Troubleshooting

This chapter provides information for troubleshooting problems on the Cisco ASR 903 Router.

•BITS Port Pinout, page 1

•GPS Port Pinout, page 2

•Time of Day Port Pinout, page 3

•Alarm Port Pinout, page 4

•Console/Aux RJ45 RS232 Serial Port Pinout, page 5

•Serial Cable Pinouts, page 11

•E and M Interface Module Pinouts, page 13

•Management Ethernet Port Pinout, page 14

•USB Console Port Pinout, page 14

•USB Flash/MEM Port Pinout, page 15

•Fiber-Optic Specifications, page 16

•LED Summary, page 16

BITS Port Pinout

The table below summarizes the BITS port pinout of the Front Panel “Building Integrated Timing Supply”

RJ48 port.

Table 1: BITS Port Pinout

DescriptionDirectionSignal NamePin

Receive RingInputRX Ring1

Receive TipInputRX Tip2

Not used3

Cisco ASR 903 Aggregation Services Router Hardware Installation Guide

DescriptionDirectionSignal NamePin

TX RingOutputTX Ring4

TX TipOutputTX Tip5

Not used6

Not used7

Not used8

GPS Port Pinout

The platform is capable of receiving or sourcing GPS signals of 1 PPS & 10 MHz. These interfaces are

provided by two mini-coax 50-Ohm, 1.0/2.3 DIN series connector on the front panel. Similarly there are two

mini-coax 50-Ohm connectors provided in the front panel to output this 1PPS and 10MHz.

The table below summarizes the GPS port pinouts.

Table 2: GPS Port Pinout

1PPS (input and output)10 Mhz (input and output)

Input—Rectangular pulse

Output—Rectangular pulse

Input—Sine wave

Output—Square wave

Waveform

Input—> 2.4 volts TTL

compatible

Output—> 2.4 volts TTL

compatible

Input—> 1.7 volt p-p(+8 to +10

dBm)

Output—> 2.4 volts TTL

compatible

Amplitude

50 ohms50 ohmsImpedance

26 microseconds50% duty cyclePulse Width

40 nanoseconds

Input—AC coupled

Output—5 nanoseconds

Rise Time

Table 3: GPS Port Pinout for ASR 900 RSP3

1PPS (input and output)10 Mhz (input and output)

Input—Rectangular pulse

Output—Rectangular pulse

Input—Sine wave

Output—Sine and Square wave

Waveform

Cisco ASR 903 Aggregation Services Router Hardware Installation Guide

Troubleshooting

GPS Port Pinout

1PPS (input and output)10 Mhz (input and output)

Input—> 2.4 volts TTL

compatible

Output—> 2.4 volts TTL

compatible

Input—> 1.7 volt p-p(+8 to +10

dBm)

Output—> 2.4 volts TTL

compatible

Amplitude

50 ohms50 ohmsImpedance

26 microseconds50% duty cyclePulse Width

40 nanoseconds

Input—AC coupled

Output—5 nanoseconds

Rise Time

Time of Day Port Pinout

The table below summarizes the ToD port pinout for ASR900-RSP1-55.

Table 4: RJ45 ToD Port Pinout

DescriptionDirectionSignal NamePin

1PPS RS422 signalOutput or Input1PPS_P1

1PPS RS422 signalOutput or Input1PPS_N2

Do NOT connectOutputRESERVED3

GND4

Time of Day characterGND5

Do NOT connectInputRESERVED6

Time of Day characterOutput or InputTOD_P7

Time of Day characterOutput or InputTOD_N8

The table below summarizes the TOD pinout for A900-RSP2A and A900-RSP3-3C-400 modules.

This port requires the use of SHIELDED cable for GR-1089-core “Intra-Bldg lightning surge”protection.

RS422 interface is per industry standard EIA-422 /RS422 specification.

