Cisco Surveillance Media Server Mode d’emploi

Americas Headquarters:

Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA

Installing and Upgrading Cisco Video

Surveillance Media Server (VSMS)

Contents

This document provides the following information and instructions:

Installation and Initial Configuration:

1. Verify minimum system requirements—System Requirements, page 2

2. Understand general installation information—Before You Install, page 4

3. Obtain the VSMS software—Obtaining VSMS Software, page 3

4. Perform pre-installation procedures—Before You Install, page 4

5. Install J2SDK—Installing J2SE 1.4.2 SDK for Linux (all platforms), page 8

6. Install the VSMS software—Installing VSMS, page 9

7. Configure video repositories for archives and clips—Configuring VSMS,

page 10

System Requirements

Installing and Upgrading Cisco Video Surveillance Media Server (VSMS)

After installation:

8. (Recommended) Back up the VSMS configuration—Backing up VSMS,

page 10, and Restoring VSMS, page 11

9. (As needed) Upgrade VSMS to a new software release—Upgrading VSMS,

page 12

System Requirements

This section describes the requirements of the server and client systems on which

you install VSMS.

The server must meet the following minimum requirements:

• Hardware

–

Intel Celeron or Pentium, 1.7 GHz

–

1 GB DRAM

–

10 GB hard disk

• Operating System (one of the following):

–

Red Hat Enterprise 4 Update 2 (RHEL4)

–

SuSE Enterprise 9 Service Pack 3 (SLES9-SP3)

–

SuSE Enterprise 10 Service Pack 1 (SLES10-SP1)

–

SuSE Enterprise 10 Service Pack 1 64-bit (SLES10-SP1-64)

• Software License Key

–

Obtain a VSMS license key by contacting [email protected]

A client PC must meet the following minimum requirements:

• Hardware

–

1.7 GHz Pentium III if running 1 video window

–

1.7 GHz Pentium 4 if running 2 video windows

–

3.2 GHz Pentium 4 with hyperthreading enabled if running 4 video

windows

–

1 GB DRAM

Installing and Upgrading Cisco Video Surveillance Media Server (VSMS)

Installation Notes

–

ATI or Nvidia DirectX 9 compatible graphics interface. The graphics

interface and Drivers must support DirectX Acceleration, Direct3D

Acceleration, and AGP texture acceleration and have at least 128 MB of

video memory.

• Operating system:

–

Microsoft Windows XP SP2 (32-bit)

• Software:

–

Microsoft Internet Explorer 6.0

–

Microsoft DirectX 9.0c

Installation Notes

• The Pegasus MJPEG video decoder is installed automatically with the VSMS

client.

• Cisco recommends that you use NTP source to maintain the correct time on

the server. Configuring NTP should be done before video recording is

configured. The hardware clock should be set to use UTC time and the

appropriate time zone for the server. If you are using SUSE, you can use YaST

to configure the server time.

• The performance of client devices can vary depending on client configuration

and applications.

Obtaining VSMS Software

The VSMS software is available from

http://tools.cisco.com/support/downloads/pub/Redirect.x?mdfid=281550158

You must log in to the Cisco website to access the software. Select the Cisco

Video Surveillance Media Server Software software version for the appropriate

for your Linux version.

Before You Install

Installing and Upgrading Cisco Video Surveillance Media Server (VSMS)

Before You Install

Before you install VSMS, you must configure the video repositories and install

all software pre-requisites.

Preparing Video Repositories

Video that is recorded by VSMS is stored in repositories on storage volumes that

are dedicated for recording video by VSMS. The repositories must be separate

partitions from the operating system partitions. Network attached storage, such as

NFS or CIFS volumes are not supported.

To create a repository, partition and format a storage volume, then configure the

operating system to access the partition.

Each repository has a mount point to specify the path through which the files are

accessed. The common convention for naming repositories is "/media#," with

/media0 used for a repository on the operating system volume, and /media1 -

/mediaN used for additional storage volumes.

Repository Greater than 2 TiB

To create partitions greater than 2 TiB, the volume must use a GPT partition table

and must be a different storage volume from the operating system volume. The

GPT partition table does not work on the boot volume.

Note The following steps erase the partition table on the specified volume, which

deletes all data on the volume.

Procedure

Step 1 Login to the VSMS server and follow these steps to create a partition GPT table

on the volume:

linux:~ # parted -- /dev/<device> mklabel gpt

Replace <device> with the volume device name, such as /dev/sdb.V

Installing and Upgrading Cisco Video Surveillance Media Server (VSMS)

Before You Install

Step 2 Verify that the volume is using the correct partition type:

linux:~ # parted -- /dev/sdb print

Disk geometry for /dev/sdb: 0kB - 10TB

Disk label type: gpt

Number Start End Size File system Name Flags

Information: Do not forget to update /etc/fstab, if necessary.

Make sure that the disk label type is set to GPT. After creating the GPT partition

table, use the standard following methods for partitioning and formatting the

partitions.

Creating Partitions

Creating partitions in SLES9-SP3 & SLES10-SP1

Use the SUSE YaST to partition, format, and configure repositories. If any of the

volumes are greater than 2TiB you must first follow the steps above to create a

GPT partition table on each volume. Cisco recommends using the XFS file system

for optimal video recording performance.

