Q&A

Cisco Catalyst Express 500 Series Switches

General

Q. What are the Cisco Catalyst Express 500 Series Switches?

A. The Cisco®Catalyst®Express 500 Series Switches deliver networking tailored for businesses

with fewer than 250 employees. Powered by Cisco technology and managed through a GUI,

they are nonblocking, wire-speed, Layer 2-managed Fast Ethernet and Gigabit Ethernet

switches. The user-friendly GUI makes setting up, running, and troubleshooting networks

easy. Built-in Cisco Smartports with preset Cisco recommended network configurations,

quality of service (QoS), and security settings allow for transparent integration of data, video,

IP communications, and wireless LAN applications.

Table 1 gives descriptions of the switches.

Table 1. Cisco Catalyst Express 500 Series Descriptions

Product Name and Number Description

Cisco Catalyst Express

500-24TT (WS-CE500-24TT) Twenty-four 10/100 ports for desktop connectivity

Two 10/100/1 000BASE-T ports for uplink or server connectivity

Cisco Catalyst Express

500-24LC (WS-CE500-24LC) Twenty 10/100 ports for desktop connectivity

Four 10/100 Power over Ethernet (PoE) ports for desktop, wireless access

point, IP telephony, or closed circuit TV camera connectivity

Two 10/100/1 000BASE-T or Small Form-Factor Pluggable (SFP) ports for

uplink or server connectivity

Cisco Catalyst Express

500-24PC (WS-CE500-24PC) Twenty-four 10/100 PoE ports for desktop, wireless, IP telephony, or closed-

circuit TV camera connectivity

Two 10/100/1 000BASE-T or SFP ports for uplink or server connectivity

Cisco Catalyst Express

500G-12TC (WS-CE500G-12TC) Eight 10/100/1 000BASE-T and four 10/100/1 000BASE-T or SFP ports for

switch aggregation or server connectivity

Cisco Catalyst Express

500 spare Rack Mount Kit

(RCKMNT-CATEXP=)

Cisco Catalyst Express 500 spare Rack Mount Kit

Product Positioning

Q. How are the Cisco Catalyst Express 500 Series Switches positioned relative to the

Cisco Catalyst 2960 Series Switches?

A. The Cisco Catalyst 2960 Series Switches are entry-level enterprise switches, whereas Cisco

Catalyst Express 500 Series Switches are targeted at businesses with 20 to 250 employees.

Enterprise branch offices should be deploying Cisco Catalyst 3000 and 2960 Series Switches

because of the need to actively manage, upgrade, and configure a large number of devices.

Q&A

Technical Details

Management

Q. How do I manage the Cisco Catalyst Express 500 Series Switches?

A. The Cisco Catalyst Express 500 Series Switches can be managed either through the

embedded Device Manager or with Cisco Network Assistant, downloadable from the Cisco

Website at no charge: http://www.cisco.com/go/cna.

Q. Is there a command-line interface (CLI) on the Cisco Catalyst Express 500 Series

Switches?

A. No, these switches cannot be managed through a CLI.

Q. Are there plans to add a CLI or Telnet to Cisco Catalyst Express 500 Series Switches?

A. No, there are no plans to add a CLI or Telnet to these switches.

Q. Can Cisco Catalyst Express 500 Series Switches be remotely configured?

A. Yes, Cisco Catalyst Express 500 Series Switches can be remotely configured using the

embedded Device Manager or with Cisco Network Assistant.

Q. Can Cisco Catalyst Express 500 Series Switches be remotely monitored?

A. Yes, Cisco Catalyst Express 500 Series Switches can be remotely monitored using the

embedded Device Manager, the Cisco Network Assistant, or Simple Network Management

Protocol (SNMP)-capable applications using read-only MIBs.

Q. Do I have to accept the suggested Smartports role?

A. No, you can choose not to accept the suggested Smartports role.

Interoperability

Q. Will Cisco Catalyst Express 500 Series Switches interoperate with other Cisco

switches?

A. Yes, these switches interoperate with other Cisco switches.

Q. Will Cisco Catalyst Express 500 Series Switches interoperate with other vendors’

switches?

A. Yes, these switches interoperate with other vendors’ switches. You can apply Cisco

Smartports “switch” port role to the port, but it will not autosuggest a Smartports port role or

detect configuration errors.

Power

Q. Is there redundant-power-supply support on the Cisco Catalyst Express 500 Series

Switches

A. The Cisco Redundant Power System (RPS) 675 supports the Cisco Catalyst Express 500-

24PC only. It does not support the Cisco Catalyst Express 500-24TT, 500-24LC, or 500G-

12TC.

