Cisco Web Security Appliance S195, S395, S695,

and S695F Getting Started Guide

Contents

Welcome

Published: June 7, 2019

Welcome

Document Network Settings

Plan the Installation

Temporarily Change Your IP Address for Remote Access

Connect to the Appliance

Run the System Setup Wizard

Check for Available Upgrades

Configure Network Settings

Configuration Summary

Additional Configurations

Related Documentation

Cisco Notification Service

Cisco Web Security Appliance S195, S395, S695, and S695F (WSA) helps organizations secure and

control web traffic. This guide describes how to setup your appliances and use the System Setup

Wizard to configure basic settings for the appliance. You can also refer to the “Deployment” chapter

in the AsyncOS for Cisco Web Security Appliances User Guide for information about how to configure

appliance settings.

Cisco Web Security Appliance S195, S395, S695, and S695F Getting Started Guide

Document Network Settings

Before you begin, write down the following information about your network and administrator settings.

Deployment Options

Web Proxy:

–

Transparent with L4

–

Switch Transparent with

WCCP Router

–

Explicit Forward Proxy

L4 Traffic Monitor:

•Simplex tap/Span port

•Duplex tap/Span port

Network Context

Is there another proxy on the

network:

Other Proxy IP Address:

Other Proxy Port:

Network Settings

Default System Hostname:

DNS Servers: Use the Internet root DNS servers.

Use the DNS servers (maximum 3):

Network Time Protocol (NTP)

Server:

Time Zone Region:

Time Zone Country:

Time Zone GMT Offset:

Cisco Web Security Appliance S195, S395, S695, and S695F Getting Started Guide

Document Network Settings

Interface Settings

Management Port

IP Address:

Network Mask:

Hostname:

Data Port (Optional, see Note)

IP Address:

Network Mask:

Hostname:

Note The Web Proxy can share the management interface. If configured separately, the Data

interface IP address and the management interface IP address cannot share the same subnet.

Routes

Internal Routes for Management

Default Gateway:

Static Route Name:

Static Route Destination Network:

Static Route Gateway:

Internal Routes for Data

Default Gateway:

Static Route Name:

Static Route Destination Network:

Static Route Gateway:

Cisco Web Security Appliance S195, S395, S695, and S695F Getting Started Guide

Document Network Settings

Transparent Routing Device

Device Type: •Layer 4 Switch or No Device

•WCCP Router

–

Enable standard service ID

(web-cache).

–

Router Addresses:

_________________

–

Enable router security.

Password:

_________________

Note When you connect the appliance to a WCCP router, you might need to configure the Web

Security appliance to create WCCP services after you run the System Setup Wizard.

Administrative Settings

Administrator Password:

Email System Alerts To:

SMTP Relay Host: (Optional)

AutoSupport: Enable

SenderBase Network

Participation:

Enable

•Limited

•Standard

Security Services

L4 Traffic Monitor: •Monitor only

•Block

Acceptable Use Controls: Enable

•Cisco IronPort Web Usage Controls

Web Reputation Filters: Enable

Malware and Spyware Scanning: •Enable Webroot

•Enable McAfee

•Enable Sophos

Action for Detected Malware: •Monitor only

•Block

IronPort Data Security Filtering: Enable

Locking Faceplate

4-digit code (for the S695-LKFP

appliance)

Cisco Web Security Appliance S195, S395, S695, and S695F Getting Started Guide

Plan the Installation

Decide how you are going to configure the Cisco Web Security Appliance within your network.

The Cisco Web Security Appliance is typically installed as an additional layer in the network between

clients and the Internet. Depending on how you deploy the appliance, you may or may not need a Layer

4 (L4) switch or a WCCP router to direct client traffic to the appliance.

Deployment options include:

•Transparent Proxy – Web proxy with an L4 switch

•Transparent Proxy – Web proxy with a WCCP router

•Explicit Forward Proxy – Connection to a network switch

•L4 Traffic Monitor – Ethernet tap (simplex or duplex)

–

Simplex Mode: Port T1 receives all outgoing traffic, and port T2 receives all incoming traffic.

–

Duplex Mode: Port T1 receives all incoming and outgoing traffic.

Note See “Connect to the Appliance” section on page 7 for more information about individual ports on the

appliance.

Note To monitor true client IP addresses, the L4 traffic monitor should always be configured inside the

firewall and before NAT (Network Address Translation).

If your installation includes multiple Cisco Web Security Appliances (S-Series) or Cisco Email Security

Appliances (C-Series), you may want to also use a Cisco Content Security Management Appliance

(M-Series) to manage them, as show in the following network diagram:

Cisco Web Security Appliance S195, S395, S695, and S695F Getting Started Guide

Temporarily Change Your IP Address for Remote Access

To remotely configure the appliance using the network connection, you must temporarily change the

IP address of your computer.