Procedure

Step 1 Open the YaST Control Center.\

Step 2 Navigate to System, Partitioner.

Step 3 Enter Yes to create new partitions as required for video storage. The creation

process may take some time.

Step 4 Choose Create and set the FileSystem = XFS and MountPoint = /media#.

Step 5 Choose Apply, Finish, Quit, and Quit.

Step 6 Change ownership of the mounted partitions to nobody.nobody.

shell> chown nobody.nobody /media1

Before You Install

Installing and Upgrading Cisco Video Surveillance Media Server (VSMS)

Creating partitions in Red Hat Enterprise 4

Open a shell session and run the following commands to create a repository. The

Ext3 file system should be used to format the repository.

Procedure

Step 1 Create new partitions:

Shell> parted -- /dev/sdb mkpart primary ext3 0 -0

Step 2 Use mkfs to make the partitions:

Shell> mkfs -t ext3 /dev/sdb1

Note: This command destroys all data that resides on that partition.

Step 3 Create a new directory.

shell> mkdir /media1

Note: Each volume needs a unique directory for a mount point.

Step 4 Add a new line to /etc/fstab, substituting the appropriate device name and mount

point:

dev/sdb1 /media1 ext3 defaults 1 2

Step 5 Mount the newly created partitions. (Usage: mount /dev/sdb1 /media1.)

Step 6 Change ownership of the mounted partitions to nobody.nobody:

shell> chown nobody: /media1

Installing and Upgrading Cisco Video Surveillance Media Server (VSMS)

Before You Install

Software Prerequisites

In additional to the default SUSE or Red Hat installation, the following software

packages are required. Unless otherwise indicated, all packages are provided by

the operating system, refer to the media from the operating system vendor to

locate the necessary files.

• All platforms

–

Sun J2SE 1.4.2 SDK

–

db1

–

libelf

–

sysstat

• SLES10-SP1-64

–

libelf-32-bit

• RHEL4

–

perl-Digest-SHA1

–

perl-Digest-HMAC

–

perl-Net-SNMP1

–

perl-Crypt-DES 1

–

perl-Socket6 1

1. These packages are not provided by Red Hat. Compatible versions can be found on

the Internet.

Installing J2SE 1.4.2 SDK for Linux (all platforms)

Installing and Upgrading Cisco Video Surveillance Media Server (VSMS)

Installing J2SE 1.4.2 SDK for Linux (all platforms)

VSMS uses the Sun Java SDK 1.4.2. Follow these steps to download and install

this package before you install VSMS.

Procedure

Step 1 Download Java 2 SDK, Standard Edition, v. 1.4.2 from the Sun Microsystems

website at http://java.sun.com/j2se/1.4.2/download.html. Although the version

must be version 1.4.2, the build number may vary. The downloaded filename is

similar to j2sdk-1_4_2_19-linux-i586-rpm.bin, adjust the commands in the

following steps if your file name is different.

Step 2 Copy the downloaded file to the VSMS server.

Step 3 On the VSMS server, extract the J2SDK .rpm file with the command:

shell> sh <filename>

This process creates a new file

Step 4 Agree to the license as applicable.

Step 5 Install the extracted J2SDK rpm file with the command:

shell> rpm -ivh <filename>

Step 6 Create symbolic link /usr/java/java to the installed J2SDK for VSMS as follows:

shell> cd /usr/java

shell> ln -s j2sdk1.4.2_19 java

Step 7 Verify the symbolic link with the command:

shell> ls -l /usr/java/

total 0

drwxr-xr-x 8 root root 376 Sep 26 10:15 j2sdk1.4.2_19

lrwxrwxrwx 1 root root 13 Sep 26 10:16 java -> j2sdk1.4.2_19

Installing and Upgrading Cisco Video Surveillance Media Server (VSMS)

Installing VSMS

Copy the downloaded .zip file with the VSMS software to the server and then

follow these steps:

Procedure

Step 1 Extract the contents of the downloaded .zip file. Cisco recommends that you

create a directory for the extracted contents.

shell> mkdir vsms-6.1.0

shell> unzip Cisco_VSMS-6.1.0-xx-xxxxx.zip -d vsms-6.1.0

Step 2 Verify that all files are present:

shell> cd vsms-6.1.0

shell> ls -1

Cisco_VSBase-6.1.0-xx-xxxxx-i686.rpm

Cisco_VSBWT-6.1.0-xx-xxxxx-i686.rpm

Cisco_VSDocs-6.1.0-xx-noarch.rpm

Cisco_VSDrivers-6.1.0-xx-xxxxx-i686.rpm

Cisco_VSMS-6.1.0-xx-xxxxx-i686.rpm

Cisco_VSRecorder-6.1.0-xxxxx-sp3-i686.rpm

Cisco_VSVM-6.1.0-xx-xxxxx.i586.rpm

Cisco_VSTools-6.0.0-noarch.rpm

Step 3 Install each of VSMS .rpm file:

shell> rpm -ivh Cisco_VSBase-6.1.0-xx-xxxxx-i586.rpm

shell> rpm -ivh Cisco_VSRecorder-6.1.0-xx-xxxxx-i586.rpm

shell> rpm -ivh Cisco_VSMS-6.1.0-xx-xxxxx-i586.rpm

shell> rpm -ivh Cisco_VSDrivers-6.1.0-xx-xxxxx-i586.rpm

shell> rpm -ivh Cisco_VSBWT-6.1.0-xx-xxxxx-i586.rpm

shell> rpm -ivh Cisco_VSDocs-6.1.0-xx-xxxxx-i586.rpm

shell> rpm -ivh Cisco_VSTools-6.0.0-noarch.rpm

Configuring VSMS

Installing and Upgrading Cisco Video Surveillance Media Server (VSMS)

