USER GUIDE
GAS BARBECUE
MODEL NO: BBQ3
PART NO: 6925300
2
INTRODUCTION
Thank you for purchasing this CLARKE product
Before attempting to use this product, please read this manual thoroughly and follow the
instructions carefully. In doing so you will ensure the safety of yourself and that of others around
you, and you can look forward to your purchase giving you long and satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12 months from the date
of purchase. Please keep your receipt which will be required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or tampered with in any
way, or not used for the purpose for which it was intended.
Faulty goods should be returned to their place of purchase, no product can be returned to us
without prior permission.
This guarantee does not effect your statutory rights.
SPECIFICATION
MODEL NUMBER BBQ3
PA R T N UM BE R 6925300
HEAT OUTPUT : Grill 3 x 3.1 kw 223g x hr (Propane)
Side Burner 1 x 3.1 kw 223g x hr (Propane)
OPERATING PRESSURE 37 mbar
APPLIANCE CATEGORY 13+
DIMENSIONS (LxWxH) 1291 x 550 x 1115 mm
WEIGHT 32.6 kg
3
WARNING AND SAFETY POINTS
Please read the following points before using your barbecue.
1. Please follow all assembly instruction in this manual; failure to follow these instructions may
result in serious bodily injury and/or property damage.
2. This barbecue will become very hot when in use; care is to be taken especially when pets,
children or elderly people are present.
3. Do not use or store any flammable liquids or vapours in the vicinity when operating the
barbecue.
4. In the event of a gas leak, shut off the gas to the barbecue, extinguish any open flames and
open the lid, if the leak continues check for damage, poor connection etc.
5. Do not use a naked flame to check for gas leaks.
6. Do not operate barbecue if there is a gas leak.
7. Do not attempt to disconnect any gas fitting if your barbecue is being used, this includes the
Gas Hose and Regulator.
8. The barbecue should be cleaned on a regular basis. Take care not to enlarge burner ports
or any openings when cleaning the burner or valves.
9. Do not use this barbecue in an enclosed area.
10. We recommend keeping the barbecue at least 1.0 meter clear of any combustible
materials.
11. We would recommend that this barbecue should be serviced at least once a year by a
competent engineer. Do not attempt to service this appliance yourself.
12. Do not attempt to modify or make any adjustment of the main controls on this barbecue,
i.e. gas taps, injectors, valve etc.
13. Stand your barbecue on a safe, level surface, away from inflammable items such as
wooden fences or overhanging trees.
14. Never use your barbecue indoors.
15. Once alight do not move your barbecue or leave it unattended.
16. Keep children and pets at a safe distance from the barbecue.
17. Keep a fire extinguisher handy.
18. Remember that hot fat may drip out from the bottom of the barbecue. Make sure the hose
is clear of any fat.
19. The barbecue will become hot when in use, so wear oven gloves to handle the lid etc.
20. Ensure that the barbecue has completely cooled down before storing.
21. Never light a barbecue with gasoline or similar liquids.
22. Always turn off the gas supply after use.
23. Do not store the LPG bottle inside the barbeque.
4
PARTS LIST
NO DESCRIPTION PART NUMBER NO DESCRIPTION PART NUMBER
1 Lid ELBBQ301 21 Wheel Cap ELBBQ321
2 Warming Rack ELBBQ302 22 Bottom Shelf ELBBQ322
3 Cooking Grill ELBBQ303 23 Castors ELBBQ323
4 Flame Diffuser Plate ELBBQ304 24 Side Burner Grid ELBBQ324
5 Main Burner ELBBQ305 25 Side Burner ELBBQ325
6 Side Table ELBBQ306 26 Spark Electrode ELBBQ326
7 Side Burner Table ELBBQ307 27 Knob ELBBQ327
8RightSideTable ELBBQ308 28 Side Burner Table ELBBQ328
9 Grill Body ELBBQ309 29 Side Burner Valve ELBBQ329
10 Drip Tray ELBBQ310 30 Gas Hose ELBBQ330
11 Leg A ELBBQ311 31 Clip on Regulator ELBBQ331
12 Door Handle ELBBQ312 A Wheel Pin ELBBQ3FP
13 Tray Handle ELBBQ313 B R-clip ELBBQ3FP
14 Back Panel ELBBQ314 C M8×21 Bolt ELBBQ3FP
15 Leg B ELBBQ315 D M5×60 Bolt ELBBQ3FP
16 Side Panel ELBBQ316 E M5×10 Bolt ELBBQ3FP
17 Right Door ELBBQ317 F M4×8 Bolt ELBBQ3FP
18 Door Stop Bar ELBBQ318 G M5 Nut ELBBQ3FP
19 Left Door ELBBQ319 H Butterfly Nut ELBBQ3FP
20 Wheel ELBBQ320 I Washer ELBBQ3FP
5
ASSEMBLY
TIPS
• Remove all parts from the 2 boxes and check if anything is missing according to the
“Parts List” on page 4.
• To assemble your barbecue you will need: a screwdriver, pliers and an adjustable
wrench.
• Assemble all nuts and bolts loosely at first. Tighten all connections once fully assembled.
This increases the stability of your barbecue.
1. Connect Legs A (11) and Leg B (15) to Side Panels (16) as shown using 8 x Bolts (E).
2. Secure the Bottom Shelf (22) to the legs using 4 x Bolts (D) and 4 x Nuts (G).
6
3. Fit the back panel (14) into position and secure in place using 4 x Bolts (E).
4. Fit both Wheels, by sliding the Wheel Pin (A) through the wheel (21) and washer (I) then
through Leg B (15) and locking the wheel in place using the R-Clip (C) supplied.
5. Clip the Wheel Cap (21) into position.
6. Screw the Castors (23) into the bottom of Leg A (11).
7
7. Fit the Door Stop Bar (18) as shown and secure in place using 2 x Bolts (E).
8. Fit the Door Handles (12) to the Doors (17 & 19).
9. Fit the Doors into position as shown.
8
10. Get someone to help lift and position the Grill Body (9) as shown above.
11. Secure in position using 8 x Bolts (D).
12. Fit the Side Table (8) and Side Burner Table (7) and fix in place using 8 x Bolts (C).
9
13. Fit the Spark Electrode (26), Side Burner Valve (29) and Side Burner (25) as shown.
• Ensure all connections are secure using Bolt (F) and Wingnut (H).
14. Place the Knob (27) and Side Burner Grid (34) into position.
15. Connect the Gas Hose (30) as shown.
10
16. Connect the Tray Handles (13) to the Drip Tray (10) and secure using 2 bolts (E).
17. Slide the oil tray into position as shown above.
18. Place the Flame Diffuser Plates (4), Cooking Grills (3) and Warming Rack (2) into position.
