OPERATION & MAINTENANCE

INSTRUCTIONS

ORIGINAL INSTRUCTIONS GC0618 iSS.1

INFRARED DIESEL HEATER

MODEL NO: DEVIL IRD40B

PART NO: 6920417

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

INTRODUCTION

Thank you for choosing this Clarke Infrared Heater. Before attempting to use

this product, please read this manual thoroughly and follow the instructions

carefully. In doing so you will ensure the safety of yourself and that of others

around you, and you can look forward to your heater giving you long and

satisfactory service.

Please keep these instructions in a safe place for future reference.

FUNCTION AND OPERATING PARAMETERS

This is a multi-fuel (Diesel or Paraffin), forced air heater. It’s intended use is for

drying and the warming of commercial/industrial buildings where adequate

ventilation is provided.

• It must be operated as prescribed in the operating manual.

• It is not intended to be used for domestic use or for the heating of

habitable areas.

• It is not intended to be used to reach and maintain a certain level of

human thermal comfort within an enclosed space in which the heater is

situated.

• It is not intended to be used in enclosed areas with restricted ventilation.

• It is not for use in areas with high levels of fluctuating drafts.

• It is not intended for warming animals or live stock.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt which will be

required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or

tampered with in any way, or not used for the purpose for which it was

intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission. This guarantee does not effect your

statutory rights.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

ENVIRONMENTAL RECYCLING POLICY

Through purchase of this product, the customer is taking on the

obligation to deal with the WEEE in accordance with the WEEE

regulations in relation to the treatment, recycling & recovery and

environmentally sound disposal of the WEEE.

In effect, this means that this product must not be disposed of with general

household waste. It must be disposed of according to the laws governing

Waste Electrical and Electronic Equipment (WEEE) at a recognised disposal

facility.

If disposing of this product or any damaged components, do not dispose of

with general waste. This product contains valuable raw materials. Metal

products should be taken to your local civic amenity site for recycling of metal

products.

TECHNICAL SPECIFICATION

Dimensions (L x W x H) 635 x 925 x 860 mm

Weight (empty) 28.4 kg

Fuel Diesel/Parafin

Fuel consumption 3.8l/h - 3.2 kg/h

Fuel Tank capacity 38 litres

Ignition type Direct spark ignition

Continuous working time 10 hr (before re-fueling)

Over heating protection 120oC

Max output 40 kW (136,484 Btu/h)

Operating Temperature -20 - 45oC

Duty cycle S1 (continuous)

Fuel pump pressure Factory set at 6.5 bar

Electrical supply 230V 50 Hz

Ingress Protection degree IPX4

Sound Power level 67 dB LpA

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

GENERAL SAFETY PRECAUTIONS

GENERAL

1. Always read and ensure you fully understand the following precautions and

the hazards associated with this heater. Do not allow anyone who has not

read these instructions to operate it.

2. Always check for damage before use. Any damage should be properly

repaired. If in doubt, do not use the heater and consult your local dealer.

3. Never carry out any modifications to this heater. If experiencing difficulty of

any kind consult your local Clarke dealer.

4. Use the heater in accordance with any applicable fire regulations.

OPERATING ENVIRONMENT

1. This heater is intended for drying & warming of commercial/industrial

buildings where adequate ventilation is provided. It is not for domestic use

or heating habitable areas.

2. Do not expose the heater or power cable to rain or wet conditions. Any

water entering the heater will increase the risk of electric shock.

3. Never use the heater where petrol, paint thinners or other highly flammable

vapour or where high levels of airborne dust may be present.

4. Never locate the heater facing combustible materials.

5. Do not locate the heater close to an adjacent wall or ceiling. Always allow

at least 3 metres clearance. Avoid placing the heater directly below

power socket outlets.

6. Always locate the heater on a level, flat, fireproof floor. Ensure that the

heater is correctly and safely positioned as described on page11.

7. Disconnect the heater from the power supply when not in use.

8. Never place anything on top of the heater.

9. Always keep combustibles, at least 3 m from the front of the heater.

10. Operate only on a stable, level surface.

11. Use only in accordance with local building regulations.

CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN

PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY.

