Cata UBESP60IX Instructions d'installation
WARNING: Read the instructions before using the appliance.
2
4
1
5
6
3
3
6
5
1
4
2
2
4
1
5
6
3
3
6
5
1
4
2
60cm Solid Hotplate Electric Hob
Model Number UBESP60IX
2
4
1
5
6
3
3
6
5
1
4
2
2
4
1
5
6
3
3
6
5
1
4
2
[01] x 1
[02] x 4
[03] x 1
[05] x 1
[04] x 4
TEMPLATE
TEMPLATE
1 : 1
60 cm Solid Plate Electric Hob
3
Let's
get started...
These instructions are for your safety. Please read through them
thoroughly before use and retain them for future reference.
Getting started… 04
Your product 04
Before you start 04
Safety 05
In more detail… 08
Operation 08
Care and maintenance 11
Troubleshooting 13
Recycling and disposal 14
Technical specications 14
Wiring 15
Technical and legal information 16
Guarantee 17
CE Declaration of conformity 19
Appendix...
20
Installation
4
Getting started...
Your product
Things to check before you start
Check the package and make sure you have all of the parts listed.
Decide on the appropriate location for your product.
The specications plate is available on this appliance. This plate displays
all the necessary identication information for ordering replacement parts.
If you sell the appliance, give it away, or leave it behind when you move
house, make sure you also pass on this manual so that the new owner
can become familiar with the appliance and its safety warnings.
You will need
Your product
Before you start
Installation guide
located at the end of
the guidebook
Control panel
2
4
1
5
6
3
3
6
5
1
4
2
2
4
1
5
6
3
3
6
5
1
4
2
To avoid the risks that are always present when you use an electrical
appliance it is important that this appliance is installed correctly and that
you read the safety instructions carefully to avoid misuse and hazards.
Please keep this instruction booklet for future reference and pass it on to
any future owners. After unpacking the appliance please check that it is
not damaged. If in doubt, do not use the appliance but contact Customer
Services on 0344 800 1128 (UK), 0144 75261 (Ireland).
5
Getting started...
Safety
Safety
These instructions are for your safety. Please read through them thoroughly
prior to installation and retain them for future reference.
• All installation work must be carried
out by a competent person or qualied
electrician.
• This appliance must be installed correctly
by a suitably qualied person, strictly
following the manufacturer’s instructions.
This appliance complies with all current
European safety legislation, however, the
Manufacturer must emphasise that this
compliance does not prevent the surfaces of
the appliance from heating up during use and
remaining hot during its operation.
Accessible parts may become hot during
use. Young children should be kept away.
Care should be taken to avoid touching the
appliance.
The Manufacturer highly recommends that this
appliance be kept out of the reach of babies
and small children.
Children should be supervised to ensure that
they do not play with the appliance.
6
Getting started...
This appliance is not intended for use by
persons (including children) with reduced
physical sensory, or mental capabilities, or by
those who lack experience and knowledge,
unless they have been given supervision and
instruction concerning the use of the appliance
by a person responsible for their safety.
Means for isolating the appliance must be
incorporated in the xed wiring in accordance
with the current wiring regulations. An all-
pole disconnection switch having a contact
separation of at least 3 mm in all poles should
be connected in xed wiring.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
Make sure that the power cord is not caught
under or in the appliance and avoid damage to
the power cable.
Do not allow the electric cables to touch the
hot parts of the appliance.
Do not install the appliance outdoors in a
damp place or in an area which may be prone
to water leaks such as under or near a sink
unit. In the event of a water leak allow the
machine to dry naturally.
Safety
7
Getting started...
Safety
Safety
A steam cleaner is not to be used.
The appliance is not intended to be operated
by means of external timer or separated
remote-control system.
The appliance is for domestic use only.
When a cooking zone has been on for a long
time, the surface remains hot for some time
afterwards so do not touch the metal surface.
Do not store detergents or ammable
materials beneath the hob.
Do not leave hot oils or fats unattended as
they may catch light.
The Manufacturer declines all liability for
personal or material damage as a result
of misuse or incorrect installation of this
appliance.
