hn3620 Induction Hob

Manual for Installation, Use and Maintenance

Important

The CDA Group Ltd cannot be held responsible for injuries or losses

caused by incorrect use or installation of this product. Please note

that CDA reserve the right to invalidate the guarantee supplied with

this product following incorrect installation or misuse of the appliance

or use in a commercial environment.

This appliance is not designed to be used by people (including

children) with reduced physical, sensorial or mental capacity, or

who lack experience or knowledge about it, unless they have had

supervision or instructions on how to use the appliance by someone

who is responsible for their safety.

Under no circumstances should any external covers be removed for

servicing or maintenance except by suitably qualiﬁed personnel.

Appliance information:

Please enter the details on the appliance rating plate below for

reference, to assist CDA Customer Care in the event of a fault with

your appliance and to register your appliance for guarantee purposes.

Appliance Model

Serial Number

CE Declarations of Conformity

This appliance has been manufactured to the strictest standards and

complies with all applicable legislation, including Electrical safety (LVD)

2006/95/EC and Electromagnetic interference compatibility (EMC)

2004/108/EC. Parts intended to come into contact with food conform

to 89/109/EC.

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE

PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.

At the end of its working life, the product must be taken to a special

local authority waste collection centre or to a dealer providing

appliance recycling services.

Disposing of a household appliance separately avoids possible

negative consequences for the environment and health. It also

enables the constituent materials to be recovered, saving both energy

and resources. As a reminder of the need to dispose of household

appliances separately, the product is marked with a crossed-out

wheeled dustbin.

Precautions before use

• Unpack the hob and all associated components, taking care not to

lose or mishandle any parts.

• We recommend that the appliance is installed by a suitably qualied

professional and connected to the electricity supply by a qualiﬁed

electrician, who is a member of the N.I.C.E.I.C. and who will comply

with the I.E.T. and local regulations.

• The appliance must be installed in a purpose-designed kitchen unit

and worktop cut out as speciﬁed below.

• This hob (Class 3) has been designed for use only as a domestic

cooking appliance. Any other use should be considered incorrect

and therefore dangerous.

• Remove all labels and other packaging materials from the ceramic

surface prior to use.

• Do not modify the appliance in any way as this will invalidate the

guarantee and is potentially dangerous.

• The hob top is not designed for any use other than cooking: any

other use (e.g. as a worktop) is potentially dangerous and will

invalidate the guarantee.

• This appliance must be connected to xed wiring and suitably

earthed according to local regulations. Alternative connection,

through a 13A plug or through an extension lead must not be used.

• This appliance must not be installed above a dishwasher, washing

machine or tumble dryer as steam may damage the electronic

components.

Using the Appliance

• Always switch cooking zones o after use.

• Take particular care when cooking with oils or fats that may ignite.

• Cooking pans and utensils and the hob itself become hot during

use. Caution, risk of injury to people and pets both during and after

use.

• Ensure no cable from any other appliance can come into contact

with the hob top or pans during use.

• Magnetic objects (such as credit cards or portable electronic

devices) must not be placed near the hob during use.

• Do not place any metal object (other than suitable pans) on the hob.

• Never cover the hob with any cloth or other cover. This may

become hot and create a re hazard.

• This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance in a

safe way and understand the hazards involved.

• Children shall not play with the appliance.

• Cleaning and user maintenance shall not be made by children

without supervision.

• Metal objects such as knives, forks, lids etc. should not be placed

on the hob as they may become hot.

Precautions to protect the hob

• Use of damaged pans or those with raw cast iron bottoms may

damage the hob ceramic glass.

• Abrasive materials such as scouring cleaners and grits may damage

the ceramic glass.

• Avoid dropping objects onto the ceramic glass.

• Take care not to strike the edges of the hob with saucepans.

• Ensure that ventilation (as specied under installation instructions)

remains free from obstructions.

• Do not place empty saucepans on the hob.

• Sugar, synthetic plastics or aluminium foil must not be allowed

to come into contact with the heating zones; these may cause

permanent damage to the ceramic glass. If these should

accidentally fall onto the hob, turn it o immediately and carefully

remove them. Take care not to burn yourself.