Q. Do Cisco Catalyst Express 500 Series Switches support the IEEE 802.3af inline power

standard and Cisco Prestandard Inline Power?

A. Yes, these switches support both IEEE 802.3af inline and Cisco Prestandard Inline Power.

Q&A

Q. Which ports support inline power on the Cisco Catalyst Express 500-24LC?

A. Ports 1 through 4 on the Cisco Catalyst Express 500-24LC can support up to 15.4 watts (W)

at the same time.

Q. What is the maximum power per port supported on the Cisco Catalyst Express 500-

24PC and the Cisco Catalyst Express 500-24LC?

A. For the Cisco Catalyst Express 500-24LC, each of the four PoE ports can support up to

15.4W per port. All four ports can supply 15.4W at the same time. For the Cisco Catalyst

Express 500-24PC, each of the twenty-four 10/100 ports can support up to 15.4W per port. All

24 ports can supply 15.4W at the same time. There is no need to do creative power budgeting

or worry about exceeding the power limit or adding an external power shelf.

Q. Do the Cisco Catalyst Express 500-24PC and 500-24LC support power management?

A. No, because the Cisco Catalyst Express 500-24PC and 500-24LC can support the IEEE

maximum of 15.4W on all PoE-capable ports simultaneously, power management is not

necessary on these switches.

Q. What are the power requirements of the Cisco Catalyst Express 500 Series Switches?

A. Table 2 lists the power requirements of the Cisco Catalyst Express 500 Series Switches.

Table 2. Power Requirements

Switch Model Power Consumption

(maximum) Power Dissipation Power Rating

Cisco Catalyst Express 500-

24TT (WS-CE500-24TT) 30W or 102 BTUs per hour 30W 0.050kVA

Cisco Catalyst Express 500-

24LC (WS-CE500-24LC) 110W or 375 BTUs per hour 45W 0.1 20kVA

Cisco Catalyst Express 500-

24PC

(WS-CE500-24PC)

460W or 1570 BTUs per hour 90W 0.460kVA

Cisco Catalyst Express

500G-12TC

(WS-CE500G-12TC)

45W or 154 BTUs per hour 45W 0.075kVA

Q. Why are some of the power dissipation numbers lower than the power consumption

numbers?

A. The difference between the power consumption number and the power dissipation number is

the amount of power dissipated in the powered end devices.

SFP Support

Q. Do the Cisco Catalyst Express 500 Series Switches support the Cisco Catalyst 3560

Small Form-Factor Pluggable (SFP) interconnect cable?

A. No, the Cisco Catalyst Express 500 Series Switches do not support the Cisco Catalyst 3560

SFP interconnect cable. Simply use the 10/100/1000BASE-T port to interconnect adjacent

switches.

Q. Which SFPs are supported on the Cisco Catalyst Express 500 Series Switches?

A. The Cisco Catalyst Express 500 Series Switches support the following Cisco SFPs:

●100BASE-BX-10D

●100BASE-BX-10U

●100BASE-FX-FE

Q&A

●100BASE-FX-GE

●100BASE-LX

●1000BASE-LX/LH

●1000BASE-SX

Q. Are the Cisco Coarse Wavelength-Division Multiplexing (CWDM) and Dense

Wavelength-Division Multiplexing (DWDM) SFPs supported on the Cisco Catalyst

Express 500 Series Switches?

A. No, the Cisco CWDM and DWDM SFPs are not supported.

Security

Q. What do the different levels of security mean in Cisco Catalyst Express 500 Series

Switches?

A. There are three levels of access security. The default level is Low.

●Low: Only one device, or one PC and IP phone, is allowed per port.

●Medium: Only authorized devices (via MAC address) are allowed on the network.

●High: Only authorized devices and authenticated users (via IEEE 802.1X) are allowed on

the network.

Software Updates

Q. How do I get a “no additional cost” Cisco IOS Software update for my Cisco Catalyst

Express 500 Series Switch?

A. Customers that own a software license for the Cisco Catalyst Express 500 series may obtain a

software update at the Cisco.com Website.

Go to http://tools.cisco.com/support/downloads/pub/MDFTree.x?butype=switches or from

http://www.cisco.com click “Downloads” and select “Switch Software.” To download software,

you will be required to log in using your Cisco.com username and password. If you do not

have a Cisco.com username, you can obtain one by clicking “Register” at the top of any

Cisco.com Webpage (http://tools.cisco.com/RPF/register/register.do).

