Cisco Catalyst 3560-24PS Manuel utilisateur

A-1

Catalyst 3560 Switch Hardware Installation Guide

OL-6337-06

APPENDIX

Technical Specifications

•Table A-1 on page A-1, Environmental Ranges for all Catalyst 3560 Switches

•Table A-2 on page A-2, Technical Specifications for the Catalyst 3560-24PS Switch

•Table A-3 on page A-2, Specifications for the Catalyst 3560-48PS Switch

•Table A-4 on page A-3, Specifications for the Catalyst 3560-24TS-S Switch

•Table A-5 on page A-3, Specifications for the Catalyst 3560-48TS-S Switch

•Table A-6 on page A-3, Specifications for the Catalyst 3560-8PC and Catalyst 3560-12PC Switches

•Table A-7 on page A-4, Specifications for the Catalyst 3560G-24TS Switch

•Table A-8 on page A-4, Specifications for the Catalyst 3560G-24PS Switch

•Table A-9 on page A-5, Specifications for the Catalyst 3560G-48TS Switch

•Table A-10 on page A-5, Specifications for the Catalyst 3560G-48PS Switch

•Table A-11 on page A-5, Specifications for the Catalyst 3560V2-48PS and 3560V2-24PS Switch

•Table A-12 on page A-6, Specifications for the Catalyst 3560V2-48TS and 3560V2-24TS Switch

•Table A-13 on page A-6, Specifications for the Catalyst 3560V2-24TS-SD Switch

Table A-1 Environmental Ranges for all Catalyst 3560 Switches

Operating temperature 32 to 113°F (0 to 45°C)

Storage temperature –13 to 158°F (–25 to 70°C)

Relative humidity 10 to 85% (noncondensing)

Operating altitude Up to 10,000 ft (3049 m)

Storage altitude Up to 15,000 ft (4573 m)

A-2

Catalyst 3560 Switch Hardware Installation Guide

OL-6337-06

Appendix A Technical Specifications

Table A-2 Technical Specifications for the Catalyst 3560-24PS Switch

Power Requirements

AC input voltage 100 to 240 VAC (autoranging)

5.5 A to 2.8 A, 50 to 60 Hz

DC input voltage for RPS 675

12 V @7.5 A and –48 V @7.8 A

Maximum power consumption 485 W

Maximum power dissipation 115 W, 393 BTUs per hour

Power rating 0.485 KVA

Power over Ethernet

15.4 W per port maximum, 370 W switch maximum

Physical Dimensions

Weight 11.3 lb (5.14 kg)

Dimensions (H x D x W) 1.73 x 11.81 x 17.5 in. (4.39 x 30 x 44.45 cm)

Table A-3 Specifications for the Catalyst 3560-48PS Switch

Power Requirements

AC input voltage 100 to 240 VAC (autoranging)

5.5 to 2.8 A, 50 to 60 Hz

DC input voltages for RPS 675

12 V @7.5 A and –48 V @7.8 A

Maximum power consumption 530 W

Maximum power dissipation 160 W, 546 BTUs per hour

Power rating 0.53 KVA

Power over Ethernet

Range from 4 to 15.4 W per port, up to 370-W switch maximum

Physical Dimensions

Weight 13.2 lb (6 kg)

Dimensions (H x D x W) 1.73 x 14.85 x 17.5 in. (4.39 x 37.72 x 44.45 cm)

A-3

Catalyst 3560 Switch Hardware Installation Guide

OL-6337-06

Appendix A Technical Specifications

Table A-4 Specifications for the Catalyst 3560-24TS-S Switch

Power Requirements

AC input voltage 100 to 240 VAC (autoranging) 450 to 190 mA,

50 to 60 Hz

DC input voltages for RPS 675

12 V @ 5 A

Power consumption 45 W

Maximum power consumption 45 W, 154 BTUs per hour

Maximum power dissipation 0.075 KVA

Physical Dimensions

Weight 8.5 lb (3.9 kg)

Dimensions (H x D x W) 1.73 x 11.81 x 17.5 in. (4.39 x 30 x 44.45 cm)

Table A-5 Specifications for the Catalyst 3560-48TS-S Switch

Power Requirements

AC input voltage 100 to 240 VAC (autoranging)

650 to 270 mA, 50 to 60 Hz

DC input voltages for RPS 675

12 V @ 5 A

Maximum power consumption 65 W

Maximum power dissipation 65 W, 222 BTUs per hour

Power rating 0.110 KVA

Physical Dimensions

Weight 9.1 lb (4.1 kg)

Dimensions (H x D x W) 1.73 x 11.81 x 17.5 in. (4.39 x 30 x 44.45 cm)

Table A-6 Specifications for the Catalyst 3560-8PC and Catalyst 3560-12PC Switches

Power Requirements

AC input voltage 100 to 240 VAC (autoranging)

2.5 to 1.3 A, 50 to 60 Hz

Maximum power consumption 204 W

Maximum power dissipation 80 W, 12 BTUs per hour

Power rating 0.2 KVA

Power over Ethernet

Up to 124-W switch maximum

A-4

Catalyst 3560 Switch Hardware Installation Guide

OL-6337-06

Appendix A Technical Specifications

Physical Dimensions

Weight 5 lb (2.3 kg)

Dimensions (H x D x W) 1.73 x 9.1 x 10.6 in. (4.4 x 23 x 26.9 cm)

Table A-6 Specifications for the Catalyst 3560-8PC and Catalyst 3560-12PC Switches

Power Requirements

Table A-7 Specifications for the Catalyst 3560G-24TS Switch

Power Requirements

AC input voltage 100 to 240 VAC (autoranging)

