Classe Audio 100-A Manuel utilisateur

CLASSÉ AUDIO

100-A

POWER AMPLIFIER

100-A

OWNER'S MANUAL

CLASSÉ DESIGN PHILOSOPHY

1. REPEATED LISTENING DESIGN SESSIONS:

Fine tuning of sound by exchanging and mixing of parts (transistors, capacitors, wiring, PCB boards

etc.), and adjusting many specific operating voltages within proper engineering ranges, producing an

overall sonic recipe giving the most natural harmonic realism of music typical of instruments in a

live performance.

2. UPGRADABLE SINGLE CIRCUIT DESIGNS:

All Classé products (all preamps and all amps) share exactly the same circuit design philosophy

(excluding moving coil and moving magnet phono circuits). This means all amplifiers and all high

level circuits of the preamps benefit from the same design goals. Similar circuits are then tailored to

different power levels etc. Differences between less expensive models and more expensive models

are parts quality and compliment, power supply extravagance and the amount of filtering etc., as

well as features and packaging.

This means that for years Classé has been constantly sonically fine tuning and technically upgrading

this circuit design and its application, thus reaching a very high level of natural musical enjoyment,

as well as excellent reliability which benefits all models - least expensive, most expensive, preamps

and amplifiers alike.

3. EXTREME LONG LIFE IN REAL WORLD CONDITIONS:

Choosing the best attainable quality parts and materials combined with the advantages of the two

above-mentioned areas provides Classé owners with years of proven trouble free reliability and

musical enjoyment.

-3-

100-A

OWNER'S MANUAL

TABLE OF CONTENTS

UNPACKING & SET-UP.................................................... 4

GENERAL CONNECTIONS.............................................. 5

CONNECTIONS................................................................... 7

WARRANTY....................................................................... 8

SPECIFICATIONS............................................................... 10

WARRANTY REGISTRATION......................................... 11

NPACKING & SET-UP

Your CLASSÉ 100-A power amplifier is packed in high density, semi-rigid foam placed in a

special cardboard box. To remove the unit, open and spread all the top flaps of the box and by its sides,

lift out the entire unit and put it on a large flat surface. Take it out of the plastic bag and inspect the unit

for any concealed damage. Apart from this owner's manual, please ensure the following has also been

included:

1) Detachable linecord

2) Allen key for top plate

3) Nut driver for CLASSÉ output bolts

Please report any damage or missing parts to your dealer as soon as possible.

Place the 100-A at or near its final set-up position, allowing 8 inches at the rear for tightening the

speaker output connectors.

The power transformer in the 100-A is located at the front-center of the unit. Ideally, a few feet

should separate this area from components which potentially could pick up hum. These include

preamplifiers, turntables, and interconnect cables. In terms of providing adequate airspace for cooling, a

good rule of thumb is to allow 6 inches above and 3 inches on each side of the unit.

Check the Serial Number sticker on the back of the unit for the correct operating voltage. The

100-A has only one fuse, the rating of which should be as follows:

LINE VOLTAGE FUSE RATING

100 or 120 V.A.C. 8 AMP FAST BLOW 125 or 250 volts

220 or 240 V.A.C. 6 AMP FAST BLOW 250 volts

-4-

ENERAL CONNECTIONS

A.C. LINE

Making sure the power switch is in the off position; insert the linecord into the A.C. receptacle

on the rear of the unit.

CAUTION: SAFETY INSTRUCTIONS

DISCONNECT AC LINE CABLE WHILE MAKING ALL CONNECTIONS. "FLOATING THE GROUND”

OR DEFEATING THE GROUND ON A 3-PRONG LINECORD MAY CREATE A SHOCK HAZARD. CONNECT

ALL INTERCONNECT CABLES BETWEEN THE ELECTRONICS BEFORE CONNECTING THE A.C.

