CipherLab 8001 Manuel utilisateur
Printed on 3 March, 2007
User Guide
8001/8300/8500 Ethernet
Cradle
Version 1.04
II
Copyright © 2007 CIPHERLAB CO., LTD.
All rights reserved
The software contains proprietary information of CIPHERLAB CO., LTD.; it is provided under a license
agreement containing restrictions on use and disclosure and is also protected by copyright law. Reverse
engineering of the software is prohibited.
Due to continued product development this information may change without notice. The information and
intellectual property contained herein is confidential between CIPHERLAB and the client and remains the
exclusive property of CIPHERLAB CO., LTD. If you find any problems in the documentation, please
report them to us in writing. CIPHERLAB does not warrant that this document is error-free.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by
any means, electronic, mechanical, photocopying, recording or otherwise without the prior written
permission of CIPHERLAB CO., LTD.
For product consultancy and technical support, please contact your local sales representative. Also, you may
visit our web site for more information.
The CipherLab logo is a registered trademark of CIPHERLAB CO., LTD.
Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation in the
United States and/or other countries.
Bluetooth is a trademark of Bluetooth SIG, Inc., U.S.A.
Other product names mentioned in this manual may be trademarks or registered trademarks of their
respective companies and are hereby acknowledged.
The editorial use of these names is for identification as well as to the benefit of the owners, with no intention
of infringement.
CIPHERLAB CO., LTD.
Website: http://www.cipherlab.com
Copyright Notice
III
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This cradle is intended for indoor use only. It may do damage to the cradle when being exposed to
extreme temperatures or soaked wet.
When the body of the cradle gets dirty, use a clean and wet cloth to wipe off the dust. DO NOT use/mix
any bleach or cleaner. Always keep the cradle dry.
If you shall find the cradle malfunctioning, write down the specific scenario and consult your local sales
representative.
FCC Regulations
Care & Maintenance
i
Contents
Copyright Notice II
FCC Regulations III
Care & Maintenance III
Preface 1
Revision History ...........................................................................................................................................1
CHAPTER 1 - Introducing the Ethernet Cradle 3
1.1 Unpacking the package...........................................................................................................................3
1.2 Features...................................................................................................................................................3
1.3 Nomenclature..........................................................................................................................................4
1.4 Data Flow Diagram.................................................................................................................................5
1.5 Working Modes ......................................................................................................................................6
1.5.1 Data Mode ................................................................................................................................6
1.5.2 Transparent Mode.....................................................................................................................7
1.5.3 Modem Mode ...........................................................................................................................8
1.6 Related Setting......................................................................................................................................10
1.6.1 Baud Rate ...............................................................................................................................10
1.6.2 Settings by Working Mode.....................................................................................................10
1.7 Status LEDs ..........................................................................................................................................11
1.7.1 8001/8300 Ethernet Cradle.....................................................................................................11
1.7.2 8500 Ethernet Cradle ..............................................................................................................12
1.8 Set-up Connection ................................................................................................................................13
1.8.1 Auto-Detect Mode ..................................................................................................................13
1.8.2 LAN Mode (8500 Only) .........................................................................................................13
CHAPTER 2 - Configuring the Ethernet Cradle 15
2.1 IP Configuration ...................................................................................................................................17
2.1.1 Local IP Address ....................................................................................................................17
2.1.2 Subnet Mask ...........................................................................................................................17
2.1.3 Default Router IP....................................................................................................................18
2.1.4 DHCP .....................................................................................................................................18
2.1.5 DNS Server.............................................................................................................................18
2.2 LED Setting (Data/Modem Mode) .......................................................................................................19
2.2.1 Network Rx/Tx Status (default)..............................................................................................19
2.2.2 IR Rx/Tx Status ......................................................................................................................19
2.3 Connection Settings (Data Mode).........................................................................................................20
2.3.1 Connection Type, Remote IP Address, Local Port & Remote Port........................................20
ii Contents
2.3.2 Timer & Line Terminator .......................................................................................................22
2.3.3 Echo Settings..........................................................................................................................24
2.4 Working Mode......................................................................................................................................25
2.4.1 Data Mode ..............................................................................................................................25
2.4.2 Transparent Mode...................................................................................................................25
2.4.3 Modem Mode (default)...........................................................................................................26
2.5 Working Type (Data Mode)..................................................................................................................27
2.5.1 Set Work Online .....................................................................................................................27
2.5.2 Set Work Offline (default)......................................................................................................27
2.6 Reset to Default ....................................................................................................................................28
2.7 Modem Configuration...........................................................................................................................28
2.8 Save and Exit ........................................................................................................................................28
CHAPTER 3 - Cradle Commands 29
3.1 Select Modem (=Ethernet)....................................................................................................................30
3.2 Select RS-232 .......................................................................................................................................30
3.3 Get Version Information.......................................................................................................................30
3.4 Unknown Command.............................................................................................................................31
CHAPTER 4 - Terminal Programming in C 33
CHAPTER 5 - Firmware Upgrade 35
5.1 Over Ethernet Connection ....................................................................................................................35
5.2 Over Terminal.......................................................................................................................................36
Specifications 37
1
Seeing the need to connect CipherLab portable terminals to your existing Ethernet
networks, CipherLab is now providing an easy solution by introducing the Ethernet Cradle
for the 8000/8300/8500 Series portable terminals.
This manual serves to guide you through how to install, configure, and operate the Ethernet
Cradle. We recommend you to keep one copy of the manual at hand for quick reference or
maintenance purposes. To avoid any improper disposal or operation, please read the manual
thoroughly before use.
Thank you for choosing CipherLab products!
Revision History
Version Release Date Notes
1.04 Mar. 03, 2007 Modified: section 3 Cradle Commands
1.03 Nov. 27, 2006 Modified: section 1.7.1 8001/8300 Ethernet Cradle – LED 3
1.02 Nov. 06, 2006 New: section 1.5.3 Escape Sequence <+++> Timeout – 10 seconds
New: section 1.5.3 “AT+IDLETIMEOUT=”, “AT+IDLETIMEOUT?”
1.01 Oct. 09, 2006 Modified: section 1.3 Cradles’ drawing – “AC” to “DC” (Power Jack)
1.00 Sep. 18, 2006 Official release
Preface
2 8001/8300/8500 Ethernet Cradle User Guide
3
For connecting to your existing networks, the Ethernet Cradle is an ideal companion for the
8000/8300/8500 Series portable terminals.
1.1 Unpacking the package
The following items are included in the package. Save the box and packaging material for
future use in case you need to store or ship the product.
Product Package Contents
8001 Ethernet Cradle or
8300 Ethernet Cradle or
8500 Ethernet Cradle
Complete set of the Ethernet Cradle
Power adaptor & power supply cord
Software CD-ROM including this User Guide
1 m Cat. 5 cable
Spare battery pack (for 8500 only)
1.2 Features
16-bit CMOS CPU, low power consumption
Firmware upgradeable
10/100 Mbps auto-switching mechanism
Front panel LED indicators for monitoring status of operation
Supports 3 operation modes: Data/Modem/Transparent
Supports DHCP IP Allocation
Supports TCP/UDP, Server/Client
Reserves Cradle-IR functionalities for switching to Ethernet by cradle commands
Supports Name Resolution via DNS in modem mode
CHAPTER 1
Introducing the Ethernet Cradle
4 8001/8300/8500 Ethernet Cradle User Guide
1.3 Nomenclature
