Quick Start Guide

Cisco RV160W Router

Package Contents

•Cisco RV160W Router

•Power Adapter

•This Quick Start Guide

•Pointer Card/RoHS

•Technical Support Contact Card

•Ethernet Cable

•EU Directives 2014/53/EU Compliance Information (for EU SKU only)

2 Cisco RV160W Router Quick Start Guide

Welcome

Thank you for choosing the Cisco RV160W router.

The RV160W router provides reliable Internet access connectivity and

includes the following features:

•Easy to use UI with multiple set-up wizards.

•Four port wireless-AC VPN router.

•Supports IPv6 firewall.

•Dualband WLAN (2.4 and 5GHz)

•Business-grade small business network in a box.

This guide describes how to install your Cisco RV160W and launch the

web-based Device Manager.

Installing the Cisco RV160W

To prevent the device from overheating or being damaged:

• Ambient Temperature — Do not operate the device in an area that

exceeds an ambient temperature of 104°F (40°C).

•AirFlow— Be sure that there is adequate airflow around the device. If

wall mounting the device, make sure that the heat dissipation holes are

to the side.

• Circuit Overloading — Adding the device to the power outlet must not

overload that circuit.

• Mechanical Loading — Be sure that the device is level and stable to

avoid any hazardous conditions, and that it is secure to prevent it from

sliding or shifting out of position. Do not place anything on top of the

device, as excessive weight may damage it.

Desktop Mounting

For desktop mounting, place the device on a flat surface so that it sits on its

four rubber feet.

Wall Mounting

The router has two wall-mount slots on the bottom panel. To mount the

router on a wall, you will need to use the wall-mount kit screws (included).

Cisco RV160W Router Quick Start Guide 3

Guidelines for Mounting the Router on a Wall

When choosing a location for mounting the router on a wall, consider cable

limitations and wall structure.

•Mount the router with the front panel facing upward. Make sure to mount

the router low enough so that you can see the LEDs.

•Make sure that the power supply rests on a horizontal surface such as

the floor or a table. If the power supply is not supported, the strain on

the power adapter cable could cause it to disconnect from the router.

•Do not install the router or its power supply next to a heat source of any

kind, including heating vents.

You can mount the router on a hollow wall or a wall stud. To mount the

router, follow these steps:

STEP 1Position the router on the wall to determine where to attach the two

mounting screws. Drill two pilot holes at approximately 109 mm

apart.

STEP 2Insert a screw into each hole, leaving a gap between the surface

and the base of the screw head of 1 to 1.2 mm.

STEP 3Place the router wall-mount slots over the screws and slide the

router down until the screws fit snugly into the wall-mount slots.

WARNING Insecure mounting might damage the router or cause injury.

Cisco is not responsible for damages incurred due to insecure

wall-mounting.

WARNING For safety reasons, please ensure that the heat dissipation

holes are facing sideways.

4 Cisco RV160W Router Quick Start Guide

Cisco RV160W Features

Front Panel

PWR Power off or in rescue mode.

Solid green when the power is on and in normal

operation.

Flashing green when the device is booting up.

VPN Off when no VPN tunnel is defined, or all defined

VPN tunnels have been disabled.

Solid green when at least one VPN tunnel is up.

Flashing green when transmitting or receiving

data over VPN tunnel.

Solid amber when no enabled VPN tunnel is up.

DIAG Off when the system is on track to bootup.

Slow blinking red (1Hz) when the firmware

upgrade is in progress.

Fast blinking red (3Hz) when the firmware

upgrade is failing.

Solid red when the system failed to boot-up with

both active and inactive images or in rescue

mode.

LINK/ACT of WAN

and LAN1-4

Off when there is no Ethernet connection.

Solid green when the GE Ethernet link is on.

Flashing green when the GE is sending or

receiving data.

GIGABIT of WAN

and LAN1-4

Solid green when at 1000M speed.

Off when at non-1000M speed.

Cisco RV160W Router Quick Start Guide 5

Back Panel

WIFI — Push the button to enable or disable the WIFI.

RESET — The RESET button has two functions:

•To reboot the unit and retain the current configuration, press

and hold RESET for a least 3 but no more than 10 seconds, by

using a paper clip or a pen tip.

•To reboot the unit and restore the factory default configuration,

press and hold the RESET button for more than 10 seconds.

Changes you have made to the router are lost.

Console Port — The router console port is designed for a serial cable

connection to a terminal or a computer that is running a terminal emulation

program.

LAN — (1-4) RJ-45 device connections to link local area network devices,

such as PCs, print servers, or switches to the router.

WAN — Connecting the router to a wide area network device such as a

cable or DSL modem.

