Cateye STRADA CADENCE CC-RD200 Manuel utilisateur

Click the button and follow the in-

structions.

CATEYE STRADA CADENCE

CC-RD200

Quick Start

START

Thank you for purchasing our cyclocomputer CATEYE STRADA.

This Quick Start Manual explains how to set up the computer and how to install the unit on

your bicycle.

Please set up the unit according to the speciﬁed procedure, then it will be ready for use as a

cyclocomputer.

Before use, read the instruction manual that comes with the product thoroughly

to the end to understand the functions of this unit, and to use it safely in a

correct manner.

This PDF contains a movie ﬁle.

When you click on the movie screen, a message regarding security appears. Click the

“Trust in the text” or “Play” button to close the message.

Click the screen again to play the movie.

CATEYE STRADA CADENCE

Quick Start Manual Contents

Click the item you wish to view.

Return to Cover

Setting up the computer

How to install the sensor

How to install the bracket (movie)

Operation of buttons

Set up the computer by operating the buttons as follows.

Check the button position before you start setting up.

MODE

Back

Press the MENU button and the MODE

button on the back of the computer.

CATEYE STRADA CADENCE

Quick Start Manual Setting up the computer

Setting the speed unit

Entering the tire

circumference

Setting the clock display

Measuring screen

(Setup completed)

Setting the hour

Setting the minute

Clear all data (initialization) Clear all data (initialization)

Press the AC button on the back of the computer.

After full lighting of the screen, the computer switch-

es to the speed unit setting screen to start setup.

ACAC

Full lighting Setting the speed unit

Return to Contents

Return

CATEYE STRADA CADENCE

Quick Start Manual Setting up the computer

Entering the tire

circumference

Setting the clock display

Measuring screen

(Setup completed)

Setting the hour

Setting the minute

Setting the speed unit

Clear all data (initialization)

Setting the speed unit

When the MODE button is pressed, either “km/h” or “mph”

is selected for the speed unit display. Select the display of

your choice.

After selecting, press the MENU button to proceed to the

next step “Entering the tire circumference”.

To the next step

MODE

km/h ↔mph

Return to Contents

Return

CATEYE STRADA CADENCE

Quick Start Manual Setting up the computer

Setting the clock display

Measuring screen

(Setup completed)

Setting the hour

Setting the minute

Entering the tire

circumference

Setting the speed unit

Clear all data (initialization) Entering the tire circumference

Enter the tire circumference (mm) of your bicycle with 4

digits using the tire circumference reference table.

Pressing the MODE button increases the value ﬂashing,

and pressing and holding the MODE button moves to the

next digit.

After entering, press the MENU button to proceed to the

next step “Setting the clock display”.

Entering the tire

circumference Move digitTo the next step

To the next step

MODE

(Press and hold)

Return to Contents

Return

Tire circum-

ference refer-

ence table

CATEYE STRADA CADENCE

Quick Start Manual Setting up the computer

Measuring screen

(Setup completed)

Setting the hour

Setting the minute

Setting the clock display

Entering the tire

circumference

Setting the speed unit

Clear all data (initialization) Setting the clock display

When you press and hold the MODE button, “24h” ﬂashes.

When the MODE button is pressed, either “12h” or “24h”

is selected for the clock display. Select the display of

your choice.

After selecting, press and hold the MODE button to pro-

ceed to the next step “Setting the hour”.

Clock display

To the next step

MODE

24h ↔12h

MODE

(Press and hold)

Return to Contents

Return

CATEYE STRADA CADENCE

Quick Start Manual Setting up the computer

Measuring screen

(Setup completed)

Setting the minute

Setting the hour

Setting the clock display

Entering the tire

circumference

Setting the speed unit

Clear all data (initialization) Setting the hour

Pressing the MODE button increases the value ﬂashing

(“Hour” of the clock). Enter any value.

After entering, press and hold the MODE button to pro-

ceed to the next step “Setting the minute”.

Hour

To the next step

MODE

To the next step

MODE

(Press and hold)

Return to Contents

Return
