Cisco WAP371 Manuel utilisateur

Quick Start Guide

Guide de démarrage rapide

快速入门指南

Cisco Small Business

371 Series Wireless Access Point

Point d'accès sans fil Série 371

371 系列无线接入点

2 Cisco Small Business WAP371 Series Wireless Access Point

Welcome

Thank you for choosing the Cisco Small Business WAP371 Wireless Access Point.

The Cisco WAP371 is an indoor dual radio 802.11ac + 802.11n access point.

This guide is designed to familiarize you with the general layout of the access point,

describe how to deploy the device in your network, and describe how to configure the

device. Your access point has more features and functionality than what is described

in this guide. For additional information, see the Administration Guide. A link to the

Administration Guide is found in “Where to Go From Here” on page 11.

Package Contents

• Wireless Access Point

• Mounting kit

• This Quick Start Guide

• Product CD

• Ethernet cable

Before You Begin

Before you begin the installation, make sure that you have the following equipment

and services:

• A computer with browser support for:

– Internet Explorer v7.0 or later

– Chrome v5.0 or later

– Firefox v3.0 or later

– Safari v3.0 or later

• Tools for installing the hardware

• One or more Ethernet network switches with PoE

Cisco WAP371 Wireless-AC/N Dual Radio Access

Point with Single Point Setup Features

Front Panel

The front panel of the device consists of three lights: Power, WLAN, and LAN. For

full descriptions of the colors of the lights and their indications, see “Verifying the

Hardware Installation”.

Cisco Small Business WAP371 Series Wireless Access Point 3

A Kensington lock slot is found under the lights.

Back Panel

The back panel of the device has an RJ-45 Ethernet port. Use the Ethernet port to

power your device using PoE. It is an auto-sensing, Gigabit Ethernet (802.3) port

used to connect your WAP devices to network devices, such as computers, routers, or

switches. We strongly recommend that you use a Category 5e or better cable for

gigabit connectivity.

The back panel of the device has a Reset button. See “Rebooting the Devices or

Returning them to their Factory Default Settings” for information on the Reset button.

Default Settings

If you are using a Cisco Small Business RV Series router, the default range for the

DHCP assigned address is from 192.168.1.100 to 192.168.1.254. Any device

connecting to the same LAN will be assigned an IP address in this range.

Parameter Default Value

Username cisco

Password cisco

LAN IP Address DHCP address assigned by

server

Fallback LAN IP 192.168.1.245

Subnetwork Mask 255.255.255.0

4 Cisco Small Business WAP371 Series Wireless Access Point

Mounting the Cisco WAP371 Wireless-AC/N Dual

Radio Access Point with Single Point Setup

You can place your access point on a desktop, or mount it on a wall or ceiling.

Placement Tips

• Ambient Temperature—To prevent the access point from overheating, do not

operate it in an area that exceeds an ambient temperature of 104°F (40°C).

• Air Flow—Both side panels have vents that must be unobstructed to prevent

overheating.

• Mechanical Loading—The device should be level, stable, and secure to prevent it

from sliding or shifting out of position.

Wall and Ceiling Mounting

The Cisco WAP371 device can be wall or ceiling-mounted. A mounting kit is

packaged with your device. The kit is designed to install your device to the wall or the

ceiling.

The mounting bracket has some flexibility so that you can reuse existing holes drilled

for a Cisco WAP551 or WAP561 device. The installer can remove the Cisco WAP551

or WAP561 and mount the Cisco WAP371.

The dimensions for the mount kit screws are as follows:

WARNING Insecure mounting might damage the device or cause injury. Cisco is not

responsible for damages incurred by insecure wall or ceiling mounting.

1.31 to .33 in (7.8

to 8.3 mm) 2.86 to .88 in (21.8

to 22.3 mm) 3.22 to .24 in (5.5

to 6.0 mm) 4.69 to .72 in (17.5

to 18.2 mm)

196243

Cisco Small Business WAP371 Series Wireless Access Point 5

To mount the Cisco WAP 371 device to a wall or ceiling:

STEP 1Determine where you want to mount the device. Verify that the surface is

smooth, flat, dry, and sturdy.

STEP 2Drill two pilot holes into the surface 2.75 inches (70 mm) apart for your

Cisco WAP device.

STEP 3Insert a screw into each hole, leaving a gap between the surface and the base

of the screw head.

STEP 4Place the upper slots of the bracket over the screws, adjust the screws

accordingly, and slide the bracket down until the screws fit snugly into the

slots.

STEP 5Using the bracket as a template, drill two more holes for the lower screws.

STEP 6Insert a screw into each lower hole.

STEP 7Slide the WAP device into the bracket, placing the cable through the break-

out tab found in the back of the bracket.

