Cisco ONS 15454 SONET and SDH TL1 Command Quick

Reference Guide, Release 4.7

This guide lists TL1 commands and autonomous messages by category. It includes basic

descriptions and input and output formats supported by Cisco ONS 15454 and

Cisco ONS 15454 SDH, Release 4.7.

TL1 commands conform to the following syntax:

a:b:c:d:e: ...z;

where:

“a” is the Command Code

“b” is the Target Identifier (TID)

“c” is the Access Identifier (AID) or the User Identifier (UID)

“d” is the Correlation Tag (CTAG)

“e: ...z;” are other positions required for various commands

The TID, AID, and CTAG parameters route and control the TL1 command.

The remaining parameters provide additional information required to complete

the action requested by the command.

1 DWDM

Ta b l e 1 DW D M

COPY-RFILE:[<TID>]:[<SRC>]:<CTAG>::TYPE=<XFERTYPE>,[SRC=<SRC1>,]

[DEST=<DEST>,][OVWRT=<OVWRT>,][FTTD=<FTTD>];

Downloads a new software package or file from the location specified by the FTP URL.

DLT-EQPT:[<TID>]:<AID>:<CTAG>[:::];

Deletes a card from the Network Element (NE).

DLT-LNK-<MOD2O>:[<TID>]:<FROM>,<TO>:<CTAG>;

Deletes an optical link between two optical connection points.

DLT-OSC:[<TID>]:<AID>:<CTAG>;

Deletes the Optical Service Channel (OSC) group of the NE.

DLT-<PAYLOAD>:[<TID>]:<AID>:<CTAG>;

Deletes a port connection from a client port to a supported payload type.

DLT-WLEN:[<TID>]:<AID>:<CTAG>:::[CMDMDE=<CMDMDE>][:];

Deletes the provisioned wavelength (WLEN).

ED-10GIGE:[<TID>]:<AID>:<CTAG>:::[NAME=<PORTNAME>,][MACADDR=<MACADDR>]:

[<PST>],[<SST>];

Edits the 10 GBit/sec parameters for the 10GIGE port.

ED-ALS:[<TID>]:<AID>:<CTAG>:::[ALSMODE=<ALSMODE>,][ALSRCINT=<ALSRCINT>,]

[ALSRCPW=<ALSRCPW>,][:];

Edits the Automatic Laser Shutdown (ALS) attributes of an OC-N facility and all facilities that

support the ALS feature.

ED-APC:[<TID>]::<AID>::<CTAG>:::[APC-ENABLE=<APCENABLE>][:];

Edits Amplification Power Control (APC) application attributes.

ED-ESCON:[<TID>]:<AID>:<CTAG>:::[ENCAP=<ENCAP>,][CMDMDE=<CMDMDE>][:]

[<PST>[,<SST>]];

Edits the attributes for an Enterprise System Connection (ESCON) interface.

ED-EQPT:[<TID>]:<AID>:<CTAG>:::[PEERID=<PEERID>,]

[REGENNAME=<REGENNAME>,][PWL=<PWL>,][CARDMODE=<CARD_MODE>];

Edits the attributes for a given equipment slot in the NE. If the card is in an equipment slot, this

command is allowed only on the working AID.

ED-FFP-OCH::[<TID>]:<AID>:<CTAG>:::[PROTID=<PROTID>,][RVRTV=<RVRTV>,]

[RVTM=<RVTM>,][PSDIRN=<PSDIRN>][:];

Edits the provisioning for the default protection group on the DWDM port of a TXP_MR_2.5G or

TXPP_MR_2.5G card.

ED-GIGE:[<TID>]:<AID>:<CTAG>:::[ENCAP=<ENCAP>,][CMDMDE=<CMDMDE>[:]

[<PST>[<,<SST>]];

Edits the Gigabit Ethernet-specific parameters for the port.

ED-LNK-<MOD2O>:[<TID>]:<FROM>,<TO>:<CTAG>::::<PST>,[<SST>];

Edits an optical link.