LINECORDS TO THE WALL OUTLETS. THIS WILL REDUCE THE POTENTIAL SHOCK HAZARD. SEE ALSO

THE 100-A WARRANTY SECTION OF THIS OWNER'S MANUAL.

STEREO

Check the setting on the STEREO/MONO toggle switch, located above the input jacks on the

back of the unit. The lever should be closest to the position marked STEREO.

Input and output connectors are clearly marked on the back of the amplifier. Left/Right

connections are oriented from the front of the unit. Stereo output connections are marked above the

connectors.

Use only high quality interconnect and loudspeaker cables, and make all connections tight. If the

input plugs are loose, remove them and pinch down the ground leaves slightly with pliers. Tighten the

output bolts with the nut driver supplied, placing the wire or lug between the washer and large chassis

nut. Observe correct phasing of the loudspeaker connections.

-5-

-6-

MONO

Firstly, please read through the previous Stereo section for general notes on securing good

connections, and safety tips. If the unit has been previously used in stereo, make sure it is OFF, and

remove all connections. The STEREO/MONO switch is located on the back panel above the input

jacks. The lever should be closest to the position marked MONO.

The MONO input is the left channel input, as marked. The unused right channel input is

automatically disconnected. The output connections are marked BELOW the connectors. (The MONO

positive is the left positive, the MONO negative is the right positive.)

Repeat the above MONO settings and connections on the second 100-A to be used for the other

channel.

Please remember that the negative output connection of a bridged amplifier is NOT a ground.

Do not use a "common ground" or switchbox set-up. Do not use with electronic crossovers which have

a common ground.

ONNECTIONS FOR REGULAR OR BALANCED INPUTS:

The CLASSÉ 100-A power amplifier is equipped with both regular and balanced inputs. Either

one may be used SEPARATELY BUT NOT SIMULTANEOUSLY. The balanced inputs must be connected to a

preamplifier which has balanced main outputs, and balanced interconnects with "XLR" connectors are

also required. Regardless of the amplifier inputs used, stereo or mono operation is still possible on the

100-A.

REGULAR INPUTS

The amplifier is factory set for REGULAR use. Connect the regular interconnects to the RCA input

jacks on the rear panel of the 100-A, and make sure the toggle switch lever is closest to the position

marked REGULAR. (The BALANCED "XLR" input connectors are automatically disable.).

BALANCED INPUTS

A balanced preamplifier and balanced interconnects are also required. For use with balanced

preamplifiers other than Classé, the wiring of the 3-pin XLR connectors must be matched to that of the

Classé 100-A which are wired as follows:

PIN 1: GROUND

PIN 2: POSITIVE (NON-INVERTED) SIGNAL

PIN 3: NEGATIVE (INVERTED) SIGNAL

If the pin configuration of the preamplifier differs from above, the balanced interconnects must be

modified to accommodate the different preamp.

Having confirmed the correct connections, plug the XLR connectors of the balanced

interconnects into the locking XLR connectors on the rear panel of the 100-A. (To remove the

connectors, press the tab above the connector.) Disconnect the 100-A from the A.C. line. Make sure the

toggle switch lever is switched from the REGULAR to the BALANCED position. This activates the

balanced inputs and disables the regular inputs.

-7-

LASSÉ 100-A LIMITED FACTORY WARRANTY (North America only).

Classé Audio Inc. warrants this amplifier to be free from defects in materials and

workmanship for a period ofFOURYEARS from the date of manufacture, provided that any claim in

virtue of this warranty be made in writing within such period.

Subject to all of the conditions stated herein,ALIMITEDFACTORYLIFETIMEWARRANTYISEXTENDEDONLY

TOTHEORIGINALOWNERWHOPURCHASEDTHEAMPLIFIERINNORTHAMERICAANDWHOCLAIMSUNDERTHISWARRANTYIN

NORTHAMERICA.