CAUTION: DUE TO THE HIGH SURFACE AND EXHAUST TEMPERATURES,

ADULTS AND CHILDREN MUST KEEP CLEAR OF THE HEATER TO AVOID

BURNS OR CLOTHING IGNITION.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

VENTILATION

Even though this heater operates very close to 100 percent combustion

efficiency, it still produces small amounts of carbon monoxide.

Carbon monoxide (CO) is toxic. It can build up in a confined spaces and

failure to provide adequate ventilation can be fatal.

The early symptoms of asphyxiation caused by inadequate ventilation are:

1. Only use in well ventilated areas and make sure that ample ventilation is

present if the heater is being started following a long period without use.

2. Never attach any duct work to the front of the heater.

3. Never cover or impede airflow into or out of the heater.

WE RECOMMEND THE USE OF A CARBON MONOXIDE DETECTOR

PERSONAL SAFETY

1. When the heater is used in the presence of other people the user is

responsible for informing those present of the safety precautions and of the

hazards involved.

2. The heater is not to be used by children or people with reduced physical,

sensory or mental capabilities, or lack of knowledge.

3. Always ensure that people and animals are at least 3 m away from the

front of the heater when in operation.

4. Never leave a heater unsupervised while in use - someone should always

be made responsible for monitoring it.

5. Do not move or service the heater while hot or in use.

6. This heater will be hot when in use and should not be touched until it has

fully cooled down after shutting down.

REFUELLING

1. Always refuel in a well ventilated area.

2. Always allow the heater to cool down before re-fuelling.

3. Always refuel away from any source of heat.

4. Never overfill the tank, only fill to the level specified.

5. Use only clean diesel oil or paraffin. NEVER use gasoline, paint thinners,

alcohol or other highly flammable fuels.

• headache • nausea

• dizziness • dry mouth or sore throat

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

6. Take care not to spill fuel onto the power cable as this could damage the

insulation.

7. Never move, replenish the fuel supply or handle the heater when it is hot, or

in use. Turn it off and wait for it to cool down first.

ELECTRICAL SAFETY

1. Electrical appliances must match the power outlet. Never modify the plug

in any way. Do not use adaptor plugs with earthed (grounded) appliances.

Correct plugs and outlets will reduce the risk of electric shock.

2. Do not abuse the electrical cable. Never use the cable for pulling or

unplugging the heater. Keep the cable away from sources of heat, oil,

sharp edges or moving parts. Damaged or tangled cables increase the risk

of electric shock.

3. Keep the mains cable well away from machines and ensure an adequate

electrical supply is close at hand so that the operation is not restricted by

the length of the cable.

4. Always disconnect from the mains supply before moving the heater or

performing any maintenance tasks.

5. Inspect the mains cable regularly for signs of damage. DO NOT use if it is

damaged and always keep it away from the source of heat.

6. If the power cable is damaged, it must be replaced by the manufacturer,

its service agent, or similarly qualified persons in order to avoid a hazard.

SERVICE & REPAIRS

1. Check the heater for damage before use. DO NOT use if the heater is

damaged. Any damage should be properly repaired or the part replaced.

If in doubt, DO NOT use the heater. Consult your local dealer.

2. When necessary, have your heater serviced or repaired by a qualified

person using identical replacement parts. This will ensure that the safety of

the heater is maintained.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

ELECTRICAL CONNECTIONS

Connect the mains lead to a standard 230Volt 50Hz electrical supply through

an approved 13 amp BS1363 plug or a suitably fused isolator switch.

If the plug has to be changed because it is not suitable for your socket, or due

to damage, it should be cut off and a replacement fitted, following the wiring

instructions shown below. The old plug must be disposed of safely, as insertion

into a mains socket could cause an electrical hazard.

If the colours of the wires in the power cable of this product do not correspond with the

markings on the terminals of your plug, proceed as follows.

• The BLUE wire must be

connected to the terminal

which is marked Nor

coloured Black.

• The BROWN wire must be

connected to the terminal

which is marked Lor

coloured Red.

• The YELLOW & GREEN wire

must be connected to the

terminal which is marked E

or or coloured Green.

We strongly recommend that this machine is connected to the mains supply

via a Residual Current Device (RCD).

If in any doubt, consult a qualified electrician. DO NOT attempt any repairs

yourself.

WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS

THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS

SUPPLY.