1.5 to 3 A, 50 to 60 Hz

DC input voltages for RPS 675

12 V @10.5 A

Maximum power consumption 100 W

Maximum power dissipation 100 W, 314 BTUs per hour

Power rating 0.10 KVA

Physical Dimensions

Weight 12 lb (5.44 kg)

Dimensions (H x D x W) 1.73 x 14.9 x 17.5 in. (4.39 x 37.8 x 44.45 cm)

Table A-8 Specifications for the Catalyst 3560G-24PS Switch

Power Requirements

AC input voltage 100 to 240 VAC (autoranging)

4 to 8 A, 50 to 60 Hz

DC input voltages for RPS 675

12 V @14 A and –48 V @7.8 A

Maximum power consumption 520 W

Maximum power dissipation 170 W, 534 BTUs per hour

Power rating 0.52 KVA

Power over Ethernet

Range from 4 to 15.4 W per port, up to 370 W switch maximum

Physical Dimensions

Weight 13.5 lb (6.1 kg)

Dimensions (H x D x W) 1.73 x 14.9 x 17.5 in. (4.39 x 37.8 x 44.45 cm)

A-5

Catalyst 3560 Switch Hardware Installation Guide

OL-6337-06

Appendix A Technical Specifications

Table A-9 Specifications for the Catalyst 3560G-48TS Switch

Power Requirements

AC input voltage 100 to 240 VAC (autoranging)

3 to 1.5 A, 50 to 60 Hz

DC input voltages for RPS 675

12 V @17.5 A

Maximum power consumption 160 W

Maximum power dissipation 160 W, 500 BTUs per hour

Power rating 0.16 KVA

Physical Dimensions

Weight 14 lb (6.4 kg)

Dimensions (H x D x W) 1.73 x 16.1 x 17.5 in. (4.39 x 40.9 x 44.45 cm)

Table A-10 Specifications for the Catalyst 3560G-48PS Switch

Power Requirements

AC input voltage 100 to 240 VAC (autoranging)

4 to 8 A, 50 to 60 Hz

DC input voltages for RPS 675

12 V @14 A and –48 V @7.8 A

Maximum power consumption 560 W

Maximum power dissipation 220 W, 690 BTUs per hour

Power rating 0.56 KVA

Power over Ethernet

Range from 4 to 15.4 W per port, up to 370 W switch maximum

Physical Dimensions

Weight 15.5 lb (7.03 kg)

Dimensions (H x D x W) 1.73 x 16.1 x 17.5 in. (4.39 x 40.9 x 44.45 cm)

Table A-11 Specifications for the Catalyst 3560V2-48PS and 3560V2-24PS Switch

Environmental Ranges

Operating temperature 32 to 113°F (0 to 45°C)

Storage temperature –13 to 158°F (–25 to 70°C)

Relative humidity 10 to 85% (noncondensing)

Operating altitude Up to 10,000 ft (3049 m)

A-6

Catalyst 3560 Switch Hardware Installation Guide

OL-6337-06

Appendix A Technical Specifications

Storage altitude Up to 15,000 ft (4573 m)

Power Requirements

AC input voltage 100 to 240 VAC (autoranging)

4 to 8 A, 50 to 60 Hz

DC input voltages for

RPS 2300 and 675

+12V @14Aand–48V @7.8A

Power consumption 560 W

Power dissipation 220 W, 690 BTUs per hour

Power rating 0.56 kVA

Power over Ethernet

Range from 4 to 15.4 W per port, up to 370 W switch maximum

Physical Dimensions

Weight 11.3 lb (5.1 kg)

Dimensions (H x W x D) 1.73 x 17.5 x 11.8 in. (4.4 x 44.5 x 30.1 cm)

Table A-12 Specifications for the Catalyst 3560V2-48TS and 3560V2-24TS Switch

Environmental Ranges

Operating temperature 32 to 113°F (0 to 45°C)

Storage temperature –13 to 158°F (–25 to 70°C)

Relative humidity 10 to 85% (noncondensing)

Operating altitude Up to 10,000 ft (3049 m)

Storage altitude Up to 15,000 ft (4573 m)

Power Requirements

AC input voltage 100 to 240 VAC (autoranging)

0.8 to 1.5 A, 50 to 60 Hz

DC input voltages for

RPS 2300 and 675

+12 V @17 A

Power consumption 180 W, 615 BTUs per hour

Power rating 0.180 kVA

Physical Dimensions

Weight 8.5 lb (3.9 kg)

Dimensions (H x W x D) 1.73 x 11.81 x 17.5 in. (4.4 x 30 x 44.45 cm)

Table A-11 Specifications for the Catalyst 3560V2-48PS and 3560V2-24PS Switch (continued)

Environmental Ranges

A-7

Catalyst 3560 Switch Hardware Installation Guide

OL-6337-06

Appendix A Technical Specifications

Table A-13 Specifications for the Catalyst 3560V2-24TS-SD Switch

Environmental Ranges

Operating temperature 32 to 113°F (0 to 45°C)

Storage temperature –13 to 158°F (–25 to 70°C)

Relative humidity 10 to 85% (noncondensing)

Operating altitude Up to 10,000 ft (3049 m)

Storage altitude Up to 15,000 ft (4573 m)

Power Requirements

DC input voltage –36 to –72 VDC

3 to 1.5 A

Power consumption 94 W, 321 BTUs per hour

Physical Dimensions

Weight 9 lb (4.1 kg)

Dimensions (H x W x D) 1.73 x 17.5 x 11.8 in. (4.4 x 44.5 x 30.1 cm)

A-8

Catalyst 3560 Switch Hardware Installation Guide

OL-6337-06

Appendix A Technical Specifications