WLAN 2.4GHz Off when the 2.4GHz wireless module is

disabled.

Flashing green when the wireless radio is

transmitting or receiving data.

Solid green when the 2.4GHz wireless module is

enabled.

WLAN 5GHz Off when the 5GHz wireless module is disabled.

Flashing green when the wireless radio is

transmitting or receiving data.

Solid green when the 5GHz wireless module is

enabled.

USB Off when the USB is not connected, or the USB

is inserted and not recognized.

Solid green when USB storage is recognized.

Flashing green when transmitting or receiving data.

Amber when the USB storage access has errors.

6 Cisco RV160W Router Quick Start Guide

SFP Port — A small factor-form pluggable (SFP) is a hot-swappable input/

output device that plugs into the SFP port, linking the port with the

network.

POWER — Toggles power to the device on or off.

12VDC (2A) — Power port that connects the device to the provided

12VDC, 2 amp power adapter.

Side Panel

USB — Type A USB port that supports flash drives. Caution: Use only the

power supply provided with the device; using another power supply may

cause the USB dongle to fail.

Kensington Lock Slot - Lock slot on the right side to secure the device

physically, using the Kensington lock-down equipment.

Connecting the Equipment

Connect a configuration terminal (PC) to the device by using a LAN port.

The terminal must be in the same wired subnetwork as the device to

perform the initial configuration. As part of the initial configuration, the

device can be configured to allow remote management.

To connect a computer to the device:

STEP 1Power off all equipment, including the cable or DSL modem, the

computer, and this device.

STEP 2Use an Ethernet cable to connect your cable or DSL modem to the

WAN por t on this device.

STEP 3Connect another Ethernet cable from one of the LAN (Ethernet)

ports to the Ethernet port on the computer.

STEP 4Power on the WAN device and wait until the connection is active.

STEP 5Connect the power adapter to the 12VDC port of this device.

CAUTION Use only the power adapter that is supplied with the device.

Using a different power adapter could damage the device or

cause the USB dongles to fail.

Cisco RV160W Router Quick Start Guide 7

The power switch is on by default. The power light on the front

panel is solid green when the power adapter is connected

properly and the device is finished booting.

STEP 6Plug the other end of the adapter into an electrical outlet. Use the

plug (supplied) specific to your country.

STEP 7Continue with the instructions in the Using the Setup Wizard to

configure the device.

Getting Started with the Configuration

To configure the router, you can either use Ethernet or wireless. Please

follow these steps to access the Wizard, and then, the web-based

configuration utility from your computer by Ethernet:

STEP 1Ethernet: Power on the PC that you connected to the LAN port. Your

PC becomes a DHCP client of the device and receives an IP

address in the 192.168.1.xxx range.

Wireless: Search the wireless SSID "CiscoSB-Setup", and connect

to this SSID with the passphrase "cisco123".

STEP 2Locate the IP address of the router. The router IP address is

192.168.1.1 by default. As well,

a. The router can be accessed and managed by Cisco’s network

tools and services, including the Cisco FindIT Network

Discovery Utility, that enables you to automatically discover all

supported Cisco devices in the same local network segment

as your computer. You can get a snapshot view of each device

or launch the product configuration utility to view and configure

the settings. For more information, see www.cisco.com/go/

findit.

b. The router is Bonjour-enabled and automatically broadcast its

services and listen for services being advertised by other

Bonjour-enabled devices. If you have a Bonjour-enabled

browser, such as Microsoft Internet Explorer with a Bonjour

plug-in, or the Apple Mac Safari browser, you can find the

router on your local network without knowing its IP address.

You can download the complete Bonjour for Microsoft Internet

Explorer browser from Apple’s website by visiting:

http://www.apple.com/bonjour/

444

8 Cisco RV160W Router Quick Start Guide

STEP 3Launch a web browser, such as Microsoft Internet Explorer or

Mozilla Firefox.

STEP 4In the address bar, enter the default IP address of the device,

https://192.168.1.1. A site security certificate message is

displayed. The Cisco RV160W uses a self-signed security

certificate. This message appears because the device is not

known to your computer.

STEP 5Enter the default user name: cisco and password: cisco in the User

Name and Password fields.

STEP 6Click Login.

STEP 7Follow the Setup Wizard instructions to finish the router installation.

We strongly recommend that you use the Setup Wizard for the first

installation.The Setup Wizard turns on the Wi-Fi radio, which allows

you to connect wirelessly. For more advanced configurations, see

the Administration Guide. A link to the Administration Guide is

found in Where to Go from Here.

Congratulations, you can now start using your router.