IMPORTANT:WARRANTYREGISTRATION,ANDACOPYOFTHE"AUTHORIZEDDEALERBILLOFSALE",MUSTBERECEIVED

ATTHECLASSÉFACTORY(addressbelow)WITHINTWENTY(20)DAYSOFPURCHASE,TOVALIDATETHISWARRANTY.

In the event of failure of this amplifier, resulting from defects in materials and workmanship,

Classé Audio Inc. will repair, recalibrate, or at its discretion, replace the unit providing that all the

conditions contained in this warranty are met.

In order to initiate service of any kind, it is necessary toOBTAINPRIORFACTORYAUTHORIZATION,AND

SHIPTHEUNITPREPAIDTOTHECLASSÉFACTORY. For units coming from outside Canada, contact the factory

for our forwarding address. Units shipped directly to our Canadian address from outside the country

will be stopped at the border, causing extensive delays or return of the unit to the sender.

The warranty shall be void and of no effect in the event of any of the following:

1) Operation not in accordance with this manual;

2) Accident, abuse, tampering, or unauthorized

modification, as determined by Classé Audio Inc.;

3) Removal, defacing, or falsifying the serial number plate;

4) Shipping without the complete factory packaging;

5) Transfer or sale of this amplifier by the original owner;

6) Non-compliance with any of the other conditions hereof.

CLASSÉAUDIOINC.SHALLNOTBELIABLEFORANYSPECIAL,INCIDENTAL,ORCONSEQUENTIALDAMAGESARISINGFROM

ORRELATINGTOTHESET-UP,OPERATION,FAILURE,TROUBLESHOOTING,ORREPAIROFTHEAMPLIFIERAND/ORANYOTHER

EQUIPMENTUSEDTHEREWITH.

THISWARRANTY,ALLCLAIMSMADEINVIRTUEHEREOF,ANDALLISSUESRELATINGTOANYSUCHCLAIMSHALLBE

GOVERNEDBYTHELAWSOFTHEPROVINCEOFQUÉBEC.

-8-

-9-

CLASSÉ 100-A

CLASS "A" STEREO/MONO POWER AMPLIFIER

FEATURES

AND

SPECIFICATIONS SHEET

100-A FEATURES:

100 watts stereo/400 watts mono, high Class "A" bias current, custom Classé curved heat sinks, rear

external switching for regular or balanced, and stereo or mono operation, thick curved faceplate with

sculpted one piece handles. Available in both Satin Black, and Soft Shadow Silver finishes.

100-A SPECIFICATIONS:

Frequency Response:

Sensitivity:

Input Impedance:

S/N Ratio:

Rated output:

8 Ohms:

4 Ohms:

2 Ohms:

Dimensions: Gross:

Net:

Weight: Gross:

Net:

20 Hz to 20 KHz +/- 0.1dB

1.10 Volt in for rated output

70 KOhms

More than 100 dB

Stereo Mono

100 400 Watts

200 800 Watts

400 - Watts

24 3/4" x 24 1/4" x 12 3/4"

19" x 17 1/4" x 7 1/4"

73 lbs

62 lbs

ARRANTY REGISTRATION

You must fill out and return the form below, along with a copy of the authorized dealer bill

of sale, to the factory within twenty (20) days of purchase. This will allow us to provide expedient

service, information regarding updates and new products, and validate the Classé warranty.

▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒

100-A SERIAL NUMBER_____________________PURCHASE DATE_____________________

AUTHORIZED DEALER________________________________________________________

PURCHASER'S NAME_________________________________________________________

STREET ADDRESS____________________________________________________________

CITY________________________________STATE/PROV.____________________________

COUNTRY________________________ZIP/POSTAL CODE__________________________

I BECAME AWARE OF THIS PRODUCT BY:_____________________________________

(DEALER, MAGAZINE, FRIEND, ETC.)

▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒▒

SEND TO: CLASSÉ AUDIO INC.

Product Registration

5070 François Cusson

Lachine, Quebec, Canada

H8T 1B3

-10-
