Optical Power Meter

- 96 Channel DWDM

OPERATING MANUAL

ChallengerOptics

CO-OPM-96

1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.1 Special Features . . . . . . . . . . . . . . . . . . . . . . 3

1.2 Specications . . . . . . . . . . . . . . . . . . . . . . . . 3

1.3 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . .4

1.5 Charge Method . . . . . . . . . . . . . . . . . . . . . . . 4

1.6 Meter Care . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2.0 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . 5

2.1 Explanation of Operating Keys . . . . . . . . . . . . . .5

2.2 Key Function . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.2.1 Power On/O . . . . . . . . . . . . . . . . . . . . 6

2.2.2 Power Meter . . . . . . . . . . . . . . . . . . . . . 7

2.2.3 dB / dBm . . . . . . . . . . . . . . . . . . . . . . . 8

2.2.4 Scan . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.2.5 Graph . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.2.6 Recall . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.2.7 Save . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.3 Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.3.1 Scan Set . . . . . . . . . . . . . . . . . . . . . . 12

2.3.2 Oset . . . . . . . . . . . . . . . . . . . . . . . . 13

2.3.3 Auto Power O . . . . . . . . . . . . . . . . . . 14

2.3.4 Time Set . . . . . . . . . . . . . . . . . . . . . . 14

2.3.5 Data Delete . . . . . . . . . . . . . . . . . . . . 15

2.3.6 Data Format . . . . . . . . . . . . . . . . . . . . 16

2.3.7 System Info . . . . . . . . . . . . . . . . . . . . 16

2.3.8 Scan Display . . . . . . . . . . . . . . . . . . . . 17

2.3.9 PM Mode . . . . . . . . . . . . . . . . . . . . . . 18

2.3.10 Scan Mode . . . . . . . . . . . . . . . . . . . . 19

2.3.11 Threshold . . . . . . . . . . . . . . . . . . . . . 20

2.3.12 Display Unit . . . . . . . . . . . . . . . . . . . 21

2.3.13 Graph Unit . . . . . . . . . . . . . . . . . . . . 22

2.3.14 Below Threshold . . . . . . . . . . . . . . . . 22

3.0 Wavelength Chart . . . . . . . . . . . . . . . . . . . . . . 24

100417

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

Chapter 1.0 - Introduction / 04Chapter 1.0 - Introduction / 03

1. Introduction

1.1 Special Features

- Automatic Wavelength specic

Power measurement

- Compact and lightweight for eld use

- Easy one hand operation

- Data Storage capabilities

- Auto shut o

- Fast power up and Test

- High-quality graphics

1.2 Specications

Channels 96 - DWDM

Frequency / Wavelength 196.45 ~ 191.70 THz

(1526.05~1563.86 nm)

Channel Spacing 50, 100 and 200 GHz

Measurement Speed 4 sec (all channels)

Measurement Range +10 dBm ~ -40 dBm

Measurement Accuracy ±1.0 @ -40 dBm

Power Resolution 0.01 dB

Optical Connector SC / APC

Display Unit dB, dBm, nm, THz

Display 3.5” TFT-LCD, 16 bit Color

Battery / Power Rechargeable Lithium-Polymer – 10 hr

Operating Temperature -4° ~ +130° F (-20° ~ +55° C )

Weight 33 oz*

Dimensions h / w / d 8.75 x 4.25 x 2.5 (inches)* *w/boot

1.3 Accessories

Description Quantity

Body 1 ea

Rubber Boot 1 ea

USB Data cable 1 ea

Charger 1 ea

USB Drive (User’s Manual) 1 ea

1.4 Charge Method

The CO-OPM-96 has a rechargeable battery. A USB power adapter and micro

USB cable are provided for charging. Typical charge time is six hours.

Charging conditions:

LED Color Action of LED Conditions for battery charge

Red ON Charging

Green ON Fully charged

1.5 Meter Care

Do not subject the CO-OPM-96 to strong impact.

The CO-OPM-96 is not water resistant or waterproof

Do not disassemble.

Always properly clean the ber interfaces before taking a measurement.

Always replace the Dust Cap for dust protection.