ED-<MOD2DWDMPAYLOAD>:[<TID>]:<AID>:<CTAG>:::[NAME=<NAME>,]

[CMDMDE=<CMDMDE>]:<PST>,[<SST>];

Edits the operating parameters for a DWDM facility.

ED-OCH:[<TID>]:<AID>:<CTAG>:::[NAME=<PORTNAME>,][SFBER=<SFBER>,]

[SDBER=<SDBER>,][ALSMODE=<ALSMODE>,][ALSRCINT=<ALSRCINT>,]

[ALSRCPW=<ALSRCPW>,][COMM=<COMM>,][GCCRATE=<GCCRATE>,]

[OSDBER=<OSDBER>,][DWRAP=<DWRAP>,][FEC=<FEC>,]

[PAYLOAD-MAP=<PAYLOADMAP>,][RLASER=<RLASER>,][SOAK=<SOAK>]:[<PST>],

[<SST>];

Edits the operating parameters of an Optical Channel (OCH) facility.

ED-<OCN_TYPE>:[<TID>]:<AID>:<CTAG>:::[NAME=<PORTNAME>,][DCC=<DCC>,]

[GCC=<GCC>,][AREA=<AREA>,][SYNCMSG=<SYNCMSG>,][SENDDUS=<SENDDUS>,]

[PJMON=<PJMON>,][SFBER=<SFBER>,][SDBER=<SDBER>,][MODE=<MODE>,]

[MUX=<MUX>,][SOAK=<SOAK>,][OSPF=<OSPF>,][LDCC=<LDCC>,][NAME=<NAME>,]

[EXPTRC=<EXPTRC>,][TRC=<TRC>,][TRCMODE=<TRCMODE>,]

[TRCFORMAT=<TRCFORMAT>,][CMDMDE=<CMDMDE>]:<PST>,[<SST>];

Edits the attributes (service parameters) and state of an OC-N facility.

ED-OMS:[<TID>]:<AID>:<CTAG>:::[RDIRN=<RDIRN>,][EXPBAND=<EXPBAND>,]

[VOAATTN=<VOAATTN>,][VOAPWR=<VOAPWR>,][CALOPWR=<CALOPWR>,]

[CHPOWER=<CHPOWER>]:[<PST>],[<SST>];

Edits the attributes (service parameters) and state of an Optical Multiplex Section (OMS) facility.

ED-OSC:[<TID>]:<AID>:<CTAG>:::[RINGID=<RINGID>,][NODEID=<NODEID>];

Edits the Optical Service Channel (OSC) group attributes.

ED-OTS:[<TID>]:<AID>:<CTAG>:::[RDIRN=<RDIRN>,][VOAATTN=<VOAATTN>,]

[VOAPWR=<VOAPWR>,][OFFSET=<OFFSET>,][CALTILT=<CALTILT>,][OSRI=<OSRI>,]

[AMPLMODE=<AMPLMODE>,][CHPOWER=<CHPOWER>,][EXPGAIN=<EXPGAIN>,]

[NAME=<NAME>,][CMDMDE=<CMDMDE>]:[<PST>],[<SST>];

Edits the attributes (service parameters) and state of an OTS facility.

ED-SLV-WDMANS:[<TID>]:[<AID>]:<CTAG>:::[HIGHSLVEXP=<HIGHSLVEXP>,]

[LOWSLVEXP=<LOWSLVEXP>][:];

Provisions the expected span loss verification.

Table 1 DWDM (continued)

ED-TRC-OCH:[<TID>]:<SRC>:<CTAG>:::[EXPTRC=<EXPTRC>,][TRC=<TRC>,]

[TRCMODE=<TRCMODE>,][TRCLEVEL=<TRCLEVEL>,][TRCFORMAT=<TRCFORMAT>][:];

Edits trace-related optical channel facilities.

ED-WDMANS:[<TID>]:<AID>:<CTAG>:::[POWERIN=<POWERIN>,]

[POWEROUT=<POWEROUT>,][POWEREXP=<POWEREXP>,][NTWTYPE=<RINGTYPE>,][:];

Edits the optical node setup application attributes.

