MOVEMENT SPECIFICATIONS

CAL. : 6P73/6P75/6P77/6P79

10-1/2 LINGE, MULTI FUNCTION WITH HIGH HAN

ANALOGUE QUARTZ, NO JEWEL

BY CITIZEN WATCH CO., LTD. JAPAN

MANUFACTURED IN JAPAN

1.BASIC SPECIFICATION

(1) Cal. No. *TO CONFIRM WITH MOV'T DRAWING ATTACHED

CALIBRE 6P73 6P75 6P77 6P79

Ligne

Size*mm

Date 12H 3H 12H 3H

×9H9H9H

24Hou

6H × 6H 6H

Total heigh

Battery life

Batter

These calibers above which has anHIGH HAND structure:

each caliber above which has an eye position same as: :

3.45mm

pprox. 3 year

SILVER OXIDE SR621S

or equivalent

10-1/2

22.6×22.6×Φ23.3mm

24H

DateDay

Date

24H

DayDateDay

Date

24H

6P73 6P796P75 6P77

6P23 6P296P25 6P27

Center Hands

Height

Small Hands

Height

6P2＊6P2＊

(2) Time standard

Type of quartz : Tuning fork type quartz crysta

Frequency : 32,768H

ccuracy : +/-20 s/month worn under normal circumstances

(3) Balanceable weight of hand

Minute hand : Max. 0.4 μN.m

Second hand : Max. 0.07 μN.m

Small hands : Max. 0.02 μN.m

(4) Function

24hour, date and retrograde day indicator by small hands.

Powercell Saving Reset Mechanism (PSRM)

Over-loading Compensation Device (OLCD)

Digital Frequency Control (DFC) for time adjustment

2.SEPARATED PART

Setting stem x1

Code 065-379

Length from movement center to far end 20.03mm

of setting stem

Thread................................. Ф0.9mm x 12.18mm

3.OTHERS

* Measurement of time rate

The unit (gate) time of measurement must be set at "10 sec." or integer fold

value of 10 sec. owing to the DFC system, and the measurement must be

performed in the form of complete watch.

* Marking on movement

JAPAN

MIYOTA CO.

6P73/75/77/79

NO JEWELS

* Typical clearance

Mov't - Caseback minimum 150 microns

Top of hands - Glass 300 - 400 microns *

* subject to the glass, case structure, and the length of hand

4. INSTRUCTIONS MANUAL

) DISPLAYS

B) SETTING THE TIME

For 6P73,6P75,6P77,6P79

1. Pull the crown out to the 2nd Click Position.

2. Turn the crown to set hour and minute hands.

C) SETTING THE DATE

For 6P73,6P75,6P77,6P79

*Please do not set the date between 9:00 PM and 1:00AM

1. Pull the crown out to the 1st Click Position.

2. Turn the crown counter-clockwise to set the date.

3.After the date has been set, push the crown back to the noraml position.

D)SETTING THE DAY

For 6P75,6P77,6P79

1. Pull the crown to the 2nd Click Position.

2. Turn the crown clockwise to gain the hour and minute hand.

*The day changes between 0:00 and 5:30AM.

3.After the day has been set, push the crown back to the noraml position.

E)24HOUR

For 6P73, 6P77, 6P79

24Hour hand moves linked with the hour hand.

These specifications might be changed without prior notice.

6P75

Hour Hand Minute Hand

Hour Hand

Day Hand

Date Hand

Normal Position

1st Click Position

2nd Click Position

6P73 6P75 6P77 6P79 6P57

* Other specifications are same as 6P23 / 6P25 / 6P27 / 6P29 .

