Cisco RV130 Manuel utilisateur

Quick Start Guide

Versión en Español para México en el CD

Version en français sur CD

Versione italiana sul CD

Deutsch Version auf CD

Cisco RV130 Multifunction VPN Router

Cisco RV130W Wireless Multifunction VPN

Router

Package Contents

•Router

•Ethernet Cable

•Power Adapter

•Quick Start Guide

•Documentation and Software on CD-ROM

2 Cisco RV130/RV130W Mutlifunction VPN Router

Welcome

Thank you for choosing the Cisco RV130/RV130W router.

This guide describes how to physically install your Cisco RV130/RV130W

and launch the web-based Device Manager.

Mounting the Cisco RV130/RV130W

Placement Tips

To prevent the device from overheating or being damaged:

• Ambient Temperature—Do not operate it in an area that exceeds an

ambient temperature of 104°F (40°C).

•AirFlow—Be sure that there is adequate air flow around the device.

• Mechanical Loading—Be sure that the device is level and stable to

avoid any hazardous conditions.

Place the device on a flat surface so that it sits on the four rubber feet.

Wall Mounting

The router has two wall-mount slots on the bottom panel. To mount the

router on a wall, you need mounting hardware (not included). Suggested

wood screw size is illustrated here (not true to scale).

6.50 - 6.86 mm 16 mm

3.0-3.5 mm

370612

Cisco RV130/RV130W Mutlifunction VPN Router 3

Cisco RV130/RV130W Features

RV130 Front Panel

Power Solid green when the device is powered on

and booted.

Flashes green when the device is booting or

upgrading the firmware.

Flashes rapidly if the device is running

corrupt firmware.

VPN

(for site-to-site

IPsec VPN

only)

Solid green when at least one VPN tunnel is

active.

Flashes green when receiving or transmitting

data through a VPN tunnel.

Amber when no enabled VPN tunnel is

active.

USB Solid green when the USB dongle is

successfully connected to an Internet

Service Provider (ISP) and an IP address has

been assigned.

Flashes green when the port is sending or

receiving data.

Amber when the USB dongle is recognized

but failed to connect to an ISP.

4 Cisco RV130/RV130W Mutlifunction VPN Router

RV130W Front Panel

WAN Solid green when the device is connected to

the Internet using a wired connection.

Off when the device is not connected to the

Internet or is connected using a USB dongle.

Flashes green when sending or receiving

data over the wired connection.

LAN (1-4) RJ-45 connectors that link local area network

devices, such as PCs, print servers, or

switches, to the device. The numbered lights

correspond to the LAN ports on the back

panel.

Solid green when the corresponding port is

connected to a device.

Flashes green when the port is sending or

receiving data.

Power Solid green when the device is powered on

and booted.

Flashes green when the device is booting or

upgrading the firmware.

Flashes rapidly if the device is running

corrupt firmware.

VPN

(for site-to-site

IPsec VPN only)

Solid green when at least one VPN tunnel is

active.

Flashes green when receiving or transmitting

data through a VPN tunnel.

Amber when no enabled VPN tunnel is active.

USB Solid green when the USB dongle is

successfully connected to an Internet

Service Provider (ISP) and an IP address has

been assigned.

Flashes green when the port is sending or

receiving data.

Amber when the USB dongle is recognized

but failed to connect to an ISP.

Cisco RV130/RV130W Mutlifunction VPN Router 5

WLAN Lit green when the wireless radio is enabled.

Off when the wireless radio is switched off.

Flashes green when transmitting or receiving

data using a wireless connection.

WAN Lit green when the device is connected to the

Internet using a wired connection.

The light is off when the device is not

connected to the Internet or is connected

using a USB dongle.

Flashes green when sending or receiving

data over the wired connection

LAN (1-4) RJ-45 connectors that link local area network

devices, such as PCs, print servers, or

switches, to the device. The numbered lights

correspond to the LAN ports on the back

panel.

