Celestron Cypress Manuel utilisateur

BINOCULARS | JUMELLE

BINOCULARES | FERNGLAS

BINOCOLI

ENGLISH .................................2

FRANÇAIS ..............................11

ESPAÑOL ................................21

DEUTSCH ................................31

ITALIANO................................41

BINOCULARS

ENGLISH

2 IENGLISH

Thank you for purchasing a Celestron Cypress binocular. We trust this binocular will provide you

with years of enjoyment and faithful service. Please read the instructions carefully before using

your binocular to ensure proper use and care.

celestron®cypress binoculars

Tripod Adapter Threads - (under cap)

Eyecup

Objective

Lens

Objective

Lens Caps

Rainguard

Eyepiece

Focus

Wheel

Fig. 1

WARNING: Viewing the Sun may cause permanent eye damage. Do not view

the Sun with your binoculars or even with the naked eye.

Diopter

Adjustment

ENGLISH I3

The interpupillary distance, or the distance

between the pupils, varies from person to

person. The binocular must be correctly aligned

(adjusted) to the distance between your pupils

to achieve a single, clear image. To adjust this

distance, lift the binocular up to your eyes (using

both hands) and look through them at an object

in the distance. Move the two barrels (halves)

of the binocular closer together or further

apart until you see a single, clear image (Fig. 2).

Check that the interpupillary distance is set

correctly every time you use your binocular.

adjusting the interpupillary distance (ipd)

Fig. 2

4 IENGLISH

To ensure a crisp, sharp image the focusing

system of the binocular must be set to

compensate for any differences in your

eyesight. This is achieved by setting the

diopter (located on the right eyepiece)

before use. To set the binocular to your

eyesight follow the instructions below.

1. View an object in the distance through the

binocular.

2. Cover the right objective lens with your hand

or the objective lens cap.

3. Rotate the focus wheel until the image

viewed with your left eye is clear and sharp.

4. Cover the left objective lens with your hand

or objective lens cap.

5. Viewing the same object, adjust the diopter

ring until the image viewed with your right

eye is clear and sharp.

6. Your binocular is now adjusted to your eyes

and focusing on any object can now be

achieved by simply turning the focus wheel.

TIp: Eyeglasses worn for nearsightedness should be worn when using

binoculars as you may not be able to obtain focus at inﬁnity

without them.

setting the diopter / Focusing

Diopter Adjustment Ring

Focus Wheel

Fig. 3

ENGLISH I5

eyecup adjustment

The Cypress binoculars feature twist-up

eyecups to accommodate both eyeglass

and non-eyeglass wearers. If you do not wear

eyeglasses, twist the eyecups counterclockwise

until they reach the up position. If you wear

eyeglasses, make sure that the eyecups are in

the down position to obtain the maximum ﬁeld

of view. The eyecups can be set at positions

between fully up and down which may suit

some users better.

Fig. 4

6 IENGLISH

tripod adaptability

The 30 mm and 50 mm versions of the Cypress

binocular series feature built-in threads that

allow the binocular to be attached to a tripod

using a binocular tripod adapter. These threads

can be accessed by unscrewing the logo plate

found on the front of the hinge (Fig. 5). To attach

the binocular to a tripod, thread the adapter into

the binocular and attach the other end of the

adapter to a photographic tripod. Mounting the

binocular on a tripod allows for added stability

and comfort during prolonged viewing.

WaterprooF / FogprooF

Fig. 5

The Cypress series binoculars are waterproof and ﬁlled with dry nitrogen gas to prevent the

housing from fogging internally.