• Never place any hot items on the control panel.

• If a drawer is located below the hob, ensure a horizontal divider is

installed leaving a minimum gap of 2cm above it for hob ventilation,

and protecting the drawer contents from striking the hob. The

divider must be made of material capable of withstanding 65°C

above ambient temperature.

• Never place inammable items or materials in a drawer or cupboard

below the hob.

Precautions in the event of an appliance fault

• If a fault is noticed, switch o the appliance and turn o the

electricity supply.

• Warning: If the ceramic glass is broken or cracked do not use the

appliance, turn o the electricity supply to avoid the possibility of

electric shock. Contact CDA Customer Support.

• There are no user-serviceable parts inside the appliance; all repairs

must be performed by a suitably qualiﬁed service engineer or

similar.

• See the “Troubleshooting” section in this manual, from page 20.

Other precautions

• Ensure that each pan is centred on its cooking zone; The pan base

must cover as much of the cooking zone as possible.

• Do not use aluminium or plastic containers: they could melt onto hot

cooking zones.

• The use of incorrect cookware or any induction adaptor plate

designed for non-magnetic cookware is outside the manufacturer’s

speciﬁcations so will invalidate the guarantee. The manufacturer

cannot be held responsible for any damage to the hob or

consequential damages as a result of such use.

FOR THOSE WITH HEART PACEMAKERS OR ACTIVE IMPLANTS:

The function of this hob conforms to current electromagnetic

interference standards and thus is in total compliance with legal

requirements (2004/108/CE directives).

To avoid interference between your hob and a pacemaker, your

pacemaker must be designed and programmed in compliance with

the regulations that apply to it. As such, CDA guarantee only that our

product is compliant.

With regard to the compliance of the pacemaker or any potential

incompatibility, you should obtain information from the manufacturer or

your attending physician.

Cooking On Induction

The principle of induction cooking is based on magnetic eect.

When you put your cookware on an induction zone and switch it on,

the electronic boards in the hob produce induced currents in the base

of the cookware and instantly raise its temperature. This heat is then

transferred to the food inside the cookware.

The best cookware to use with induction cooking has thick at bases,

as the heat will be better distributed so cooking more evenly.

Most cookware is compatible with induction cooking. There are three

ways to check the suitability of your cookware:

1. Use a magnet to see if the base of the pan is magnetic: if the

magnet sticks, then the cookware is compatible.

2. Place the pan on one of the cooking zones switched on to power

level 4: If the display remains on, then the cookware is

compatible. If the display ashes, the cookware cannot be used on

an induction hob.

3.Check the instructions or packaging of the pans for the symbols

indicating suitability for use with induction.

Using Your Hob

Fig.1

Control panel:

3. Power key

4. Timer display

5. Zone selection keys

6. Zone displays

7. - key

8. + key

9. Timer control light

Zones:

1. Front 1.4 kW 175 mm

2. Back 1.4 kW 175 mm

3 6

Using Your Hob

The table below oers guidance as to what each power level is for.

To switch the hob on

To switch the power on, touch and hold the key for approximately

two seconds. The hob will beep and both zone displays will show

zero.

Please note: If a power level is not set within ten seconds, the hob

will switch o automatically.

To set the power level

Touch the “Zone selection” key for the zone required, then set the

power level by touching the “+” or “-” keys within ve seconds.

To increase the power level from 1 (minimum) toward 9 (maximum),

touch the “+” key.

To go straight to power level 9, touch the “-” key when the zone

display shows “0”.

Power level Type of cooking

0Switched o

1/2 Melting (butter/chocolate) or keeping food warm

2/3 Keeping food hot or to heat small quantities of liquid

3/4 Heat larger quantities of liquid (sauces etc.)

4/5 Slow boiling, e.g spaghetti, soups, stews, potatoes

6/7 Gentle frying

7/8 Browning meats, frying ﬁsh, omelettes

9 Fast frying steaks