Configuring VSMS

After you install VSMS, perform the following steps to use the Management

Console (VSMC) to set repositories for archives, clips and events. The VSMC

authentication information is:

Userid: root

password: secur4u

Procedure

Step 1 Open a web browser from a Windows PC and enter http://<server name/IP

address>/vsmc.html.

Step 2 Click the Media Server link to access the VSMS configuration. You are prompted

to authenticate.

Step 3 Enter the license key on the VSMS configuration page.

Step 4 Check the Local Archives Repositories check box.

Step 5 Click Update.

Step 6 Click Restart Server, Restart Now, and Verify.

Backing up VSMS

After configuring VSMS, you can back up the VSMS configuration.

Procedure

Step 1 In a web browser, open http://<Server HostName>/vsmc.html and navigate to the

Encoding Server Backup on the Console page.

Step 2 Click Download.

Step 3 When prompted, save the .tar file to a secure directory.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Cisco Logiciel

Cisco

Cisco TELEPRESENCE MANAGEMENT SUITE EXTENSION 2.2 - FOR MICROSOFT... Manuel de service

Cisco

Cisco 2600 Series Comment utiliser

Cisco

Cisco 2509 - Router - EN Manuel utilisateur

Cisco

Cisco PVDM2 24DM - Digital Modem Module Manuel utilisateur

Cisco

Cisco TELEPRESENCE MOVI 4.1 - FOR MAC OS X Manuel utilisateur

Cisco

Cisco TELEPRESENCE MANAGEMENT SUITE EXTENSION - INSTALLATION GUIDE FOR IBM LOTUS NOTES... Manuel utilisateur

Cisco

Cisco CSACSE-1111-K9 - Secure Access Control Server Solution... Manuel utilisateur

Cisco

Cisco OL-10426-01 Manuel utilisateur

Cisco

Cisco DCNM Guide rapide

Cisco

Cisco CRS-1 Series Manuel utilisateur

Cisco

Cisco Servers Manuel utilisateur

Cisco

Cisco IP Communicator Manuel utilisateur

Cisco

Cisco Unified MeetingPlace H.323/SIP Manuel de service

Cisco

Cisco TMS SQL DATABASE Manuel utilisateur

Cisco

Cisco Unified Contact Center Express Manuel utilisateur

Cisco

Cisco CRS-1 - Carrier Routing System Router Mode d’emploi

Cisco

Cisco CiscoWorks 1105 Manuel utilisateur

Cisco

Cisco WS-SUP32-GE-3B - Supervisor Engine 32 Manuel utilisateur

Cisco

Cisco DVD-ROM Manuel d'installation et d'exploitation

Cisco

Cisco TELEPRESENCE MOVI 4.1 - ADMINISTRATOR GUIDE... Manuel de service

Cisco

Cisco TELEPRESENCE MANAGEMENT SUITE EXTENSION - FOR IBM LOTUS NOTES... Manuel utilisateur

Cisco

Cisco XO Manuel utilisateur

Cisco

Cisco TELEPRESENCE MANAGEMENT SUITE EXTENSION 2.2 - FOR MICROSOFT... Manuel utilisateur

Cisco

Cisco ASA5500-SC-5= - ASA 5500 Security Context Manuel utilisateur

Manuels Logiciel populaires d'autres marques

COMPRO

COMPRO COMPROFM Manuel utilisateur

Muratec

Muratec OFFICEBRIDGE ONLINE Manuel utilisateur

Oracle

Oracle Contact Center Anywhere 8.1 Manuel utilisateur

Adobe

Adobe 65007312 - Photoshop Lightroom Manuel

Avaya

Avaya NULL One-X for RIM Blackberry Manuel utilisateur

HP ProLiant BL420c Manuel utilisateur

PS Audio

PS Audio PowerPlay Manuel du propriétaire

Brady

Brady LOCKOUT PRO 3.0 Manuel de service

Avaya

Avaya Interaction Center Manuel utilisateur

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuel

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuel utilisateur

Oracle

Oracle Application 9i Manuel utilisateur

Acer

Acer RDM Manuel utilisateur

Canon

Canon Vixia HF21 Manuel utilisateur

Canon

Canon ZR950 Manuel utilisateur

Samsung

Samsung Auto Backup Manuel utilisateur

Polycom

Polycom Vortex EF2201 Instructions d'installation et d'utilisation

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuel utilisateur
