Cisco APP1000 - One Application Server Appliance Mode d’emploi

Installation and Administration Guide

Model: APP1000

Linksys One Application Server

Appliance

Linksys One Application Server Appliance

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . 1

Front Panel . . . . . . . . . . . . . . . . . . . . . . . 2

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . 3

Wall Mounting . . . . . . . . . . . . . . . . . . . . . 4

Cable Installation . . . . . . . . . . . . . . . . . . . . 5

Administration . . . . . . . . . . . . . . . . . . . . . 6

Specifications . . . . . . . . . . . . . . . . . . . . . . 7

Safety Information . . . . . . . . . . . . . . . . . . . 9

License Agreement . . . . . . . . . . . . . . . . . . 11

Limited Warranty . . . . . . . . . . . . . . . . . . . 12

Linksys One Application Server Appliance

Introduction

Congratulations on your purchase of an APP1000 Application Server

Appliance. You will improve productivity and enable centrally

managed, robust features such as Interactive Video Surveillance. New

applications will leverage the APP1000 to introduce new features and

functionality.

The APP1000 application server appliance enables the deployment

of Linksys One applications for Linksys One networks. It features a

500 MHz ARM-based processor with 256 MB of RAM, 512 MB of FLASH,

a single 10/100 Ethernet port, and a USB 2.0 host port. The Ethernet

port is IEEE 802.3af PoE capable allowing the application server

appliance to be powered by a PoE switch.

We hope you enjoy your new productivity.

Linksys One Application Server Appliance

Front Panel

LED Off Solid Blinking or Flashing

POWER No power Power

present

n/a

DIAG n/a n/a Downloading software image

ETHERNET No link Link

established

Incoming/outgoing traffic

USB* n/a n/a n/a

FLASH No activity n/a Read/write activity

* Reserved for future use.

Linksys One Application Server Appliance

Rear Panel

Name Description

Power 48-VDC power port (only use Power Cube AC to 48-VDC

power adapter, part number CP-PWR-CUBE-3).

ETHERNET Ethernet port, supports Power over Ethernet (IEEE 802.3af

PoE).

USB Reserved for future use.

RESET Reset button.

Press for 1 to 5 seconds to reset the APP1000.

Press for 6 to 14 seconds to restore the application data

(software) to default values.

Press for 15 seconds or more to reset the APP1000 to its

factory default settings.

•

Linksys One Application Server Appliance

4Wall Mounting

The APP1000 is designed to rest on a flat surface. Optionally, it can be

wall mounted in either a front-side-up or left-side-up configuration.

Mounting screws are not supplied; recommended screw head diameter

is 6mm to 8mm (0.2362 in to 0.3149 in). In the image, the front-side-

up mounting holes are indicated by circles; the left-side-up mounting

holes are indicated by triangles. Screw spacing for front-side-mounting

is 150 mm (5.9055 in); for left-side-up mounting, the spacing is 108 mm

(4.2519 in).

Install mounting screws according to the mounting conﬁguration

that you selected. Use appropriate wall anchors to secure the

screws.

Align the mounting holes on the bottom of the APP1000 to the

wall-mounted screws and slide down.

Verify that the APP1000 is securely attached to the wall.

Linksys One Application Server Appliance

Cable Installation

The APP1000 can be connected directly to either a Linksys One

Services Router (SVR) or to a Linksys One Ready Ethernet Switch that is

connected to an SVR.

Connect an ethernet cable

from the ETHERNET port to

an SVR or to a Linksys One

Ready Switch.

Verify that the POWER and

ETHERNET indicators light

on the front panel.

(Optional) If the Ethernet

Switch that you connected

to the Application Server

does not supply power via

the ethernet cable (802.3af

PoE), connect power to the

Power port with a Cisco

Power Cube 3 (AC to 48-

VDC power adapter, part

number CP-PWR-CUBE-3).

For further details on installing Linksys One products, refer to the

Linksys One Communications Solution Quick Installation Guide.





Linksys One Application Server Appliance

The APP1000 is conﬁgured through the Linksys One Administrator

portal (refer to the Linksys One Customer Premises Equipment

Administration Guide for details on using the Linksys One Administrator

portal). You can check the status of the APP1000 via the Install >

Applications screen or you can restart the application, reboot the

APP1000, or power cycle it via the Support View > Devices screen.

To view the status of the

APP1000, click the Install tab

and the Applications tab. A

status screen opens showing

this information:

Location—Text label indicating the physical location of the APP1000.

IP—Internet Protocol (IP) and Media Access Control (MAC) address of

the APP1000.

Initialization—The status of the initialization process.

Last started—The time since the APP1000 was last started.

Use—Name of the application running on the APP1000.

To restart the application

running on the APP1000, click

the Support View tab and

click Devices. A screen opens

showing the attached devices.

From this screen you can:

Restart App—Restarts the current application running on the

APP1000.

Reboot—Reboots the APP1000, same as pressing the reset button 1 to

5 seconds.

Power Cycle—Cycles the power to the APP1000, same as momentarily

removing power from the APP1000.

Administration
