Introduction

General Information

81213

Introduction

General Information 116370

Using the manual

The present Repair Manual is to assist in maintaining

permanent machine availability. This ensures the high

value of your machine by thorough care and service.

Experience gathered by both our service engineers

and factory staff has been compiled in this Repair

Manual.

The sequence of pictures shows the procedure of a

repair. The text provides the necessary information

about the adjustments to be made, the use of special

tools etc.

The illustrations included in support to the explana-

tions show the sequence of major repairs so that minor

repairs can easily be followed.

which allows to insert supplementary pages as issued

following technical developments and to always have

an updated manual at hand for reference.

To be sure, always compare settings and filling capac-

ities with specifications stated in the current Operator’s

Manual which applies to the combine harvester.

Texts and figures

Pictures and graphics are neutral. Differences are

pointed out by notes beneath the figure.

Texts are short and not machine-specific as far as pos-

sible. Differences are pointed out by intermediate

headings.

Different types of texts can easily be distinguished

from one another by their formats. The following for-

mats are distinguished:

Formatting Meaning Description

Description Text Further information on the subject.

– Instructions Operation Operations which must be carried out one after the

other.

Result Result Consequence of operations carried out.

Find manuals at http://best-manuals.com/search?&s=CLA-2945140

00 0294 514 0 - RHB QUADRANT 3400 - 03/10 5

Introduction

General Information

81213

References can easily be distinguished by suitable

symbols. The following symbols are distinguished:

Document structure based on subassemblies

As far as the contents permit, the chapters of this man-

ual are structured according to subassemblies. The

structure of these subassemblies is the same in all

chapters.

Different product groups have different document

structures based on subassemblies. CLAAS always

takes care to keep these document structures based

on subassemblies identical in any documents.

Search and find

The wanted subject can easily be found with the recur-

ring subassembly structure, using the table of contents

or the header line of this manual.

In addition, the index of this manual is a useful tool for

locating a specific subject. The index can be found on

the last pages of this manual.

Directions

Text elements such as front, rear, right and left always

apply to the direction of travel. In figures, the direction

of travel may be indicated by a direction arrow.

Your CLAAS Service Department

116732

Validity of manual

This manual is valid for the following machines:

Symbol Meaning Description

See index The symbol indicates that further information on

this subject is available in other sections of this

manual.

See the index of the

Operator's Manual in

question

The symbol indicates that further information on

this subject is available in the Operator's Manual of

the machine or of the implement in question.

See index of Technical

Systems documentation The symbol indicates that further information on

this subject is available in the Technical Systems

documentation of this machine or this implement.

Description Type Machine number

from to

QUADRANT 3400 740 74000016 ―

Find manuals at http://best-manuals.com/search?&s=CLA-2945140

6 00 0294 514 0 - RHB QUADRANT 3400 - 03/10

Introduction

General repair instructions

81213

General repair instructions 2475

Specifications

Technical data, dimensions and weights are given as

an indication only. CLAAS reserves the right to make

changes subsequently as technical developments con-

tinue. Responsibility for errors or omissions not

accepted.

14015

Reason of damage

Identify reason of damage, limit the case of damage

and safeguard the machine.

115321

Spare parts

Use CLAAS original parts and the corresponding spe-

cial tools.

For any spare parts orders or technical requests, indi-

cate the machine serial number and, if applicable, the

equipment serial number. This measure is necessary

to prevent incorrect spare parts deliveries.

Use only CLAAS original spare parts, accessories and

tools that have been inspected and approved by

CLAAS. Only these measures can ensure that the

properties defined in the design of CLAAS harvesting

machines, as well as their operating capacity, are

maintained. CLAAS original parts also maintain active

and / or passive driving safety, as well as machinery

working safety.

CLAAS disclaims all liability in the event of damage

resulting from the use of parts, accessories and equip-

ment that are not CLAAS original products.

