Cisco M SFS7000E Manuel d'installation et d'exploitation

Americas Headquarters:

Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA

Cisco M SFS7000E Installation Note:

InfiniBand Blade Switch for the Dell Modular

Server Chassis

This document provides instructions on how to install the Cisco M SFS7000E InfiniBand Switch in the

Dell Modular Server Chassis. The Dell Modular Server Chassis is a system that supports up to sixteen

server modules and up to four InfiniBand switches. You may install the InfiniBand switch in one of four

chassis I/O module bays on the rear panel of the server chassis.

Note There are six chassis I/O module bays on the rear panel of the server chassis. The InfiniBand switches

are supported in the middle four bays that are connected to Fabrics B and C.

For details about the number, types, and location of the module bays and for additional information about

the entire modular server system, see the documentation for the Dell PowerEdge Servers at

www.support.dell.com.

Contents

This publication includes the following sections:

•Safety Overview, page 2

•Parts List, page 3

•Switch Description, page 4

•I/O Module Bays and HCA Expansion Cards, page 5

•Pre-installation Guidelines, page 6

•Installing the Cisco M SFS7000E InfiniBand Switch, page 6

•Removing the Cisco M SFS7000E InfiniBand Switch, page 11

•Connecting InfiniBand Cables, page 11

•External LED Specifications, page 14

Cisco M SFS7000E Installation Note: InfiniBand Blade Switch for the Dell Modular Server Chassis 78-18371-01

Safety Overview

•External Network Management Requirements, page 15

•Warning Translation, page 16

•Related Documentation, page 21

•Obtaining Documentation, Obtaining Support, and Security Guidelines, page 22

Safety Overview

Safety warnings appear throughout this publication in procedures that, if performed incorrectly, may

harm you. A warning symbol precedes each warning statement.

Warning

During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly

touch the backplane with your hand or any metal tool, or you could shock yourself.

Statement 94

Warning

Voltage ispresentonthe backplane when thesystem isoperating.Toreduceriskof an electricshock,

keep hands and fingers out of the power supply bays and backplane areas.

Statement 166

Warning

Read the installation instructions before connecting the system to the power source.

Statement 1004

Warning

This unit is intended for installation in restricted access areas. A restricted access area can be

accessed only through the use of a special tool, lock and key, or other means of security.

Statement 1017

Warning

This equipment must be grounded. Neverdefeat the ground conductor or operate the equipmentin the

absence of a suitably installed ground conductor. Contact the appropriate electrical inspection

authority or an electrician if you are uncertain that suitable grounding is available.

Statement 1024

Warning

Only trained and qualified personnel should be allowed toinstall, replace, or service this equipment.

Statement 1030

Warning

IMPORTANT SAFETY INSTRUCTIONS

This warning symbol means danger. You are in a situation that could cause bodily injury. Before you

work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar

with standard practices for preventing accidents. Use the statement number provided at the end of

each warning to locate its translation in the translated safety warnings that accompanied this

device.

Statement 1071

SAVE THESE INSTRUCTIONS

Cisco M SFS7000E Installation Note: InfiniBand Blade Switch for the Dell Modular Server Chassis

78-18371-01

Parts List

Warning

Ultimate disposal of this product should be handled according to all national laws and regulations.

Statement 1040

Warning

Class 1M laser radiation when open. Do not view directly with optical instruments.

Statement 1053

Warning

Use of controls, adjustments, or performing procedures other than those specified may result in

hazardous radiation exposure.

Statement 1057

Parts List

This section describes the parts list. The Cisco M SFS7000E InfiniBand Switch package includes the

following parts:

•One Cisco M SFS7000E InfiniBand Switch

•One document titled Regulatory Compliance and Safety Information for the Cisco M SFS7000E

InfiniBand Blade Switch for the Dell Modular Server Chassis

•One document titled Cisco M SFS7000E Installation Note:

InfiniBand Blade Switch for the Dell Modular Server Chassis

•One warranty card

Cisco M SFS7000E Installation Note: InfiniBand Blade Switch for the Dell Modular Server Chassis 78-18371-01

Switch Description

This section describes the Cisco M SFS7000E InfiniBand Switch.

The Cisco M SFS7000E InfiniBand Switch (see Figure 1) connects to the mid-plane of the Dell Modular

Server Chassis and provides user-accessible rear-plane ports. The blade switches are installed in the

system I/O module bays in the rear of the chassis. Each switch has sixteen 4x ports facing the mid-plane

and eight 4x ports facing the exterior of the chassis. These ports drive Cisco- or Dell-approved DDR IB

cables.

Figure 1 Cisco M SFS7000E InfiniBand Switch

TX/RX

M SFS7000E

250396

Cisco M SFS7000E Installation Note: InfiniBand Blade Switch for the Dell Modular Server Chassis

78-18371-01

I/O Module Bays and HCA Expansion Cards

Within the Dell Modular Server Chassis unit, blade switches manage traffic to and from up to two HCA

IB mezzanine cards on the hosts. Each HCA IB mezzanine card adds two IB ports to a host. Each HCA

port connects through the unit mid-plane to a particular blade switch slot. The IB ports of the HCA card

that is seated in the HCA B location, connect to I/O module bays B1 and B2. The IB ports of the HCA

card that is seated in the HCA C location, connect to I/O module bays C1 and C2. See Figure 2 and

Table 1 for the location of the HCA cards and the corresponding I/O module bays.

