Christie LX501 Manuel utilisateur

LX501/LW401/LWU421/

LX601i/LW551i/LWU501i

User Manual-Instant Stack Guide

020-000489-02

Instant Stack Guide 020-000489-02 Rev. 1 (06-2012)

LX501/LX601i/LW401/LW551i/LWU421/LWU501i

WARNING ►Before using this product, be sure to read all manuals for this

product. After reading them, store them in a safe place for future reference.

►Follow all the instructions in the manuals or on the product. The manufacturer

assumes no responsibility for any damage caused by mishandling that is beyond

normal usage dened in the manuals.

NOTE • The information in this manual is subject to change without notice.

• The manufacturer assumes no responsibility for any errors that may appear in

this manual.

• The reproduction, transfer or copy of all or any part of this document is not

permitted without express written consent.

Trademark acknowledgment

All the trademarks in this manual are the properties of their respective owners.

Various symbols are used in this manual. The meanings of these symbols are

described below.

About this manual

WARNING

CAUTION

NOTICE

This symbol indicates information that, if ignored, could possibly

result in personal injury or even death due to incorrect handling.

This symbol indicates information that, if ignored, could possibly result

in personal injury or physical damage due to incorrect handling.

This entry notices of fear of causing trouble.

Please refer to the pages written following this symbol.



Features

This projector can be used with another projector of the same model to project an

image on the same screen using the Instant Stack feature.

The two projectors can be operated simultaneously to make the image brighter.

Moreover, if you connect two projectors with RS-232C cross-over cable, it turns to

a kind of intellectual stacking system. The two projectors can work alternately by

themselves, and once one projector has an accident the other voluntarily starts to

work to keep your presentation going.

These features, generically called Instant Stack, provide you with the broad use.

Projector

LX501/LW401/LWU421/

LX601i/LW551i/LWU501i

User Manual

Instant Stack Guide

User's Manual (detailed) - Instant Stack Guide

Thank you for purchasing this projector.

Instant Stack Guide 020-000489-02 Rev. 1 (06-2012)

LX501/LX601i/LW401/LW551i/LWU421/LWU501i

 

1. Introduction ........................3

1.1 Basic information

and preparations ............................. 3

Instant Stack ........................................ 3

Intellectual Stack and Simple Stack ..... 3

Remote control for Intellectual Stack

and Simple Stack ............................. 3

2. Installation ..........................5

2.1 Preparing for Intellectual Stack..... 5

2.2 Installing

the rst projector (Set A) ................ 6

Deciding installation position ............... 6

Setting up Set A ................................... 6

2.3 Installing

the second projector (Set B) .......... 8

Deciding installation position ............... 8

Connecting projectors .......................... 8

Setting up Set B ................................... 8

2.4 Conrming Main

and Sub settings ............................ 10

2.5 Fine adjusting

image position ............................... 11

For Intellectual Stack users ............... 11

For Simple Stack users ...................... 12

3. STACK menu settings ......13

3.1 Displaying STACK menu ............ 13

3.2 Selecting Main, Sub or off .......... 14

3.3 Selecting lamp operation mode .. 15

3.4 Selecting lamp switching mode .. 17

3.5 Selecting input source for Sub.... 18

3.6 Exiting Intellectual

Stack menu ................................... 19

STACK menu ..................................... 19

Dialog from STACK menu .................. 19

3.7 Important information

for Intellectual Stack ...................... 20

4. Connecting cables ...........23

4.1 Connecting an RS-232C cable ... 23

4.2 Connecting signal cables............ 24

Inputting image from Main to Sub ...... 24

Inputting image

to Sub and Main individually ........... 24

5. Setting input ports

using menu .........................25

5.1 Preparing for menu operations ... 25

5.2 Checking Main projector's

operating status ............................. 25

5.3 Starting up Main projector .......... 26

5.4 Setting the menu ........................ 27

Inputting image from Main to Sub

- Computer signal ........................... 27

Inputting image from Main to Sub

- Video signal

(either component or video) ........... 28

Inputting image to

Sub and Main individually ............... 28

6. Restrictions

on Schedule function ........30

7. Troubleshooting ...............32

Contents

Instant Stack Guide 020-000489-02 Rev. 1 (06-2012)

LX501/LX601i/LW401/LW551i/LWU421/LWU501i

(continued on next page)

1. Introduction

1.1 Basic information and preparations

Instant Stack

Instant Stack is a feature that allows you to superimpose images projected from

two projectors easily.

Intellectual Stack and Simple Stack

Instant Stack includes the following two features.

When two projectors are connected via an RS-232C cable with necessary set-

tings performed on the projectors, these two projectors will automatically operate

in synchronization with each other according to the settings. This is known as

Intellectual Stack in this manual.

The two projectors operate individually without the RS-232C connection. This is

known as Simple Stack in this manual.

Remote control for Intellectual Stack and Simple Stack

For Intellectual Stack, one projector is set as Main and the other is set as Sub.

Only the Main projector is capable of receiving the remote control signals.

Operate

the projectors from the control panel of the Main projector or with the remote control

pointing at the Main projector. For details on operating by remote control and from

the control panel, refer to 3.7 Important Information for Intellectual Stack.