Note

Cisco ASR 903 Aggregation Services Router Hardware Installation Guide

Troubleshooting

Time of Day Port Pinout

Table 5: RJ48 IPPS/ToD Port Pinout

DescriptionDirectionSignal NamePin

V.11 Cable CorporationOutput or InputRESERVED1

Output or InputRESERVED2

1PPS RS422 signalOutput1PPS_N3

GND4

1PPS RS422 signalInput1PPS_P6

Time of Day R422 output

or input signal

Output or InputTOD_N7

Time of Day R422 output

or input signal

Output or InputTOD_P8

Alarm Port Pinout

The table below summarizes the external alarm input pinout.

Table 6: External Alarm Input Pinout

DescriptionSignal NamePin

Alarm input 0ALARM0_IN1

Alarm input 1ALARM1_IN2

No connect3

Alarm input 2ALARM2_IN4

Alarm input 3ALARM3_IN5

No connect6

No connect7

Alarm commonCOMMON8

Cisco ASR 903 Aggregation Services Router Hardware Installation Guide

Troubleshooting

Alarm Port Pinout

Console/Aux RJ45 RS232 Serial Port Pinout

The table below summarizes the console/aux RJ45 RS232 serial port pinout.

Table 7: Console/Aux RJ45 RS232 serial port

DescriptionDirectionSignal NamePin

Request to sendOutputRTS1

Data Terminal Ready

(always On).

OutputDTR2

Transmit dataOutputTXD3

Ring IndicatorRI4

GND5

Receive dataInputRXD6

Data set ready/Data

Carrier detect

InputDSR/DCD7

Clear to sendInputCTS8

16 T1/E1 Interface Module Pinout

The table below summarizes the pinouts of the cable (Tyco part number 2163442-1, Cisco part number

72-5184-01) used to connect the T1/E1 interface module to the rear of the patch panel.

Table 8: 16 T1/E1 Interface Pinouts

Jack PinTelco RXSignal

Name

Board

Pins

Jack PinTelco TXSignal

Name

Board

PIns

Line

439RX_RING_P192139TX_RING_P188Line 0

514RX_TIP_P142214TX_TIP_P138

438RX_RING_P291138TX_RING_P287Line 1

513RX_TIP_P241213TX_TIP_P237

435RX_RING_P380135TX_RING_P376Line 2

510RX_TIP_P330210TX_TIP_P326

Cisco ASR 903 Aggregation Services Router Hardware Installation Guide

Troubleshooting

Console/Aux RJ45 RS232 Serial Port Pinout

Jack PinTelco RXSignal

Name

Board

Pins

Jack PinTelco TXSignal

Name

Board

PIns

Line

434RX_RING_P479134TX_RING_P475Line 3

59RX_TIP_P42929TX_TIP_P425

441RX_RING_P594141TX_RING_P5100Line 4

516RX_TIP_P544216TX_TIP_P550

440RX_RING_P693140TX_RING_P699Line 5

515RX_TIP_P643215TX_TIP_P649

437RX_RING_P782137TX_RING_P786Line 6

512RX_TIP_P732212TX_TIP_P736

436RX_RING_P881136TX_RING_P885Line 7

511RX_TIP_P831211TX_TIP_P835

431RX_RING_P968131TX_RING_P964Line 8

56RX_TIP_P91826TX_TIP_P914

430RX_RING_P1067130TX_RING_P1063Line 9

55RX_TIP_P101725TX_TIP_P1013

427RX_RING_P1156127TX_RING_P1152Line 10

52RX_TIP_P11622TX_TIP_P112

426RX_RING_P1255126TX_RING_P1251Line 11

51RX_TIP_P12521TX_TIP_P121

433RX_RING_P1370133TX_RING_P1374Line 12

58RX_TIP_P132028TX_TIP_P1324

432RX_RING_P1469132TX_RING_P1473Line 13

57RX_TIP_P141927TX_TIP_P1423

429RX_RING_P1558129TX_RING_P1562Line 14

54RX_TIP_P15824TX_TIP_P1512

Cisco ASR 903 Aggregation Services Router Hardware Installation Guide

Troubleshooting

16 T1/E1 Interface Module Pinout

Jack PinTelco RXSignal

Name

Board

Pins

Jack PinTelco TXSignal

Name

Board

PIns

Line

428RX_RING_P1657128TX_RING_P1661Line 15

53RX_TIP_P16723TX_TIP_P1611

The figure below shows the wiring schematic of the cable used to connect the T1/E1 interface module to the

rear of the patch panel.