WARNING: THE WIRES IN THE POWER CABLE OF THIS PRODUCT ARE

COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:

BLUE = NEUTRAL BROWN = LIVE YELLOW AND GREEN = EARTH

Plug must beB1363/A approved.

Always fit

Ensure the outer sheath of the

Neutral

(Blue)

Live

(Brown)

Earth

(Green and

a 13 Amp

fuse.

cable is firmly held by the clamp

Yellow)

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

DEVIL IRD40B HEATER OVERVIEW

FUNCTIONAL DESCRIPTION

A pump draws fuel from the tank and drives it to the burner under pressure.

Fuel is sprayed and atomised by the nozzle and then ignited by the burner

ignition device. A built-in radial blower provides combustion airflow while air

and fuel forms a combustion mixture. The flames heat up the front plate and

guard, thus releasing heat by radiation.

The burner pre-heater warms up the fuel before start-up and the post-

ventilation function cools down the chamber after each use. No flue or

exhaust pipe is required as all combustion gasses are catalysed during

operation.

The unit can be tilted from 12 to 27oto direct heat at a particular target.

1Power-on LED 5Fuel gauge

2Digital temperature display 6Fuel Filter

3Power switch 7Fuel filler cap

4Temperature control knob

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

SAFETY FEATURES

The unit is fitted with a temperature limit sensor, which is designed to turn the

heater off if the temperature should rise to an unsafe level. If the sensor is

tripped and the heater is turned off it may require a service. Once the

temperature falls back below the reset temperature, the heater should re-

start.

The heater is fitted with an electrical circuit breaker to protect the internal

components from damage. If the heater should fail to work, this fuse may

require checking by your dealer.

The heater is fitted with a tilt switch designed to turn the unit off immediately if

it should tip over beyond a pre-determined angle.

SAFETY SYMBOLS

The following symbols appear on the heater.

Hot Surface, do not

touch

Read these

instructions before use

Do not cover

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

PREPARATION

UNPACKING & ASSEMBLY

When unpacking, check the heater for any damage that may have occurred

in transit and notify your Clarke dealer immediately should any be apparent.

1. Fit the heat shield to the heater

body using three screws/nuts near

the top of the heater.

2. Fit the front grille to the heater

using four screws into the captive

nuts secured to the frame.

3. Fit the handle to the rear of the

heater using four bolts/nuts

supplied loose.

SUITABLE FUELS

Diesel or paraffin (kerosene) are the only fuels that should be used.

Table des matières

Autres manuels Clarke Chauffage

Clarke

Clarke DEVIL 2000PTC-B Mode d’emploi

Clarke

Clarke DEVIL 340 Mode d’emploi

Clarke

Clarke CONTRACTOR DEVIL 351C Manuel d'installation et d'exploitation

Clarke

Clarke DEVIL 350C Manuel d'installation et d'exploitation

Clarke

Clarke XR60B Mode d’emploi

Clarke

Clarke DEVIL 371SPC Manuel d'installation et d'exploitation

Clarke

Clarke Devil 370B Series Manuel d'installation et d'exploitation

Clarke

Clarke 6933990 Mode d’emploi

Clarke

Clarke DEVIL 371PC Manuel d'installation et d'exploitation

Clarke

Clarke DEVIL 370SPC Manuel d'installation et d'exploitation

Clarke

Clarke DEVIL 7030 Mode d’emploi

Clarke

Clarke DEVIL 4003 Mode d’emploi

Clarke

Clarke OFR 9 Mode d’emploi

Clarke

Clarke DEVIL 350 230V Manuel d'installation et d'exploitation

Clarke

Clarke IRD40 6920415 Manuel d'installation et d'exploitation

Clarke

Clarke CONTRACTOR GSH15 Mode d’emploi

Clarke

Clarke DEVIL 370PD Manuel d'installation et d'exploitation

Clarke

Clarke DEVIL 2800PTC-B Mode d’emploi

Clarke

Clarke XR75 Manuel d'installation et d'exploitation

Clarke

Clarke DEVIL155 Manuel

Clarke

Clarke IQ2000 Manuel utilisateur

Clarke

Clarke DEVIL 9000PTC Mode d’emploi

Clarke

Clarke OFR 5/50 Mode d’emploi

Clarke

Clarke GRH15 Mode d’emploi

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur

iLO

iLO IHP2424 Manuel d'utilisation