14021

Gearboxes

When dismounting the gearboxes, always drain the

transmission oil first and then remove the gearbox.

Separate parts sticking firmly together with a soft

metal-tip or plastic-tip hammer.

14045

Welding Work

115323

Tensioning the steel roller chains

The steel roller chains are correctly tensed when you

can push down the slack section with your thumb by

around 2% of its length (gear interaxial distance), while

the tense strand is under low stress. Verify the tension

on new chains more often.

Note!

All information regarding this subject-matter

can be found in the current Operator's manual

of the machine.

Find manuals at http://best-manuals.com/search?&s=CLA-2945140

00 0294 514 0 - RHB QUADRANT 3400 - 03/10 7

Introduction

General repair instructions

81213

Example: interaxial distance 500 mm = thrust stroke

on the slack strand, around 10 mm.

116379

Taper ring fasteners

Conical ring assemblies represent a safe connection,

even if high forces are transferred from the drive com-

ponent to the shaft and vice-versa, as long as the

prestressing is correct.

During installation, it is important that the shaft, hub,

sunk keys and tapered rings be carefully cleaned

and then greased with gearbox fluid grease, NLGI-

class 00,suchas:CLAAS AGRIGREASE LC 00 / 000,

and then assembled in the correct order and tightened

to the recommended torque.

Dismantling:

After unlocking the axial stop, release the tapered ring

assembly with a driver tube, applying a firm and clean

strike.

85677

Gib head key joints

Prior to installation, the shaft, the hub and the keyway

must be cleaned so they are free of grease, paint and

rust.

When delivered as a spare part, the gib head key is in

its raw condition, it is therefore too high and would

stick out too far after arresting it. Consequently the gib

head key must be matched to the component in ques-

tion by milling or grinding of the bottom face so that it

will not stick out more than necessary after arresting,

but can still be dismounted perfectly using the CLAAS

special tools (straight or cranked key extractor). The

conical top face must not be machined. Treatment

with a file is not recommended.

Caution!

Sticking on tapered ring assemblies.

–Never mount parts using thick lubricating

grease.

Warning!

Damage to the taper ring fastener.

– The inside diameter of the block-ended

tube must be large enough to extend over

the tapered ring.

Caution!

Damage to the gib head key joint.

– Arrest the gib head key with a suitable

hammer that is not too heavy and with the

right touch.

Find manuals at http://best-manuals.com/search?&s=CLA-2945140

8 00 0294 514 0 - RHB QUADRANT 3400 - 03/10

Introduction

General repair instructions

81213

Never use force for arresting the gib head key in order

to avoid damage to the components (especially the

brake discs) and to enable loosening with the CLAAS

special tool.

14029

Self-locking bolts with micro-encapsulated

adhesive

Replace all self-locking bolts, e.g. Verbus-Plus and

Imbus-Plus, every time when removing them. In

exceptional cases, such bolts can be reused up to

three times.

Always tighten self-locking bolts with micro-encapsu-

lated glue quickly to the specified tightening torque.

Always observe the specified tightening torque.

When unscrewing self-locking bolts, unscrew them

quickly. Self-locking bolt must not get in contact with

sealing compound.

Self-locking bolts with micro-encapsulated glue can be

used only in locations where the operating tempera-

ture will not exceed +90°C.

The full load capacity of these bolts is achieved after

24 hours at +20°C. Full hardening can be accelerated

by heating-up, e.g. to 15 minutes at +70°C.

In specific cases, bolts with liquid locking compound

can be used instead of self-locking bolts only where

such threaded joints can be heated up to around

200 °C for slackening off. The specified bolt quality

grade, e.g. 8.8 or 10.9, must be observed here as well.

14031

Liquid locking compound

Use liquid locking compound only where this is speci-

fied by the manufacturer.

Proper application:

Metal joints intended for liquid locking compound use

must be absolutely free from grease. Clean such joints

with the "Activator" enclosed in the workshop package.