Figure 1: Wiring Schematic of Cable between 16 T1/E1 Interface and Patch Panel

32 T1/E1 Interface Module Pinout

The table below summarizes the pinouts of the cable used to connect the 32 T1/E1 interface module to the

rear of the patch panel.

Cisco ASR 903 Aggregation Services Router Hardware Installation Guide

Troubleshooting

32 T1/E1 Interface Module Pinout

Table 9: 32 T1/E1 Pinout

Jack PinTelco RXSignal

Name

Board

Pins

Jack PinTelco TXSignal

Name

Board

PIns

LineBoard

Connector

439RX_RING_P066139TX_RING_P048Line 0PORTS

0-15

514RX_TIP_P032214TX_TIP_P014

438RX_RING_P165138TX_RING_P147Line 1

513RX_TIP_P131213TX_TIP_P113PORTS

0-15

435RX_RING_P262135TX_RING_P244Line 2PORTS

0-15

510RX_TIP_P228210TX_TIP_P210

434RX_RING_P361134TX_RING_P343Line 3PORTS

0-15

59RX_TIP_P32729TX_TIP_P39

441RX_RING_P468141TX_RING_P450Line 4PORTS

0-15

516RX_TIP_P434216TX_TIP_P416

440RX_RING_P567140TX_RING_P549Line 5PORTS

0-15

515RX_TIP_P533215TX_TIP_P515

437RX_RING_P664137TX_RING_P646Line 6PORTS

0-15

512RX_TIP_P630212TX_TIP_P612

436RX_RING_P763136TX_RING_P745Line 7PORTS

0-15

511RX_TIP_P729211TX_TIP_P711

431RX_RING_P858131TX_RING_P840Line 8PORTS

0-15

56RX_TIP_P82426TX_TIP_P86

430RX_RING_P957130TX_RING_P939Line 9PORTS

0-15

55RX_TIP_P92325TX_TIP_P95

427RX_RING_P1054127TX_RING_P1036Line 10PORTS

0-15

52RX_TIP_P102022TX_TIP_P102

Cisco ASR 903 Aggregation Services Router Hardware Installation Guide

Troubleshooting

32 T1/E1 Interface Module Pinout

Jack PinTelco RXSignal

Name

Board

Pins

Jack PinTelco TXSignal

Name

Board

PIns

LineBoard

Connector

426RX_RING_P1153126TX_RING_P1135Line 11PORTS

0-15

51RX_TIP_P111921TX_TIP_P111

433RX_RING_P1260133TX_RING_P1242Line 12PORTS

0-15

58RX_TIP_P122628TX_TIP_P128

432RX_RING_P1359132TX_RING_P1341Line 13PORTS

0-15

57RX_TIP_P132527TX_TIP_P137

429RX_RING_P1456129TX_RING_P1438Line 14PORTS

0-15

54RX_TIP_P142224TX_TIP_P144

428RX_RING_P1555128TX_RING_P1537Line 15PORTS

0-15

53RX_TIP_P152123TX_TIP_P153

439RX_RING_P1666139TX_RING_P1648Line 16PORTS

16-31

514RX_TIP_P1632214TX_TIP_P1614

438RX_RING_P1765138TX_RING_P1747Line 17

513RX_TIP_P1731213TX_TIP_P1713PORTS

16-31

435RX_RING_P1862135TX_RING_P1844Line 18PORTS

16-31

510RX_TIP_P1828210TX_TIP_P1810

434RX_RING_P1961134TX_RING_P1943Line 19PORTS

16-31

59RX_TIP_P192729TX_TIP_P199

441RX_RING_P2068141TX_RING_P2050Line 20PORTS

16-31

516RX_TIP_P2034216TX_TIP_P2016

440RX_RING_P2167140TX_RING_P2149Line 21PORTS

16-31

515RX_TIP_P2133215TX_TIP_P2115

Cisco ASR 903 Aggregation Services Router Hardware Installation Guide

