Cisco WAP361 Manuel utilisateur

Quick Start Guide

Cisco WAP361 Wireless-AC/N Dual Radio Wall

Plate Access Point with PoE

2 Cisco WAP361 Quick Start Guide

Welcome

Thank you for choosing the Cisco WAP361 Wireless-AC/N Dual Radio Wall

Plate Access Point with PoE. The Cisco WAP361 is an indoor concurrent

dual-band radio 802.11ac and 802.11n access point with integrated PoE

switch. -PoE Supplied by UL Listed I.T.E.

This guide provides the general layout of the Cisco WAP361, describe

how to deploy the Cisco WAP361 in your network, and describe how to

configure the Cisco WAP361. For additional information, see

www.cisco.com/go/300_wap_resources.

Package Contents

•Wireless Access Point

•Mounting Kit

•This Quick Start Guide

•Ethernet Cable

•Technical Support Contact

•Pointer Card China RoHS

•EU Directives 1999/5/EC Compliance Information (for EU SKU only)

Before You Begin

Before you begin the installation, make sure that you have the following

equipment and services:

•A computer with browser support for:

– Internet Explorer 7.0 or later

– Chrome 5.0 or later

– Firefox 3.0 or later

– Safari 3.0 or later

•Tools for installing the hardware

•FindIt tool for locating the access point

•One or more Ethernet network switches with PoE

•Mobile devices (iPhone, Android, etc.) via wireless setup SSID.

(Configure via Wi-Fi mobile device with a web browser.)

Cisco WAP361 Quick Start Guide 3

Cisco WAP361 Features

Front Panel

The front panel of the Cisco WAP361 consists of one system LED. For full

descriptions of the colors of the lights and their indications, see “Verifying

the Hardware Installation”.

Back Panel

RESET—See “Rebooting the Cisco WAP361 or Resetting to Factory

Defaults” for information on the RESET button.

PD/LAN0—The Powered Device (PD/LAN0) port is used to power the

Cisco WAP361 using PoE.

Right-Side Panel

The right-side panel of the Cisco WAP361 has a Kensington lock slot. You

can use it to attach a cable and lock to the Cisco WAP361.

48V DC—The 48V DC jack is used to connect the power adapter to the

Cisco WAP361 if you are not using PoE.

Top Panel

The top panel of the Cisco WAP361 has the security screw hole.

Bottom Panel

PSE—The Power Sourcing Equipment (PSE) port is used to power the

device that is connected to the Cisco WAP361 through this port.

LAN1-4—The RJ-45 Ethernet port is an auto-sensing, Gigabit Ethernet

(802.3) port used to connect the Cisco WAP361 to network devices, such

as computers, routers, or switches. We strongly recommend that you use a

Category 5e or better cable for gigabit connectivity.

Default Settings

Parameter Default Value

Username cisco

Password cisco

LAN IP Address DHCP address assigned by server

Fallback LAN IP 192.168.1.245

Subnetwork Mask 255.255.255.0

4 Cisco WAP361 Quick Start Guide

If you are using a Cisco RV series router, the default range for the DHCP

assigned address is from 192.168.1.100 to 192.168.1.254. Any device

connecting to the same LAN will be assigned an IP address in this range.

Mounting the Cisco WAP361

•We recommend that you mount the Cisco WAP361 to a wall or junction

box.

Placement Tips

• Ambient Temperature—To prevent the Cisco WAP361 from

overheating, do not operate it in an area that exceeds an ambient

temperature of 104°F (40°C).

•AirFlow—Both side panels have vents that must be unobstructed to

prevent overheating.

• Mechanical Loading—The Cisco WAP361 should be level, stable, and

secure to prevent it from sliding or shifting out of position.

Wall Mounting

Cisco WAP361 access points can be mounted on walls and junction

boxes, in the vertical orientation with the security screw on the top and the

LED which is located above the Cisco logo.

Cisco WAP361 Quick Start Guide 5

STEP 1If you are mounting the AP directly to a junction box, go to Step 3.

