PREPARE FOR INSTALLATION

RACK-MOUNT THE ROUTER

CONNECT THE ROUTER TO THE NETWORK

CONNECT THE POWER

START THE SYSTEM

Quick Start Guide

CISCO 7100 SERIES VPN ROUTER

18481

Cisco 7100

SERIES

Prepare for Installation

Note: For detailed hardware installation instructions and safety guidelines, refer to the

Cisco 7100 Series VPN Router Installation and Conﬁguration Guide.

Warning Only trained and qualiﬁed personnel should install, replace, or service this

equipment.

Warning Read the Installation instructions before you connect the system to its

power source.

Warning This unit is intended for installation in restricted access areas. A restricted

access area is where access can only be gained by service personnel through the use of

a special tool, lock and key, or other means of security, and is controlled by the

authority responsible for the location.

1Ensure the site is set up properly and ensure your safety when installing the router:

—Lift the router safely out of the packing container.

—Ensure the power service at the site is suitable for the router you are installing.

2Check the packing slip to ensure that all the proper components are present.

3Verify that you have the required tools and parts:

—19- and 24-inch rack-mount brackets.

—Four screws for installing the router in the rack (not included).

—One double ground lug and two Phillips-head machine screws with locking washers.

—Number 2 Phillips screwdriver (not included).

—Appropriate cables to connect the router to the network and console terminal.

—Power cord (two power cords if dual power supply).

—ESD-preventive wrist strap.

—One grounding wire—6-AWG, 0.162-inch (4.115-mm) diameter, with approximately

0.108 inch (2.743 mm) of insulation, for a total wire diameter of approximately

0.27 inch (6.858 mm). The wire’s length is dependent on your router location and site

environment. This wire is not available from Cisco Systems; it is available from any

commercial cable vendor.

—Crimping tool large enough to accommodate the diameter of the wire receptacle on

your grounding lug.

—Wire stripper.

Prepare for Installation (continued)

Rack-Mount the Router

22061

Cisco 7100

SERIES

22062

Attach the Brackets to the

Router

1Locate the brackets and screws.

2Use a Phillips screwdriver to attach the

brackets on the side panels of the router

in one of the following ways:

—Front panel forward

—Rear panel forward

Note: Although these installations show

the 19-inch brackets, the procedure is the

same for the larger brackets.

Note: This procedure assumes you are

installing the router in a rack. For tabletop

installation, refer to the Cisco 7100 Series

VPN Router Installation and Conﬁguration

Guide.

.Rack-Mount the Router (continued)

22064

Note: The second bracket attaches to the other side of the chassis.

The brackets can also be installed with the front panel forward.

Attach the Router to the Rack

1Locate the screws to mount the chassis

in the rack.

2Position one person to lift the chassis

into the equipment rack.

3Align the bracket holes with the

mounting holes in the equipment rack.

4Use a Phillips screwdriver to attach the

router to the equipment rack.

Warning Donottouch thepower

supply when the power cord is

connected. For systems with a

power switch, line voltages are

present within the power supply

even when the power switch is off

and the power cord is connected.

For systems without a power

switch, line voltages are present

within the power supply when the

power cord is connected.

Rack-Mount the Router (continued)

22065

Chassis grounding receptaces

Grounding wire

Grounding lug

Screws

Attach the Grounding Lug

Note: Before you connect power or power

onyour router,we stronglyrecommend that

you attach the grounding lug to the chassis

grounding receptacles.

1Locate the grounding lug and screws.

2Use the wire stripper to strip one end of

the 6-AWG wire approximately

0.75 inch (19.05 mm).

3Insert the 6-AWG wire into the wire

receptacle on the grounding lug.

4Use the crimping tool to carefully crimp

thewire receptaclearound thewire;this

step is required to ensure a proper

mechanical connection.

5Insert the two screws through the holes

in the grounding lug. Ensure that the

grounding lug does not interfere with

other router hardware.

6Use a Phillips screwdriver to carefully

tighten the screws until the grounding

lug is held ﬁrmly to the chassis. Do not

overtighten the screws.

7Connect the opposite end of the

grounding wire to the appropriate

grounding point at your site to ensure

an adequate chassis ground.

Connect the Router to the Network

ACOK

DCOK

OTF

ACOK

DCOK

OTF

RX TX

CEL CAR ALM

CONS

FE 0 / 0 FE

ACT

0 / 1

AUX

7140 - 2AE3

100-240Vac 50/60Hz 5-2.5A 525W

CEL CAR ALM

ACT

LNK

0LNK

PWR

SYS

RDY

SLOT 0 SLOT 1

Ethernet hub

Cisco 7100 series router

Crossover

Ethernet cable

22068

10BaseT/100BaseTX ports

Fast Ethernet 0/0

(RJ-45)

7654321

Connect the Fast Ethernet

Ports

The 10BaseT/100BaseTX Fast Ethernet

ports support IEEE 802.3 and IEEE 802.3u

speciﬁcations for 10-Mbps and 100-Mbps

transmission over unshielded twisted-pair

(UTP) cables. These ports support

autosensing and autonegotiation of the

proper transmission mode with an attached

device.

Note: Unless noted otherwise, all

procedures apply to any Cisco 7100 series

router.

1Attach a standard straight-through or

crossover Category 3 or Category 5

UTP cable directly to the RJ-45

receptacle on the router.

2Attach the network end of the cable to

an Ethernet hub or end station.

Connect the Router to the Network

(continued)

To CSU, DSU, or external

synchronous serial equipment

TD TC RD RC LB CD

TC RD RC LB CD

22070

Strain-relief screws

Serial 1/0

Connect the T1 Ports

(Cisco 7120-4T1 only)

The four T1 ports operate at T1

(1.544-Mbps) and E1 (2.048-Mbps) speeds

Each port uses an identical 60-pin D-shell

receptacle that supports the following

interface types:

• EIA/TIA-232

• V.35

• EIA/TIA-449

• X.21

• EIA-530

1Attach the appropriate serial cable

directly to the receptacle on the router

and tighten the strain-relief screws.

2Attach the network end of the serial

cable to a DSU, CSU, DTE, or other

external synchronous serial equipment

and tighten the strain-relief screws.

Connect the Router to the Network

(continued)

XMTRRCVR

EN RCLK FERF RL

AIS OOF LL

RCLK FERF RL

AIS OOF LL

22072

To T3 network

equipment

Serial 1/0 Serial 2/0

Connect the T3 Ports

The T3 port supports full-duplex operation

at T3 (45-Mbps) speeds. Use a 75-ohm

coaxial cable to connect to a T3 serial

network. Serial cables conform to

EIA/TIA-612 and EIA/TIA-613

speciﬁcations. The T3 serial ports on the

router are considered to be DTE devices.

Note: The T3 ports support several types

of integrated DSUs. For a listing of DSU

featurecompatibilities,refer toAppendix C,

“Cable Speciﬁcations,” in the Cisco 7100

Series VPN Router Installation and

Conﬁguration Guide.

1Attach the appropriate 75-ohm coaxial

cable directly to the receptacle on the

router and tighten the strain-relief

screws.

2Attach the network end of the coaxial

cable to the external synchronous serial

equipment.
