CATEYE VELO WIRELESS+
CC-VT235W
Quick Start
Click the button and follow the in-
structions.
START
Thank you for purchasing our cyclocomputer CATEYE VELO WIRELESS +.
This Quick Start Manual explains how to set up the computer and how to install the unit on
your bicycle.
Please set up the unit according to the specified procedure, then it will be ready for use as a
cyclocomputer.
Before use, read the instruction manual that comes with the product thoroughly
to the end to understand the functions of this unit, and to use it safely in a
correct manner.
Next
This PDF contains a movie file.
When you click on the movie screen, a message regarding security appears. Click the
“Trust in the text” or “Play” button to close the message.
Click the screen again to play the movie.
Next
CATEYE VELO WIRELESS+
Quick Start Manual Contents
Click the item you wish to view.
Return to a Cover
Setting up the computer
How to install the speed sensor (movie)
How to install the bracket (movie)
Backlight (Night Mode)
Operation of buttons
Set up the computer by operating the buttons as follows.
Check the button position before you start setting up.
Front Back
Press the MENU button on the back
of the computer.
Press the MODE button on the front
of the computer.
MENU
MODE
Next
CATEYE VELO WIRELESS+
Quick Start Manual Setting up the computer
Setting the speed unit
Setting the tire size
Setting the clock display
Measuring screen
(Setup screen)
Setting the hour
Setting the minute
AC
Formatting operation Clear all data (initialization)
Press the AC button on the back of the computer.
After full lighting of the screen, the computer
switches to the speed unit setting screen to start
setup.
Full lighting Setting the speed unit
Return to Contents
Next
Return
CATEYE VELO WIRELESS+
Quick Start Manual Setting up the computer
Setting the tire size
Setting the clock display
Measuring screen
(Setup screen)
Setting the hour
Setting the minute
Setting the speed unit
Formatting operation
Setting the speed unit
Setting the speed unit
When the MODE button is pressed, either “km/h” or
“mph” is selected for the speed unit display. Select the
display of your choice.
After selecting, press the MENU button to proceed to the
next step “Entering the tire circumference”.
km/h ↔mph To the next step
MODE
MENU
Return to Contents
Next
Return
CATEYE VELO WIRELESS+
Quick Start Manual Setting up the computer
Setting the clock display
Measuring screen
(Setup screen)
Setting the hour
Setting the minute
Setting the tire size
(1/2) (1/3)
Setting the speed unit
Formatting operation Setting the tire size
There are two different ways to set the tire size with this
unit; simple setting by selecting the tire size in inches,
and detailed setting by entering the tire circumference.
To set the tire size by selecting the size in inches, click•
“Simple setting”.
To set the tire circumference in detail, click “Detailed•
setting”.
Setting the tire size
Return to Contents
Return
Next (Detailed setting)
Next (Simple setting)
CATEYE VELO WIRELESS+
Quick Start Manual Setting up the computer
Setting the clock display
Measuring screen
(Setup screen)
Setting the hour
Setting the minute
Setting the tire size
(2/2)
Setting the speed unit
Formatting operation Setting the tire size (Simple setting)
When the MODE button is pressed, different sizes in
inches are displayed. Select the display of your choice.
After selecting, press the MENU button to proceed to the
next step “Setting the clock display”.
Different sizes in inches
Select the size in inches To the next step
MODE
26" 700c 27"
16"18"20"
22"
24"
205[]
27.5"
29"
MENU
Return to Contents
Return
Next
CATEYE VELO WIRELESS+
Quick Start Manual Setting up the computer
Setting the clock display
Measuring screen
(Setup screen)
Setting the hour
Setting the minute
MODE
26" 700c 27"
16"18"20"
22"
24"
205[]
27.5"
29"
MODE
Setting the tire size
(2/3)
Setting the speed unit
Formatting operation Setting the tire size (Detailed setting)
When the MODE button is pressed, different sizes in
inches are displayed. Press the MODE button until
“205[]” is displayed.
Press and hold to the MODE button with “205[]” dis-
played to change to the circumference entry screen.
Different sizes in inches
Select the size in inches To the circumference
entry screen
(Press and hold)
Return to Contents
Next
ReturnReturn