ED-WLEN:[<TID>]:<AID>:<CTAG>:::[SIZE=<SIZE>]:[<PST>],[<SST>];

Edits wavelength (WLEN) provisioning.

ENT-EQPT:[<TID>]:<AID>:<CTAG>::[<EQPTTYPE>]:[PEERID=<PEERID>,]

[REGENNAME=<REGENNAME>,][PWL=<PWL>,][CARDMODE=<CARD_MODE>];

Creates the card type and attributes for a given equipment slot in the NE. It also automatically enters

all facilities supported by the card, assigning default values to all port and path attributes.

ENT-LNK-<MOD2O>:[<TID>]:<FROM>,<TO>:<CTAG>::::<PST>,[<SST>];

Creates an optical link between two optical connection points.

ENT-OSC:[<TID>]:<AID>:<CTAG>:::[RINGID=<RINGID>,]NODEID=<NODEID>,]

[EAST=<EAST>,][WEST=<WEST>];

Creates the OSC (optical service channel) group of the NE.

ENT-<PAYLOAD>:[<TID>]:<AID>:<CTAG>;

Creates a port connection from a client port to a supported payload type.

ENT-WLEN:[<TID>]:<AID>:<CTAG>::[<WCT>]:[SIZE=<SIZE>]:[<PST>],[<SST>];

Allocates a wavelength.

INIT-REG-<MOD2>:[<TID>]:<AID>:<CTAG>::<MONTYPE>,,[<LOCN>],[<DIRN>],

[<TMPER>][,,];

Initializes the performance monitoring registers on an OMS card.

OPR-ALS:[<TID>]:<AID>:<CTAG>[:::::];

Restarts the laser of an OC-N facility and all facilities that support the ALS feature.

OPR-APC:[<TID>]::<CTAG>[::::];

Permits the Amplifier Power Control (APC) application inside the NE to force regulation of the

optical power to the entire DWDM ring.

OPR-LNK:[<TID>]::<CTAG>;

Permits the optical link application inside the NE to calculate all the automatic optical links between

end points that can be univocally identified by the NE.

OPR-PROTNSW-OCH:[<TID>]:<AID>:<CTAG>[::];

Performs a protection switch on the trunk port of a TXPP_MR_2.5G card.

Table 1 DWDM (continued)

OPR-SLV-WDMANS:[<TID>]:<AID>:<CTAG>[::::];

Invokes the calculation of the expected span loss verification.

OPR-WDMANS:[<TID>]::<CTAG>;

Operates the Automatic Optical Node Setup (AONS) application inside the NE to force a recompute

of the value to be assigned to all variable optical attenuators (VOAs) representing the Optical Path

inside the node.

RLS-PROTNSW-OCH:[<TID>]:<AID>:<CTAG>[::];

Performs a protection switch on the trunk port of a TXPP_MR_2.5G card.

RMV-<MOD2_IO>:[<TID>]:<AID>:<CTAG>::[<CMDMODE>],[<PST>],[<SST>];

Removes a facility from service.

RST-<MOD2_IO>:[<TID>]:<AID>:<CTAG>[::];

Provisions a facility in-service.

RTRV-10GIGE:[<TID>]:<AID>:<CTAG>[::::];

Retrieves the 10 GBit/sec parameters for the 10GIGE port.

Output format:

SID DATE TIME

M CTAG COMPLD

“<AID>::[NAME=<PORTNAME>,][MACADDR=<MACADDR>,][LBCL=<LBCLCURR>,]

[OPT=<OPTCURR>,][OPR=<OPRCURR>]:<PST>,[<SST>]”

;

RTRV-ALM-ALL:[<TID>]::<CTAG>::[<NTFCNCDE>],[<CONDITION>],[<SRVEFF>][,,,];

Retrieves and sends the current status of all active alarm conditions.

