OPERATING INSTRUCTIONS

PANEL HEATER

For Model: CELEPANELD

1. Use only the voltage specified on the rating

label of the appliance.

2. Keep all objects at least 1 metre from the

front and sides of the appliance. Do not

place appliance close to radiant heat source.

3. Do not operate in areas where petrol, paint or

other flammable liquids are used or stored.

4. Do not insert or allow foreign objects to enter

any ventilation or exhaust opening, as this

may cause an electric shock, fire or damage

to the appliance.Do not sit on the appliance.

5. Do not operate this appliance with a

damaged cord, plug or after the appliance

malfunctions or has been dropped or

damaged in any manner. Return to a qualified

electrical person for examination, electrical

service or repair.

6. This appliance is intended for household use

only and not for commercial or industrial use.

7. Use this appliance only as described in this

manual. Any other use is not recommended

by the manufacturer and may cause fire,

electrical shock or injury.

8. The common cause of overheating is

deposits of dust or fluff in the appliance.

Ensure these deposits are removed regularly

by unplugging the appliance and vacuum

cleaning the air vents and grills.

9. Do not use abrasive cleaning products on this

appliance. Clean with a damp cloth (not wet)

rinsed in hot soapy water only. Always

remove plug from the mains supply before

cleaning.

10. Do not connect the appliance to mains supply

until completely assembled and adjusted.

11. Switch off when moving.

12. Do not operate with cord set coiled up as a

heat build up is likely, which could be

sufficient to become a hazard.

13. Do not use an extension cord, power board or

external timer with this appliance.

14. Do not remove plug from power socket until

the appliance has been switched off.

15. Do not remove plug from power socket by

pulling cord; always grip plug.

16. Always unplug appliance when not in use.

17. Do not locate the heater directly below any

power socket during operation.

18. Do not twist, kink or wrap the cord around the

appliance, as this may cause the insulation to

weaken and split. Always ensure that all cord

has been removed from any cord storage

area and is unrolled before use.

19. This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities or

lack of experience and knowledge, unless

they are supervised or have been given

instruction concerning the use of the

appliance by a person responsible for their

safety.

20. Do not use this appliance in the immediate

surrounds of a bath, a shower, or a swimming

pool or other liquids. The appliance must not

be immersed in any liquids.

21. When the appliance has been unpacked,

check it for transport damage and ensure all

parts have been delivered. If parts are

missing or the appliance has been damaged,

contact the Celsius Customer Services Team.

22. If your appliance does not work, or is not

working properly, contact the place of

purchase or the Celsius Customer Services

Team. Repair work on the appliance by

unqualified persons can cause serious risk to

the user.

23. There are no user serviceable parts installed

in the unit.

24. Do not place the unit in wardrobes or other

enclosed spaces as this may cause fire

hazards.

25. This unit is not supposed to be used in or

around locations where foodstuffs, works of

art or delicate articles of science, etc are

stored.

26. Indoor use only.

27. Children should be supervised to ensure that

they do not play with the appliance.

WARNINGS AND SAFEGUARDS

Celsius –New Zealand

Monday –Friday 8am-5pm

Phone +64 (0)9 917 4000

Phone 0800 232 633

[email protected]

Celsius –Australia

Monday –Friday 8am-5pm

Phone +61 (0)3 9336 4423

Phone 1300 465 324

[email protected]

SUPPORT AND TECHNICAL ADVICE

WALL MOUNTING POSITION INSTRUCTIONS

NOTE: Your Celsius panel heater should be installed with at least 300mm clearance from the

floor and any other surrounding parts including other appliances, side walls, ceilings, shelves

and soft furnishings.

300mm

CONTENTS

1 x Celsius panel heater

1 x Wall mounting accessories pack

2 x Drill bits (1 x 7mm for plasterboard or wooden walls, 1 x 8mm for drilling masonry)

4 x Rail fittings

4 x Screw bolts

4 x Bolt caps

NOTE: Please ensure you use the correct drill bit for the wall surface material you are mounting on to.

Please contact your local hardware retailer or builder for advice.

WALL MOUNTING INSTRUCTIONS

Always choose a safe location for the heater, keeping in mind the safety precautions outlined.

Ensure all packaging and the wall mounting accessories pack has been removed from the unit

before use.

1. Mark the positions of the four holes to be drilled on the wall. Ensure there is a 300mm

clearance on all sides of the heater.

2. Drill holes with an appropriate drill bit for the wall type you are mounting the heater on to.

3. Insert the plastic rail fittings into the holes.

4. Install the panel heater onto the four rail fittings matching the four holes on the heater.

5. Screw the four screw bolts into the plastic rail fittings.

6. Put the caps onto the end of the screw bolts. It is recommended to use some normal glue

to stick the caps onto the bolts.

To remove the unit from the wall, simply remove the bolt caps, unscrew the bolts with a screw driver

and take the heater down

OVERVIEW OF YOUR CELSIUS PANEL HEATER

Your Celsius Panel Heater will provide background warmth.

Your Panel Heater is designed to take the chill off the room.

The surface of this Panel Heater can be painted with good quality paint (acrylic or enamel).

Decorating tip: All wall mounted heaters may cause paint to discolour or wall paper to lift.

CARE AND CLEANING

Do not attempt to dismantle the Panel Heater. There are no user serviceable parts. For service or

repair, contact an authorised electrical service technician.

Unplug the heater from the mains supply before cleaning. Ensure that the heater has been allowed to

cool down completely before cleaning.

To remove the unit from the wall, simply remove the bolt caps, unscrew the bolts with a screw driver

and then take the heater down. Use a vacuum cleaner to remove dust and fluff from behind the

heater.

The outside can be cleaned by wiping it over with a soft dry cloth.