Connecting the Cisco WAP371 Wireless-AC/N

Dual Radio Access Point with Single Point Setup

The default configuration of the device has the Wi-Fi radio turned off. You must

perform the initial configuration using a wired Ethernet connection. To connect the

device to the wired network:

STEP 1Connect the Ethernet cable to the Ethernet port of a switch, a router, or a PC.

STEP 2Connect the other end of the network Ethernet cable to the Ethernet port of

the wireless access point.

After installation, all lights should be active. Refer to Verifying the Hardware

Installation, page 6 for details about the different lights on each switch.

6 Cisco Small Business WAP371 Series Wireless Access Point

Verifying the Hardware Installation

To verify the hardware installation, complete the following tasks:

• Check the cable connections.

• Check the state of the indicator lights.

NOTE If you need help resolving a problem, visit the Cisco Small Business Support

Community at www.cisco.com/go/smallbizsupport.

Label Activity Description

Power Off The device has no power.

Solid Green The device is powered on. Normal operation.

Flashing Green Upgrading firmware or acquiring an IPv4 address.

Solid Red Booting or firmware upgrade failed.

WLAN Off Wireless is disabled, for both 2.4 GHz and 5 GHz.

Solid Wireless is enabled.

Green Concurrent mode enabled. (The intensity needs to be

the same)

Amber 5 GHz is in use.

Blue 2.4 GHz is in use.

Flashing Transmitting or receiving data.

LAN Off No Ethernet link.

Solid Green GE Ethernet link is active.

Solid Amber FE Ethernet link is active.

Flashing Transmitting or receiving data.

Cisco Small Business WAP371 Series Wireless Access Point 7

Getting Started with the Configuration

To configure the wireless access points, follow these steps to access the Wizard and

then the web-based configuration utility from your computer:

STEP 1Connect the wireless access point to the same network (IP subnet) as your

computer. The factory default IP address configuration of the access points is

DHCP. Make sure your DHCP server is running and can be reached.

See “Incorrect IP Address” on page 9 for troubleshooting information, or if

you do not have a DHCP server.

STEP 2Locate the IP address of the wireless access point.

a. The wireless access points can be accessed and managed by Cisco Small

Business network tools and services including the Cisco FindIT

Network Discovery Utility that enables you to automatically discover

all supported Cisco Small Business devices in the same local network

segment as your computer. You can get a snapshot view of each device

or launch the product configuration utility to view and configure the

settings. For more information, see www.cisco.com/go/findit.

b. The wireless access points are Bonjour-enabled and automatically

broadcast their services and listen for services being advertised by other

Bonjour-enabled devices. If you have a Bonjour-enabled browser, such

as Microsoft Internet Explorer with a Bonjour plug-in, or the Apple Mac

Safari browser, you can find the wireless access point on your local

network without knowing its IP address.

You can download the complete Bonjour for Microsoft Internet

Explorer browser from Apple’s website by visiting:

http://www.apple.com/bonjour/

c. Locate the IP address assigned by your DHCP server by accessing your

router or DHCP server. See your DHCP server instructions for more

information.

STEP 3Launch a web browser, such as Microsoft Internet Explorer or Mozilla

Firefox.

STEP 4In the Address field, enter the default DHCP address and press the Enter key.

STEP 5Enter the default user name of cisco and password of cisco in the User Name

and Password fields.

STEP 6Click Login. The Wireless Access Point Setup Wizard appears.

STEP 7Follow the Setup Wizard instructions to finish the WAP device installation.

We strongly recommend that you use the Setup Wizard for the first

installation.The Setup Wizard turns on the Wi-Fi radio, which allows you to

8 Cisco Small Business WAP371 Series Wireless Access Point

connect wirelessly. For more advanced configurations, see the

Administration Guide. A link to the Administration Guide is found in

“Where to Go From Here” on page 11.

Congratulations, you can now start using your wireless access point.

Suggested Next Steps

In case of an error while installing, try the following troubleshooting procedures

described in this section:

Troubleshooting

If you cannot display the configuration utility, you can test the ability of the computer

to communicate with the device by using ping. To use ping on a computer running

Windows:

STEP 1Verify that the Cisco WAP371 is powered on and the lights indicate the

appropriate links.

STEP 2Locate the device’s IP address. While there are different ways to locate your

device’s IP address, this procedure uses Cisco FindIT.

a. If you have previously downloaded Cisco FindIT, open Internet

Explorer and launch Cisco FindIT. For more information on

downloading Cisco FindIT, see www.cisco.com/go/findit.

b. In the Cisco FindIT display, place your mouse over the device’s name.

The device IP address is displayed along with other device information.

STEP 3Open a command window by choosing Start > Run and enter cmd.

STEP 4At the command window prompt, enter ping and the device IP address. In

this example, we pinged 192.0.2.10.