For wall mounting, use the mounting bracket as a template to mark

the locations of the mounting holes on the bracket. Figure 1 shows

the dimensions of the mounting bracket.

CAUTION To ensure a safe and secure installation, make sure you are

using adequate screws and mount the access point using no

less than two screws.

Figure 1 Mounting Bracket Dimensions

6 Cisco WAP361 Quick Start Guide

STEP 2For wall mounting, drill four pilot holes at the mounting hole

locations you have marked (at opposite corners of the bracket),

and use appropriate anchors as required.

NOTE The pilot hole size varies according to the material, and its

thickness, you are fastening. Cisco recommends that you test the

material to determine the ideal hole size for your mounting

application.

STEP 3Feed the cable(s) from the junction box / wall through the large

center cable access hole in the bracket, with the words “NOTICE

WALL MOUNT ONLY” facing you as shown in Figure 2.

Figure 2 Bracket Mounting Direction

STEP 4Position the mounting bracket mounting holes (with the words

“NOTICE WALL MOUNT ONLY” facing you) over the screw holes.

STEP 5Insert a screw into each mounting hole and tighten.

NOTE Screws supplied in kit (see Figure 3) may not be appropriate

for

all

mounting options. You may need to obtain screws which fit

your custom installation.

Cisco WAP361 Quick Start Guide 7

Figure 3 Mounting Bracket Screw Dimensions

NOTE Make sure all cables are clear and the bracket sits flush

against the wall / junction box. The joint created with the screws

must have a minimum pullout force of 20 lbs (9 kg).

STEP 6Connect the Ethernet cable and the power cable (optional) to the

access point.

STEP 7With the access point’s LAN1-4 ports facing down and the rear

metal side of the access point facing the bracket, gently slide the

access point onto the bracket. If properly done, the Kensington

lock slot on the AP and the security screw hole on the mounting

bracket will be aligned.

STEP 8Insert the security screw (see Figure 4) into the hole on the top of

the access point and tighten it till the screw head is flush with the

access point's body (see Figure 2). The security screw is

provided in the Mounting Kit.

Figure 4 Security Screw Dimensions

All dimensions in millimeters (mm).

8 Cisco WAP361 Quick Start Guide

Connecting the Cisco WAP361

You can perform the initial configuration using either a wired or wireless

connection. The default configuration of the Cisco WAP361 has the Wi-Fi

radio turned on.

To connect the Cisco WAP361 to the wired network:

STEP 1Connect the Ethernet cable to the Ethernet port of a switch, a router,

or a PC.

STEP 2Connect the other end of the network Ethernet cable to the

Ethernet port of the Cisco WAP361.

STEP 3If PoE is not provided, plug in the supplied power adapter to

provide power to the Cisco WAP361.

This wireless default configuration will not allow traffic between WiFi and

Ethernet; users will need to go through the setup wizard to resume the

traffic between WiFi and Ethernet.

To connect the Cisco WAP361 to the network wirelessly:

STEP 1Use wireless clients to locate the WAP361’s SSID (CiscoSB-Setup).

STEP 2Use the ‘cisco123’ passkey to access the access point.

NOTE The system provides a one-time-only access to configure the

access point using a wireless connection.

After installation, all lights should be active. Refer to Verifying the

Hardware Installation for details about the different lights on the Cisco

WAP361.

Cisco WAP361 Quick Start Guide 9

Verifying the Hardware Installation

To verify the hardware installation, complete the following tasks:

•Check the cable connections.

•Check the state of the indicator light.

NOTE If you need help resolving a problem, visit the Cisco Support

Community at www.cisco.com/go/smallbizsupport.

Label Activity Description

Power Off The WAP361 is out of power.

Solid Green The Cisco WAP361 is normal; no wireless

client connected.

Solid Blue The Cisco WAP361 is normal; at least one

wireless client connected.

Solid Red The Cisco WAP361 fails to boot with both

firmware images.

Flashing Green The Cisco WAP361 is booting.

Flashing Blue Firmware upgrade is in progress.

LAN0-4 Off No Ethernet link.