Note Make a note of your current IP configuration settings as you will need to revert to these settings after

you finish the configuration.

Alternatively, you can use the serial console to configure the appliance, without changing the IP address.

If you use the serial console, see Connect to the Appliance, page 7.

Temporarily Change Your IP Address on Windows

Note The exact steps depend on the version of your operating system.

Procedure

Step 1 Connect your laptop to the primary Management Port (labeled M1) using the cross over or Ethernet cable

included in the system box. The Cisco Web Security Appliance uses the M1 Management port only. See

“Plan the Installation” section on page 5.

Step 2 Go to the Start menu and choose Control Panel.

Step 3 Double-click Network and Sharing Center.

Cisco Web Security Appliance S195, S395, S695, and S695F Getting Started Guide

Connect to the Appliance

Step 4 Click Local Area Connection and then click Properties.

Step 5 Choose Internet Protocol (TCP/IP) and then click Properties.

Step 6 Choose Use the Following IP Address.

Step 7 Enter the following changes:

–

IP Address: 192.168.42.43

–

Subnet Mask: 255.255.255.0

–

Default Gateway: 192.168.42.1

Step 8 Click OK and Close to exit the dialog box.

Temporarily Change Your IP Address on Mac

Note The exact steps depend on the version of your operating system.

Procedure

Step 1 Launch the Apple menu and choose System Preferences.

Step 2 Click Network.

Step 3 Click lock icon to allow changes.

Step 4 Select the Ethernet network configuration with the green icon. This is your active connection. Then click

Advanced.

Step 5 Click the TCP/IP tab and from Ethernet settings, choose Manually from the drop-down list.

Step 6 Enter the following changes:

–

IP Address: 192.168.42.43

–

Subnet Mask: 255.255.255.0

–

Router: 192.168.42.1

Step 7 Click OK.

Connect to the Appliance

After rack-mounting the appliance, follow these steps to connect cables, turn on power, and verify

connectivity.

•Cisco S195 Appliance, page 8

•Cisco S395 Appliance, page 9

•Cisco S695 Appliance, page 10

•Cisco S695F Appliance, page 12

Cisco Web Security Appliance S195, S395, S695, and S695F Getting Started Guide

Connect to the Appliance

Note The connection diagram in each topic shows the default configuration using a management computer

connected to your private network. Your deployment may vary depending on your basic logical network

connectivity, ports, addressing, and configuration requirements.

Cisco S195 Appliance

Step 1 Plug one end of the straight power cable into the power supply on the back panel of the appliance.

Note It is optional to order a separate power cable and connect to the second power supply at the back

panel of the appliance for redundancy.

Step 2 Plug the other end into an electrical outlet.

Step 3 Plug the Ethernet cables into the appropriate ports on the back panel of the appliance.

•The proxy ports are labeled P1 and P2.

–

P1 only enabled: When only P1 is enabled, connect it to the network for both incoming and

outgoing traffic.

–

P1 and P2 enabled: When both P1 and P2 are enabled, you must connect P1 to the internal

network and P2 to the internet.

•The traffic monitor ports are labeled T1 and T2.

–

Simplex tap: Ports T1 and T2; one cable for all packets destined for the internet (T1) and one

cable for all packets coming from the internet (T2).

–

Duplex tap: Port T1; one cable for all incoming and outgoing traffic.

Step 4 Connect your laptop to the Management port (M1) using the Ethernet cable included in the system box.

Step 5 Power up the appliance by pressing the On/Off switch on the front panel of the appliance. You must

wait 10 minutes for the system to initialize each time you power up the system. After the appliance

powers up, a solid green light on the front panel indicates that the appliance is operational.

1 Management port (M1) - (192.168.42.42) 2 Management computer (192.68.42.43)

3 Traffic monitor port 1 (T1) 4 WAN modem

5 Internet

Cisco Web Security Appliance S195, S395, S695, and S695F Getting Started Guide

Connect to the Appliance

Caution If you turn the power off before the initialization is complete, the appliance will not reach an operational

state and must be returned to Cisco.

Note If turned on quickly after connecting power to the appliance, the appliance powers up, the fans spin and

the LEDs turn on. Within 30-60 seconds, the fans stop and all LEDs turn off. The appliance powers on

31 seconds later. This behavior is by design to allow the system firmware and controller to synchronize.

Step 6 See the AsyncOS for Cisco Web Security Appliances User Guide for further configuration.