If successful, you should get a reply similar to the following:

Pinging 192.0.2.10 with 32 bytes of data:

Reply from 192.0.2.10: bytes=32 time<1ms TTL=128

If it fails, you should get a reply similar to the following:

Pinging 192.0.2.10 with 32 bytes of data:

Request timed out.

Possible Cause of Installation Failure

Cisco Small Business WAP371 Series Wireless Access Point 9

Devices Cant Connect using Wi-Fi

• Complete the Setup Wizard. The Wi-Fi radio on the device is turned offbydefault,

and the Setup Wizard activates it. For users who do not want to use the Setup

Wizard, log into the device using a Category 5e Ethernet cable, and activate the

Wi-Fi radio manually. See the Administration Guide for details on activating the

Wi-Fi radio.

No Power

• Power up the switch and your computer if they are turned off.

• Make sure your PoE switch is powered on and the lights indicate that you have a

link. See “Verifying the Hardware Installation” on page 6.

• Verify that the devices on your network are not plugged into a switchable outlet.

Bad Ethernet Connection

• Check the state of the indicator lights. See “Verifying the Hardware Installation”

on page 6.

• Check the Ethernet cable to ensure that it is firmly connected to your devices.

Devices connected by the Ethernet cable can include the WAP device, and routers,

any switches, and your computer.

• Verify the connected switch has auto-negotiation enabled. The access point and

the switch need the same negotiation parameters set.

Bad Image

After a new firmware installation, if the Power light is flashing quickly, contact

system support; see “Where to Go From Here” on page 11.

Incorrect IP Address

The most likely cause of connectivity failure is an incorrect IP address. The Web

browser may be pointing to the wrong IP address, or your computer may be

configured with an IP address that is not in the same subnet as the device.

Because the factory default IP address configuration is DHCP, make sure that your

DHCP server is running and can be reached. You may need to disconnect and

reconnect the devices for them to discover their new IP addresses from the DHCP

server. You can then query the DHCP server for the new IP address. See Step 2 of

“Getting Started with the Configuration” on page 7 for more information on how to

find the DHCP address.

If the wireless access points do not receive a DHCP response (there is no DHCP

server on your network) after 60 seconds, the access points will fallback to the

following default static IP address: 192.168.1.245 and a default mask of

255.255.255.0. To reach that IP address, be sure that your computer is on the

192.168.1.xxx network.

10 Cisco Small Business WAP371 Series Wireless Access Point

Rebooting the Devices or Returning them to their

Factory Default Settings

To reboot your device:

• When the power supply is PoE, unplug your Ethernet connection for three seconds

and plug it back in.

• With the power on, press the Reset button with an opened paperclip for less than

three seconds, or until the lights go off.

– When all the lights go off, release the Reset button.

– Release the Reset button as soon as the lights go off, or you will restore the

device to factory default settings and lose your configurations.

To reset the device to factory default settings:

• With the power on, press and hold the Reset button with an opened paperclip for

more than 10 seconds.

– All of the lights will go off.

– Release the Reset button when the power light turns on.

Autres manuels pour WAP371

Table des matières

Langues :

Autres manuels Cisco Point d'accès sans fil

Cisco

Cisco Aironet 1600 Series Guide de référence rapide

Cisco

Cisco 1130AG - Aironet - Wireless Access Point Manuel utilisateur

Cisco

Cisco WAP2000 Mode d’emploi

Cisco

Cisco WAP571E Manuel utilisateur

Cisco

Cisco Aironet 1550 Series Manuel

Cisco

Cisco AIR-LAP1242AG-A-K9 Manuel utilisateur

Cisco

Cisco GR10-HW Manuel utilisateur

Cisco

Cisco Small Business WAP551 Mode d’emploi

Cisco

Cisco AIR-MP20B Manuel utilisateur

Cisco

Cisco Catalyst Wireless 9164I Series Manuel utilisateur

Cisco

Cisco WAP131 Manuel utilisateur

Cisco

Cisco WAP121 Manuel utilisateur

Cisco

Cisco Catalyst Wireless 9162I Series Manuel

Cisco

Cisco WAP121 Manuel utilisateur

Cisco

Cisco Aironet 521 Manuel utilisateur

Cisco

Cisco MERAKI MR66 Manuel utilisateur

Cisco

Cisco Aironet 1100 Series Manuel de l'opérateur

Cisco

Cisco Catalyst IW6300 Series Mode d’emploi

Cisco

Cisco Small Business WAP44 Mode d’emploi

Cisco

Cisco Meraki CW9162I-MR Manuel

Cisco

Cisco Aironet 1250 Series Manuel utilisateur

Cisco

Cisco M10-RM Guide de démarrage rapide

Cisco

Cisco Meraki Go GR60 Manuel utilisateur

Cisco

Cisco Linksys WAP54GX Instructions d'utilisation d'origine

Manuels Point d'accès sans fil populaires d'autres marques

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur

Draytek

Draytek VIGORAP 902 Manuel utilisateur