For Simple

Stack, both projectors can receive the remote control signals.

To avoid incorrect operations with the remote control, it is recommended to

operate both projectors with the control panel or a wired remote control, or one

projector with the remote control and the other with the control panel or a wired

remote control. In this case, disable the remote control receiving on the other

projector with the KEY LOCK feature. (Operating Guide → OPTION menu)

If you require more information on Instant Stack, please consult your dealer.

CAUTION ► Place the projector in a cool place with sufcient ventilation.

Keep a space of 30 cm or more between a side of the projector and other

objects such as a wall. Keep a space of 30 cm or more between the two

projectors, especially if you are installing the projectors side by side. Take care

not to let the hot exhaust air from other projectors enter the intake vents of the

projector.

WARNING ► Do not place projectors directly on top of other projectors.

Introduction

Instant Stack Guide 020-000489-02 Rev. 1 (06-2012)

LX501/LX601i/LW401/LW551i/LWU421/LWU501i

1.1 Basic information and preparations (continued)

NOTICE ► Intellectual Stack can be operated only in pairs of the same model

projectors.

► A maximum of two projectors can be used as Intellectual Stack.

► Depending on the installation and surrounding environment, images

projected from the two projectors may not superimpose well enough. The

images cannot superimpose well enough especially when the screen is slanted,

deformed or the surface is uneven.

• Images projected immediately after turning on the projectors are unstable due

to rising internal temperature. Wait for more than 20 minutes before starting

to adjust the superimposed images.

• The image positions may shift due to temperature change, vibration, or shock

caused by hitting the projector. Install the projectors in a stable environment

when using Instant Stack. If the image positions are shifted, readjust the

images. (

6, 8, 11

)

• The image positions may shift over time due to the tension and the weight of

the connecting cables. Make sure not to impose any load on the projectors

when arranging the cables.

• If the volume level of the built-in speakers is too high, noise may occur and

the image quality may deteriorate. In this case, check the volume setting on

both projectors.

• When two projectors are connected using the RS-232C cable, the Main

projector will be able to control the Sub projector. This feature is known as

Intellectual Stack. (

) When Intellectual Stack by means of RS-232C

feature is used, RS-232C communication cannot be used to control the

projector. If you wish to control the projectors from a computer, use the LAN

connection that is connected to any of the projectors.

• When Intellectual Stack is used, the operations or settings of some functions

are restricted. Refer to this manual for details. (

)

Instant Stack Guide 020-000489-02 Rev. 1 (06-2012)

LX501/LX601i/LW401/LW551i/LWU421/LWU501i

For safety reasons, read 1.1 Basic information and preparations (

3, 4

) carefully

before installation. In addition, take note of the followings for proper use of Instant

Stack.

● Use the same model projectors.

● Arrange the projectors side by side.

● Make sure the projection screen is

perpendicular to the projectors.

● Project images larger than the recommended

screen size shown in the table. The greater

the distance between the projectors, the

larger the screen size needs to be.

● If you control one projector with the remote control during installation, it is

recommended to operate the other with the control panel or a

wired remote

control. In this case, disable the remote control receiving on the other projector with

the KEY LOCK feature. (Operating Guide → OPTION menu)

● Images from Set A and Set B may superimpose well but the image positions

can shift over time.

Readjust to superimpose the images.

2.1 Preparing for Intellectual Stack

When using Intellectual Stack via RS-232C connection, ensure the following settings

are set on the two projectors. Otherwise, the Intellectual Stack menu cannot be

operated.

● STANDBY MODE in SETUP menu: NORMAL

(Operating Guide → SETUP menu)

● COMMUNICATION TYPE under COMMUNICATION in SERVICE menu: OFF

(Operating Guide → OPTION menu)

● STACK LOCK in SECURITY menu: OFF

When STACK LOCK is set to on, menus related to Instant Stack cannot be operated.

It is therefore necessary to set it to off during installation and menu setting.

(1) Use the ▲/▼/◄/► buttons to go into the following menu.

ADVANCED MENU > SECURITY (> ENTER PASSWORD) > STACK LOCK

STACK LOCK dialog will appear on screen. (Operating

Guide → SECURITY menu)

(2) Use the ▲/▼ buttons to highlight OFF, and press the ►

button to complete the setting.

2. Installation

L (30cm or more)

Projector

Screen

size

0 ± 10cm

L: distance [cm] Recommended screen size [inch]

30 200

50 250

100 380

Installation

Instant Stack Guide 020-000489-02 Rev. 1 (06-2012)

LX501/LX601i/LW401/LW551i/LWU421/LWU501i

NOTE • Set the tilt angle of Set A to within 9 degrees from the level line.

(continued on next page)

Deciding installation position

Decide the position of Set A and its projection angle. (User’s Manual (concise)

→ Arrangement and Adjusting the projector’s elevator)

2.2 Installing the rst projector (Set A)

Setting up Set A

2. Perform the INSTALLATION setting rst if necessary as it may change the

image position. (Operating Guide → SETUP menu )

3. Adjust the image of Set A to t the screen with the ZOOM, FOCUS and LENS

SHIFT features. (Operating Guide → Adjusting the lens)

Adjust the image position using KEYSTONE and PERFECT FIT if necessary.

