Cavalry CAND Series Manuel utilisateur
CAND Series
User’s Guide
Network Attached Storage
4
Table of Contents
4 TABLE OF CONTENTS
INTRODUCTION
6 Features
6 Accessories
7 Conventions & Safety Instructions
QUICK START
11 Mapping
11 Web-based GUI
12 Printer
12 IP Address
12 FTP Service
COMPLETE USER’S GUIDE
Chapter 1 - Basics
1.1 - Quick Setup
15 1.1.1 - Wizard
16 1.1.2 - Add User
17 1.1.3 - Add Group
18 1.1.4 - Add Share
Chapter 2 - Control Panel
2.1 - Users and Groups
21 2.1.1 - User Management
22 2.1.2 - Group Management
2.2 File and Print
23 2.2.1 - File Server
24 2.2.2 - Share Management
25 2.2.3 - Printer Server
2.3 System
26 2.3.1 - LAN Settings
5
27 2.3.2 - Time Settings
27 2.3.3 - Turn O
28 2.3.4 - Information
28 2.3.5 - Disk Usage
29 2.3.6 - Error Notication
2.4 Network Service
30 2.4.1 - DHCP Server
31 2.4.2 - Bonjour
2.5 Maintenance
32 2.5.1 - Disk Utility
33 2.5.2 - RAID Settings
34 2.5.3 - Firmware Upgrade
34 2.5.4 - Save Conguration
34 2.5.5 - Restore Conguration
34 2.5.6 - Factory Reset
34 2.5.7 - Software Update
2.6 Log File
35 2.6.1 - Samba Log
35 2.6.2 - FTP Log
35 2.6.3 - DHCP Log
35 2.6.4 - System Log
35 2.6.5 - Administration Log
Chapter 3 - Personal Information
3.1 Personal Information
37 3.1.1 Account
Chapter 4 - Help
39 FAQ and Troubleshooting
6
Introduction
Features
• 10/100/100 Mbit/s LAN Speed
• Printer server capability with USB 2.0
• Precongured to RAID 1
• Preformatted to ext3
• Supports RAID 0, RAID 1, Spanning, and JBOD
• Supports ext 2, ext 3, FAT32 (JBOD only) formatting
• Supports FTP/SMB server
• Supports UPnP Protocol
• Exceptional heat dissipation
• PC, Mac and Linux compatible
Accessories
• Ethernet Cable (RJ45)
• Power Adapter
• User Guide
7
Conventions & Safety Instructions
CAUTION: This symbol is to remind you to pay attention and read carefully. Failure to do
so could result in injury or data loss.
NOTE: This symbol is used to provide you with useful information.
• Read through this entire manual and save for future reference.
• Place unit in a secure location to prevent being bumped or dropped.
• Do not place near a radiator or other heat sources.
• Do not use near water.
• Gaps and opening on the outer enclosure are intended to provide airow. Never
block or cover these openings or it may cause overheating.
• The unit must be grounded. It is equipped with a 3-wire, grounded power cable.
• Do not place where the cables could be stepped on.
• Unplug the power cable from the unit before cleaning. Keep the unit dry. Do not
use liquid cleaners, aerosol cleaners, or a wet cloth to clean.
• Disassembling the enclosure will void your warranty.
Copyright
Please respect copyrighted content. Duplication or modication of this publication in
part or in whole is prohibited without expressed or written authorization.
Usage
Strong impacts or dropping of the product may cause damage. Only allow qualied
personnel to repair this product. Disassembling or opening this product will void your
warranty.
Disclaimer
Cavalry is not liable for compensation for data loss which may result from a malfunction
of the product or from changes due to improper use, repairs, defects, or battery change.
Please back up your data to avoid unexpected losses. Cavalry reserves the right to make
changes to the content of this manual without notice. The most current manuals and
software are available for download at Cavalry’s website.
!
ATTENTION: This guide will assist you in the operation of the product. For your
safety and to optimize your experience with this product, please reading this
entire manual before usage.
8
9
Quick Start Guide
This portion of the manual gives a brief overview of the
steps required to start transferring les. It also goes over
the main features and functions of the NAS drive such as
attaching a printer and determining the unit’s IP address.
Advanced conguration of formatting and RAID settings
are not required to use the unit. The drive is already
precongured to RAID 1 and formatted to ext3.
10
Quick Start
NOTE: For optimal security and convenience, we recommend designating a single
computer to handle all congurations.
1. Connect the power adapter to the NAS. Then plug the adapter into an electrical
outlet.
2. Turn on the power; the “Power” LED light will indicate the unit is on.
3. Insert the Ethernet cable to the LAN port on the back of the NAS and the other
end to an Ethernet port on the network adapter of a router/switch/hub. The “Link”
LED will indicate a connection.
