OPERATION & MAINTENANCE
INSTRUCTIONS
LS0613
½” IMPACT WRENCH SET
MODEL NO: CAT117
PART NO: 3110873
2
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
INTRODUCTION
Thank you for purchasing this CLARKE product.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
ENVIRONMENTAL PROTECTION
Recycle unwanted materials instead of disposing of them as
waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is
compatible with the environment.
SET CONTENTS
1 x Impact Wrench
10 x Impact Sockets: 9, 10, 11,13, 14, 17, 19, 22, 24 & 27 mm.
1 x 125mm (5") Extension Bar
1 x In-Line Oiler and 1 x Oil Bottle
1 x 4.0 mm Hexagon Key
1 x Air Inlet Adapter (PCL type)
3
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
GENERAL SAFETY RULES
WORK ENVIRONMENT
1. Keep the work area clean and tidy.
2. Dress appropriately - Do not wear loose clothing or jewellery. Tie long hair
out of the way.
3. Keep children and visitors away - Do not let children handle the impact
wrench.
4. Do not operate the impact wrench where there are flammable liquids or
gases.
5. Keep the air supply hose away from heat, oil and sharp edges.
6. Do not fit the impact wrench to any stand or clamping device that may
damage the tool.
USE
1. Stay alert and use common sense - Do not operate the impact wrench
when you are tired or under the influence of alcohol, drugs or medication.
2. Always wear eye protectors when using the impact wrench - Eye
protectors must provide protection from flying particles from the front and
the side.
3. Always wear ear protectors when using the impact wrench .
4. Do not overreach - Keep proper footing and balance at all times.
5. Never use any type of bottled gas as a source of power for the impact
wrench.
6. Do not connect the air supply hose with your finger on the trigger of the
impact wrench.
7. Do not exceed the maximum pressure for the impact wrench: 90 psi / 6.2
bar.
8. Check hoses for leaks or worn condition before use, and ensure that all
connections are secure.
9. Do not use the impact wrench for any other purpose than that described
in this book.
CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN
PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY.
4
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
10. Do not carry out any alterations or modifications to the impact wrench.
11. Always disconnect from the air supply when:
• Performing any maintenance
• The impact wrench is not in use.
• The impact wrench will be left unattended.
• Moving to another work area.
• Passing the impact wrench to another person.
12. Never use the impact wrench if it is defective or operating abnormally.
13. The impact wrench should be serviced at regular intervals by qualified
service personnel.
14. Avoid damaging the impact wrench for example by applying excessive
force of any kind.
15. ALWAYS maintain the tool with care. Keep it clean for the best and safest
performance.
16. Quick change couplings should not be located at the tool. They add
weight and could fail due to vibration.
17. DO NOT force or misuse the tool. It will do a better and safer job at the rate
for which it was designed.
18. Do not remove any labels. Damaged labels should be replaced.
19. This tool vibrates with use. Vibration may be harmful to your hands or arms.
Stop using the tool if discomfort, a tingling feeling or pain occurs. Seek
medical advice before resuming use.
20. NEVER use standard sockets. These may shatter with serious consequences.
Use ONLY impact sockets.
TRANSPORTATION
1. Never carry the impact wrench by the air supply hose.
2. Never carry the impact wrench with your finger on the trigger.
STORAGE
1. When not in use the impact wrench must be disconnected from the air
supply and stored in a dry place out of the reach of children (preferably in
a locked cabinet).
2. Avoid storing the impact wrench in environments where the temperature is
below 0oC.
5
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
OVERVIEW
NO DESCRIPTION NO DESCRIPTION
1 Anvil 5 1/4” BSP (Female Air Inlet)
2 Forward/Reverse button 6 Handle
3 Trigger 7 Oil Port
4 Speed Control
6
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
BEFORE USE
AIR SUPPLY
• Use only clean, dry, regulated compressed air as a power source for
the impact wrench.
• Air compressors used with the impact wrench must comply with the
appropriate European Community safety directives.
• A build up of moisture or oil in the air compressor will accelerate
wear and corrosion in the impact wrench.