Lit green when the corresponding port is

connected to a device.

Flashes green when the port is sending or

receiving data.

6 Cisco RV130/RV130W Mutlifunction VPN Router

RV130/RV130W Back Panel

RV130/RV130W Side Panel

USB—Type A USB port on the right side of the housing that supports

3G/4G/LTE USB dongles.

Kensington Lock Slot— Lock slot on the right side to secure the device

physically, using Kensington lockdown equipment (not included).

RESET The RESET button has two functions:

•To reboot the unit and retain the current

configuration, press and hold RESET for at

least 3, but no more than 10 seconds, by using

a paper clip or a pen tip.

•To reboot the unit and restore the factory

default configuration, press and hold the

RESET button for more than 10 seconds.

Changes you have made to the Cisco RV130/

RV130W configuration are lost.

LAN (1-4) RJ-45 device connections to link local area

network devices, such as PCs, print servers, or

switches, to the device.

WAN Internet device connection for connecting the

device to a wide area network device, such as a

cable or DSL modem.

POWER Switch that toggles power to the device on or off.

12VDC Power port that connects the device to the

provided 12VDC power adapter.

Cisco RV130/RV130W Mutlifunction VPN Router 7

Connecting the Equipment

You must connect a PC to the device by using an Ethernet cable to perform

the initial configuration. After the initial configuration, administrative tasks

can be performed through the network or by using a wireless connection.

To connect a PC to the device for initial configuration:

STEP 1Power off all equipment, including the cable or DSL modem, the PC,

and the device.

STEP 2Use an Ethernet cable to connect your cable or DSL modem to the

WAN port on your device.

STEP 3Connect another Ethernet cable from one of the LAN (Ethernet)

ports to the Ethernet port on the PC.

STEP 4Power on the cable or DSL modem and wait until the connection is

active.

STEP 5Connect the power adapter to the device’s 12VDC port.

CAUTION Use only the power adapter that is supplied with your device.

Using a different power adapter could damage the device.

The POWER button is on by default. The power light on the front

panel is solid green when the power adapter is connected

properly and the device has finished booting.

STEP 6Plug the other end of the adapter into an electrical outlet. Use the

plug (supplied) specific to your country.

STEP 7Continue with the instructions in the Using the Setup Wizard to

configure the device.

8 Cisco RV130/RV130W Mutlifunction VPN Router

Using the Setup Wizard

The Setup Wizard and Device Manager are supported on Microsoft

Internet Explorer 7.0 or later, Mozilla Firefox 3.5 or later, Apple Safari 3.0 or

later, and Google Chrome 5.0 or later.

To configure the device by using the Setup Wizard:

STEP 1Power on the PC that you connected to the LAN1 port in Step 3 of

the Connecting the Equipment section. Your PC becomes a DHCP

client of the device and receives an IP address in the 192.168.1.xxx

range.

STEP 2Launch a web browser window on your PC.

STEP 3In the address bar, enter the default IP address of the device

192.168.1.1. A site security certificate message appears. Cisco

RV130/RV130W uses a self-signed security certificate. This

message appears because the device is not known to your PC.

STEP 4Click Continue to this website (or the option shown on your

particular web browser) to continue. The login page appears.

STEP 5Enter the username and password. The default username is cisco.

The default password is cisco. Passwords are case sensitive.

STEP 6Click Log In. The Router Setup Wizard is luanched.

STEP 7Follow the on-screen instructions to set up your device. The Router

Setup Wizard tries to automatically detect and configure your

connection. If it is unable to do so, it might ask you for information

about your Internet connection. Contact your ISP for this

information.

STEP 8Change the password as instructed by the Router Setup Wizard or

follow the instructions in the Changing the Administrator

Username and Password section. Log into the device with the

new username and password.

The Device Manager Getting Started page appears. It displays the

most common configuration tasks.