NOTE: Do not use abrasive cleaning agents or polish, this can damage the surface and finish.

For short term non-use, simply turn off the unit with the power switch on the side of the heater and

disconnect the mains power supply at the wall.

SAFETY FEATURE

In case of overheating, this heater is fitted with a thermal fuse which is located inside the construction

of the heater. If this thermal fuse activates it will turn the heater off however the light in the power

switch will remain on to let you know there is still power going into the heater.

In the event that this happens, turn the heater off at the switch and the wall socket and unplug it. Then

contact our Customer Service Team.

WARNING: Do not use this heater with a programmer, remote-control system , separate timer or any

other device that switches the heater on automatically, since a fire risk exists if the heater is covered

or positioned incorrectly.

WARNING: Keep all objects at least 1 metre from the front and sides of the appliance.

CAUTION: The heater generates heat during use. Proper precautions must be taken to prevent the

risk of burns, scalds, fires or other damage to persons.

IMPORTANT! NEVER COVER THIS HEATER

OPERATING INSTRUCTIONS

Before plugging in and using your new Celsius panel heater, check all surfaces to ensure the heater

is not damaged in any way.

Check that the On/Off switch is set to the Off position before plugging the heater into the mains

supply.

Use the On/Off switch along the side of the heater to turn your heater on.

WARNING! Take care in positioning your heater, using the timer will mean the heater will come on

automatically. Fire may result if placed next to combustible material.

PROOF OF PURCHASE

To receive warranty retain receipt as proof of

purchase. Refer to back of booklet.

TECHNICAL SPECIFICATION

Model No: CELEPANELD

Supply: 220-240VAC 50Hz

Wattage: 400-425W

SETTING THE TIME ON YOUR DIGITAL DISPLAY

While holding the CLOCK button down:

Press the WEEK button until the display shows the current day.

Press the HOUR button until the display shows the current hour.

Press the MIN (Minute) button until the display shows the current minute.

SETTING THE MODE

The AUTO function will cycle ON and OFF as per the program set.

To change the current program between ON, OFF, AUTO ON, AUTO OFF press the ON/AUTO/OFF

button until the desired program is set on the screen.

PROGRAMMING YOUR TIMER

Press the PROG (Program) button once, the display will look as shown below:

Now you must set the time at which you want your heater to turn on:

The number "1" in the display indicates you are now programming EVENT 1.

Press the WEEK button until the display shows the day in which you want the heater to turn on.

The options are:

•One day of the week (any day from MON to SUN)

•Every weekday (MON-FRI)

•The weekend (SAT-SUN)

•Every weekday plus Saturday (MON-SAT)

•Alternating days (MON, WED, FRI)

•Alternating days (TUE, THU, SAT)

•First 3 days (MON-WED)

•Second 3 days (THU-SAT)

•Every day of the week (MON-SUN)

PROGRAMMING MULTIPLE TIMER EVENTS

Press the HOUR and MIN buttons to set up the time of day when you want the heater to turn on.

Press the PROG button again, the display shows as below. Now set the time of the day when you

want the heater to turn off.

Repeat the program procedures above for each event (up to 7 events required if you set each

individual day)

When the programming is complete, press the CLOCK button to return to the current time display.

REVIEWING YOUR PROGRAM

In the current time display, press the PROG button repeatedly to check your settings.

When finished, press the CLOCK to return to current time display

Thank you for purchasing this Celsius product. Your product is warranted against faults and manufacture when used in

normal domestic use for a period of two years. In non-domestic use Celsius limits the voluntary warranty to three

months.

Celsius undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault

during the warranty period.

This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out

by anyone other than a qualified electrical service technician.

PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.

The benefits to you given by this warranty are in addition to other rights and remedies available to you under a law in

relation to the goods or services to which this warranty relates.

In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are

entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or

damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure.

In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).

Two Year Warranty

Celsius Two Year Warranty (IMPORTANT: Please complete and retain this warranty card)

Name

Address

Place Of Purchase Date Of Purchase

Name Of Product Model Number

Attach a copy of the purchase receipt to this warranty card

Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.

Celsius –New Zealand

PO Box 100-707

N.S.M.C

Auckland

Phone +64 (0)9 917 4000

Phone 0800 232 633

[email protected]

Celsius –Australia

PO Box 574

South Morang

Victoria, 3752

Phone +61 (0)3 9336 4423

Phone 1300 465 324

[email protected]

Table des matières

Autres manuels Celsius Chauffage électrique

Celsius

Celsius CELRH200 Manuel utilisateur

Manuels Chauffage électrique populaires d'autres marques

Heatscope

Heatscope PURE Guide rapide

Sunbeam

Sunbeam Calentador SFH457A Manuel utilisateur

Dura Heat

Dura Heat DH2000C Manuel utilisateur

Harvia

Harvia K10.5GS Manuel utilisateur

Harvia

Harvia GL70 Manuel utilisateur

Heylo

Heylo DE 2 XL Manuel utilisateur

Heylo

Heylo DE 20 SH Manuel utilisateur

Harvia

Harvia PP70SP Manuel utilisateur

Tylo

Tylo SENSE SPORT Manuel utilisateur

Dirna

Dirna ecodirna SUN Mode d’emploi

Creda

Creda Heating Solution Manuel utilisateur

THERMEx

THERMEx Frame E Wi-Fi Series Manuel utilisateur

SHUFT

SHUFT UniMAX-R 1400VE EC Manuel utilisateur

HUUM

HUUM CLIFF Series Manuel utilisateur

Harvia

Harvia HL70S Manuel utilisateur

Dimplex

Dimplex DHEBHT Manuel utilisateur

Radialight

Radialight SIRIO Manuel utilisateur

Polaris

Polaris PRE E 0715 H Manuel utilisateur