Output format:

SID DATE TIME

M CTAG COMPLD

“[<AID>],[<AIDTYPE>]:<NTFCNCDE>,<CONDTYPE>,<SRVEFF>,,,,:[<DESC>],[<AIDDET>]”

;

RTRV-ALM-EQPT:[<TID>]:<AID>:<CTAG>::[<NTFCNCDE>],[<CONDTYPE>],

[<SRVEFF>][,,,];

Retrieves and sends the current status of alarm conditions associated with the equipment units.

Output format:

SID DATE TIME

M CTAG COMPLD

“[<AID>],[<AIDTYPE>]:<NTFCNCDE>,<CONDTYPE>,<SRVEFF>,,,,:[<DESC>]”

;

Table 1 DWDM (continued)

RTRV-ALM-<MOD2ALM>:[<TID>]:<AID>:<CTAG>::[<NTFCNCDE>],[<CONDTYPE>],

[<SRVEFF>][,,,];:

Instructs the NE to retrieve and send the current status of an alarm condition.

Output format:

SID DATE TIME

M CTAG COMPLD

“<AID>,[<AIDTYPE>]:<NTFCNCDE>,<CONDTYPE>,<SRVEFF>,[<OCRDAT>],[<OCRTM>],,

:[<DESC>]”

;

RTRV-ALMTH-<MOD2>:[<TID>]:<AID>:<CTAG>::<ALMTHR>[,,::];

Retrieves the alarm threshold values.

Output format:

SID DATE TIME

M CTAG COMPLD

“<AID>,<MOD>:<CONDTYPE>,,,<THLEVEL>”

;

RTRV-ALS:[<TID>]:<AID>:<CTAG>[:::::];

Retrieves the ALS attributes of an OC-N facility and all facilities that support the ALS feature.

Output format:

SID DATE TIME

M CTAG COMPLD

“<AID>,<AIDTYPE>::[ALSMODE=<ALSMODE,>][ALSRCINT=<ALSRCINT>,]

[ALSRCPW=<ALSRCPW>,][LSRSTAT=<LSRSTAT>]:”

;

RTRV-APC:[<TID>]::<AID>::<CTAG>[::::];

Retrieves the APC application attributes.

Output format:

SID DATE TIME

M CTAG COMPLD

“::[APCENABLE=<APCENABLE>,][APCSTATE=<APCSTATE>][:]”

;

Table 1 DWDM (continued)

RTRV-COND-ALL:[<TID>]::<CTAG>::[<TYPEREQ>][,,,];

Retrieves the current standing condition for all entities.

Output format:

SID DATE TIME

M CTAG COMPLD

“<AID>,[<AIDTYPE>]:[<NTFCNCDE>],<TYPEREP>,[<SRVEFF>],[<OCRDAT>],

[<OCRTM>],,,[<DESC>]”

;

RTRV-COND-EQPT:[<TID>]:<AID>:<CTAG>::[<TYPEREQ>][,,,];

Retrieves the equipment conditions.

Output format:

SID DATE TIME

M CTAG COMPLD

“<AID>,[<AIDTYPE>]:[<NTFCNCDE>],<TYPEREP>,[<SRVEFF>],[<OCRDAT>],

[<OCRTM>],,,[<DESC>]”

;

RTRV-COND-<MOD2ALM>:[<TID>]:<AID>:<CTAG>::[<TYPEREQ>][,,,];

Retrieves the current standing condition or/and state associated with an entity.

Output format:

SID DATE TIME

M CTAG COMPLD

“<AID>,[<AIDTYPE>]:[<NTFCNCDE>],<TYPEREP>,[<SRVEFF>],[<OCRDAT>],

[<OCRTM>],,,[<DESC>]”

;

RTRV-ESCON:[<TID>]:<AID>:<CTAG>;

Retrieves the attributes for an ESCON interface.

Output format:

SID DATE TIME

M CTAG COMPLD

“<AID>::[NAME=<PORTNAME>,]ENCAP=<ENCAP>:<PST>,<SST>”

;

Table 1 DWDM (continued)

RTRV-EQPT:[<TID>]:<AID>:<CTAG>;

Retrieves card level attributes.