Before applying the liquid locking compound, the acti-

vator (cleaning agent) must have dried on the metal

surfaces. No more activator residues may be present,

especially in blind holes.

Apply the liquid locking compound of threaded joints

only to the inside thread of the nut drop by drop if pos-

sible. In blind holes, wet only around 1 d (d = rated Ø

of threaded pin) at the thread bottom. Proceed in the

same way with all excess-length screw threads. When

applying the liquid locking compound on the threaded

bolt or at the beginning of the screw thread, it will

spread over the entire thread length while screwing it

in and the breakaway torque is too high when slacken-

ing the bolt off later – danger of bolt tearing.

Find manuals at http://best-manuals.com/search?&s=CLA-2945140

00 0294 514 0 - RHB QUADRANT 3400 - 03/10 9

Introduction

General repair instructions

81213

Threaded joints secured with liquid locking compound

can be slackened off easily after heating them up to

around 200 °C.

14033

Lock collar bearing

Lock collar bearings are arrested on the shaft by twist-

ing the eccentric ring over the inside bearing race.

Before inserting, it is useful to apply some semi-fluid

lubricant of NLGI class 00, e.g.

CLAAS AGRIGREASE LC 00 / 000 to the inner race

and the shaft to enable easier dismounting of bearings

at a later date.

Always arrest the eccentric ring moderately indirection

of rotation of the shaft and lock it with a set screw. To

loosen the bearing, drive off the eccentric ring against

the sense of rotation of the shaft.

14035

Adapter sleeve bearing

Adapter sleeve bearings do not require a specially

machined bearing seat. They may be mounted on any

drawn or scalped shaft. This is an advantage because

it allows the shaft to be axially moved as required to

obtain correct alignment.

Always install adapter sleeve bearings according to

the conical inside ring. Clean the taper lock adapter

sleeve and the shaft and check that the sleeve nut

runs easily so the taper lock adapter sleeve will not

turn on the shaft when tightening.

Tightening:

First tighten the sleeve nut to the point where the taper

lock adapter sleeve has no more play and is under

slight preload. Now tighten the nut by approx. 90° and

continue turning until the next nearest slot fits the tab.

Secure sleeve nut with the tab.

Slackening off:

Slacken off the released sleeve nut for some turns only

for the time being. The thread must still be fully load-

bearing. Loosen the taper lock adapter sleeve with

a sharp blow, using a block-ended tube.

14037

Ferrule fittings on hydraulic lines

When pre-assembling the unit and for pre-assembled

factory-delivered ferrule fittings, the following applies:

installation is in the associated, well-oiled threaded

joint with half a turn of the union nut beyond the point

where resistance is felt.

Pre-assembly:

– Cut the tube at a right angle.

Do not use a tube cutter! This would cut the tube

wall at an angle and would cause a significant

amount of burr lines on both the interior and

exterior.

Find manuals at http://best-manuals.com/search?&s=CLA-2945140

10 00 0294 514 0 - RHB QUADRANT 3400 - 03/10

Introduction

General repair instructions

81213

– Lightly deburr the interior and exterior tube ends.

Do not chamfer!

– Clean the tube ends.

If the tube is angled, the straight edge of the tube lead-

ing up to the beginning of the curve's radius must be at

least twice as high as the box nut.

– Push the box nut and the cutting ring onto the

tube.

– Press the tube against the stop on the connection

sleeve and tighten the box nutuntil the cutting ring

surrounds the tube.

The tube must not turn during this process. This

may easily happen due to a significant increase in

force.

– Tighten the box nut a 1/2 turn beyond the resist-

ance point.

– Check the notch on the cutting edge.

A visible raised shoulder must fill the space in

front of the front surface of the cutting ring. The

cutting ring can turn, but may not shift axially.

Final assembly

– Fit the pre-assembled tube in the well-greased

threaded connector.