• Never exceed the maximum operating pressure for the impact
wrench.
AIR HOSE
• The air hose must be rated at least 150% of the maximum operating
pressure of the tool.
RECOMMENDED AIR SUPPLY CONNECTION
WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU
ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF
COMPRESSORS AND COMPRESSED AIR SUPPLY.
7
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
BEFORE USE
NOTE: Ensure the compressor is turned off.
1. Remove the travel plug from the
1/4” BSP (Female Air Inlet) as
shown.
2. Fit the inline mini oiler.
• A mini oiler helps to prolong the
life of the impact wrench.
Remove the oil fill screw from
the side of the mini oiler and fill
with Air Line Oil available from
your CLARKE dealer. Replace
the screw before using the
impact wrench.
3. Connect a suitable hose as shown.
• Use the adapter supplied if
required.
4. Connect the other end of the hose
to the compressor.
5. Your impact wrench is now ready
for use.
You can fit a whip hose with a quick fit
coupling if required (available from
your Clarke dealer.)
WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU
ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF AIR
COMPRESSORS AND COMPRESSED AIR SUPPLY.
Oil Fill Screw
Mini Oiler
8
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
USING THE FORWARD/REVERSE BUTTON
The Forward/Reverse button should be used as follows.
1. For normal tightening, the impact wrench should be operated in the
forward (F) direction.
2. For loosening, the impact wrench should be operated in the reverse (R)
direction.
FITTING THE IMPACT SOCKET
1. Select the impact socket you
require.
2. Push the impact socket onto the
anvil as shown.
WARNING: WAIT UNTIL THE ANVIL HAS STOPPED ROTATING BEFORE
OPERATING THE FORWARD/REVERSE BUTTON.
WARNING: NEVER USE STANDARD SOCKETS. THESE MAY SHATTER WITH
SERIOUS CONSEQUENCES. ONLY USE IMPACT SOCKETS DESIGNED FOR
USE WITH IMPACT TOOLS.
FORWARD REVERSE
PUSH
9
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
OPERATION
ADJUSTING THE POWER
To adjust the power, set the air regulator
to one of the 4 settings available.
1 (Low) - 4 (High).
OPERATING THE IMPACT WRENCH
1. Locate the socket over the nut to
be tightened or loosened.
2. Squeeze the trigger to start the
wrench.
3. Release the trigger switch to stop
the wrench.
• The anvil will continue to rotate
briefly after the trigger has been
released.
DISCONNECTING THE AIR SUPPLY
Do not disconnect the air supply hose until the compressor has been shut
down and the compressed air released.
1. Refer to the compressor instruction manual for the procedure to shut down
and release the compressed air.
2. Once the pressure has been released, disconnect the air supply hose from
the impact wrench.
3. Store the impact wrench safely in its box in a dry, secure environment.
10
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
MAINTENANCE
DAILY
• Drain water from the air tank, air line and compressor.
• Pour a few drops of CLARKE air line oil, into the air inlet. This should be
carried out regardless of whether or not the inline mini oiler is used. If
the inline mini oiler is not used, this procedure should be repeated
after every two to three hours of use.
WEEKLY
• Check the air inlet screen filter and clean if necessary.
• Remove the grub screw and
insert a few drops of oil into the
oil port on the side of the
impact wrench.
CLEANING
• Keep the body of the impact
wrench clean and free from
debris. Grit or gum deposits in
the tool may reduce efficiency.
SERVICE AND REPAIR
• All servicing and repair must be carried out by qualified service
technicians.
NOTES
• Please note that factors other than the tool may effect its operation
and efficiency such as reduced compressor output, excessive drain
on the airline, moisture or restrictions in the line, or the use of
connectors of improper size or poor condition which will reduce air
supply.
• **Clarke Air Line Oil (part no. 3050825) is available from your CLARKE
dealer .
WARNING: MAKE SURE THAT THE IMPACT WRENCH IS DISCONNECTED
FROM THE AIR SUPPLY BEFORE STARTING ANY CLEANING, OR
MAINTENANCE PROCEDURES.
