PROPER USE AND INSTALLATION FOR CHAMPION VSC SERIES CABINETS
QUESTIONS
Phone: 866-391-4200
8 AM - 5PM, PST, Monday-Friday
The following instructions will provide you with a guide for installation and usage
for the VSC Series cabinets. If at any time you need guidance or help, please do
not hesitate to call us. Thanks again for choosing Champion Tool Storage.
THIS DOCUMENT IS CONFIDENTIAL AND PROPRIETARY PART NO. 1000619
Installation
THIS DOCUMENT IS CONFIDENTIAL AND PROPRIETARY
1. Use forklift or pallet jack to move and set cabinet in place.
Check to make sure the thumb turn latches(See Detail A) are in
the locked position before moving unit. Cabinet must be
locked while moving. Only move the cabinet using the fork
pockets shown. Moving any other way may cause damage or
injury.
2.
Thumb Turn Latch
Adjusting Tool Holder and Standard Shelving Height.
Remove all tooling in shelf. Remove the (4) 10-24 screws and nuts(See Detail B) from each
corner of the shelf. Move shelf to desired height. Install the (4) 10-24 screws and nuts and
tighten.
DETAIL B
DETAIL A
PART NO. 1000619
Holding Bracket
Installation
THIS DOCUMENT IS CONFIDENTIAL AND PROPRIETARY
3. Add or removing tool holder or standard shelves. See step 2.
4. Adjusting for Broach Tooling.
Your cabinet will deliver ready to be used. You will need to work with your sales associate
to get the correct layout for the broaches you wish to store as there are many options. To
insert a broach, remove the Holding Bracket(see Detail C) from the rail by lifting the
bracket upwards. This may require a soft tap with a mallet. While the broach tool is being
held in place, insert the Holding Bracket into the square knockouts in the rail and push in
the downward position. Repeat process for the remaining rail.
To adjust the broach rail in or out, adjust the thumbwheels to move the rails(broaches
must not be in cabinet).
Holding Bracket
Holding Bracket
Thumb Wheels
Rail
PART NO. 1000619
Use this screw to adjust
drawer left to right
Installation
THIS DOCUMENT IS CONFIDENTIAL AND PROPRIETARY
5. Adjusting the drawer face left to right.
If you need to adjust the drawer face left or right, turn the screw in the drawers slide
underneath the drawer unit, see Fig 1 using the supplied wrench. To adjust the drawer
height, use the screw underneath the drawer, see Fig. 1.
PART NO. 1000619
Use this screw to adjust
drawer up or down.
Fig. 1
Supplied Wrench
Do not open more than one drawer at a time.
THIS DOCUMENT IS CONFIDENTIAL AND PROPRIETARY
Proper Use
1000lb
MAX
1000lb Max load per
drawer, evenly distributed
Do not drop
items into
drawers,
damage may
occur.
Do not use shelves as a step, or seat,
injury or damage may occur.
PART NO. 1000619
Secure the product before use.
Do not tow the product with power equipment.
Do not alter this product in any manner. Doing so will void the warranty.
When locking unit, make sure all drawers or doors are in the fully closed position in order
for the locking system to work properly.
THIS DOCUMENT IS CONFIDENTIAL AND PROPRIETARY
How to Load
Start by loading the bottom
shelf first.
Load the shelf from the back to
the front.
STEP 1.
Load the second lowest shelf in
the same manner as the first.
Repeat until shelves are filled.
STEP 2.
Proper Care
Periodically clean the drawer fronts and other surfaces with a mild detergent and water.
Auto wax preserves the storage unit’s finish and protects against scratches. Apply the
wax as you would on a car.
Safety Information
Do not attach or mount this product to a vehicle.
This may cause personal injury or product
damage. Mounting this product to a vehicle in any
manner will void the warranty.
Do not stand or sit on this product. Doing so may
casuse personal injury..
Do not use drawers as steps or sit in drawer on this
product. Doing so may casuse personal injury..
This product must be on a level surface at all
times. If stored or moved on an unlevel surface,
personal injury or product damage.may occur. If
product is moved, lock all drawer before moving.
Warranty
Champion Tool Storage warrants only to the original purchaser that our Tool
Storage products are free from defects in materials and workmanship for so
long as the original purchaser retains ownership, possession and control of the
product. Our Warranty only applies to Champion Tool Storage manufactured
Professional Series, Modular Series, Flight lineSeries, and Military. Our
warranty excludes damage caused by misuse, abuse, modifications to the unit,
or the user not conforming to the recommended capacities as stated on our
website or catalog. All hardware including drawer slides, hinges, and locks are
warranted for one year from delivery date of the original invoice. If buyer
claims that a product violates such warranty, Champion, upon notice promptly
given, will either issue an RMA and shipping instructions for return to
Champion at buyer’s expense or provide transportation charges prepaid.
Champion’s sole obligation under its warranty shall be, at its option, to repair,
replace or refund the price of any product thereof which is proved to violate
such warranty.In no event shall Champion be liable to the buyer for special,
indirect, incidental or consequential damages whatsoever including, without
limitation, loss of profit or revenue.Title and risk of loss have passed to the
original purchaser upon deliver to a common carrier. If any product is
damaged in transit, the original purchaser must file a claim with the carrier,
which claim is not a warranty claim. If you have any questions regarding your
warranty please contact our sales department at 1-866-391-4200.
PART NO. 1000619