Please dispose of the packing material
carefully.
Do not use ammable sprays in close vicinity
to the appliance.
We also recommend that great care be taken
during use and cleaning. Read the cleaning
and maintenance sections for this appliance
carefully.
8
In more detail...
Operation
Product functions
• 2 x 2.00 kW thermostatic plates (diameter 180 mm). Rapid hot plates.
• 2 x 1.50 kW thermostatic plates (diameter 155 mm). Semi-rapid hot plates.
• Side control operation. 6 power levels.
Control elements
Control panel
2
4
1
5
6
3
3
6
5
1
4
2
2
4
1
5
6
3
3
6
5
1
4
2
Reference Description Qty
A Rapid hot plates 2
B Semi-rapid hot plates 2
C Control panel 1
Operation
2
4
1
5
6
3
3
6
5
1
4
2
2
4
1
5
6
3
3
6
5
1
4
2
Caution
Any lm or stickers that are present on the hob surface when it is
delivered should be removed before use.
Care should be used when utilizing the appliance, otherwise there is a
risk of burns being caused.
If fat and oil overheats, then it can ignite extremely quickly. For this reason,
when cooking with fat and oil the appliance should not be left unattended.
Make sure that all of the cooking zones are switched off after use.
9
In more detail...
Before rst use
• You should switch on one cooking zone at a time, for 5 minutes at the
maximum setting. This will help to eliminate any new smell that exists and
evaporate any humidity that has formed on the heating elements during
transit. Make sure the room is properly ventilated during this procedure.
• When doing this burn off process, an appropriately sized saucepan
containing cold water should be placed on the zone in question.
• Do not burn off more than one zone at once.
Control knobs
• All operations are performed by means of the 4
control knobs that can be found on the right hand
side of the hob top.
• The control knobs can be turned either clockwise
or anti-clockwise to select a heating level. The
numbers around the outside of each control knob
indicates the power level that you have set the zone
to.
• A marking to the bottom right of each control knob,
indicates which zone that it controls.
2
4
1
5
6
3
Turning on a zone and setting a power level
Control panel
2
4
1
5
6
3
3
6
5
1
4
2
2
4
1
5
6
3
3
6
5
1
4
2
• Turn the control knob of the zone that you wish to cook on, clockwise or
anticlockwise until it reaches the power level that you desire.
• Each cooking zone can be adjusted between 1 and 6, one being the coolest
zone setting and six being the hottest zone setting.
• When you have nished cooking, make sure that you turn the control knob
anti-clockwise, to the 0 position.
10
In more detail...
Operation
Turning on a zone and setting a power level
Hob guidelines
• The rst few times the hob top is used, it may give off an acrid, burning smell.
• This smell will disappear completely with repeated use.
• The hob surface is tted with cooking areas of different diameter and power.
• The positions where the heat will radiate from are clearly marked on the hob
top. The saucepans must be positioned exactly on these zones for efcient
heating to occur. Pans should have the same diameter as the cooking zone
that they are being used on.
• You should not use saucepans with rough bottoms, as this can scratch the
solid plates.
• Before use, make sure that the bottoms of the saucepans are clean and dry.
• When cold, the bottom of the pans should be slightly concave, as they
expand when hot and lie at on the surface of the hob. This will allow the
heat to transfer more easily.
• The best thickness for the bottom of the pans is 2 – 3 mm of enameled steel
and 4 – 6 mm for stainless steel with sandwich type bottoms.
• If these rules are not followed, then there will be a great loss of heat and
energy. Heat not absorbed by the saucepan, will spread to the hob, frame
and surrounding cabinets.
• Preferably cover pans with a lid to permit cooking at a lower heat.
• Always cook vegetables and potatoes, etc. in as little water to reduce cooking
times.
• Food or liquid that has high sugar content may damage the hob top if it
comes into contact with the hob surface. Any spillages should be wiped up
immediately, however this may not prevent the hob surface from becoming
damaged.
Hotplate Recommended pan diameters (cm)
ASmall Hotplate 14-22
BLarge Hotplate 18-22