For more details about the location of the HCA IB mezzanine card slots in the Dell Server Blade, see the

Dell PowerEdge M600 and M605 Hardware Owners Manual.

Figure 2 HCA Mezzanine Card Ports and Corresponding Switch I/O Module Bays

ell Server Blade

Chassis Rear - I/O Module Bays

B1 C1 C2 B2

185785

HCA C

HCA B

Port 2

Port 1

Port 2

Table 1 HCA Mezzanine Card Ports and Corresponding Switch I/O Module Bays

HCA Mezzanine Card HCA InfiniBand Port InfiniBand Switch I/O Module

Bay

B1B1

2B2

C1C1

2C2

Cisco M SFS7000E Installation Note: InfiniBand Blade Switch for the Dell Modular Server Chassis 78-18371-01

Pre-installation Guidelines

This section describes some pre-installation guidelines. Before you begin installation, complete the

following procedures:

•Ground yourself using an approved ground wrist strap.

•Make sure that you have the correct cables.

•Unpack the Cisco M SFS7000E InfiniBand Switch. Remove the packaging from around the switch.

Do not cut the packaging, as you could damage the switch. Save the box and packaging.

Note If you order the switches with the Dell Modular Server Chassis, the switches are already installed, and

no unpacking is required. The unpacking procedure applies only if you order a

Cisco M SFS7000E InfiniBand Switch, separately or without a chassis.

Installing the Cisco M SFS7000E InfiniBand Switch

This section describes how to install the Cisco M SFS7000E InfiniBand Switch.

The Cisco M SFS7000E InfiniBand Switch can be hot-swappedwhile the Dell 10G system (PowerEdge)

is online. When you install a switch, you do not need to power down the server chassis.

The Cisco M SFS7000E InfiniBand Switch fits into four different bays on the Dell Modular Server

Chassis. These bays connect to either fabric B or C. Each one of these fabrics connects to a mezzanine

card on each of the 16 server modules. The HCA is designed to reside in these mezzanine connectors.

Two switches may be used for each fabric in a non-blocking configuration. Multiple fabrics may be used

simultaneously for increased bandwidth.

Note Each bay into which a Cisco M SFS7000E InfiniBand Switch fits must contain either a switch or a blank

input/output module (IOM). When you remove a switch, you must either replace it with an identical

switch or a blank IOM within one minute of removal.

To install the Cisco M SFS7000E InfiniBand Switch in the Dell Modular Server Chassis, perform the

following steps:

Step 1 Select a chassis I/O module bay in which to install the switch. (See Figure 3 for the location of the I/O

module bays.)

If the HCA IB mezzanine card B is installed, you may install the Cisco M SFS7000E InfiniBand Switch

in I/O slots B1 and/or B2. If the HCA IB mezzanine card C is installed, you may install the

Cisco M SFS7000E InfiniBand Switch in I/O slots C1 and/or C2.

Cisco M SFS7000E Installation Note: InfiniBand Blade Switch for the Dell Modular Server Chassis

78-18371-01

Installing the Cisco M SFS7000E InfiniBand Switch

Figure 3 Chassis I/O Module Bays

Step 2 Remove the IOM blank from the selected bay, if it is present, and store it for future use.

250401

!!!!!!

12345

1Dell Modular Server Chassis 2I/O module B1

3I/O module C1 4I/O module C2

5I/O module B2

Cisco M SFS7000E Installation Note: InfiniBand Blade Switch for the Dell Modular Server Chassis 78-18371-01

Installing the Cisco M SFS7000E InfiniBand Switch

Step 3 Remove the connector cover from the switch, and save it for future use. (See Figure 4.)

Figure 4 Removing the Connector Cover

250398

Connector

cover

Cisco M SFS7000E Installation Note: InfiniBand Blade Switch for the Dell Modular Server Chassis

78-18371-01

Installing the Cisco M SFS7000E InfiniBand Switch

Step 4 Press the release latch upward so the switch handle springs open and is perpendicular to the module. (See

Figure 5.)

Figure 5 Switch Handle in Open Position

250397

TX/RX

M SFS7000E

1Release latch 2Switch handle

Cisco M SFS7000E Installation Note: InfiniBand Blade Switch for the Dell Modular Server Chassis 78-18371-01

Installing the Cisco M SFS7000E InfiniBand Switch

Step 5 Slide the switch completely into the selected bay until it stops, and then rotate the switch handle upward

until it is secured by the release latch.

Figure 6 shows the switch being inserted into the server chassis and the direction in which to rotate the

switch handle to secure it.

Figure 6 Inserting the Switch into the Server Chassis

250400

!!!!!!

TX/RX

M SFS7000E

TX/RX