– Tighten the box nut until the resistance point is

felt.

– Tighten another 1/2 turn beyond this point.

Repetitive assembly

– After each time the cutting ring bolt connector is

loosened, the box nut must be re-tightened using

only the minimum amount of force necessary.

Unsealed cutting ring bolt connector

– If the connector is not sealed, it is necessary to

first loosen the box nut until a small amount of oil

flows out.

– Then re-tighten as directed. 14039

Progressive ring fittings on hydraulic lines

When pre-assembling the unit and for pre-assembled

factory-delivered profiled ring fittings, the following

applies: installation is in the associated, well-oiled

threaded joint with half a turn of the union nut beyond

the point where resistance is clearly felt.

Pre-assembly

– Cut the tube at a right angle.

Do not use a tube cutter! This would cut the tube

wall at an angle and would cause a significant

amount of burr lines on both the interior and

exterior.

– Lightly deburr the interior and exterior tube ends.

Do not chamfer!

– Clean the tube ends.

Find manuals at http://best-manuals.com/search?&s=CLA-2945140

Table des matières

Autres manuels Claas Matériel agricole

Claas

Claas DOMINATOR 150 Manuel utilisateur

Claas

Claas LEXION 600 Mode d'emploi

Claas

Claas TUCANO 500 Guide d'installation

Claas

Claas ELIOS 240-210 Mode d'emploi

Claas

Claas QUANTUM 3500 Mode d’emploi

Claas

Claas JAGUAR 8500 C Mode d’emploi

Claas

Claas LEXION 670 Manuel utilisateur

Claas

Claas DOMINATOR 208 MEGA III Manuel utilisateur

Claas

Claas LEXION 480 Mode d'emploi

Claas

Claas LEXION 570 Montana Manuel utilisateur

Claas

Claas C490-C370 Mode d'emploi

Claas

Claas TUCANO 2017 Guide d'installation

Claas

Claas LEXION 560 Manuel utilisateur

Claas

Claas DOMINATOR 68 S Manuel utilisateur

Claas

Claas LEXION 8000 Guide d'installation

Claas

Claas LEXION 780 Guide d'installation

Claas

Claas ROLLANT 250 Mode d'emploi

Claas

Claas 930 Guide d'installation

Claas

Claas 930 Guide d'installation

Claas

Claas TUCANO 400-300 Guide d'installation

Claas

Claas LEXION Mode d'emploi

Claas

Claas TARGO K50 Mode d'emploi

Claas

Claas QUADRANT 5300 Manuel utilisateur

Claas

Claas ROLLANT 66 Mode d'emploi

Manuels Matériel agricole populaires d'autres marques

GSi

GSi PNEG-2314 Manuel utilisateur

Checchi & Magli

Checchi & Magli TEXDRIVE Manuel utilisateur

Amazone

Amazone Cenius 4003-2TX Manuel utilisateur

MASSEY FERGUSON

MASSEY FERGUSON MF 9313S Manuel utilisateur

Cima

Cima BLITZ Instructions d'utilisation et d'entretien

Amazone

Amazone CombiDisc 3000 Instructions d'installation

HE-VA

HE-VA Disc-Roller XL Contour Manuel utilisateur

AGT

AGT AGT-SSFM Manuel utilisateur

Milestone

Milestone 72-84 Manuel utilisateur

KUHN

KUHN Hector 3000 Manuel utilisateur

Krone

Krone X-Disc 6200 Manuel utilisateur

Eliet

Eliet DZC450 Manuel utilisateur

Taarup

Taarup BIO+ B4000 Manuel utilisateur

Garland

Garland SHAKER 310 DPG Manuel utilisateur

stable comfort

stable comfort StableWall System Manuel utilisateur

Raven

Raven AccuBoom Manuel utilisateur

International

International 710 Manuel utilisateur

Ashland

Ashland HDW-3217-14 Manuel utilisateur
