Christie Mirage M Series Manuel utilisateur

Using 3D in Mirage

013-100195

Christie Digital Systems Inc. Using 3D in Mirage i

This document contains proprietary information of Christie Digital Systems

Canada, Inc. and Christie Digital Systems USA, Inc. (collectively known as

“Christie Digital Systems, Inc.”), and may not be reproduced, stored in a

retrieval system, transferred to other documents, disclosed to other

manufacturers, or used for manufacturing or for any other purpose, in whole

or in part, without prior written permission of Christie Digital Systems, Inc.

Christie Digital Systems, Inc. reserves the right to make changes in

specifications at any time without notice. The information furnished in this

publication was believed to be accurate and reliable. Christie Digital

Systems, Inc. makes no warranty of any kind with regard to this material,

including, but not limited to, implied warranties of fitness for a particular

purpose. Christie Digital Systems, Inc. shall not be liable for errors contained

herein or for incidental or consequential damages in connection with the

performance or use of this material.

GRAPHICS

All drawings, including system layout, hardware devices, controls and

indicators, screens, and maintenance drawings are provided to enhance

understanding of the accompanying text. These graphics are representations

only; they are not necessarily drawn to scale and may not represent parts of

your specific system.

TRADEMARKS

All trademarks used in this manual are the property of their respective

owners.

Christie Digital Systems Inc. Using 3D in Mirage iii

Table of Contents

ABOUT THIS GUIDE 1

1. OVERVIEW 3

1.1. What Do I Need for Stereo 3D? 3

2. QUICK START – BASIC SETUP 5

3. MIRAGE 3D STEREO SYNC CABLE 7

3.1. Active and Passive Stereo 3D Configurations 8

4. STEREO 3D SETUP AND OPTIMIZATION 11

4.1. Stereo 3D Setup Options 11

4.2. Setup Diagrams 12

Basic Setup 12

Basic Setup with CRT Monitor 13

High Performance Setup 13

High performance Setup with CRT Monitor 14

4.3. Optimization Procedures 14

Navigating to the Simulation 3D Submenu 15

3D Stereo Sync Locking Options 15

Enable Frame Lock 16

Display the Test Pattern 16

Match the Projector to the CRT Monitor 16

Optimize the Frame Delay 16

Optimize the Stereo Sync Delay 17

Optimize the Stereo Dark Interval 18

5. 3D SOURCE REQUIREMENTS 19

APPENDIX A: TROUBLESHOOTING 21

APPENDIX B: UNDERSTANDING THE PROJECTOR

ADJUSTMENTS 22

APPENDIX C: VRCO TEST PATTERN SOFTWARE SETUP 27

5.1. Download the CAVELib_EOE software 27

5.2. Unix Installation 27

Install CAVELib_EOE 27

Install Christie-Supplied Program Scripts 28

Test the Test Pattern 28

5.3. Windows Installation 29

Install CAVELib_EOE 29

Install Christie-Supplied Program Scripts 29

Test the Test Pattern 30

INDEX 35

iv Using 3D in Mirage Christie Digital Systems Inc.

Christie Digital Systems Inc. Using 3D in Mirage 1

About This Guide

This guide describes the setup and operation of 3D Stereo displays using

Christie’s Mirage projectors. It explains the various functions of the display

solution and points to additional information in related manuals.

You will also find information about optimizing 3D stereo separation for the

left and right eyes using CAVELIB_EOE software test utility from VRCO.

• Overview

• Quick Start

• Mirage 3D Stereo Sync Cable

• Stereo 3D Setup and Optimization

• 3D Source Requirements

• Appendix A: Troubleshooting

• Appendix B: Understanding the Projector Adjustments

• Appendix C: VRCO Test Pattern Software Setup

• Contact and Support Information

2 Using 3D in Mirage Christie Digital Systems Inc.

Christie Digital Systems Inc. Using 3D in Mirage 3

1. Overview

A single Mirage projector can automatically display stereographic 3D images

as described below. Such images require a specialized video signal source as

well as additional hardware and software in order to be displayed and

interpreted correctly in a typical 3D stereo viewing environment.

In simple terms, images generated from a stereo 3D-video source consist of a

series of images (frames or fields) that alternate quickly between two slightly

different viewpoints corresponding to our left and right eyes. When these

frames are displayed fast enough and viewed with special stereo glasses

synchronized to the left/right (L/R) changes, the resulting perceived image

can appear with the same depth and perspective we sense in the real world.

NOTE: The type of special glasses can be active stereo or passive stereo glasses

depending on the type of stereo controllers and screen used.

1.1. What Do I Need for Stereo 3D?

Stereo 3D applications require a stereo 3D-capable source, few special

hardware/software setups described here, and the Mirage projector’s 3D

Simulation submenu options to control the projector’s processing,

synchronizing and displaying of your stereographic 3D source material.

Note: Christie’s Stereo 3D™ Interface Module used with earlier SXGA Mirage

2000/4000/5000/6000 models is not compatible with Mirage S+ models.

Note: Mirage projectors support plug ‘n play graphics cards through EDI-D

functionality as described in the Roadster/Mirage S+ User’s Manual.

HARDWARE:

• Christie’s Mirage S+ projector

• Christie’s 3D Stereo Sync Cable (recommended; ensures minimum

frame delay). This GPIO cable is standard with all Mirage

projectors.

• A source, usually a computer with a stereo 3D graphics card capable

of displaying progressive scan (alternating frames) of OpenGL

(quadbufffered) stereo 3D applications (suggested cards include

ATI’s FireGL, nVIDIA’s QuadroFX, SGI InfiniteReality, and

others), and running under Windows (2000, XP), Linux, IRIX, HPUX,

OSX or Solaris operating systems.

• Stereo-sync emitter for controlling active shutter glasses such as

those by StereoGraphics, NuVision or equivalent.

StereoGraphics Z-screen equipment consisting of a polarizing

preserving screen and Z-screen eyewear.

SOFTWARE:

• VRCO CAVELIB_EOE software or similar. See Appendix C for

more information.
