OPERATING INSTRUCTIONS
Introduction :
1. Read These Operating Instructions thoroughly before installing
or using this Equipment. Improper installation or use can result
in equipment or property damage, electric shock or personal
injury.
2. Centaur Hot Dog Grills are heavy duty and are designed for
commercial use.
3. Only trained personnel should operate this equipment.
Electrical Requirements :
Refer to the product tag (serial plate) on the back of the
unit for voltage and wattage requirements. Be sure to plug
unit into grounded outlet with sufficient power.
WARNING: DURING NORMAL OPERATION, THE
EXTERIOR OF THE UNIT IS HOT!
Preparation :
1. Remove all packing pieces and lift unit out of the box.
2. Remove any outside packaging.
3. Set unit on a flat surface.
4. Position the unit near a power outlet. Avoid the use of
extension cords. Do not run cord under carpeting or
cover with runners or the like. Arrange cord where it
will not be tripped over.
5. This appliance has hot and live electrical parts inside.
Do not use it in areas where gasoline, paint or
flammable liquids are used or stored.
6. Remove any white plastic coating that may be affixed
to stainless steel surfaces.
7. If unit fails to work properly when first operated call
Global Solutions customer service at 1-800-782-6761.
8. If you purchased a roller grill cover for the roller grill,
follow the Assembly instructions below.
Assembly :
1. Remove hot dog grill, glass cover and side guards
carefully from the carton. Locate parts list of the hot
dog grill cover to be sure you have all parts to
complete the assembly.
2. Place the plastic base onto the grill, then tighten the
screws. Place first glass panel into one set of the
plastic bases. Repeat for opposite side.
3. Place the curved front glass into the plastic base on
either side of the roller grill and fasten to the grill using
supplied bolts.
4. Lastly, place the stainless-steel plate onto the edge of
the curved front glass and tighten the stainless-steel
plate to the glass with supplied nuts and bolts.
Mechanical Roller Grill
Model Series:
CEN-RS30, CEN-RG30SG
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions
should always be followed, including the following:
1. Plug electrical cord into a certified electrical outlet with a
corresponding voltage rating as listed on the machine model
labels.
2. Always unplug the electric cord when appliance is not in use
and before cleaning, adjusting or maintaining this machine.
Do not operate with a damaged cord or plug or after the
machine malfunctions, has been dropped or damaged. Use
authorized service for examination, electrical or mechanical
adjustment or repair.
3. This machine will be HOT during use and for a short time
after it is turned off –BE CAREFUL. Do not let children near
appliance. To avoid burns, do not let bare skin touch hot
surfaces. Keep combustible materials away from appliance.
4. Never leave the unit unattended.
5. This appliance is not intended for use near or around water.
Never locate appliance where it may fall into a vessel of
water.
6. Protect appliance from strong vibrations during transport.
Do not store the unit outside.
7. The grill is capable of reaching very high temperatures.
Follow all safety procedures to avoid injury.
November 10, 2020
Operation :
1. Wash all surfaces of the grill with soap and water,
then dry thoroughly.
2. Apply food grade lubricant to the rollers to promote
smooth operation.
3. Turn the power switch to ON.
4. Set the temperature control to the desired
temperature using the button on the front panel. The
temperature control will illuminate as you adjust it.
Once the set temperature is reached, the light will go
off automatically. When the temperature falls below
the set temperature, the light will automatically
illuminate until the desired temperature is reached;
when it will again, go off.
5. Turn the power switch to OFF when you are finished
using the unit.
Cleaning :
NOTE: Proper maintenance plays an important part in the
life span and functioning of the unit.
1. Make sure unit is powered off before cleaning.
2. Allow the unit to cool 30 minutes.
3. Cleaning the appliance on a daily basis is the key to
keeping it in perfect working condition and prolonging
its life. Clean the outside of the appliance with a
damp cloth using water and mild soap that is not
abrasive.
4. Use a non-abrasive cleaner and soft cloth to clean the
rollers. The rollers have a non-stick coating that can
be damaged by abrasive cleaners and cleaning tools.
5. Never use direct water jets to clean the unit as this
could result in water entering into the grill and
damaging it.
SERVICE INSTRUCTIONS :
REPAIR :
To avoid serious injury or damage, do not repair the hot
dog grill or replace a damaged power cord yourself.
Repairs must be coordinated through Global Solutions
customer service at 1-800-782-6761.