Warranty and Service

Limited Lifetime Warranty

The hardware warranty available on Cisco Catalyst 3750-E, 3560-E, 3750, 3560, 3550, 2970,

2960, 2950, 2940, Express 500, and 3500 XL Series Switches is the Limited Lifetime Hardware

Warranty. This warranty automatically comes with the purchase of eligible Cisco Catalyst products,

free of charge. Additionally, it offers free advanced replacement of products within 10 business

days. For details about the Limited Lifetime Hardware Warranty, visit

http://www.cisco.com/univercd/cc/td/doc/es_inpck/lh2ben__.htm.

Q. What service and support are available for the Cisco Catalyst Express 500 Series

Switches?

A. Cisco is committed to minimizing total cost of ownership. The company offers a portfolio of

technical support services to help ensure that its products operate efficiently, remain highly

available, and benefit from the most up-to-date system software. The services and support

programs described in Table 3 (SMARTnet®) and Table 4 (SMBSA) are available as part of

Q&A

the Cisco Catalyst Express 500 Service and Support solution and are available directly from

Cisco and through resellers.

Table 3. SMARTnet Service and Support Programs

Service and Support Features Benefits

●Cisco SMARTnet, available direct

from Cisco

●Cisco Packaged SMARTnet support

program, available through resellers

●Access to software updates 24 hours

a day

●Web access to technical repositories

●Telephone support through the Cisco

Technical Assistance Center (TAC)

●Advance replacement of hardware

parts

●Supplements existing staff

●Helps ensure that functions meet

needs Mitigates risk

●Helps enable proactive or expedited

issue resolution

●Lowers total cost of ownership by

using Cisco expertise and knowledge

●Helps minimize network downtime

Table 4. SMBSA Service and Support Programs

Service and Support Features Benefits

●Cisco SMB Support Assistant direct

from Cisco

●Packaged Cisco SMB Support

Assistant support: available through

resellers

●24x7 service request (case): SMB

Technical Assistance Center (TAC)

engineers will respond within one

business day during normal business

hours

●Next business day advance

replacement of hardware, where

available; otherwise same day ship.

●Management tools designed for

SMBs: startup and configuration

assistance, basic health checks and

troubleshooting, inventory, and

contract management

●Lowers cost of ownership by using

Cisco expertise and knowledge

●Minimizes network downtime

Additional Product Information

Q. Where can I find product specifications and other information about the Cisco Catalyst

Express 500 Series Switches?

A. For product literature such as data sheets and product specifications, visit

http://www.cisco.com/go/catalystexpress500.

Printed in USA C67-350999-02 05/09

Autres manuels pour Catalyst Express 500-24LC

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Cisco Changer

Cisco

Cisco C9200L-24T-4X-A Manuel

Cisco

Cisco ENCS 5406-W Manuel utilisateur

Cisco

Cisco MGX 8850 Instructions d'utilisation et d'entretien

Cisco

Cisco 100 Series Manuel utilisateur

Cisco

Cisco Catalyst 4000 series Mode d’emploi

Cisco

Cisco SR2024 - Small Business Unmanaged Switch Manuel utilisateur

Cisco

Cisco Nexus 3400 Series Manuel

Cisco

Cisco SG 200-08P Manuel utilisateur

Cisco

Cisco Catalyst Express 500 Series Manuel utilisateur

Cisco

Cisco Catalyst 2960 Series Manuel utilisateur

Cisco

Cisco BPX-BXM-T3-12 Manuel utilisateur

Cisco

Cisco Catalyst Series Switch 2940 Manuel

Cisco

Cisco Catalyst 2960 Series Manuel d'utilisation

Cisco

Cisco Catalyst 4124 Instructions d'utilisation et de sécurité

Cisco

Cisco Small Business SF200-24P Manuel utilisateur

Cisco

Cisco 100 Series Manuel utilisateur

Cisco

Cisco SF 100D-05 Manuel utilisateur

Cisco

Cisco 500 Series Manuel utilisateur

Cisco

Cisco AP775A - Nexus Converged Network Switch 5010 Mode d’emploi

Cisco

Cisco Meraki MS350 Series Manuel utilisateur

Cisco

Cisco AJ732A - MDS 9134 Fabric Switch Mode d’emploi

Cisco

Cisco ME 3800X Manuel utilisateur

Cisco

Cisco Catalyst 2960 Series Manuel utilisateur

Cisco

Cisco Nexus 5000 Series Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