Output format:

SID DATE TIME

M CTAG COMPLD

“<AID>:<EQPTTYPE>,<EQUIP>,[<ROLE>],[<STATUS>]:[PROTID=<PROTID>,]

[PRTYPE=<PRTYPE>,][RVRTV=<RVRTV>,][RVTM=<RVTM>,]

[CARDNAME=<CARDNAME>,][PEERID=<PEERID>,][REGENNAME=<REGENNAME>,]

[PWL=<PWL>,][CARDMODE=<CARD_MODE>:]<PST>],[<SST>]”

;

RTRV-FAC:[<TID>]:<SRC>:<CTAG>[::::];

Retrieves facility data (port data).

Output format:

SID DATE TIME

M CTAG COMPLD

"<SRC>::PAYLOAD=<PAYLOAD>:<PST_PSTQ>,[<SSTQ>]"

;

RTRV-FFP-OCH:[<TID>]:<AID>:<CTAG>[::::];

Retrieves the protection group information for the TXPP_MR_2.5G trunk port.

Output format:

SID DATE TIME

M CTAG COMPLD

“<WORK>,<PROTECT>::[PROTTYPE=<PROTTYPE>,][PROTID=<PROTID>,]

[RVRTV=<RVRTV>,][RVTM=<RVTM>,][PSDIRN=<PSDIRN>]”

;

RTRV-GIGE:[<TID>]:<AID>:<CTAG>;

Retrieves the Gigabit Ethernet-specific parameters for the port.

Output format:

SID DATE TIME

M CTAG COMPLD

“<AID>::[ADMINSTATE=<ADMINSTATE>,][LINKSTATE=<LINKSTATE>,]

[MTU=<MTU>,][FLOWCTRL=<FLOWCTRL>,][OPTICS=<OPTICS>,]

[DUPLEX=<DUPLEX>,][SPEED=<SPEED>,][ENCAP=<ENCAP>]:<PST>[SST>]”

;

Table 1 DWDM (continued)

RTRV-INV:[<TID>]:<AID>:<CTAG>[::::];

Queries the NE and returns a listing of the equipment inventory. For each unit in the system, it

identifies the unit’s firmware numbers and the unit’s Common Language Equipment Identification

(CLEI) code.

Output format:

SID DATE TIME

M CTAG COMPLD

“<AID>,<AIDTYPE>::[PN=<PN>],[HWREV=<HWREV>],[FWREV<FWREV>],

[SN=<SN>],[CLEI=<CLEI>],[TWL1=<TWL1>],[TWL2=<TWL2>],[TWL3=<TWL3>],

[TWL4=<TWL4>]””

;

RTRV-LNK:[<TID>]::<CTAG>;

Retrieves all the optical links created in the NE.

Output format:

SID DATE TIME

M CTAG COMPLD

“<FROM>,<TO>::[OLNKT=<OLNKT>,][CTYPE=<CTYPE>,][RDIRN=<RDIRN>,]

[BAND=<BAND>,][WLEN=<WLEN>]:<PST>,[<SST>]”

;

RTRV-LNK-<MOD2O>:[<TID>]:<AID>:<CTAG>:::[OLNKT=<OLNKT>,][CTYPE=<CTYPE>,]

[RDIRN=<RDIRN>];

Retrieves any optical link associated with the entered AIDs or AID range.

Output format:

SID DATE TIME

M CTAG COMPLD

“<FROM>,<TO>::[OLNKT=<OPTICALLINKTYPE>,][CTYPE=<CREATIONTYPE>,]

[RDIRN=<RDIRN>,][BAND=<BAND>,][WLEN=<WLEN>]:<PST>,[<SST>]”

;

RTRV-<MOD2DWDMPAYLOAD>:[<TID>]:<AID>:<CTAG>[::::];

Retrieves the configuration parameters of a DWDM Client.