Troubleshooting

32 T1/E1 Interface Module Pinout

Jack PinTelco RXSignal

Name

Board

Pins

Jack PinTelco TXSignal

Name

Board

PIns

LineBoard

Connector

437RX_RING_P2264137TX_RING_P2246Line 22PORTS

16-31

512RX_TIP_P2230212TX_TIP_P2212

436RX_RING_P2363136TX_RING_P2345Line 23PORTS

16-31

511RX_TIP_P2329211TX_TIP_P2311

431RX_RING_P2458131TX_RING_P2440Line 24PORTS

16-31

56RX_TIP_P242426TX_TIP_P246

430RX_RING_P2557130TX_RING_P2539Line 25PORTS

16-31

55RX_TIP_P252325TX_TIP_P255

427RX_RING_P2654127TX_RING_P2636Line 26PORTS

16-31

52RX_TIP_P262022TX_TIP_P262

426RX_RING_P2753126TX_RING_P2735Line 27PORTS

16-31

51RX_TIP_P271921TX_TIP_P271

433RX_RING_P2860133TX_RING_P2842Line 28PORTS

16-31

58RX_TIP_P282628TX_TIP_P288

432RX_RING_P2959132TX_RING_P2941Line 29PORTS

16-31

57RX_TIP_P292527TX_TIP_P297

429RX_RING_P3056129TX_RING_P3038Line 30PORTS

16-31

54RX_TIP_P302224TX_TIP_P304

428RX_RING_P3155128TX_RING_P3137Line 31PORTS

16-31

53RX_TIP_P312123TX_TIP_P313

Cisco ASR 903 Aggregation Services Router Hardware Installation Guide

Troubleshooting

32 T1/E1 Interface Module Pinout

Autres manuels pour ASR 903

Table des matières

Autres manuels Cisco Routeur réseau

Cisco

Cisco 828 Manuel utilisateur

Cisco

Cisco vEdge 100b Manuel utilisateur

Cisco

Cisco 1921-T1SEC/K9 Manuel utilisateur

Cisco

Cisco CRS Manuel utilisateur

Cisco

Cisco 12000 - Series Chassis Modular Expansion... Guide d'installation

Cisco

Cisco 3600 Series Manuel utilisateur

Cisco

Cisco 867VAE-W Manuel utilisateur

Cisco

Cisco ASR 920 series Mode d’emploi

Cisco

Cisco Internet Router Cisco 12404 Manuel de l'opérateur

Cisco

Cisco ASR 9000 Series Manuel d'installation

Cisco

Cisco SLM248P Manuel utilisateur

Cisco

Cisco 2611 - Router - EN Manuel utilisateur

Cisco

Cisco 850 Series Manuel utilisateur

Cisco

Cisco SPS2024 Manuel utilisateur

Cisco

Cisco 2524 - Router - EN Manuel utilisateur

Cisco

Cisco 2851 - Integrated Services Router Manuel utilisateur

Cisco

Cisco RV260P Manuel utilisateur

Cisco

Cisco NCS 5500 Series Manuel utilisateur

Cisco

Cisco SFE1000P - Small Business Managed Switch Manuel utilisateur

Cisco

Cisco 2691 Series Manuel utilisateur

Cisco

Cisco 900 Series Manuel

Cisco

Cisco CVR328W Manuel utilisateur

Cisco

Cisco ASR 9000 Series Manuel utilisateur

Cisco

Cisco 678 Mode d'emploi

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

EnGenius

EnGenius ESR-9710 Manuel utilisateur

LevelOne

LevelOne FBR-1416 Manuel utilisateur

Dynacord

Dynacord Promatrix 6000 Manuel utilisateur

Lorex

Lorex F5D8230-4 Manuel utilisateur