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

Chapter 2.2 - Key Function / 06Chapter 2.1 - Explanation of Key Function / 05

2. Getting Started

2.1 Explanation of Operating Keys

Key Function

Backlight Power and backlight On/O

Menu Access system Menu and settings

Mode Options : ‘Auto’ and ‘Manual’

dB/dBm Toggle between dB and dBm UOM

SCAN All wavelengths are scanned and power levels are displayed

Graph Power levels of selected channels displayed as a graph.

Save Save measurements

Recall Recall saved measurements

ESC Cancel or move back to previous menu

OK Enter

◄ ► ▲ ▼ Left, right, up and down arrow key

0 ~ 9 Number and letters key

Del Delete key

+/- Sign key

2.2 Key Function

2.2.1 Power ON / OFF

To turn on and o.

Press the button more than 2 seconds, the logo

shown below appears and it moves to ‘Power Meter’page.

Press the button more than 2 seconds to turn the

power o.

Backlight

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

Chapter 2.2 - Key Function / 08Chapter 2.2 - Key Function / 07

2.2.2 Mode

Power Measurement has 2 options‘Auto’and‘Manual’.

If you select ‘Auto’, the instrument automatically scans the

optical input and displays the wavelength which has been

detected with the highest level of power.

If you select ‘Manual’, the power of the wavelength selected

by the user is displayed in real time.

You can select the dierent wavelengths using ◄ ► ▲ ▼.

Selection of Manual and Auto can be done by this button

‘PM Mode’or Click button.

Mode

2.2.3 dB / dBm

The button toggles between dB and dBm UOM.

2.2.4 Scan

Press the button, to measure all selected wavelengths

and display in table format.

You can select the page using ◄ ► ▲ ▼.

dB/dBm

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

Chapter 2.2 - Key Function / 10Chapter 2.2 - Key Function / 09

2.2.5 Graph

Press the button after scanning, to display power

measurements in graph format.

2.2.6 Save

Press the button, the measurement will be saved

using the current date and time as the le name. Or, a 17

character lename can be entered using the keypad.

Press the button to save.

If you want to cancel saving, press button.

Graph

Save

ESC

2.2.7 Recall

Press the button, to view les saved on device.

Use ▲, ▼ to highlight desired le.

Press the button to select the le to be displayed.

Recall

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

Chapter 2.3 - Menu / 12Chapter 2.3 - Menu / 11

2.3 MENU

The button, allows you to congure the operating

environment of the CO-OPM-96.

The menu consists of:

Scan Set

Oset

Auto Power O

Time Set

Data Delete

Data Format

System Info

Scan Display

PM Mode

SCAN Mode

Threshold

Display unit

Below threshold

2.3.1 Scan Set

When you choose the Scan Set, ‘Odd Channels’, ‘Even Channels,

‘All Scan’ and ‘Selected’ are displayed.

ODD Channels measures all the HALF channels - 17.5, 18.5, 19.5, etc.

EVEN Channels measures all the WHOLE channels - 17.0, 18.0, 19.0, etc.

‘All Scan’will measure all 96 channels.

‘Selected’ allows user-selected wavelength measurement.

Press the‘Selected’, you will see the screen below.

Press to toggle ON/OFF the highlighted wavelength.

The ‘Selected’ option allows user to select specic channels to be

measured. Highlight the channel and press‘Enter’ to toggle channel

ON/OFF.

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

Chapter 2.3 - Menu / 14Chapter 2.3 - Menu / 13

2.3.2 Oset

When measuring form a test port the ‘Oset’can be added

to the signal power. When you choose the‘Oset’, you can

choose either, ‘All Channel’ and ‘Each Channel’.

Press the button after selecting ‘All Channel’,

you can set up the oset with values between

–25.99 to +25.99 dB for all channels.

‘+’ and‘-’ sign can be changed to (+/-) button.

Press the button after selecting ‘Each Channel’,

you can set up each channel’s oset value.

+/-

2.3.3 Auto Power O

The power automatically goes o if the user does not

input any key in the determined time.

Press the button after selecting ‘Auto Power OFF’,

you can set the Auto power o time in minutes.

You can set the time between 5 to 600 min. by pressing

the number key and button.

2.3.4 Time Set

Press the button after selecting ‘Time Set’, you can

set today’s date and current time.

You can set the time by pressing the number key

and button.