Changing the Administrator Username and Password

To change the Administrator username and password on the device:

STEP 1From the Getting Started page, select Change Administrator

Password or select System Configuration > User Accounts from

the navigation bar.

STEP 2Check a username from the Local User Membership list and click

Edit.

STEP 3Enter the Username.

STEP 4Enter the old Password.

STEP 5Enter the new Password.

STEP 6Confirm the new Password.

STEP 7Select the group (admin, guest) from the drop-down list in the

Password Strength Meter.

STEP 8Click Save.

Cisco RV160W Router Quick Start Guide 9

Troubleshoot Your Connection

If you cannot access your device by using the Setup Wizard, the device

may not be reachable from your computer. You can test network

connections by using ping on a computer running Windows:

STEP 1Open a command window by using Start > Run and enter cmd.

STEP 2At the Command window prompt, enter ping and the device IP

address. For example, ping 192.168.1.1 (the default static IP

address of the device).

If you can reach the device, you should get a reply similar to the

following:

Pinging 192.168.1.1 with 32 bytes of data:

Reply from 192.168.1.1: bytes=32 time<1ms

TTL=128.

If you cannot reach the device, you should get a reply similar to the

following:

Pinging 192.168.1.1 with 32 bytes of data:

Request timed out.

Possible Causes and Resolutions

Bad Ethernet connection:

Check the LEDs for the proper indications. Check the connectors of the

Ethernet cable to ensure that they are firmly plugged into the device

and your computer.

Wrong or conflicting IP address:

Verify that you are using the correct IP address of the device.

Verify that no other device is using the same IP address as this device.

No IP route:

If the device and your computer are in different IP subnetworks,

remote access must be enabled and you need at least one router on

the network to route the packets between the two subnetworks.

Unusually long access time:

Adding new connections may take 30–60 seconds for the affected

interfaces and LAN to become operational.

Bad Image

10 Cisco RV160W Router Quick Start Guide

After a new firmware installation, if the Power light is solid red, contact

system support; see Where to Go from Here.

Where to Go from Here

Support

Cisco Support

Community

www.cisco.com/go/smallbizsupport

Cisco Support and

Resources

www.cisco.com/go/smallbizhelp

Phone Support Contacts www.cisco.com/en/US/support/

tsd_cisco_small_business

_support_center_contacts.html

Cisco Firmware

Downloads

www.cisco.com/go/smallbizfirmware

Select a link to download firmware for Cisco

products. No login is required.

Cisco Open Source

Request

www.cisco.com/go/

smallbiz_opensource_request

Cisco Partner Central

(Partner Login Required)

http://www.cisco.com/c/en/us/

partners.html

Product Documentation

Cisco RV160W www.cisco.com/go/RV160W

Table des matières

Autres manuels Cisco Routeur réseau

Cisco

Cisco Linksys SFE2000 Comment utiliser

Cisco

Cisco 12000 - Series Chassis Modular Expansion... Guide de démarrage rapide

Cisco

Cisco ASR 903 Manuel utilisateur

Cisco

Cisco 7201 Manuel utilisateur

Cisco

Cisco 220 Series Smart Plus Mode d’emploi

Cisco

Cisco 2800 Series Manuel utilisateur

Cisco

Cisco 7206VXR - VPN Bundle Router Manuel

Cisco

Cisco Small Business Pro SRP527W Manuel utilisateur

Cisco

Cisco Catalyst IR1800 Rugged Series Manuel

Cisco

Cisco ASR 907 Manuel

Cisco

Cisco ASR 5500 Manuel utilisateur

Cisco

Cisco 12016 Manuel utilisateur

Cisco

Cisco 7604 Manuel utilisateur

Cisco

Cisco ASR 9000 Series Manuel utilisateur

Cisco

Cisco ASR1004 - ASR 1004 Modular Expansion Base Manuel

Cisco

Cisco 7513 Series Manuel utilisateur

Cisco

Cisco 2821 - Integrated Services Router Unified Communications... Guide rapide

Cisco

Cisco RV260P-K9-G5 Manuel utilisateur

Cisco

Cisco NCS 5500 Series Manuel utilisateur

Cisco

Cisco 807 Manuel

Cisco

Cisco GSR12/60 - 12012 Router -AnyLAN Manuel de l'opérateur

Cisco

Cisco 6000 series Manuel technique

Cisco

Cisco 7600 Series Instructions de montage

Cisco

Cisco Linksys SE2800 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

EnGenius

EnGenius ESR-9710 Manuel utilisateur

LevelOne

LevelOne FBR-1416 Manuel utilisateur

Dynacord

Dynacord Promatrix 6000 Manuel utilisateur

Lorex

Lorex F5D8230-4 Manuel utilisateur