STEP 9Click one of the listed tasks or a task listed in the navigation bar to

complete the configuration.

STEP10 Save any additional configuration changes and log out of Device

Manager.

Cisco RV130/RV130W Mutlifunction VPN Router 9

Changing the Administrator Username and Password

To change the administrator username and password on the device:

STEP 1From the Getting Started page, select Change Default

Administrator Password or select Administration > Users.

STEP 2Check Edit Admin Settings.

STEP 3Enter a new username in Administrator Account Settings. We

recommend that you do not use cisco.

STEP 4Enter the old password.

STEP 5Enter the new password. Passwords should not contain dictionary

words from any language or be the default password. They should

contain a mix of uppercase and lowercase letters, numbers, and

symbols. Passwords must be at least 8 but no more than 30

characters in length.

STEP 6Enter the new password again to confirm.

STEP 7Click Save.

10 Cisco RV130/RV130W Mutlifunction VPN Router

Where to Go From Here

For EU Lot 26 related results, see www.cisco.com/go/eu-lot26-results.

Support

Cisco Support

Community

www.cisco.com/go/smallbizsupport

Cisco Support and

Resources

www.cisco.com/go/smallbizhelp

Phone Support Contacts www.cisco.com/en/US/support/

tsd_cisco_small_business

_support_center_contacts.html

Cisco Firmware

Downloads

www.cisco.com/cisco/software/

navigator.html?i=!ch

Select a link to download firmware. No login

is required.

Cisco Open Source

Requests www.cisco.com/go/

smallbiz_opensource_request

Cisco Partner Central

(Partner Login Required)

www.cisco.com/web/partners/sell/smb

Product Documentation

Cisco RV130/RV130W

Wireless Multifunction

VPN Router

www.cisco.com/en/US/products/ps9923/

tsd_products_support_series_home.html

Autres manuels pour RV130

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Cisco Routeur réseau

Cisco

Cisco Catalyst 7500 Series Manuel utilisateur

Cisco

Cisco 520-T1 - Small Business Pro SR Secure Router Manuel utilisateur

Cisco

Cisco Linksys WRT54G3GV2-ST Mode d’emploi

Cisco

Cisco 7301 Series Manuel utilisateur

Cisco

Cisco 3200 Series Manuel d'installation et d'exploitation

Cisco

Cisco ASR1004 - ASR 1004 Modular Expansion Base Manuel utilisateur

Cisco

Cisco 4000-M series Manuel de la liste des pièces

Cisco

Cisco NCS 540 Series Manuel d'installation

Cisco

Cisco Nexus 5600 Series Manuel de service

Cisco

Cisco WRT54G2 Linksys Manuel utilisateur

Cisco

Cisco ME-C6524GS-8S Manuel utilisateur

Cisco

Cisco 3800 Series Manuel utilisateur

Cisco

Cisco Linksys E4200 Manuel du propriétaire

Cisco

Cisco IR1101 Manuel

Cisco

Cisco ASR 14000 Series Manuel utilisateur

Cisco

Cisco CRS-1 - Carrier Routing System Router Manuel utilisateur

Cisco

Cisco uBR924 Feuille d'instructions

Cisco

Cisco ASR 1000 Series Manuel utilisateur

Cisco

Cisco Catalyst 3560-X Series Manuel utilisateur

Cisco

Cisco 3200 Series Guide d'application

Cisco

Cisco ASR 5000 Series Instructions d'utilisation et de sécurité

Cisco

Cisco aironet 1240 Manuel

Cisco

Cisco 2524 - Router - EN Guide d'installation

Cisco

Cisco SRP521W Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

EnGenius

EnGenius ESR-9710 Manuel utilisateur

LevelOne

LevelOne FBR-1416 Manuel utilisateur

Dynacord

Dynacord Promatrix 6000 Manuel utilisateur

Lorex

Lorex F5D8230-4 Manuel utilisateur