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

Chapter 2.3 - Menu / 16Chapter 2.3 - Menu / 15

2.3.5 Data Delete

Press the button after selecting ‘Delete Data’, you

can delete measurement les.

Press the key after choosing the le you want to

delete, the message appears on the screen to conrm to

delete or not.

Press the button, and le will be deleted from the

memory.

2.3.6 Data Format

You can delete all saved les by formatting the memory.

Press the button after‘Data Format’, message

appears on the screen to conrm.

Press the button, all les are deleted from the

memory.

2.3.7 System Info

General information about the equipment.

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

Chapter 2.3 - Menu / 18Chapter 2.3 - Menu / 17

2.3.8 Scan Display

‘Scan Display’ consists of‘All’ and ‘Measured’. This can be

selected using ◄ ► ▼ ▲.

‘All ’will display power levels of All wavelengths measured

by the meter REGARDLESS of power level.

If you choose the ‘Measured’, only wavelengths with a

power level higher than -40 dBm are displayed.

2.3.9 PM Mode

The ‘PM Mode’consists of the ‘Auto’and ‘Manual’.

This can be selected using the ◄ ► ▼ ▲ buttons.

If you choose the ‘Auto’, The meter will automatically

detect and display the channel with the highest power.

If Manual is selected the meter will display power level

of the last channel measured. User can display adjacent

channels using the ◄ ► ▼ ▲ buttons.

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

ChallengerOptics.com

Wavelength Specic Optical Testing and Measurement Equipment

Chapter 2.3 - Menu / 20Chapter 2.3 - Menu / 19

2.3.10 Scan Mode

The ‘SCAN Mode’ consists of the ‘Repeat’and ‘Single’. This

can be selected using ◄ ► ▼ ▲.

If you select ‘Repeat’, the instrument repeatedly scans the

optical input measurements are displayed in real time.

If you select ‘Single’, The moment you click on the ‘SCAN’

button, the light source is scanned only once.

2.3.11 Threshold

Threshold allows you to change the baseline, or lowest

power level, of the meter.

Enter the desired value. Use the ‘+/-‘ key as needed.

–30.00 dBm is the default setting.

Press the button after inputting the new threshold

to SAVE the value.

Baseline changes can be found at the graph screen.

Autres manuels pour CO-OPM-96

Table des matières

Autres manuels Challenger Optics Instrument de mesure

Challenger Optics

Challenger Optics CO-OTDR-CWDM-10M Series Manuel utilisateur

Challenger Optics

Challenger Optics CO-OLS-MPO12U Manuel utilisateur

Challenger Optics

Challenger Optics CO-OPM-96 Manuel utilisateur

Challenger Optics

Challenger Optics CO-OLS-MPO12U Manuel utilisateur

Challenger Optics

Challenger Optics CO-OPM-10 Manuel utilisateur

Challenger Optics

Challenger Optics CO-OTDR-DWDM Manuel utilisateur

Challenger Optics

Challenger Optics CO-OLS-6100 Manuel utilisateur

Challenger Optics

Challenger Optics CO-OLS-MP012 Manuel utilisateur

Challenger Optics

Challenger Optics CO-OPM-PON Manuel utilisateur

Challenger Optics

Challenger Optics CO-OPM-48 Manuel utilisateur

Challenger Optics

Challenger Optics CO-OPM-CW12 Manuel utilisateur

Challenger Optics

Challenger Optics CO-OPM-18 Manuel utilisateur

Challenger Optics

Challenger Optics CO-OPM-48 Manuel utilisateur

Challenger Optics

Challenger Optics CO-OPM-PON Manuel utilisateur

Challenger Optics

Challenger Optics CO-OPM-18 Manuel utilisateur

Challenger Optics

Challenger Optics CO-OLS-MPO12 Manuel utilisateur

Challenger Optics

Challenger Optics CO-OPM-MPO24 Manuel utilisateur

Challenger Optics

Challenger Optics CO-OLS-MPO12 Manuel utilisateur

Challenger Optics

Challenger Optics CO-OPM-MPO12 Manuel utilisateur

Challenger Optics

Challenger Optics CO-OPM-96 Manuel utilisateur

Challenger Optics

Challenger Optics CO-OPM-48 Manuel utilisateur

Challenger Optics

Challenger Optics CO-OPM-10 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