Cisco S395 Appliance

Step 1 Plug one end of each straight power cable into the redundant power supplies on the back panel of the

appliance.

Step 2 Plug the other end into an electrical outlet.

Step 3 Plug the Ethernet cables into the appropriate ports on the back panel of the appliance.

•The proxy ports are labeled P1 and P2.

–

P1 only enabled: When only P1 is enabled, connect it to the network for both incoming and

outgoing traffic.

–

P1 and P2 enabled: When both P1 and P2 are enabled, you must connect P1 to the internal

network and P2 to the internet.

•The traffic monitor ports are labeled T1 and T2.

–

Simplex tap: Ports T1 and T2; one cable for all packets destined for the internet (T1) and one

cable for all packets coming from the internet (T2).

–

Duplex tap: Port T1; one cable for all incoming and outgoing traffic.

Step 4 Connect your laptop to the Management port using the Ethernet cable included in the system box. The

S-Series appliance uses the M1 Management port only.

Cisco Web Security Appliance S195, S395, S695, and S695F Getting Started Guide

Connect to the Appliance

Step 5 Power up the appliance by pressing the On/Off switch on the front panel of the appliance. You must

wait 10 minutes for the system to initialize each time you power up the system. After the appliance

powers up, a solid green light on the front panel indicates that the appliance is operational.

Caution If you turn the power off before the initialization is complete, the appliance will not reach an operational

state and must be returned to Cisco.

Note If turned on quickly after connecting power to the appliance, the appliance powers up, the fans spin and

the LEDs turn on. Within 30-60 seconds, the fans stop and all LEDs turn off. The appliance powers on

31 seconds later. This behavior is by design to allow the system firmware and controller to synchronize.

Step 6 See the AsyncOS for Cisco Web Security Appliances User Guide for further configuration.

Cisco S695 Appliance

Step 1 Plug one end of each straight power cable into the redundant power supplies on the back panel of the

appliance.

Step 2 Plug the other end into an electrical outlet.

Step 3 Plug the Ethernet cables into the appropriate ports on the back panel of the appliance.

•The proxy ports are labeled P1 and P2.

–

P1 only enabled: When only P1 is enabled, connect it to the network for both incoming and

outgoing traffic.

–

P1 and P2 enabled: When both P1 and P2 are enabled, you must connect P1 to the internal

network and P2 to the internet.

•The traffic monitor ports are labeled T1 and T2.

–

Simplex tap: Ports T1 and T2; one cable for all packets destined for the internet (T1) and one

cable for all packets coming from the internet (T2).

–

Duplex tap: Port T1; one cable for all incoming and outgoing traffic.

Step 4 Connect your laptop to the Management port using the Ethernet cable included in the system box.

1 Management Port (M1) - (192.168.42.42) 2 Management Computer (192.168.42.43)

3 Traffic Monitor Port 1 (T1) 4 WAN Modem

5 Internet

Autres manuels pour S195

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Cisco Serveur

Cisco

Cisco UCS B440-M1 Manuel utilisateur

Cisco

Cisco UCS B200 M3 Manuel

Cisco

Cisco UCS C220 M4 Instructions de montage

Cisco

Cisco UCS E Series Manuel utilisateur

Cisco

Cisco UCS B200 Manuel

Cisco

Cisco TelePresence Manuel de service

Cisco

Cisco TelePresenceMCU 5300 Series Manuel utilisateur

Cisco

Cisco AS5800 Manuel utilisateur

Cisco

Cisco UCS C260 M2 Manuel utilisateur

Cisco

Cisco SCE 8000 10GBE Manuel utilisateur

Cisco

Cisco UCS B200 M4 Manuel utilisateur

Cisco

Cisco UCS C24 Instructions d'installation et d'entretien

Cisco

Cisco UCS C240 M4 Instructions d'installation et d'entretien

Cisco

Cisco UCS C240 M5 Instructions d'installation et d'entretien

Cisco

Cisco MSE 3365 Manuel utilisateur

Cisco

Cisco AS5300 - Universal Access Server Manuel utilisateur

Cisco

Cisco UCS 6500 Series Manuel utilisateur

Cisco

Cisco UCS C240 M4 Instructions d'installation et d'entretien

Cisco

Cisco SNS-3415 series Manuel de programmation

Cisco

Cisco TelePresence Manuel utilisateur

Cisco

Cisco UCS B200 Manuel utilisateur

Cisco

Cisco UCS B440 M2 Manuel utilisateur

Cisco

Cisco TelePresence MSE 8710 Manuel utilisateur

Cisco

Cisco Profile Series Manuel utilisateur

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