(Operating Guide → EASY MENU or SETUP menu)

NOTE • KEYSTONE cannot be operated when PERFECT FIT is in use.

To adjust the image using both KEYSTONE and PERFECT FIT, adjust

KEYSTONE rst.

• If you are using Simple Stack, go to 2.3 Installation of the second projector

(Set B). (

)

1. Turn on Set A.

WARNING ►Only for LX601i, LW551i and LWU501i, it is possible to install

the projector for any direction with specied mounting accessories. Consult with

your dealer about such a special installation.

Installation

Instant Stack Guide 020-000489-02 Rev. 1 (06-2012)

LX501/LX601i/LW401/LW551i/LWU421/LWU501i

4. Display the menu with the MENU button. (Operating Guide → Using the

menu function)

5. Use the ▲/▼/◄/► buttons to go into the following menu.

ADVANCED MENU > OPTION

> SERVICE > COMMUNICATION

> STACK

STACK menu will appear on screen.

(Operating Guide → OPTION menu)

NOTE • Set A will not be operated by the remote control hereafter. To

avoid crosstalk when operating with the remote control, it is recommended to

disable the remote control receiving using KEY LOCK.

• After the STACK MODE setting is completed, Set A (Sub) will not be able

to receive the remote control signals. When STACK MODE is set to OFF,

enable the remote control receiving using KEY LOCK if necessary.

8. If you are using Intellectual Stack, disable the remote control receiving using

KEY LOCK. (Operating Guide → OPTION menu)

7. After pressing the ► button, a dialog to

conrm whether or not to save the setting is

displayed.

Press the ► button to complete the setting. (

)

6. Use the ▲/▼ buttons to highlight STACK

MODE, and press the ► button to display

the STACK MODE dialog.

Highlight SUB pressing the ▲/▼ buttons,

and press the ► button.

2.2 Installing the rst projector (Set A) - Setting up Set A (continued)

Installation

Instant Stack Guide 020-000489-02 Rev. 1 (06-2012)

LX501/LX601i/LW401/LW551i/LWU421/LWU501i

2.3 Installing the second projector (Set B)

Connecting projectors

To use Intellectual Stack, connect an RS-232C cross cable between the

CONTROL port of Set A and Set B.

(continued on next page)

NOTE • KEYSTONE cannot be operated when PERFECT FIT is in use. To

reset both functions, reset PERFECT FIT rst.

• Perform the INSTALLATION setting rst if necessary as it may change the

image position. (Operating Guide → SETUP menu)

2. Reset the adjustment of KEYSTONE and PERFECT FIT on Set B.

(Operating Guide → EASY MENU or SETUP menu)

1. Turn on Set B.

NOTE • After turning on Set B, make sure the image of Set B is not

signicantly tilted compared to the image of Set A. If the image is overly

tilted, rotate the elevator feet of Set B to adjust the angle such that the tilt is

just about right.

Setting up Set B

NOTE • Set the tilt angle of Set B to within 9 degrees from the level line.

Deciding installation position

Decide the position of Set B and its projection angle. (User’s Manual (concise)

→ Arrangement and Adjusting the projector’s elevator)

WARNING ►Only for LX601i, LW551i and LWU501i, it is possible to install

the projector for any direction with specied mounting accessories. Consult with

your dealer about such a special installation.

Autres manuels pour LX501

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Christie Projecteur

Christie

Christie CP2308-G Manuel utilisateur

Christie

Christie 38-VIV208-01 Manuel utilisateur

Christie

Christie 38-VIV302-01 Manuel utilisateur

Christie

Christie Projector Manuel utilisateur

Christie

Christie M Series Manuel utilisateur

Christie

Christie GraphXMASTER DLV1400-DX Manuel utilisateur

Christie

Christie CP4230 Manuel utilisateur

Christie

Christie DWU951 Manuel utilisateur

Christie

Christie LS+58 Manuel utilisateur

Christie

Christie DS+26 Manuel utilisateur

Christie

Christie DWU951 Manuel utilisateur

Christie

Christie HS Series Manuel utilisateur

Christie

Christie 38-VIV402-01 Manuel utilisateur

Christie

Christie 38-VIV204-01 Manuel utilisateur

Christie

Christie DWU850-GS Instructions d'installation et d'utilisation

Christie

Christie Vivid LX35 Manuel utilisateur

Christie

Christie TPC-60 Manuel utilisateur

Christie

Christie CP2208 Guide de l'utilisateur

Christie

Christie Vista S3 Manuel utilisateur

Christie

Christie CP2220 Manuel utilisateur

Christie

Christie TruLife+ Griffyn 4K32-RGB Manuel utilisateur

Christie

Christie Roadie 4K35 Manuel utilisateur

Christie

Christie DHD700 Manuel utilisateur

Christie

Christie Lcd projector Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur

Asus

Asus ZenBeam Latte Manuel utilisateur