Output format:

SID DATE TIME

M CTAG COMPLD

“<AID>,<AIDTYPE>::[NAME=<NAME>,][LBCL=<LBCL>,][OPT=<OPT>,][OPR=<OPR>]:

<PST_PSTQ>,[<SST>]”

;

Table 1 DWDM (continued)

RTRV-NE-APC:[<TID>]::<CTAG>;

Retrieves the APC application ports that are involved in node setup regulation.

Output format:

SID DATE TIME

M CTAG COMPLD

“<AID>,<AIDTYPE>::[MODIFDAT=<MODIFDAT>,][MODIFTM=<MODIFTM>,]

[CHECKDAT=<CHECKDAT>,][CHECKTM=<CHECKTM>, [:]”

;

RTRV-NE-WDMANS:[<TID>]:[<AID>]:<CTAG>[::::];

Retrieves the optical node setup application ports involved in node setup regulation.

Output format:

SID DATE TIME

M CTAG COMPLD

“<AID>,<AIDTYPE>::[REGULATED=<REGULATED,>][PARAM=<PARAM>][:]”

;

RTRV-OCH:[<TID>]:<AID>:<CTAG>;

Retrieves the attributes (service parameters) and state of an OCH facility.

Output format:

SID DATE TIME

M CTAG COMPLD

“<AID>:,,,[<STATUS>]:[NAME=<PORTNAME>,][SFBER=<SFBER>,]

[SDBER=<SDBER>,][ALSMODE=<ALSMODE>,][ALSRCINT=<ALSRCINT>,]

[ALSRCPW=<ALSRCPW>,][COMM=<COMM>,][GCCRATE=<GCCRATE>,]

[DWRAP=<DWRAP>,][FEC=<FEC>,][PAYLOAD-MAP=<PAYLOADMAP>,]

[OFSBER=<OFSBER>][OSDBER=<OSDBER>][MACADDR=<MACADDR>,]

[SYNCMSG=<SYNCMSG>,][SENDDUS=<SENDDUS>,][LSRSTAT=<LSRSTAT>,]

[LBCL=<LBCL>,][OPT=<OPT>,][OPR=<OPR>][SOAK=<SOAK>]:,PST>,[<SST>]”

;

Table 1 DWDM (continued)

Ce manuel convient aux modèles suivants

Autres manuels Cisco Serveur

Cisco

Cisco UCS C220 M3 Manuel du système

Cisco

Cisco UCS C240 Manuel utilisateur

Cisco

Cisco UCS C240 M3 Manuel utilisateur

Cisco

Cisco Digital Media System 3.5 Manuel utilisateur

Cisco

Cisco VPN 3002 Hardware Client Manager Manuel utilisateur

Cisco

Cisco Secure Network Server 3600 Series Manuel

Cisco

Cisco C880 Series Instructions de montage

Cisco

Cisco UCS B420 M4 Manuel

Cisco

Cisco UCS B440 M2 Manuel du système

Cisco

Cisco UCS B420 M3 Manuel d'installation et d'exploitation

Cisco

Cisco TelePresence Manuel de service

Cisco

Cisco TelePresenceMCU 5300 Series Manuel utilisateur

Cisco

Cisco UCS C260 Instructions d'installation et d'entretien

Cisco

Cisco UCS C210 Instructions d'installation et d'entretien

Cisco

Cisco TelePresence Video Communication Server Manuel de service

Cisco

Cisco UCS E Series Manuel utilisateur

Cisco

Cisco UCS X9508 Guide de démarrage rapide

Cisco

Cisco C220 M3 Manuel

Cisco

Cisco UCS B200 M3 Manuel

Cisco

Cisco UCS Invicta C3124SA Manuel utilisateur

Cisco

Cisco TelePresence Manuel de service

Cisco

Cisco UCS C200 Instructions d'installation et d'entretien

Cisco

Cisco UCS B200 Manuel utilisateur

Cisco

Cisco TelePresence Manuel utilisateur

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