High Hand version of 6P23 / 6P25 / 6P27 / 6P29















































***** CAL.

6P73/75/77/79

MOV'T PARTS LIST *****

HIGH HAND

ORIGINAL PARTS, MADE IN JAPAN

PART NAME

6P73

6P75

6P77

6P79

HOUR

WHEEL

075-306

CANON PINION WITH DRIVING WHEEL

028-137

FORTH WHEEL AND PINION

023-224

24HOUR

WHEEL

100-430

DAY

WHEEL

200-070

DATE

WHEEL

187-130

187-150

187-130

187-150

*Ot er parts are same as

・・・

)

6P25 (=6P75)

)

***** CAL.

6PXX

MOV'T PARTS LIST *****

ORIGINAL PARTS, MADE IN JAPAN

PART NAME

6P23

6P25

6P27

6P29

24 HOUR WHEEL

100-350

100-340

100-350

24 HOUR WHEEL GUARD

117-270

117-260

117-270

BATTERY

280-340

BATTERY CONNECTOR SPRING

231-163

CALENDAR CORRECTING PILLAR WHEEL

255-340

CANNON PINION WITH DRIVING WHEEL

028-196

CENTER WHEEL COCK

711-183

CLUTCH WHEEL

064-790

COIL UNIT

246-121

DATE CORRECTOR WHEEL

213-330

DATE DIAL DRIVING WHEEL

103-970

DATE FINGER

106-740

DATE JUMPER

109-520

DATE WHEEL

187-060

187-080

187-060

187-080

DAY WHEEL

200-030

DIAL GUARD

293-870

DIAL GUARD GIB

027-102

ELECTRINIC CIRCUIT UNIT

279-735

FIFTH WHEEL & PINION

084-460

FOURTH WHEEL & PINION

023-205

HOUR WHEEL

075-328

INTERMEDIATE 24 HOUR DRIVING WHEEL(1)

087-990

INTERMEDIATE 24 HOUR DRIVING WHEEL(2)

087-101

INTERMEDIATE DATE CORRECTING WHEEL

087-620

INTERMEDIATE DATE WHEEL(1)

100-330

INTERMEDIATE DATE WHEEL(2)

103-950

100-340

MINUTE WHEEL AND PINION

072-890

MONTH CORRECTOR LEVER GUARD

117-260

ROTOR

285-800

SCREW FOR CALENDAR GUARD(X3)

929-520

SCREW FOR TRAIN FOR BRIDGE(X4)

923-810

SCREW FOR TRAIN FOR BRIDGE(X3)

923-810

SETTING LEVER

067-173

MINIMUM UNIT ORDER : 100PCS PER EACH EXCEPT * MARK(=1,000PCS)

SETTING LEVER SPRING

077-109

SETTING STEM

065-379

SETTING WHEEL

076-640

SPACER FOR SETTING STEM

212-146

SPACER FOR TRAIN WHEEL BRIDGE(2)

027-101

STATOR

190-790

THIRD WHEEL AND PINION

017-119

TRAIN WHEEL BRIDGE

701-F58

701-B84

701-B86

701-B87

YOKE

071-970

LONGER SETTING STEM(20.985MM)

065-407

LONGER SETTING STEM(23.985MM) *standard

065-426

UNIVERSAL MASTERPIECE BORN IN JAPAN

MADE IN JAPAN

METAL MOVEMENT

INSTRUCTION MANUAL FOR MIYOTA WATCH MOVEMENT

CALIBER NO. 6P27/6P77

BATTERY: SR621SW

FEATURES : ANALOG MULTI-FUNCTION QUAR TZ WATCH WITH DAY, DATE AND 24HOUR

INSTRUCTION MANUAL

A) DISPLAY

B) OPERATION PROCEDURE

C) SETTING THE DAY AND TIME (HOUR, 24 HOUR, MINUTE, SECOND)

D) SETTING THE DATE (BY QUICK OPERATION)

A) DISPLAY

NORMAL CROWN POSITION

1ST POSITION QUICK OPERATION - DATE (COUNTERCLOCKWISE)

2ND POSITION TIME/DAY SETTING (CLOCKWISE)

B) OPERATION PROCEDURE

1 SETTING THE DAY

SETTING THE TIME (HOUR, 24HOUR, MINUTE and SECOND)

2 SETTING THE DATE

24HOUR HAND

DATE

DAY (OF THE WEEK)

HOUR HAND

SECOND HAND

MINUTE HAND 1ST POSITION

2ND

POSITION

NORMAL CROWN POSITION