Solid Green Gigabit Ethernet link is active.

Solid Amber Fast Ethernet link is active.

Flashing Transmitting or receiving data.

10 Cisco WAP361 Quick Start Guide

Getting Started with the Configuration

To configure the Cisco WAP361, follow these steps to access the the web-

based Configuration Utility and then the Setup Wizard from your computer:

STEP 1Connect the Cisco WAP361 to the same network (IP subnet) as your

computer. The factory default IP address configuration of the Cisco

WAP361 is DHCP. Make sure that your DHCP server is running and

can be reached.

See “Incorrect IP Address” for troubleshooting information, or if

you do not have a DHCP server.

STEP 2Locate the IP address of the Cisco WAP361.

a. The Cisco WAP361 can be accessed and managed by Cisco

network tools and services including the Cisco FindIT Network

Discovery Utility that enables you to automatically discover all

supported Cisco devices in the same local network segment

as your computer. You can get a snapshot view of each device

or launch the product configuration utility to view and

configure the settings. For more information, see

www.cisco.com/go/findit.

b. The Cisco WAP361 is Bonjour-enabled and automatically

broadcasts its services and listens for services being

advertised by other Bonjour-enabled devices. If you have a

Bonjour-enabled browser, such as Microsoft Internet Explorer

with a Bonjour plug-in, or the Apple Mac Safari browser, you

can find the Cisco WAP361 on your local network without

knowing its IP address.

You can download the complete Bonjour for Microsoft Internet

Explorer browser from Apple’s website by visiting:

http://www.apple.com/bonjour/

c. Locate the IP address assigned by your DHCP server by

accessing your router or DHCP server. See your DHCP server

instructions for more information.

STEP 3Launch a web browser, such as Microsoft Internet Explorer.

STEP 4In the address bar, enter the default DHCP address and press the

Enter key.

STEP 5Enter the default user name of cisco and password of cisco in the

Username and Password fields.

STEP 6Click Log In. The Wireless Access Point Setup Wizard appears.

Table des matières

Autres manuels Cisco Point d'accès sans fil

Cisco

Cisco Meraki MR20-HW Manuel utilisateur

Cisco

Cisco aironet 1524SB Instructions d'installation et d'utilisation

Cisco

Cisco Catalyst IW9167I Manuel

Cisco

Cisco VEN501 Manuel utilisateur

Cisco

Cisco AP541N-A-K9 Mode d’emploi

Cisco

Cisco AIR-BR1310G-A-K9 - Aironet 1310 Outdoor Access... Manuel

Cisco

Cisco AIR-AP1131G-A-K9 Manuel utilisateur

Cisco

Cisco WAP571 Mode d’emploi

Cisco

Cisco Meraki MR42 Manuel utilisateur

Cisco

Cisco AIR-BR1310G-A-K9-R - Aironet 1310 Outdoor Access... Manuel utilisateur

Cisco

Cisco MERAKI MR66 Manuel utilisateur

Cisco

Cisco Catalyst 9166 Series Manuel

Cisco

Cisco Aironet 2600 Series Manuel utilisateur

Cisco

Cisco 1130AG - Aironet - Wireless Access Point Manuel

Cisco

Cisco Catalyst 9117AX Series Manuel utilisateur

Cisco

Cisco Aironet 700W Series Manuel utilisateur

Cisco

Cisco Aironet 1700 Guide de référence rapide

Cisco

Cisco Meraki MR53E Manuel utilisateur

Cisco

Cisco AIR-AP1010 - 1000 Series Lightweight Access... Manuel utilisateur

Cisco

Cisco 3310 Mobility Services Engine Manuel utilisateur

Cisco

Cisco Aironet 1570 Series Manuel

Cisco

Cisco aironet 1522 Mode d’emploi

Cisco

Cisco Catalyst 9120AX Series Manuel utilisateur

Cisco

Cisco Aironet 1300 Series Manuel utilisateur

Manuels Point d'accès sans fil populaires d'autres marques

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur

Draytek

Draytek VIGORAP 902 Manuel utilisateur
