pressurized water from any side. Typical use for outdoor rated
stage events with normal weather acceptance. So no heavy rain, because then the water pressure over exceeds the IP norm.
Condensation/moisture inside housing
Because of high humidity levels during production condensation can occur inside the housing. This is mostly visible on the coldest parts of
the xture, like the front glass or display. To prevent this problem we work with special conditioned areas for outdoor xtures. Because of
the breathing air valves it is still possible to get humidity inside the xture. This will evaporate slowly. Do not put wet xtures in a ightcase,
this will help humidity enter the xture.
Fixtures temperature specication
Make sure the xture is used within its working temperature range. Outside this range we cannot guarantee correct operation.
Temporary usage:
Stage event equipment is designed for temporary outdoor use. Materials are not designed for long-term exposure to heavy weather
conditions. Rubber covers will be negatively aected by long-term UV exposure and should be checked by qualied service technicians
over time. Tightening screws too hard will negatively aect the IP-rating.
solid object Moisture
12345678
IP
Ingress
Protection
65
Protected against a solid object greater
than 50mm such as a hand.
Protected against a solid object greater
than 12.5mm such as a finger.
Protected against a solid object greater
than 2.5mm such as a screwdriver.
Protected against a solid object greater
than 1mm such as a wire.
Dust protected. Limited ingress of
dust permitted. Will not interfere
with operation of the equipment.
Dust tight. No ingress of dust.
Protected against vertical falling drops of
water. Limited ingress permitted.
Protected against water splashes from
all directions. Limited ingress permitted.
Protected against vertical falling drops
of water with enclosure tilted up to 15
degrees from the vertical. Limited
ingress permitted.
Protected against sprays of water up
to 60 degrees from the vertical.
Limited ingress permitted.
Protected against jets of water.
Limited ingress permitted.
Protected against powerful jets of water.
Limited ingress permitted.
Protected against the effects of
immersion in water between 15cm and
1m for 30 minutes.
Protected against the effects of
immersion in water under pressure for
long periods.
123456
